SavageAUS Posted July 10, 2020 Share Posted July 10, 2020 3 hours ago, Stefanalmare said: https://medium.com/@andv/making-wifi-on-big-sur-unsupported-macs-with-failed-with-66-error-36c98e3f7965 Followed to the T and now having to do a fresh install. Not a good method. 1 Link to comment Share on other sites More sharing options...
ameenjuz Posted July 10, 2020 Share Posted July 10, 2020 (edited) 16 minutes ago, mnfesq said: Same as yours: Sunrise Point-LP SATA Controller (AHCI mode) 9D03, 8086. This is native support no need rename SAT0 to SATA Patch Remove SSDT-SATA.aml and rename SAT0 to SATA Patch from config Remember i m using kingstone SSD Edited July 10, 2020 by ameenjuz edited Link to comment Share on other sites More sharing options...
Blu24 Posted July 10, 2020 Share Posted July 10, 2020 (edited) 34 minutes ago, hohoho said: Thanks for the reply. I don’t know what a snapshot is, but do you mean my laptop specs? Acer Aspire 3 (A315-51-51B0) Intel i5-7200u (intel hd 620) 12 GB ram Your config.plist is not correctly compiled for kaby Lake https://dortania.github.io/OpenCore-Desktop-Guide/config.plist/kaby-lake.html I can compile your EFI if you want. it's 4AM here in the UK, I can compile it later. It's much better if you do it so you can learn OpenCore. Edited July 10, 2020 by Blu24 Link to comment Share on other sites More sharing options...
mnfesq Posted July 10, 2020 Share Posted July 10, 2020 4 minutes ago, ameenjuz said: This is native support no need rename SAT0 to SATA Patch Remove SSDT-SATA.aml and rename SAT0 to SATA Patch from config Remember i m using kingstone SSD I tried using no DSDT at all. It still doesn't work. IOAHCIBlockStorageDriver.kext fails to read any drives connected by SATA to PRT devices. Link to comment Share on other sites More sharing options...
hohoho Posted July 10, 2020 Share Posted July 10, 2020 1 minute ago, Blu24 said: Your config.plist is not correctly compiled for kaby Lake what does that mean? is the problem with the DeviceProperties? or boot args? or quirks? or something else? here is my clover efi. i have been using clover since the beginning and i am just starting to migrate to OC so that i can install Big Sur. i followed a vanilla guide to make the OC config. thanks for the help! clover EFI catalina working perfectly.zip Link to comment Share on other sites More sharing options...
Blu24 Posted July 10, 2020 Share Posted July 10, 2020 (edited) 14 minutes ago, hohoho said: what does that mean? is the problem with the DeviceProperties? or boot args? or quirks? or something else? here is my clover efi. i have been using clover since the beginning and i am just starting to migrate to OC so that i can install Big Sur. i followed a vanilla guide to make the OC config. thanks for the help! clover EFI catalina working perfectly.zip boot args, quirks, ACPI, are all wrong for kaby Lake OpenCore. personally I would start with macOS Catalina first In your OC kext folder you have USBInjectAll.kext and USBPorts.kext. only one can be used. You can't use both. Please follow the guide https://dortania.github.io/OpenCore-Desktop-Guide/config.plist/kaby-lake.html Edited July 10, 2020 by Blu24 Link to comment Share on other sites More sharing options...
hohoho Posted July 10, 2020 Share Posted July 10, 2020 19 minutes ago, Blu24 said: Your config.plist is not correctly compiled for kaby Lake https://dortania.github.io/OpenCore-Desktop-Guide/config.plist/kaby-lake.html I can compile your EFI if you want. it's 4AM here in the UK, I can compile it later. It's much better if you do it so you can learn OpenCore. that is the guide i followed to make my opencore config. yeah. i'd rather do it myself. i have only been doing OC just for about a couple of days now. i have been editing the OC config using ProperTree.. i will try to figure out that compile thing. any clues where it is would be very appreciated! thanks a lot! Link to comment Share on other sites More sharing options...
