eSaF Posted December 28, 2020 Share Posted December 28, 2020 (edited) 1 hour ago, pkdesign said: I've noticed that currently in my set up I have "EFI version found 1554.50.2.0.0 but should be 1554.60.15.0.0" How do I update that in OC? I do not see an entry for it in config.plist. Hi pk - Don't know how much this will help but this is my version, I was running Beta 11.2 but reverted back to the released version 11.1 after losing Boot Chime at startup, I am running OpenCore version 0.6.5. What you reported is certainly peculiar indeed. Are you sure you're running latest version? Spoiler Edited December 28, 2020 by eSaF 1 Link to comment Share on other sites More sharing options...
MorenoAv Posted December 28, 2020 Share Posted December 28, 2020 I'm in OpenCore 0.6.5 and I have BS Version 11.2 (Build 20D5029f) and my value is the following 1554.40.41.0.0. More BS weirdness I'm sure ...LOL 1 Link to comment Share on other sites More sharing options...
ammoune78 Posted December 28, 2020 Share Posted December 28, 2020 (edited) @Download-Fritz i've made some progress there, the performances are back now. But a problem that i didn't get done to fix is RTC, every boot i've it, even if using Windows from OpenCore. Dunno how to solve it, even with SSDT. Do you have any idea on how do i Fix that problem which i think will be the last i guess. EFI.zip Edited December 28, 2020 by ammoune78 Link to comment Share on other sites More sharing options...
eSaF Posted December 28, 2020 Share Posted December 28, 2020 14 minutes ago, MorenoAv said: I'm in OpenCore 0.6.5 and I have BS Version 11.2 (Build 20D5029f) and my value is the following 1554.40.41.0.0. More BS weirdness I'm sure ...LOL @MorenoAv - Have you got the Boot Chime feature activated with this Beta version? The reason I ask I lost it when I installed Beta 11.2 so decided to go back to the released version (Yea I know but I am a bit picky like that ) also a lot of bugs are reported to be in this latest Beta so the general consensus is to stick to the 11.1 released. Link to comment Share on other sites More sharing options...
kode54 Posted December 29, 2020 Share Posted December 29, 2020 I would like to contribute to the development process of getting OpenCore working with "Resize BAR Support", possibly specific to AMD B450 motherboards, possibly not. I know it's a memory map issue, but I need to know what steps I should take to log OpenCore to contribute to getting a memory mapping workaround in place for it. Above 4G Decoding and Resize BAR Support disabled: Boots with ncpi=0x2000 Above 4G Decoding enabled, Resize BAR Support disabled: Boots without npci setting. Both enabled: Locks up at the point where it would switch on the video card. I can log information on this system using a debug version of OpenCore, but I need to know precisely what settings I need to change to enable the correct logging for this exact issue. Link to comment Share on other sites More sharing options...
MorenoAv Posted December 29, 2020 Share Posted December 29, 2020 15 hours ago, eSaF said: @MorenoAv - Have you got the Boot Chime feature activated with this Beta version? The reason I ask I lost it when I installed Beta 11.2 so decided to go back to the released version (Yea I know but I am a bit picky like that ) also a lot of bugs are reported to be in this latest Beta so the general consensus is to stick to the 11.1 released. Hi @eSaF, No I don't use boot chime, and I know how it is, I'm a bit OC about things too... I don't have speakers so I don't have boot chime... Good 2021 for you and your family Cheers 1 Link to comment Share on other sites More sharing options...
mhaeuser Posted December 29, 2020 Share Posted December 29, 2020 (edited) @ammoune78 When precisely does it happen? Does it happen also when only booting OC (no further OS) and then resetting the machine? Does it happen with Windows without OC? Does it *always* happen? @kode54 Nothing of what you described gets stuck in OC... PS: I did not set this cringy role tag, is this new? Edited December 29, 2020 by Download-Fritz Link to comment Share on other sites More sharing options...
ammoune78 Posted December 29, 2020 Share Posted December 29, 2020 @Download-Fritz It does happen when booting macOS/Windows using OpenCore only. Without OC it does not happen. 1 Link to comment Share on other sites More sharing options...
Pavo Posted December 29, 2020 Share Posted December 29, 2020 1 hour ago, Download-Fritz said: @kode54 Nothing of what you described gets stuck in OC... @Download-Fritz what @kode54 is basically saying is that enabling the new BIOs setting of Resize PCI BAR makes the GPU get disabled in macOS. Agree this isn't specific to OpenCore, but could be something worth looking into since even Intel boards will be getting this new BIOS option soon because of the RX 6xxx series GPUs. Link to comment Share on other sites More sharing options...
mhaeuser Posted December 29, 2020 Share Posted December 29, 2020 1 minute ago, Pavo said: @Download-Fritz what @kode54 is basically saying is that enabling the new BIOs setting of Resize PCI BAR makes the GPU get disabled in macOS. Agree this isn't specific to OpenCore, but could be something worth looking into since even Intel boards will be getting this new BIOS option soon because of the RX 6xxx series GPUs. Well maybe, but it's not related to OC, that is the point. I don't know what the issue is, but if there is an actual issue, it's probably WhateverGreen territory? Link to comment Share on other sites More sharing options...
