[pre-release] macOS Big Sur

d5aqoep · September 6, 2020

5 hours ago, Alex HQuest said:

What are your SMBIOS/selected model for your hardware? If you are using a CPU way different from the Apple device model selected (I.e., an iMacPro with non-Xeon CPUs), this is expected unless you have a super detailed injection of much more data than current tools are able to generate.

I used iMacPro1,1 as SMBIOS and now the latest iMac20,1 as it closely matches my i5 10600 CPU. But it just does not sleep with any of those SMBIOSes.

fusion71au · September 6, 2020

4 hours ago, Matgen84 said:

Hi @fusion71au

Maybe you can help me: got two problems with Beta 6.

1 - mount -uw / don't work error 66, despite of your csr-config in my OC config.plist. I check the status, both are disable. I try terminal command on Recovery mode: same issue.

2 - Preferences / Software Update don't show up enrollment despite terminal command, Apple Utility and SwitchermacOS.app. But this app shows the Developer enrollment is active

If you have any ideas. Please

Hi @Matgen84,

1. If you are booting into a standard Big_Sur installation, it is normal to see error 66 when trying to mount the root volume as read-write, due to presence of APFS snapshot(s), even with SIP disabled. Need to boot to Big_Sur Recovery and delete all the APFS snapshots (as well as SIP disabled) before the system will allow it - see guide post.

In Recovery, mounting r/w should work, even with snapshots present, but needs the correct syntax/path eg below, Big_Sur is on disk6s5 and I am replacing IO80211Family.kext in Big_Sur Beta6/S/L/E...

Spoiler


-bash-3.2# nvram csr-active-config
csr-active-config	w%08%00%00
-bash-3.2# csrutil status
System Integrity Protection status: disabled.
-bash-3.2# diskutil list
/dev/disk0 (internal, physical):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *128.0 GB   disk0
   1:                        EFI ⁨EFI⁩                     209.7 MB   disk0s1
   2:                 Apple_APFS ⁨Container disk2⁩         30.6 GB    disk0s2
                    (free space)                         268.4 MB   -
   3:       Microsoft Basic Data ⁨Windows 10 SSD⁩          97.0 GB    disk0s3

/dev/disk1 (internal, physical):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *1.0 TB     disk1
   1:                        EFI ⁨EFI⁩                     209.7 MB   disk1s1
   2:                  Apple_HFS ⁨Macintosh HD⁩            119.5 GB   disk1s2
   3:                 Apple_Boot ⁨Recovery HD⁩             650.0 MB   disk1s3
   4:       Microsoft Basic Data ⁨HDD⁩                     815.4 GB   disk1s4
   5:         Microsoft Reserved ⁨⁩                        134.2 MB   disk1s5
   6:       Microsoft Basic Data ⁨BOOTCAMP⁩                63.8 GB    disk1s6
   7:           Windows Recovery ⁨⁩                        532.7 MB   disk1s7

/dev/disk2 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme -                      +30.6 GB    disk2
                                 Physical Store disk0s2
   1:                APFS Volume ⁨Macintosh SSD — Data⁩    4.3 GB     disk2s1
   2:                APFS Volume ⁨Preboot⁩                 91.3 MB    disk2s2
   3:                APFS Volume ⁨Recovery⁩                525.7 MB   disk2s3
   4:                APFS Volume ⁨VM⁩                      2.1 GB     disk2s4
   5:                APFS Volume ⁨Macintosh SSD⁩           11.1 GB    disk2s5

/dev/disk3 (external, physical):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *320.1 GB   disk3
   1:                        EFI ⁨EFI⁩                     209.7 MB   disk3s1
   2:                 Apple_APFS ⁨Container disk6⁩         59.6 GB    disk3s2
                    (free space)                         268.4 MB   -
   3:       Microsoft Basic Data ⁨MACRIUM Backups⁩         166.4 GB   disk3s3
   4:                 Apple_APFS ⁨Container disk5⁩         53.6 GB    disk3s4
                    (free space)                         268.4 MB   -
   5:                 Linux Swap ⁨⁩                        4.3 GB     disk3s5
   6:       Microsoft Basic Data ⁨⁩                        314.6 MB   disk3s6
   7:           Linux Filesystem ⁨⁩                        35.1 GB    disk3s7

