AudioGod's Aorus Z390 Pro Patched DSDT Mini Guide and Discussion

AudioGod

By AudioGod,
in Installation Guides

 Share
5,966 posts in this topic

Recommended Posts

hackinhacker
hackinhacker
Posted
Posted
18 hours ago, AudioGod said:


here you go buddy, it’s got wizemans name on it but its the new EFI for him to test.



Wizeman EFI.zip



switch the dsdt inside this EFI for your RX 580 one and remove agdpmod=pikera from the boot arguments.



new DSDTs ain’t ready yet so this is for bios F11 only



If you don't mind could you please clarify what DSDT.aml needs to be replaced with what?  From your older EFI?  by the way I removed the agdpmod line as you instructed.  Anything else needs to be changed if I want to go with iMacPro1,1?









Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
3 minutes ago, hackinhacker said:



If you don't mind could you please clarify what DSDT.aml needs to be replaced with what?  From your older EFI?  by the way I removed the agdpmod line as you instructed.  Anything else needs to be changed if I want to go with iMacPro1,1?











Replace DSDT.AML with this one.



If your using a RX Polaris Series GPU with bios revision F11 then use this DSDT

DSDT.RX Series.zip   (TO BE USED WITH BIOS REVISION F11 ONLY)





Edited by AudioGod
Link to comment
Share on other sites
WizeMan
WizeMan
Posted
Posted
33 minutes ago, AudioGod said:



Replace DSDT.AML with this one.



If your using a RX Polaris Series GPU with bios revision F11 then use this DSDT

DSDT.RX Series.zip   (TO BE USED WITH BIOS REVISION F11 ONLY)






Also replace shikigva=80 with shikigva=32 and add another boot flag:

shiki-id=Mac-7BA5B2D9E42DDD94



This will get you AppleTV(+) working with RX580 and Safari will not crash on other DRM streams like Netflix and Prime Video. They will not work (DRM on Safari does not work with RX580 and generally Polaris Cards for the time being) but at least they won’t hang your hackintosh with Safari.

Link to comment
Share on other sites
hackinhacker
hackinhacker
Posted
Posted (edited)
51 minutes ago, AudioGod said:



Replace DSDT.AML with this one.



If your using a RX Polaris Series GPU with bios revision F11 then use this DSDT

DSDT.RX Series.zip   (TO BE USED WITH BIOS REVISION F11 ONLY)







Unplugged the power cable

pulled out the battery

put the battery back in

with iGPU enabled I can't even boot



from the boot loader, it goes to "error loading kernel cache (0x7) boot failed: will sleep for 10 seconds before exiting"



also tried with iGPU disabled and changed the SMBIOS to iMacPro1,1; but still the same error.



"error loading kernel cache (0x7) boot failed: will sleep for 10 seconds before exiting"



12 minutes ago, WizeMan said:


Also replace shikigva=80 with shikigva=32 and add another boot flag:

shiki-id=Mac-7BA5B2D9E42DDD94



This will get you AppleTV(+) working with RX580 and Safari will not crash on other DRM streams like Netflix and Prime Video. They will not work (DRM on Safari does not work with RX580 and generally Polaris Cards for the time being) but at least they won’t hang your hackintosh with Safari.

my GPU is RX570, not 580.



Edited by hackinhacker
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted
12 minutes ago, hackinhacker said:



Unplugged the power cable

pulled out the battery

put the battery back in

with iGPU enabled I can't even boot



from the boot loader, it goes to "error loading kernel cache (0x7) boot failed: will sleep for 10 seconds before exiting"



also tried with iGPU disabled and changed the SMBIOS to iMacPro1,1; but still the same error.



"error loading kernel cache (0x7) boot failed: will sleep for 10 seconds before exiting"



my GPU is RX570, not 580.




as it’s a test version and not my official release it was done for For somebody specifically so I might of left KernalPM Unchecked so go into the clover config and make sure KernelPM is Enabled if your MSR is locked or Disabled if it’s unlocked.

Link to comment
Share on other sites
WizeMan
WizeMan
Posted
Posted (edited)
39 minutes ago, hackinhacker said:



Unplugged the power cable

pulled out the battery

put the battery back in

with iGPU enabled I can't even boot



from the boot loader, it goes to "error loading kernel cache (0x7) boot failed: will sleep for 10 seconds before exiting"



also tried with iGPU disabled and changed the SMBIOS to iMacPro1,1; but still the same error.



"error loading kernel cache (0x7) boot failed: will sleep for 10 seconds before exiting"



my GPU is RX570, not 580.




The same applies. RX570 is a Polaris card

Edited by WizeMan
Link to comment
Share on other sites
pkdesign
pkdesign
Posted
Posted (edited)
1 hour ago, AudioGod said:



Replace DSDT.AML with this one.