jmacie Posted July 10, 2020 Share Posted July 10, 2020 15 minutes ago, hohoho said: what does that mean? is the problem with the DeviceProperties? or boot args? or quirks? or something else? here is my clover efi. i have been using clover since the beginning and i am just starting to migrate to OC so that i can install Big Sur. i followed a vanilla guide to make the OC config. thanks for the help! clover EFI catalina working perfectly.zip no kexts files in your efi Link to comment Share on other sites More sharing options...
ameenjuz Posted July 10, 2020 Share Posted July 10, 2020 23 minutes ago, mnfesq said: I tried using no DSDT at all. It still doesn't work. IOAHCIBlockStorageDriver.kext fails to read any drives connected by SATA to PRT devices. please provide me your EFI folder and i also provide my config and DSDT tommorow Link to comment Share on other sites More sharing options...
hohoho Posted July 10, 2020 Share Posted July 10, 2020 8 minutes ago, jmacie said: no kexts files in your efi oh sorry, i forgot to include it. here is the one with the kext folder. thanks Part 2 - clover EFI catalina working perfectly.zip 1 Link to comment Share on other sites More sharing options...
Blu24 Posted July 10, 2020 Share Posted July 10, 2020 (edited) 6 19 minutes ago, hohoho said: that is the guide i followed to make my opencore config. yeah. i'd rather do it myself. i have only been doing OC just for about a couple of days now. i have been editing the OC config using ProperTree.. i will try to figure out that compile thing. any clues where it is would be very appreciated! thanks a lot! Sent you a PM. How to compile an EFI folder, snapshot, etc Edited July 10, 2020 by Blu24 1 Link to comment Share on other sites More sharing options...
jmacie Posted July 10, 2020 Share Posted July 10, 2020 1 minute ago, Blu24 said: Sent you a PM. How to compile an EFI folder Could you pm me that info for compiling an efi folder? I can't successfully make an OC efi either. Thanks a lot Link to comment Share on other sites More sharing options...
DarkNeptune0 Posted July 10, 2020 Share Posted July 10, 2020 Does it happen to anyone else that the trackpad has lag when the computer is not connected to the power? or does it just happen to me? Link to comment Share on other sites More sharing options...
Blu24 Posted July 10, 2020 Share Posted July 10, 2020 12 minutes ago, jmacie said: Could you pm me that info for compiling an efi folder? I can't successfully make an OC efi either. Thanks a lot Done 1 Link to comment Share on other sites More sharing options...
pico joe Posted July 10, 2020 Share Posted July 10, 2020 (edited) Open Sealed first see this assumed you run script BigSur prelinkedkernel fix2.command or prelinkedkernel fix4 see my post above credit to : jackluke and the follow this step first set nvram csr-active-config w%08%00%00 (or w%09%00%00 ) on OC config.plist from a BigSur normal booting terminal:sudo mkdir ~/Snapshot/ (this makes an empty folder mount point on your home folder so copy exactly as written)mount (on the first output "mount" line you can notice a diskXsYsZ you have to consider only diskXsY)sudo mount -o nobrowse -t apfs /dev/diskXsY ~/Snapshot/ open ~/Snapshot/ (from Finder you can now rename your Volume Label, note from Finder the mount point has your BigSurLabel while from terminal it has the "Snapshot" folder name so the folder name must be used from BigSur terminal) then just copy - paste file or folder you want inject or modif (in my case I want change my DisplayVendorID-1e6d) sudo chown -R 0:0 ~/Snapshot/System/Library/Displays/Contents/Resources/Overrides/ sudo chmod -R 755 ~/Snapshot/System/Library/Displays/Contents/Resources/Overrides/ sudo bless --folder ~/Snapshot/System/Library/CoreServices/ --bootefi --create-snapshot tmutil localsnapshot (check that the listed snapshot has the current date time) reboot ……. and Viola Spoiler Edited July 10, 2020 by pico joe Link to comment Share on other sites More sharing options...
htanh034 Posted July 10, 2020 Share Posted July 10, 2020 17 minutes ago, DarkNeptune0 said: Does it happen to anyone else that the trackpad has lag when the computer is not connected to the power? or does it just happen to me? error same for me Link to comment Share on other sites More sharing options...
jmacie Posted July 10, 2020 Share Posted July 10, 2020 7 minutes ago, Blu24 said: Done Thanks Blu24. I appreciate it! Link to comment Share on other sites More sharing options...