/dev/disk4 (external, physical):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *15.9 GB    disk4
   1:                        EFI ⁨EFI⁩                     209.7 MB   disk4s1
   2:                  Apple_HFS ⁨Install macOS Big Su...⁩ 15.5 GB    disk4s2

/dev/disk5 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme -                      +53.6 GB    disk5
                                 Physical Store disk3s4
   1:                APFS Volume ⁨Catalina - Data⁩         8.9 GB     disk5s1
   2:                APFS Volume ⁨Preboot⁩                 80.7 MB    disk5s2
   3:                APFS Volume ⁨Recovery⁩                731.6 MB   disk5s3
   4:                APFS Volume ⁨VM⁩                      2.1 GB     disk5s4
   5:                APFS Volume ⁨Catalina⁩                11.4 GB    disk5s5

/dev/disk6 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme -                      +59.6 GB    disk6
                                 Physical Store disk3s2
   1:                APFS Volume ⁨Big_Sur — Data⁩          4.5 GB     disk6s1
   2:                APFS Volume ⁨Preboot⁩                 245.3 MB   disk6s2
   3:                APFS Volume ⁨Recovery⁩                754.6 MB   disk6s3
   4:                APFS Volume ⁨VM⁩                      1.1 MB     disk6s4
   5:                APFS Volume ⁨Big_Sur⁩                 15.4 GB    disk6s5

/dev/disk7 (disk image):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        +1.9 GB     disk7
   1:                 Apple_APFS ⁨Container disk8⁩         1.9 GB     disk7s1

/dev/disk8 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme -                      +1.9 GB     disk8
                                 Physical Store disk7s1
   1:                APFS Volume ⁨macOS Base System⁩       1.6 GB     disk8s1
   2:                APFS Volume ⁨Preboot⁩                 126.2 MB   disk8s2