Pavo Posted December 29, 2020 Share Posted December 29, 2020 (edited) 6 minutes ago, Download-Fritz said: Well maybe, but it's not related to OC, that is the point. I don't know what the issue is, but if there is an actual issue, it's probably WhateverGreen territory? Agreed, just something to be mindful about. Edited December 29, 2020 by Pavo Link to comment Share on other sites More sharing options...
pkdesign Posted December 29, 2020 Share Posted December 29, 2020 (edited) 22 hours ago, eSaF said: Hi pk - Don't know how much this will help but this is my version, I was running Beta 11.2 but reverted back to the released version 11.1 after losing Boot Chime at startup, I am running OpenCore version 0.6.5. What you reported is certainly peculiar indeed. Are you sure you're running latest version? Hide contents I was using Silent Knight from Eclectic Light Company to just check things and noticed this: Spoiler That is the only reason I even knew about it. In my sig you will see I am still on Mojave and using OC 0.6.4. I updated some of those other things with Lock Rattler earlier. Purely cosmetic, I'm sure, but with Clover you were able to enter this in the config plist. Edited December 29, 2020 by pkdesign 3 Link to comment Share on other sites More sharing options...
Erroruser Posted December 29, 2020 Share Posted December 29, 2020 is there any chance that there will be support added in for the expansion slot utility? seems that i may fall under the PlatformInfo similar to the memory? Link to comment Share on other sites More sharing options...
Paksman Posted December 30, 2020 Share Posted December 30, 2020 (edited) Maybe this is off topic but I need to ask: is there anyone here successfully using opencore on Big Sur with fakesmc kext? It causes kernel panic with "You shutdown your computer because of a problem ..." message. Tried reading logs but found nothing useful. I need fakesmc with radeon monitor plugin as it's the only way to read temperature from my 5700 gpu opencore-2020-12-18-192820.txt edit: solved thanks to Slice Edited December 30, 2020 by Paksman Link to comment Share on other sites More sharing options...
ameenjuz Posted December 30, 2020 Share Posted December 30, 2020 @vit9696 @Andrey1970 i m using macOS Big Sur 11 i have strange problem in system preference under Battrey section when i plug USB flash drive then (put hard disk to sleep when possible) tick box is reappear which can you look attached screenshot Spoiler when i unplug USB flash drive then (put hard disk to sleep when possible) tick box is disappear which can you look attached screenshot Spoiler this is strange behavior in system preference under battery section which i m facing i mapped my all usbports correctly i don't know idea what is this issue and i boot my system using my internal EFI Partition when i boot my system with external usb flash drive then (put hard disk to sleep when possible) tick box is reappear i need help about this behavoir Link to comment Share on other sites More sharing options...
PC IT Posted December 30, 2020 Share Posted December 30, 2020 On 12/24/2020 at 2:47 AM, eSaF said: Hi - There are a few things you need to have in place. I don't think you need chime.dxe but you will need the AudioDxe.efi file in the Drivers Folder also listed in the config.plist along with these settings as shown. With everything in place, reduce your speakers volume just incase, reboot and clean the NVRAM. You should then have Boot Chime as Long as your Codec Value is correct for your machine. Good luck. Edit - I forgot you will need the Boot Chime Wav File in EFI/Resources/Audio Folder - I have attached it here also. Hide contents OCEFIAudio_VoiceOver_Boot.wav Thank you @eSaF for the reply, i did it and it is working properly. still i am having a problem in my audio device, it cannot detect the external mic, do you have any ideas, i can send you clover codec dump , hope you can help me or forward it to who can help me adding it to appleALC kext, waiting any reply from you and all , Thanks so much Link to comment Share on other sites More sharing options...
eSaF Posted December 30, 2020 Share Posted December 30, 2020 1 hour ago, PC IT said: Thank you @eSaF for the reply, i did it and it is working properly. still i am having a problem in my audio device, it cannot detect the external mic, do you have any ideas, i can send you clover codec dump , hope you can help me or forward it to who can help me adding it to appleALC kext, waiting any reply from you and all , Thanks so much Hi as far as I know, now that you have sound working the Microphone settings should be Generic and not needing any special settings as such. In the FaceTime app when in use, the camera and microphone just automatically switches on, Spoiler that's the way it is in my rig anyway. Make sure your microphone is registered in the System Preferences/Sound like the attached. Link to comment Share on other sites More sharing options...