If your using a RX Polaris Series GPU with bios revision F11 then use this DSDT

DSDT.RX Series.zip   (TO BE USED WITH BIOS REVISION F11 ONLY)





Hey, should we all replace our DSDT with this one? Did you edit something?

Edited by pkdesign
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
1 minute ago, pkdesign said:

Hey, should we all replace our DSDT with this one? Did you edit something?

No lol

thats the standard F11 DSDT that you already use



just wait,

il put up a big fat notice on the thread when I update it.

soon come my friend

Edited by AudioGod
  • Haha 1
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
9 minutes ago, pkdesign said:

Hey, should we all replace our DSDT with this one? Did you edit something?


@pkdesign  if you really want the new EFI to test with the new F12d DSDT then I can PM it to you to try out for me if you like?

your need to update the bios too and I haven’t created a MSR Ulocked profile for F12d yet so your have to run it with KernelPM Enabled unless you know how to unlock your MSR yourself? (There’s nothing wrong with running it with your MSR Locked and KernelPM Checked)

let me know if you want to be a tester bee buddy? :startreck:

Edited by AudioGod
Link to comment
Share on other sites
hackinhacker
hackinhacker
Posted
Posted
1 hour ago, AudioGod said:


as it’s a test version and not my official release it was done for For somebody specifically so I might of left KernalPM Unchecked so go into the clover config and make sure KernelPM is Enabled if your MSR is locked or Disabled if it’s unlocked.





just unlocked MSR by following the procedure.  KernelPM is unchecked.  rebooted, then from the boot loader still the same error

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted
8 minutes ago, hackinhacker said:





just unlocked MSR by following the procedure.  KernelPM is unchecked.  rebooted, then from the boot loader still the same error

I wonder what’s happened to your kernel cache?

thats not the EFI Tbh,

have you tried clearing your kernel cache by any chance?

if you haven’t and you don’t know how look it up on here or google as I’m not in front on my hack to send you a link.

one way to clear it though is to boot into safe made and then restart and that clears it automatically.

theres other ways if you can’t get into safe mode though.



Link to comment
Share on other sites
hackinhacker
hackinhacker
Posted
Posted
15 minutes ago, AudioGod said:

I wonder what’s happened to your kernel cache?

thats not the EFI Tbh,

have you tried clearing your kernel cache by any chance?

if you haven’t and you don’t know how look it up on here or google as I’m not in front on my hack to send you a link.

one way to clear it though is to boot into safe made and then restart and that clears it automatically.

theres other ways if you can’t get into safe mode though.





found few ways to clear the cache but when my system is complete useless how am I supposed to go into the cmd line?  as I mentioned before my previous Mojave is completely destroyed so there is no way I can't go into safe mode or anyother way of going to the command line to clear the cache; unless there is another way to clear the cache other than going to the command line.



Link to comment
Share on other sites
pkdesign
pkdesign
Posted
Posted
1 hour ago, AudioGod said:


@pkdesign  if you really want the new EFI to test with the new F12d DSDT then I can PM it to you to try out for me if you like?

your need to update the bios too and I haven’t created a MSR Ulocked profile for F12d yet so your have to run it with KernelPM Enabled unless you know how to unlock your MSR yourself? (There’s nothing wrong with running it with your MSR Locked and KernelPM Checked)

let me know if you want to be a tester bee buddy? :startreck:

I'll think about it. It’s a production machine and I'm in the middle of a project so I'd hate to screw something up :shock:

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted
Just now, pkdesign said:

I'll think about it. It’s a production machine and I'm in the middle of a project so I'd hate to screw something up :shock:

Just wait until the people testing it give me the thumbs up then and i post it on here properly.

Most Probably tomorrow.

  • Thanks 1
Link to comment
Share on other sites
Tiem
Tiem
Posted
Posted (edited)

Awesome man, can't wait! :thumbsup_anim:

1 hour ago, pkdesign said:

I'll think about it. It’s a production machine and I'm in the middle of a project so I'd hate to screw something up :shock:

Recovering your EFI is trivial. Just rename your old EFI folder to EFI.old (or whatever). Toss in the new one. Have your UBS installer handy in case it won't boot. If it doesn't work, just boot with your USB installer's EFI and then roll the changes back. You can't really fubar your install just messing with the EFI. It may not boot, but the system itself isn't touched.



The only thing you have to be careful with is the SMBIOS. If you mess that up you're going to break iCloud and coming back from that can be arduous and quite time consuming (mostly because you have to wait on Apple's servers as forcing a sanity check isn't really possible).

Edited by Tiem
Link to comment
Share on other sites
pkdesign
pkdesign
Posted
Posted
1 hour ago, Tiem said:

Recovering your EFI is trivial. Just rename your old EFI folder to EFI.old (or whatever). Toss in the new one. Have your UBS installer handy in case it won't boot. If it doesn't work, just boot with your USB installer's EFI and then roll the changes back. You can't really fubar your install just messing with the EFI. It may not boot, but the system itself isn't touched.