-bash-3.2# diskutil mountDisk disk6s5
Volume(s) mounted successfully
-bash-3.2# mount -uw /Volumes/Big_Sur
-bash-3.2# mv /Volumes/Big_Sur/System/Library/Extensions/IO80211Family.kext /Volumes/Big_Sur/System/Library/Extensions/IO80211Family.orig
-bash-3.2# cp -R /Volumes/Image\ Volume/Kexts/IO80211Family.kext /Volumes/Big_Sur/System/Library/Extensions
-bash-3.2# ls -l /Volumes/Big_Sur/System/Library/Extensions
total 0
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AFKACIPCKext.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AGXFirmwareKextG11GRTBuddy.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AGXFirmwareKextRTBuddy64.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AGXG11G.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AGXGPURawCounterBundle.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AGXMetalA12.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 ALF.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMD10000Controller.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMD7000Controller.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMD8000Controller.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMD9000Controller.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMD9500Controller.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDFramebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDMTLBronzeDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonServiceManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonVADriver2.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonX4000.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonX4000GLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonX4000HWServices.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonX5000.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonX5000GLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:28 AMDRadeonX5000HWServices.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX5000MTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX5000Shared.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX6000.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX6000Framebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX6000GLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX6000HWServices.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX6000MTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRadeonX6000Shared.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDRawCounterPlugin.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDShared.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AMDSupport.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AUC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 Apple16X50Serial.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleA7IOP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleACPIPlatform.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAE2Audio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAHCIPort.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleALSColorSensor.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleANXDPTX.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAOPAudio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAOPVoiceTrigger.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAPIC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleARMIISAudio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleARMPMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleARMPlatform.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAVD.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAVE2.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAVEBridge.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleActuatorDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAfterburner.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleAuthCP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBCMWLANBusInterfacePCIe.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBCMWLANBusInterfacePCIeMac.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBCMWLANCore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBCMWLANCoreMac.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBSDKextStarter.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBacklight.kext
drwxr-xr-x@ 7 root  wheel  224  4 Sep 06:41 AppleBacklightExpert.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBiometricSensor.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBiometricServices.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBluetoothDebug.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBluetoothDebugService.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBluetoothModule.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBluetoothMultitouch.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBluetoothRemote.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleBusPowerController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleCSEmbeddedAudio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleCameraInterface.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleConvergedIPCOLYBTControl.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleConvergedPCI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleCredentialManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleCycloneErrorHandler.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD1755PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD1815PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD1881PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD1946PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD1972PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD1974PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2018PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2045PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2089PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2186PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2207PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2238PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2255PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2257PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2333PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2346PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2365PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2400PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2401PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2422PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2449PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleD2460PMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleDAPF.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleDPDisplay.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleDPRepeater.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleDiagnosticDataAccessReadOnly.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleDialogPMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleDiskImages2.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEFIRuntime.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEffaceableBlockDevice.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEffaceableNOR.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEffaceableStorage.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEffaceableTDM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedAudio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedAudioLibs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedBluetoothMultitouch.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedLightSensor.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedOSSupportHost.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedPCIE.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedSimpleSPINORFlasherDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedTempSensor.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedTouchEEPROMDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedUSB.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedUSBHost.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleEmbeddedUSBXHCIPCI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFAN53740.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFDEKeyStore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFIVRDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFSCompressionTypeDataless.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFSCompressionTypeZlib.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFWAudio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFileSystemDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFileUtil.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleFirmwareUpdateKext.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleGFXHDA.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleGPIOICController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleGameControllerPersonality.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleGraphicsControl.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleGraphicsPowerManagement.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleH10CameraInterface.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleH10PearlCameraInterface.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleH11ANEInterface.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHDA.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHIDALSService.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHIDKeyboard.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHIDKeyboardEmbedded.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHIDMouse.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHIDTransport.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHPET.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHPM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHSSPIHIDDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHSSPISupport.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHV.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleHighVoltageCharger.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIPAppender.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIRController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleImage4.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleInputDeviceSupport.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelBDWGraphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelBDWGraphicsFramebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelBDWGraphicsGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelBDWGraphicsMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelBDWGraphicsVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelBDWGraphicsVAME.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelCFLGraphicsFramebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelCFLGraphicsVAME.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelCPUPowerManagement.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelCPUPowerManagementClient.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelFramebufferAzul.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelFramebufferCapri.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelGraphicsShared.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD4000Graphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD4000GraphicsGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD4000GraphicsMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD4000GraphicsVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD5000Graphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD5000GraphicsGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD5000GraphicsMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHD5000GraphicsVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelHSWVA.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelICLGraphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelICLGraphicsGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelICLGraphicsMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelICLGraphicsVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelICLLPGraphicsFramebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelICLLPGraphicsVAME.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelIVBVA.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelKBLGraphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelKBLGraphicsFramebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelKBLGraphicsGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelKBLGraphicsMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelKBLGraphicsVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelKBLGraphicsVAME.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssDmac.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssGspi.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssI2C.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssI2CController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssSpiController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssUARTCommon.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssUARTv0.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelLpssUARTv1.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelMCEReporter.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelPCHPMC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSKLGraphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSKLGraphicsFramebuffer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSKLGraphicsGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSKLGraphicsMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSKLGraphicsVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSKLGraphicsVAME.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleIntelSlowAdaptiveClocking.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleInterruptController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleJPEGDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleKeyStore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleLMBacklight.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleLPC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleLSIFusionMPT.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleLightningErrorHandler.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleM2ScalerCSC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleM68Buttons.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMCA2_T8027.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMCCSControl.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMCP89RootPortPM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMIDIBluetoothDriver.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMIDIFWDriver.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMIDIIACDriver.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMIDIRTPDriver.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMIDIUSBDriver.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMatch.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMesaSEPDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMetalGLRenderer.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMikeyHIDDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMobileApNonce.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMobileDispH11G.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMobileFileIntegrity.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMultiFunctionManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMultiFunctionManagerMac.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleMultitouchDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleNANDConfigAccess.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleOnboardSerial.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ApplePMGR.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ApplePMP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ApplePVPanic.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleParavirtGPU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleParavirtGPUMetal.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ApplePassthroughPPM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ApplePlatformEnabler.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleRAID.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleRTC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS5L8920XPWM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS5L8940XI2C.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS5L8960XNCO.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS5L8960XUSB.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS5L8960XWatchDogTimer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS8000AES.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleS8000DWI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSART.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSDXC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSEPGenericTransfer.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSEPHDCPManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSEPKeyStore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSEPManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSMBIOS.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSMBusController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSMBusPCI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSMC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSMCLMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSMCRTC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSPMI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSPMIPMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSPU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSRP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSSE.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSamsungPKE.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSamsungSPI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSamsungSerial.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSmartBatteryManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSmartIO2.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleStockholmControl.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleStorageDrivers.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSummitLCD.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSynopsysMIPIDSI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleSystemPolicy.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8010PMPFirmware.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8011PMPFirmware.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8011USB.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8015PMPFirmware.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8020.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8020DART.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8020PMPFirmware.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8020SOCTuner.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8027.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8027CLPCv3.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8027PCIe.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8027PMGR.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8027PMPFirmware.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleT8027USB.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleTCA7408GPIOIC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleThunderboltDPAdapters.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleThunderboltEDMService.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleThunderboltIP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleThunderboltNHI.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleThunderboltPCIAdapters.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleThunderboltUTDM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleTopCase.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleTriStar.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleTwisterErrorHandler.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleTypeCPhy.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBACM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBAudio.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBCDC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBCommon.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBDMM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBDeviceMux.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBDeviceNCM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBDisplays.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBECM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBEEM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBEthernet.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBEthernetHost.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBHostT6000.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBHostT8027.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBMike.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBMultitouch.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBNCM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBNetworking.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBRealtek8153Patcher.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBSerial.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBTopCase.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBWCM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBXHCIARM.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUSBiBridge.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleUpstreamUserClient.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleVirtIO.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleVirtualGraphics.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleVirtualMCA.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleVortexErrorHandler.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 AppleXsanScheme.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 Apple_iSight.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ArcMSR.kext
drwxr-xr-x@ 6 root  wheel  192  4 Sep 06:41 AudioAUUC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BCMWLANFirmware4355_Hashstore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BCMWLANFirmware4364_Hashstore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BCMWLANFirmware4377_Hashstore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BCMWLANFirmware4378_Hashstore.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BootCache.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BootPolicy.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BridgeAudioCommunication.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 BridgeAudioController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 CellPhoneHelper.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 CoreAnalyticsFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 CoreKDL.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 CoreStorage.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 CoreTrust.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 Dont Steal Mac OS X.kext