rvxtm Posted December 31, 2020 Share Posted December 31, 2020 4 hours ago, ameenjuz said: @vit9696 @Andrey1970 i m using macOS Big Sur 11 i have strange problem in system preference under Battrey section when i plug USB flash drive then (put hard disk to sleep when possible) tick box is reappear which can you look attached screenshot Reveal hidden contents when i unplug USB flash drive then (put hard disk to sleep when possible) tick box is disappear which can you look attached screenshot Reveal hidden contents this is strange behavior in system preference under battery section which i m facing i mapped my all usbports correctly i don't know idea what is this issue and i boot my system using my internal EFI Partition when i boot my system with external usb flash drive then (put hard disk to sleep when possible) tick box is reappear i need help about this behavoir Same issue here. Z87-UD3H / I7 4770K Link to comment Share on other sites More sharing options...
ghost8282 Posted December 31, 2020 Share Posted December 31, 2020 (edited) On 12/29/2020 at 6:16 PM, pkdesign said: Purely cosmetic, I'm sure, but with Clover you were able to enter this in the config plist. This is possible also with OC, of course. usually these data are updated by Andrey1970AppleLife really fast, as soon as they are available: so if you use PlatformInfo --> Automatic=true just update your opencore version to the latest master. Otherwise, if you use PlatformInfo --> Automatic=false you need to input all your smbios data by hand, and the field you are interested in is PlatformInfo --> SMBIOS --> BIOSVersion Edited December 31, 2020 by ghost8282 Link to comment Share on other sites More sharing options...
Alpha22 Posted December 31, 2020 Share Posted December 31, 2020 Hi everyone dual boot windows 10 Big Sur using OC 0.6.4 I have the problem that windows does not start, advice I have a guide to show me thanks Link to comment Share on other sites More sharing options...
plsh2me Posted December 31, 2020 Share Posted December 31, 2020 3 hours ago, Alpha22 said: Hi everyone dual boot windows 10 Big Sur using OC 0.6.4 I have the problem that windows does not start, advice I have a guide to show me thanks I faced the windows booting problem on my Asus. If you have the acpi error on windows boot then try to patch the acpi correctly on Mac. Windows booting problem will solve automatically. Link to comment Share on other sites More sharing options...
ammoune78 Posted December 31, 2020 Share Posted December 31, 2020 @Download-Fritz please any advice for that RTC? Link to comment Share on other sites More sharing options...
joevt Posted January 1, 2021 Share Posted January 1, 2021 On 12/29/2020 at 11:08 AM, Erroruser said: is there any chance that there will be support added in for the expansion slot utility? seems that i may fall under the PlatformInfo similar to the memory? What kind of support do you want? The Expansion Slot Utility is for Mac Pro 2019 only. It is very specific to that hardware. The Mac Pro 2019 has a CPU with 64 PCIe lanes. 16 are used for slot 1, 16 for slot 3, 16 for Pool A, 16 for Pool B. Pool A and Pool B are connected to two upstream 16 lane links of a 96 lane PEX chip which has 64 downstream lanes connected to the 2, 4, or 6 Thunderbolt controllers (hard coded to Pool B ), and slots 2, 4, 5, 6, 7, and 8 which can be assigned to Pool A or Pool B. An Expansion Slot Utility for a hackintosh will require a totally different UI and code. Any settings a hackintosh may have are controlled by the BIOS so making a utility would be a waste of time, except as a graphical substitute to pciutils because the PCI tab of System Information.app is inadequate. Link to comment Share on other sites More sharing options...
pkdesign Posted January 1, 2021 Share Posted January 1, 2021 12 hours ago, ghost8282 said: This is possible also with OC, of course. usually these data are updated by Andrey1970AppleLife really fast, as soon as they are available: so if you use PlatformInfo --> Automatic=true just update your opencore version to the latest master. Otherwise, if you use PlatformInfo --> Automatic=false you need to input all your smbios data by hand, and the field you are interested in is PlatformInfo --> SMBIOS --> BIOSVersion Mine is set to True so I guess I will just wait. As I said, it's just cosmetic and I just noticed it. Link to comment Share on other sites More sharing options...
Alpha22 Posted January 1, 2021 Share Posted January 1, 2021 (edited) 11 hours ago, plsh2me said: I faced the windows booting problem on my Asus. If you have the acpi error on windows boot then try to patch the acpi correctly on Mac. Windows booting problem will solve automatically. thanks for your reply, can you help me my asus Z97 card I forgot the windows problem and at startup an infinite loading comes out (the dots moving in a circle) i don't get to the desktop Edited January 1, 2021 by Alpha22 Link to comment Share on other sites More sharing options...
