Jake Lo Posted October 28, 2023 Share Posted October 28, 2023 (edited) I'v updated to the latest OCLP 1.1.0 and was able to enable airportBrcmFixup.kext but need to bootarg amfi=0x80 Otherwise DW1830 is not detected. I'm not sure if others have the same experience. Without AirportBrcmFixup.kext, system information will display the wireless as 3rd party wireless device or something along that line. Edited October 28, 2023 by Jake Lo 1 Link to comment Share on other sites More sharing options...
deeveedee Posted October 31, 2023 Share Posted October 31, 2023 (edited) On 10/28/2023 at 11:50 AM, Jake Lo said: I'v updated to the latest OCLP 1.1.0 and was able to enable airportBrcmFixup.kext but need to bootarg amfi=0x80 Otherwise DW1830 is not detected. I'm not sure if others have the same experience. Without AirportBrcmFixup.kext, system information will display the wireless as 3rd party wireless device or something along that line. Can you post your config.plist? Also post your versions for AirportBrcmFixup.kext, Lilu.kext, RestrictEvents.kext, AMFIPass.kext? Edited October 31, 2023 by deeveedee Link to comment Share on other sites More sharing options...
jlrycm Posted December 9, 2023 Share Posted December 9, 2023 (edited) After upgrading to Sonoma, I installed an Intel AX210 card and so far the wifi and BT services are working well. Here is the link to the card in AmazonEDUP PCIE WiFi 6E Card AX210 Bluetooth 5.2 AX5400M 802.11ax Tri-Band 6G/5.8G/2.4GHz Heat Sink 6dBi Antenna PCI-E Wireless Network Cards for Desktop PC Support Windows 11/10 64-bit https://www.amazon.com/dp/B08519ST43?tag=tonymacx86com-20 I’m trying Local Send for file transfer. I realized I wasn’t using the other features that I would loose by switching to an Intel AX210. I preferred security above everything else, but the fenvi card can make a comeback in my PC if the OCLP can be made without disabling some of the security. Edited December 14, 2023 by jlrycm 4 Link to comment Share on other sites More sharing options...
Ravenstein Posted December 22, 2023 Share Posted December 22, 2023 (edited) On 10/28/2023 at 5:50 PM, Jake Lo said: I'v updated to the latest OCLP 1.1.0 and was able to enable airportBrcmFixup.kext but need to bootarg amfi=0x80 Otherwise DW1830 is not detected. I'm not sure if others have the same experience. Without AirportBrcmFixup.kext, system information will display the wireless as 3rd party wireless device or something along that line. Thanks @Jake Lo for sharing this finding, esp. wrt. DW1830 which I am still struggling on only one-way Handoff at Monterey. DW1830 works w/o kext(*3) injection up to 12.7.1 (I can confirm), as @deeveedee mentioned as well. Now if you say DW1830 works for you, esp. w. AirportBrcmFixup.kext thus NOT marked as "Third Party Wireless Card"(which I can confirm at Monterey 12.7.1 as well), do you mean: BT module works as well? as BCM920703 or BCM2045A0? Handoff (Airdrop, clipboard, etc.) works as well or only Wi-Fi connectivity (2.4Ghz & 5Ghz); In System Report > Network > Wi-Fi > en1: Card Type now indicate correct vendor/device-id as DW1830? Also maybe double check w. IOReg.'s WiFi detection under ... AirPort_BrcmNIC > IOvendor as "Unknown" I am asking these is to understand and doubt on macOS may have implemented this integrity check(which AMFI does) already since later Monterery and thus hinder the 2-way Handoff? PS: as checking your repo@osxlatitude < @deeveedee , you didn't mention Handoff functionality with DW1830 or DW1560? Edited December 22, 2023 by Ravenstein 1 Link to comment Share on other sites More sharing options...
chris1111 Posted January 8 Share Posted January 8 WIFI USB Adapter Realtek SIP activated Apple Sevices full fonctional (FaceTime, Messages) Yes Spoiler 6 Link to comment Share on other sites More sharing options...
Olion Posted February 6 Share Posted February 6 (edited) On 12/9/2023 at 4:42 PM, jlrycm said: After upgrading to Sonoma, I installed an Intel AX210 card and so far the wifi and BT services are working well. Here is the link to the card in Amazon EDUP PCIE WiFi 6E Card AX210 Bluetooth 5.2 AX5400M 802.11ax Tri-Band 6G/5.8G/2.4GHz Heat Sink 6dBi Antenna PCI-E Wireless Network Cards for Desktop PC Support Windows 11/10 64-bit https://www.amazon.com/dp/B08519ST43?tag=tonymacx86com-20 I’m trying Local Send for file transfer. I realized I wasn’t using the other features that I would loose by switching to an Intel AX210. I preferred security above everything else, but the fenvi card can make a comeback in my PC if the OCLP can be made without disabling some of the security. Thanks, I bought almost same card, wifi works with HeliPort, BT is ok also. No AirDrop. EDUP EP-9651 WiFi 6E адаптер Intel AX210, 5374 Мбит/с, Bluetooth 5.3, PCI Express, 802.11AX Edited February 12 by Olion Link to comment Share on other sites More sharing options...