drwxr-xr-x@ 4 root  wheel  128 29 Aug 06:29 DriverKit
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 EAP-RSA.ppp
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 EncryptedBlockStorage.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 EndpointSecurity.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 FSPlaceholder.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 FairPlayIOKit.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 GeForce.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 GeForceAIRPlugin.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 GeForceGLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 GeForceMTLDriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 GeForceVADriver.bundle
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFSEncodings.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS_MacCentralEurRoman.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS_MacChineseSimp.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS_MacChineseTrad.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS_MacCyrillic.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS_MacJapanese.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 HFS_MacKorean.kext
drwxr-xr-x@ 3 root  wheel   96  4 Sep 08:02 IO80211Family.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IO80211Family.orig
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IO80211FamilyV2.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOACPIFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAHCIFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOATAFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAVBFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAVFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAccelerator2D.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAcceleratorFamily2.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAccessoryManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAccessoryPortUSB.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAudio2Family.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOAudioFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOBDStorageFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOBiometricFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOBluetoothFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOBluetoothHIDDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOBufferCopyController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOBufferCopyEngineFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOCDStorageFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOCECFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOCryptoAcceleratorFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IODARTFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IODVDStorageFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IODisplayPortFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOFireWireAVC.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOFireWireFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOFireWireSBP2.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOFireWireSerialBusProtocolTransport.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOGPUFamily.kext
drwxr-xr-x@ 7 root  wheel  224  4 Sep 06:41 IOGraphicsFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOHDCPFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOHDIXController.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOHIDFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOImageLoader.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOKitRegistryCompatibility.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOMobileGraphicsFamily.kext
drwxr-xr-x@ 6 root  wheel  192  4 Sep 06:41 IONDRVSupport.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IONVMeFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IONetworkingFamily.kext
drwxr-xr-x@ 7 root  wheel  224  4 Sep 06:41 IOPCIFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOPlatformPluginFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOReportFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSCSIArchitectureModelFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSCSIParallelFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSMBusFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSerialFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSkywalkFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSlaveProcessor.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSlowAdaptiveClockingFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOStorageFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOStreamFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOSurface.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOTextEncryptionFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOThunderboltFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOTimeSyncFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOUSBDeviceFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOUSBFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOUSBHostFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOUSBMassStorageDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOUserEthernet.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOUserSerial.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 IOVideoFamily.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 KernelRelayHost.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 KextAudit.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 L2TP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 Libm.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 LightweightVolumeManager.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 NVDAGF100Hal.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 NVDAGK100Hal.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 NVDAResman.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 NVDAStartup.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 NVMeSMARTLib.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 NVSMU.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 OSvKernDSPLib.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 PPP.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 PPPoE.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 PromiseSTEX.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 Quarantine.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 RTBuddy.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 SMARTLib.plugin
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 SMCMotionSensor.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 Sandbox.kext
drwxr-xr-x@ 6 root  wheel  192  4 Sep 06:41 System.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 acfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 acfsctl.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 afpfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 apfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 asp_tcp.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 autofs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 cd9660.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 cddafs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 corecapture.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 corecrypto.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 eficheck.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 exfat.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 iPodDriver.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 mcxalr.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 msdosfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 ntfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 pmtelemetry.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 pthread.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 smbfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 tmpfs.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 triggers.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 udf.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 vecLib.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 watchdog.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 webcontentfilter.kext
drwxr-xr-x@ 3 root  wheel   96 29 Aug 06:29 webdav_fs.kext
-bash-3.2# chown -R 0:0 /Volumes/Big_Sur/System/Library/Extensions/IO80211Family.kext && chmod -R 755 /Volumes/Big_Sur/System/Library/Extensions/IO80211Family.kext
-bash-3.2# touch /Volumes/Big_Sur/System/Library/Extensions && kmutil install --volume-root /Volumes/Big_Sur --update-all --force
checking collections...
Warning: com.apple.driver.KextExcludeList was not found!
considering release out-of-date because of --force
rebuilding release collections: boot, system
rebuilding release collections:
	boot kernel collection
	system kext collection
rebuilding local auxiliary collection
kmutil done
-bash-3.2# /Volumes/Big_Sur/usr/sbin/kcditto
Copying deferred prelinked kernels in /Volumes/Big_Sur...
/AppleInternal/BuildRoot/Library/Caches/com.apple.xbs/Sources/kext_tools/kext_tools-692.40.3/kc_staging.m.279: Encountered error while inspecting path: Error Domain=NSCocoaErrorDomain Code=260 "The folder “PrelinkedKernels” doesn’t exist." UserInfo={NSFilePath=/Volumes/Big_Sur/Library/Apple/System/Library/PrelinkedKernels, NSUserStringVariant=(
    Folder
), NSUnderlyingError=0x7f800d604080 {Error Domain=NSOSStatusErrorDomain Code=-43 "fnfErr: File not found"}}
/AppleInternal/BuildRoot/Library/Caches/com.apple.xbs/Sources/kext_tools/kext_tools-692.40.3/kc_staging.m.279: Encountered error while inspecting path: Error Domain=NSCocoaErrorDomain Code=260 "The folder “PrelinkedKernels” doesn’t exist." UserInfo={NSFilePath=/Volumes/Big_Sur/Library/Apple/System/Library/PrelinkedKernels, NSUserStringVariant=(
    Folder
), NSUnderlyingError=0x7f800eb06fc0 {Error Domain=NSOSStatusErrorDomain Code=-43 "fnfErr: File not found"}}
Copying KCs in /Volumes/Big_Sur...
System Volume UUID: A62DEFF8-A6E1-4742-B6CF-D51DF4F1010C
Volume Group UUID: 1D6EB770-639C-3C97-82A7-A0722E1998EB
Preboot disk: /dev/disk6s2
Preboot volume: /Volumes/Preboot
Copying: /Volumes/Big_Sur/System/Library/KernelCollections/BootKernelExtensions.kc.elides -> /Volumes/Preboot/1D6EB770-639C-3C97-82A7-A0722E1998EB/boot/System/Library/KernelCollections
Copying: /Volumes/Big_Sur/System/Library/KernelCollections/BootKernelExtensions.kc -> /Volumes/Preboot/1D6EB770-639C-3C97-82A7-A0722E1998EB/boot/System/Library/KernelCollections
Copying: /Volumes/Big_Sur/System/Library/PrelinkedKernels/immutablekernel -> /Volumes/Preboot/1D6EB770-639C-3C97-82A7-A0722E1998EB/System/Library/PrelinkedKernels
Copying: /Volumes/Big_Sur/System/Library/PrelinkedKernels/prelinkedkernel -> /Volumes/Preboot/1D6EB770-639C-3C97-82A7-A0722E1998EB/System/Library/PrelinkedKernels
-bash-3.2# bless --folder /Volumes/Big_Sur/System/Library/CoreServices --bootefi --create-snapshot
-bash-3.2# reboot