DarkNeptune0 Posted July 10, 2020 Share Posted July 10, 2020 3 minutes ago, htanh034 said: error same for me Great, I was thinking maybe there was something wrong with my plist Link to comment Share on other sites More sharing options...
mnfesq Posted July 10, 2020 Share Posted July 10, 2020 55 minutes ago, ameenjuz said: please provide me your EFI folder and i also provide my config and DSDT tommorow Here's a working EFI folder. I have tried several and all of them boot to the installer but none of them allow me to see my internal drives. mnfesq EFI.zip Link to comment Share on other sites More sharing options...
DarkNeptune0 Posted July 10, 2020 Share Posted July 10, 2020 19 minutes ago, DarkNeptune0 said: Great, I was thinking maybe there was something wrong with my plist Removing ACPIBatteryManager works perfectly, it will probably be solved when SMCBatteryManager works again. Link to comment Share on other sites More sharing options...
hohoho Posted July 10, 2020 Share Posted July 10, 2020 (edited) 1 hour ago, Blu24 said: boot args, quirks, ACPI, are all wrong for kaby Lake OpenCore. personally I would start with macOS Catalina first In your OC kext folder you have USBInjectAll.kext and USBPorts.kext. only one can be used. You can't use both. Please follow the guide https://dortania.github.io/OpenCore-Desktop-Guide/config.plist/kaby-lake.html I see. I will try it out. I used this guide to make my initial config because i am using a laptop.: https://dortania.github.io/vanilla-laptop-guide/OpenCore/config-laptop.plist/kaby-lake.html thanks for the help! I was having problems booting even with my catalina using OC but these fixed the problems and i was able to successfully boot with catalina using my initial OC config: (First fix) RebuildAppleMemoryMap = FALSE (2nd fix) npci=0x3000 ..i was not able to boot catalina using OC without them. Edited July 10, 2020 by hohoho Link to comment Share on other sites More sharing options...
Matgen84 Posted July 10, 2020 Share Posted July 10, 2020 (edited) 15 hours ago, Matgen84 said: Hi Guys I try to install Beta 2 on a external drive (OC 0.6.0 + latest Lilu + his plugins). Big Sur stuck at "less than 1 minutes" with full progress bar since 20 minutes. Any ideas? Please. Any ideas to solve this issue. Please. (Z390 config of course) Edited July 10, 2020 by Matgen84 1 Link to comment Share on other sites More sharing options...
dehjomz Posted July 10, 2020 Share Posted July 10, 2020 8 hours ago, Shikumo said: You can try this patch, which works for me. Hello, thank you for your correspondence. Can you post the patch again please? Some how it got cutoff. All I can see is <dict><key>Base</key> <string>__ZN27AppleEthernetAquantiaAqtion5startEP9IOService< Link to comment Share on other sites More sharing options...
hohoho Posted July 10, 2020 Share Posted July 10, 2020 i made a new OC EFI and this new one is working perfectly now with Catalina but i still can't boot the Big Sur USB Installer with it though. Thanks! updated OC running perfect in catalina but can't boot Big Sur.zip 1 Link to comment Share on other sites More sharing options...
subjectdenied Posted July 10, 2020 Share Posted July 10, 2020 39 minutes ago, hohoho said: i made a new OC EFI and this new one is working perfectly now with Catalina but i still can't boot the Big Sur USB Installer with it though. Thanks! updated OC running perfect in catalina but can't boot Big Sur.zip i have exactly the same issue, and this is the first time i saw it mentioned by someone else. what system are you on? i'm on a xps13 9380 FHD, using a amd 570x egpu and booting / installing to from a tb3 samsung xd5. i still try to update an existing and working OC based catalina with big.sur beta1. funny thing is, i had it already working on the internal ssd by using qemu to update catalina via vm-method, until it crashed pretty hard after some hours (i think because of an incompatible non hackintosh related kext) and i couldnt boot it again afterwards Link to comment Share on other sites More sharing options...