XanthraX Posted February 17 Share Posted February 17 To replace the airdrop, it exists the free app, called Blip (blip.net/download). Install it on your hack and your phone and this is all. 2 Link to comment Share on other sites More sharing options...
miliuco Posted February 17 Share Posted February 17 @XanthraX I did not know this app, it looks very nice, I’ll try it. Now using LocalSend as Airdrop replacement. 2 Link to comment Share on other sites More sharing options...
miliuco Posted February 18 Share Posted February 18 @XanthraX Tried but I prefer LocalSend. Blip asks for email and installs many files to work 4 1 Link to comment Share on other sites More sharing options...
XanthraX Posted February 24 Share Posted February 24 On 2/19/2024 at 12:13 AM, miliuco said: @XanthraX Tried but I prefer LocalSend. Blip asks for email and installs many files to work Thank you. I agree with you. I did not know about LocalSend. 2 Link to comment Share on other sites More sharing options...
Cyberdevs Posted February 24 Share Posted February 24 I agree with @miliuco Blip's email requirement was a no go for me! 2 Link to comment Share on other sites More sharing options...
hackattak Posted March 28 Share Posted March 28 (edited) Hi - I'm newly on Sonoma 14.4.1 with BCM94360CS2 as of yesterday (came over from Monterey for 120hz/4k) Bluetooth of course works, but I thought I'd spend some time tackling the WiFi situation if it's possible. In the meantime I bought Tp-Link mini travel router so I can access internet via ethernet > WiFi if need be Is getting previously native Broadcom WiFi still working as of today and/on 14.4.1? Which instructions should I follow here? Thank you! Edited March 28 by hackattak Link to comment Share on other sites More sharing options...
miliuco Posted March 28 Share Posted March 28 @hackattak Posts 1 and 2 of this thread: https://www.insanelymac.com/forum/topic/358630-get-back-fenvi-t919-and-other-broadcom-wi-fi-on-macos-14-sonoma-thanks-to-olcp/#comment-2818615 Broadcom wifi working on Ventura or Sonoma prior to 14.4 can work on Sonoma 14.4 or 14.4.1, follow instructions (post 2 is for 14.4 or 14.4.1). 1 Link to comment Share on other sites More sharing options...
Max.1974 Posted March 28 Share Posted March 28 Hi all friends, since I decide put my Broadcom Wireless Card + BT on my Aorus Z790 (with intel WI-Fi 6 Ax211 + intel BT), when I mapped my usb ports, I block intel BT and use BRCM Broadcom bluetooth working fine, and using compiled Clover 5156 or 5157 (not works with "another" boot loader), to send from my Desktop to my iPhone works fine or another real Mac. Include too my not real Mac Lenovo E470. I believe that coders will find way to work AirDrop with intel Wireless card. 1 Link to comment Share on other sites More sharing options...
miliuco Posted March 28 Share Posted March 28 @Max.1974 I'm skeptical, I don't think Intel wifi can ever use Airdrop. Apple configures macOS by default to use Airdrop only under very specific conditions. itlwm spoofs itself as wifi but it is not seen by macOS as real wifi. AirportItlwm works the way Airdrop compatible wifi work, it can support Airdrop in theory but so far the developer has not been able to do it, this kext comes from the Linux driver and the Linux code surely lacks what Broadcom has to allow Airdrop. Link to comment Share on other sites More sharing options...
Max.1974 Posted March 29 Share Posted March 29 Hi my friend works from Desktop to iPhone for while, and I believe it's not Bluetooth or even Wireless, but permission or configuration from Kext. See my Desktop Airdrop intel Wireless + Broadcom BT to my Iphone Spoiler 1 1 Link to comment Share on other sites More sharing options...
Max.1974 Posted March 29 Share Posted March 29 Spoiler 3D7E01D8-DBBD-4F61-A920-3DCDACD2ADBE.mp4 Spoiler 0EE6CB2A-3981-4C92-8FDD-17CDFF463B65.mp4 see my friend @miliuco and above too My Lenovo 100% intel Wifi and BT to my Desktop intel Wifi + BRCM BT And both to my Iphone The "secret" to me is Clover and compiled Kexts and Bootloader with GCC compiler 3 Link to comment Share on other sites More sharing options...
witjojo Posted March 29 Share Posted March 29 (edited) Hello everyone, I have a "Lenovo ThinkCentre M93 Tiny" with the Mini PCI-E WIFI card BCM94352HMB. As far as Ventura, the WIFI worked without any problems. But now I can't get the WIFI card to work under Sonoma. I've read everything here over and over again 20 times. Unfortunately I can't come to a positive solution. The system is configured as Mac Mini 7,1 and I made all the settings for WIFI as described here. Here are screenshots of my system. During root patching, the graphics and WIFI cards were correctly recognized and the graphics card is also patched correctly. But the WIFI card is not patched properly. Tha WIFI card is displayed here as a FakeBCM card. I hope you can help me. Edited March 30 by witjojo 1 Link to comment Share on other sites More sharing options...