-bash-3.2# diskutil mountDisk disk6s5
Volume(s) mounted successfully
-bash-3.2# mount -uw /Volumes/Big_Sur

2. From Big_Sur Beta6 release notes in @Alex HQuest's post, there is a bug where you might be unable to update automatically to Beta6 if Secure Boot is set to No Security. This is a problem for many hacks since we may need to disable Secure Boot in order to boot and also disable SIP for various reasons eg to enable third party USB wifi kexts. Personally, I download the full installer app and it hasn't failed (yet) for in place upgrades and/or clean installs.

jmacie · September 6, 2020

Still no install/boot for x99. Any other chipsets not working with BigSur?

xtddd · September 7, 2020

@Matgen84 hi, i use the lateset opencore and kexts...it can install beta6 in sata ssd.. but failed in the sm961 nvme ssd. finished the first install then choose the macos installer,it shows forbidden symbol

Donw35 · September 7, 2020

not all NVMe are supported, you can tru NVMEfix.kext, see if that helps

xtddd · September 7, 2020

3 minutes ago, Donw35 said:

not all NVMe are supported, you can tru NVMEfix.kext, see if that helps

ok. thank you...i will try..samgsung sm961 may be not supported?

Donw35 · September 7, 2020

FYI My Samsung PM981 isn't supported either, I use the 970 EVO plus..

xtddd · September 7, 2020

@Down35 i got it .thank you

BALDY_MAN · September 7, 2020

ADATA SX8200PNP:

Capacity: 512.11 GB (512,110,190,592 bytes)

TRIM Support: Yes

Model: ADATA SX8200PNP

my drive I'm using

csdsf · September 7, 2020

16 hours ago, Pavo said:

您必须从OpenCore编译最新提交以获取新的Force功能 https://github.com/acidanthera/OpenCorePkg/blob/master/Docs/Sample.plist#L449

Can you elaborate on the method?

SavageAUS · September 7, 2020

On 9/6/2020 at 2:25 PM, pico joe said:

I made app with automator to force load the kext at login, just try ...

smb-On.zip

Yay i can access my unraid server now.

ITzTravelInTime · September 7, 2020

12 hours ago, jmacie said:

Still no install/boot for x99. Any other chipsets not working with BigSur?

That seems to be an rtc bug which is motherboard-dependant but i haven't figured out how to get it booting on my gigabyte x99 system

ANTIKO · September 7, 2020

49 minutes ago, ITzTravelInTime said:

That seems to be an rtc bug which is motherboard-dependant but i haven't figured out how to get it booting on my gigabyte x99 system

Yes, there is still no way to install Big sur from a USB flash drive. As I understand it, this is only for x99 owners. You can deploy a ready-made image from under a virtual machine, but this is not an honest option.)) We will look for a solution.))

ITzTravelInTime · September 7, 2020

17 minutes ago, Антико said:

Yes, there is still no way to install Big sur from a USB flash drive. As I understand it, this is only for x99 owners. You can deploy a ready-made image from under a virtual machine, but this is not an honest option.)) We will look for a solution.))

The problem is bios-related and should be fixable with a custom dsdt, but it depends on the motherboard-specific rtc implementation, in fact many owners of chinese motherboards are free of this problem and they are able to boot big sur without any of those problems

ANTIKO · September 7, 2020

5 minutes ago, ITzTravelInTime said:

The problem is bios-related and should be fixable with a custom dsdt, but it depends on the motherboard-specific rtc

Both me and jmacie have tried various installation options, but alas, not yet. If you find a solution, we will only be glad. Sorry for my english, I use google translator.

ITzTravelInTime · September 7, 2020

6 minutes ago, Антико said:

Both me and jmacie have tried various installation options, but alas, not yet. If you find a solution, we will only be glad. Sorry for my english, I use google translator.