The only thing you have to be careful with is the SMBIOS. If you mess that up you're going to break iCloud and coming back from that can be arduous and quite time consuming (mostly because you have to wait on Apple's servers as forcing a sanity check isn't really possible).

It isn't a trivial matter since I'd have to update my BIOS to another version. It isn’t as simple as just an EFI swap.

Link to comment
Share on other sites
c1ru
c1ru
Posted
Posted
11 hours ago, AudioGod said:



its not the finished EFI as I have a new DSDT update too for bios F12d,

Its under test now but should go live sometime tomorrow or the day after that at the latest.



I have two question, can I use iMessage with a different account than my iCloud? isn't working right now.

Also, what can I test in my Catalina OS to check if everything is perfect or working fine? some benchmark?

Link to comment
Share on other sites
Tiem
Tiem
Posted
Posted

No, iMessage is account bound.



Yes, there are some checks you can use. Synthetic benchmarks don't identify problems. They push the hardware to its limits and report back. If Hackintool reports back that your VDA decoder is fully supported and you see the headless icon, you know your GPU is set up correctly. Sidecar should be working beautifully. Outside of that, if macOS just runs, then you're good. Feel free to dig through system logs and google away lol.

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)

NEW Clover Major EFI and DSDT UPDATE, 15th January 2020 (Use With Bios Revision F12d Only or read below)



Important Notice

This New EFI Contains a brand new DSDT made for for the Z390 Pro Bios Revision F12d ONLY,

If you dont want to update your bios and I personally recommend you do then replace the new DSDT with your old F11 DSDT and then you can continue using the F11 bios with the new EFIs.


The EFI and DSDT has now been updated to the my latest version.

Changes made include,

New DSDT's For bios revision F12d ONLY

OcQuirks Revision 12

Whatevergreen 1.3.6

Lilu 1.4.1

AppleALC-1.4.5

VirtualSMC 1.10

MemoryAllocation.efi now added to the UEFI driver folder to fix failure to boot because of memory allocation failures at start up

Clover Updated too Revision 5103

Plus other minor tweaks to the clover config



I have also now created a HD630 IGPU only version of the EFI so for all you people out there that have been asking me for this your wish is my command. :)




Aorus Z390 Pro Vega Navi VII F12d EFI .zip - Use with Bios revision F12d Only (15/01/2020 Catalina 10.15.2 Vega, Navi (5700, 5700xt), Radeon VII DSDT Installed) SMBios 19,1
Aorus Z390 Pro RX Polaris F12d EFI .zip - Use with Bios revision F12d Only (15/01/2020 Catalina 10.15.2 RX5XX Polaris DSDT Installed) SMBios 19,1

HD630 Z390 Pro F12d EFI.zip - Use with Bios revision F12d Only (15/01/2020 Catalina 10.15.2 HD630 IGPU Only) SMBios 18,1



If you prefer using SMBios 1,1 then by all means switch to it but all the old problems of using 19,1 are corrected now with this EFI plus DRM is fully working unless you have a Polaris gpu. Just to add, SMBios 19,1 is the correct one to be using for our chipset and cpu, if you check the spec of a real macpro it is not a using a CoffeeLake CPU or Z3xx chipset. It does work perfectly but correct is correct so 19,1 it is.



Please Note, If you use a 5700 or 5700XT then SMBios 1,1 is unstable using the Navi GPUs so please stick to 19,1 with igpu enabled.



Latest Gigabyte Z390 PRO BIOS (F12d)

mb_bios_z390-aorus-pro_f12d.zip



CFG Unlock (MSR) F12d BIOS Profile - The Easy Way

@texem Has kindly made this bios profile for you all to use that will unlock CFG on your motherboard making it play alot more friendly with the NVRam.

It also has all the bios settings listed on this guide pre done and saved onto the profile.



F12d_UNLOCK.zip  - Use with Bios Revision F12d ONLY



1 - Download the profile and save it to a USB Key

2 - Go into the bios,

3 - Load the profile,

4 - Save and exit

5 - Go straight back into the bios and save your bios to a new profile and name it Default CFG Unlocked or something like that.

6 - Boot back into Catalina go into your clover config and under Kernal and Kext Patches Uncheck KernalPM

7 - Save the changes and then restart and your done, your motherboard will now be CFG (MSR) Unlocked



PLEASE NOTE - If you reset the bios or load bios defaults it will clear the Unlock making CFG Locked again.

Edited by AudioGod
  • Like 4
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted
7 minutes ago, vyu01773 said:

Hi,
I've tried your new intel hd profile/EFI but mouse and keyboard are not recognized for me.

Using F12d and the stick has Catalina on it.

Did you add any usb kext or make any changes?

if you did then try again but without adding anything or making any changes other then your details.

Link to comment
Share on other sites