Max.1974 Posted March 30 Share Posted March 30 Hi @witjojo Maybe you can try use MacBook Pro 15,1, 15,2 or 16,2 SMBIOS. And if you can, post your EFI 1 Link to comment Share on other sites More sharing options...
witjojo Posted March 30 Share Posted March 30 (edited) Hi Max, I have now switched my SMBIOS to MacBook Pro 15.2 and repached again. But no difference, no WiFi. I noticed that Bluetooth is also recognized as a third party dongle. That wasn't the case at Ventura. Here is my EFI. I deleted IO80211FamilyLegacy.kext from the EFI, because I can only upload 10 MB. EFI.zip Edited March 30 by witjojo 1 Link to comment Share on other sites More sharing options...
datafeedexpert Posted March 30 Share Posted March 30 (edited) 15 hours ago, witjojo said: Hello everyone, I have a "Lenovo ThinkCentre M93 Tiny" with the Mini PCI-E WIFI card BCM94352HMB. As far as Ventura, the WIFI worked without any problems. But now I can't get the WIFI card to work under Sonoma. I've read everything here over and over again 20 times. Unfortunately I can't come to a positive solution. The system is configured as Mac Mini 7,1 and I made all the settings for WIFI as described here. Here are screenshots of my system. During root patching, the graphics and WIFI cards were correctly recognized and the graphics card is also patched correctly. But the WIFI card is not patched properly. Tha WIFI card is displayed here as a FakeBCM card. I hope you can help me. 1 - AirportBrcmFixup.kext/Contents/PlugIns/AirPortBrcmNIC_Injector.kext , Add Max Kernel 22.99.99 2 - Your EFI has missing IO80211FamilyLegacy.kext Macmini7,1 is good for your Hardware Edited March 30 by datafeedexpert 1 1 Link to comment Share on other sites More sharing options...
witjojo Posted March 30 Share Posted March 30 1 hour ago, datafeedexpert said: 1 - AirportBrcmFixup.kext/Contents/PlugIns/AirPortBrcmNIC_Injector.kext , Add Max Kernel 22.99.99 2 - Your EFI has missing IO80211FamilyLegacy.kext Macmini7,1 is good for your Hardware 1. I thnk Max Kernel 22.99.99 is not necessary. 2. I deleted IO80211FamilyLegacy.kext from the EFI, because I can only upload 10 MB. It's inside my EFI. I think if Macmini 7,1 or MacBook Pro 15,2 is not important. Link to comment Share on other sites More sharing options...
datafeedexpert Posted March 30 Share Posted March 30 36 minutes ago, witjojo said: 1. I thnk Max Kernel 22.99.99 is not necessary. 2. I deleted IO80211FamilyLegacy.kext from the EFI, because I can only upload 10 MB. It's inside my EFI. I think if Macmini 7,1 or MacBook Pro 15,2 is not important. Try Adding Max Kernel 22.99.99 its confirmed from my side i am having same hardware & the same issue when updated to Sonoma 14.4 Link to comment Share on other sites More sharing options...
witjojo Posted March 30 Share Posted March 30 5 hours ago, datafeedexpert said: Try Adding Max Kernel 22.99.99 its confirmed from my side i am having same hardware & the same issue when updated to Sonoma 14.4 That can't be right, can it? Sonoma is 23.0.0 and if Max Kernel is 22.99.99 then AirportBrcmFixup.kext/Contents/PlugIns/AirPortBrcmNIC_Injector.kext will not be injected. This would mean that AirPortBrcmFixup.kext is not needed for Sonoma. Only the IOSkywalkFamily.kext and IO80211FamilyLegacy.kext and the root patching? I have changed to Max Kernel 22.99.99. But I still don't have WiFI. If you have the same hardware, can you give me your EFI to test? Maybe I have errors somewhere else in settings, ACPI, USB, etc. Link to comment Share on other sites More sharing options...
miliuco Posted March 30 Share Posted March 30 (edited) @witjojo Load IO80211FamilyLegacy.kext/Contents/PlugIns/AirPortBrcmNIC.kext instead of AirportBrcmFixup.kext/Contents/PlugIns/AirPortBrcmNIC_Injector.kext. Spoiler Maybe you need extra kexts but try the above and comment. And add a signature to your Account Settings. Edited March 30 by miliuco Link to comment Share on other sites More sharing options...