You need to see your rtc implementation in your oem dsdt and figure out what's wrong with it, there is an example for this on the open core desktop guide but it's related to asus x299 boards

Edited September 7, 2020 by ITzTravelInTime

jmacie · September 7, 2020

2 hours ago, ITzTravelInTime said:

You need to see your rtc implementation in your oem dsdt and figure out what's wrong with it, there is an example for this on the open core desktop guide but it's related to asus x299 boards

It's easy to say "look at your rtc in your specific dsdt and see what's wrong", but we don't know what to "look for". This is where the experts @vit9696 @Download-Fritzet al have to help, which we've been asking for for 2 months. Here I'll post my dsdt.aml for the 3rd time and you can look at it and tell me what's wrong, I've read and tried the info from Dortania with every combination and permutation of quirk with no luck,we need the experts to help with x99 and BigSur

DSDT.aml

2 hours ago, ITzTravelInTime said:

1 hour ago, ITzTravelInTime said:

Edited September 7, 2020 by jmacie

xtddd · September 7, 2020

@Matgen84i installed big sur beta6, after finishing the first install , i chose the macos installer and then show below:

Edited September 7, 2020 by xtddd

D-an-W · September 7, 2020

3 hours ago, xtddd said:

@Matgen84i installed big sur beta6, after finishing the first install , i chose the macos installer and then show below:

Spoiler

See if this post helps, it did me.

Blu24 · September 7, 2020

OC 0.61 officially released

d5aqoep · September 7, 2020

Here is my Gigabyte Z490 Vision G EFI based on 0.6.1 final release with latest release kexts. It should work with most Z490 Systems. Make sure you use Big Sur Beta 6 and higher. If you want to use this for Catalina, add correct Cpuid1Data and Cpuid1Mask under Open Core's Kernel section.

EFI-Gigabyte-Z490-BigSur-DP6.zip

MorenoAv · September 7, 2020

Hi guys,

I have one more problem, one more, with BS beta 6, but is equal in previous versions, with my usb/wifi combo BCM 94362, and my lack of a dedicated GPU, that is thee lack of sleep button beta 6 it goes to sleep but only wakes with the power button, the activity lights blink like mad but the hack don't wake up... the solution press the power button until goes off and then restart the machine again.

The machine starts and then stops always needed restarting 2 times for the machine to work properly... anyone could help pinpoint the solution?

Thanks

config.plist.zip

Ellybz · September 7, 2020

@ITzTravelInTime

I looked at your DSDT.aml

if you search for Device (RTC) you'll see that your RTC range is incomplete and needs a remap. It's lacking the section 0x72 & 0x73

To compensate this the RTC0.ssdt does the trick. ( Same on Asus Mobos)

You can also try the following ACPI rtc patch. It might work for you.

FIND: 5F435253 11180A15 47017000 70000102 47017400 74000104 22000179

REPLACE: 5F435253 11180A15 47017000 70000104 47017400 74000104 22000179

Best of luck.

Edited September 7, 2020 by Ellybz

jmacie · September 7, 2020

14 minutes ago, Ellybz said:

@ITzTravelInTime

I looked at your DSDT.aml

if you search for Device (RTC) you'll see that your RTC range is incomplete and needs a remap. It's lacking the section 0x72 & 0x73

To compensate this the RTC0.ssdt does the trick. ( Same on Asus Mobos)

You can also try the following ACPI rtc patch. It might work for you.

FIND: 5F435253 11180A15 47017000 70000102 47017400 74000104 22000179

REPLACE: 5F435253 11180A15 47017000 70000104 47017400 74000104 22000179

Best of luck.

Thank you, That was my dsdt. I have tried this solution 2 months back. @vit9696 says the issue is unsolvable without the source for iopcifamily ( where the boot KPs) and a x99 mobo for someone to actualize a patch and no plans any time soon to investigate. But thank you, someday maybe we'll get it straight. I appreciate your help.

ITzTravelInTime · September 7, 2020

1 hour ago, Ellybz said:

@ITzTravelInTime

I looked at your DSDT.aml

if you search for Device (RTC) you'll see that your RTC range is incomplete and needs a remap. It's lacking the section 0x72 & 0x73

To compensate this the RTC0.ssdt does the trick. ( Same on Asus Mobos)

You can also try the following ACPI rtc patch. It might work for you.

FIND: 5F435253 11180A15 47017000 70000102 47017400 74000104 22000179

REPLACE: 5F435253 11180A15 47017000 70000104 47017400 74000104 22000179

Best of luck.

I will test you fix as soon as i can and the report back, thank you for the help

EDIT: my dsdt for the rtc device was just like @jmacie 's one if you are wondering

Edited September 7, 2020 by ITzTravelInTime

[pre-release] macOS Big Sur

Recommended Posts

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites
