riden666, please delete flag bus ratio ! And here result .



boot-args=npci=0x3000 kext-dev-mode=1 ncl=262144 busratio=36

hw.tbfrequency: 1000000000
hw.cpufrequency_max: 3601000000
hw.cpufrequency_min: 3601000000
hw.cpufrequency: 3601000000
hw.busfrequency_max: 100000000
hw.busfrequency_min: 100000000
hw.busfrequency: 100000000
machdep.tsc.frequency: 3600565200

0:100  0:100  MemLog inited, TSC freq: 3600565200
0:100  0:000  CPU was calibrated without ACPI PM Timer: Intel ICH device was not found., use RTC
0:100  0:000
0:100  0:000  Now is 15.7.2017,  21:22:36 (GMT)
0:100  0:000  Starting Clover revision: 4114 on American Megatrends EFI
0:100  0:000  Build with: [Args: -D NO_GRUB_DRIVERS_EMBEDDED | -D NO_GRUB_DRIVERS_EMBEDDED -D USE_LOW_EBDA -a X64 -b RELEASE -t XCODE5 -n 5 | OS: 10.12.5 | XCODE: 8.3.3]
0:100  0:000  SelfDevicePath=PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FF3EF174-38AA-44B7-A131-898CFDE5166D,0x28,0x64000) @DAF31998
0:100  0:000  SelfDirPath = \EFI\BOOT
0:103  0:003  === [ Get Smbios ] ========================================
0:103  0:000  Type 16 Index = 0
0:103  0:000  Total Memory Slots Count = 4
0:103  0:000  Type 17 Index = 0
0:103  0:000  Table has error information, checking
0:103  0:000  Found memory information in table 18/1, type=0x3, operation=0x2 syndrome=0x0
0:103  0:000  ...memory OK
0:103  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:103  0:000  SmbiosTable.Type17->Size = 0MB
0:103  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL A DIMM 0
0:103  0:000  SmbiosTable.Type17->Vendor = Unknown
0:103  0:000  SmbiosTable.Type17->SerialNumber = Unknown
0:103  0:000  SmbiosTable.Type17->PartNumber = Unknown
0:103  0:000  Type 17 Index = 1
0:103  0:000  Table has error information, checking
0:103  0:000  Found memory information in table 18/2, type=0x3, operation=0x2 syndrome=0x0
0:103  0:000  ...memory OK
0:103  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:103  0:000  SmbiosTable.Type17->Size = 8192MB
0:103  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL A DIMM 1
0:103  0:000  SmbiosTable.Type17->Vendor = Unknown
0:103  0:000  SmbiosTable.Type17->SerialNumber = 00000000
0:103  0:000  SmbiosTable.Type17->PartNumber = CMK16GX4M2B3200C16
0:103  0:000  Type 17 Index = 2
0:103  0:000  Table has error information, checking
0:103  0:000  Found memory information in table 18/3, type=0x3, operation=0x2 syndrome=0x0
0:103  0:000  ...memory OK
0:103  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:103  0:000  SmbiosTable.Type17->Size = 0MB
0:103  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL B DIMM 0
0:103  0:000  SmbiosTable.Type17->Vendor = Unknown
0:103  0:000  SmbiosTable.Type17->SerialNumber = Unknown
0:103  0:000  SmbiosTable.Type17->PartNumber = Unknown
0:103  0:000  Type 17 Index = 3
0:103  0:000  Table has error information, checking
0:103  0:000  Found memory information in table 18/4, type=0x3, operation=0x2 syndrome=0x0
0:103  0:000  ...memory OK
0:103  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:103  0:000  SmbiosTable.Type17->Size = 8192MB
0:103  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL B DIMM 1
0:103  0:000  SmbiosTable.Type17->Vendor = Unknown
0:103  0:000  SmbiosTable.Type17->SerialNumber = 00000000
0:103  0:000  SmbiosTable.Type17->PartNumber = CMK16GX4M2B3200C16
0:103  0:000  Boot status=0
0:103  0:000  Running on: 'MS-7A37' with board 'B350M MORTAR (MS-7A37)'
0:103  0:000  === [ GetCPUProperties ] ==================================
0:103  0:000  CPU Vendor = 68747541 Model=800F11
0:103  0:000   The CPU supported SSE4.1
0:103  0:000  	Looking to disable C1E if is already enabled by the BIOS:
0:103  0:000  BrandString = AMD Ryzen 7 1800X Eight-Core Processor
0:103  0:000  CurrentSpeed: 3600
0:103  0:000  maxratio 72
0:103  0:000  cpudid_zen 8
0:103  0:000  FSBFrequency = 50 MHz, DMI FSBFrequency = 100 MHz, Corrected FSBFrequency = 100 MHz
0:103  0:000  MaxDiv/MinDiv: 36.0/22
0:103  0:000  Turbo: 0/0/0/0
0:103  0:000  Features: 0x178BFBFF
0:103  0:000  Threads: 16
0:103  0:000  Cores: 8
0:103  0:000  FSB: 100 MHz
0:103  0:000  CPU: 3600 MHz
0:103  0:000  TSC: 3600 MHz
0:103  0:000  PIS: 100 MHz
0:103  0:000  ExternalClock: 25 MHz
0:103  0:000  === [ GetDevices ] ========================================
0:103  0:000  PCI (00|00:00.00) : 1022 1450 class=060000
0:103  0:000  PCI (00|00:01.00) : 1022 1452 class=060000
0:103  0:000  PCI (00|00:01.03) : 1022 1453 class=060400
0:103  0:000  PCI (00|03:00.00) : 1022 43BB class=0C0330
0:103  0:000  PCI (00|03:00.01) : 1022 43B7 class=010601
0:103  0:000  PCI (00|03:00.02) : 1022 43B2 class=060400
0:103  0:000  PCI (00|04:00.00) : 1022 43B4 class=060400
0:103  0:000  PCI (00|04:01.00) : 1022 43B4 class=060400
0:103  0:000  PCI (00|1E:00.00) : 10EC 8168 class=020000
0:103  0:000   - LAN: 0 Vendor=Realtek
0:103  0:000  PCI (00|04:04.00) : 1022 43B4 class=060400
0:103  0:000  PCI (00|1F:00.00) : 1B73 1100 class=0C0330
0:103  0:000  PCI (00|00:02.00) : 1022 1452 class=060000
0:103  0:000  PCI (00|00:03.00) : 1022 1452 class=060000
0:103  0:000  PCI (00|00:03.01) : 1022 1453 class=060400
0:103  0:000  PCI (00|20:00.00) : 10DE 1187 class=030000
0:103  0:000   - GFX: Model=MSI GeForce GTX 760 family E4 (Nvidia)
0:103  0:000  PCI (00|20:00.01) : 10DE 0E0A class=040300
0:103  0:000   - HDMI Audio:
0:103  0:000  PCI (00|00:04.00) : 1022 1452 class=060000
0:103  0:000  PCI (00|00:07.00) : 1022 1452 class=060000
0:103  0:000  PCI (00|00:07.01) : 1022 1454 class=060400
0:103  0:000  PCI (00|21:00.00) : 1022 145A class=130000
0:103  0:000  PCI (00|21:00.02) : 1022 1456 class=108000
0:103  0:000  PCI (00|21:00.03) : 1022 145C class=0C0330
0:103  0:000  PCI (00|00:08.00) : 1022 1452 class=060000
0:103  0:000  PCI (00|00:08.01) : 1022 1454 class=060400
0:103  0:000  PCI (00|22:00.00) : 1022 1455 class=130000
0:103  0:000  PCI (00|22:00.02) : 1022 7901 class=010601
0:104  0:000  PCI (00|22:00.03) : 1022 1457 class=040300
0:104  0:000  PCI (00|00:14.00) : 1022 790B class=0C0500
0:104  0:000  PCI (00|00:14.03) : 1022 790E class=060100
0:104  0:000  PCI (00|00:18.00) : 1022 1460 class=060000
0:104  0:000  PCI (00|00:18.01) : 1022 1461 class=060000
0:104  0:000  PCI (00|00:18.02) : 1022 1462 class=060000
0:104  0:000  PCI (00|00:18.03) : 1022 1463 class=060000
0:104  0:000  PCI (00|00:18.04) : 1022 1464 class=060000
0:104  0:000  PCI (00|00:18.05) : 1022 1465 class=060000
0:104  0:000  PCI (00|00:18.06) : 1022 1466 class=060000
0:104  0:000  PCI (00|00:18.07) : 1022 1467 class=060000
0:104  0:000  === [ GetDefaultSettings ] ================================
0:104  0:000  Clover load options size = 0 bytes
0:114  0:010  EFI\CLOVER\config.plist loaded: Success
0:114  0:000  === [ GetListOfThemes ] ===================================
0:116  0:001  - [00]: BGM
0:122  0:006  - [01]: embedded
0:128  0:005  - [01]: random
0:134  0:006  - [01]: Shield
0:142  0:007  === [ Found config plists ] ===============================
0:144  0:002  - config.plist
0:146  0:002  - config Kopie.plist
0:148  0:002  - config_pro61.plist
0:150  0:001  === [ GetEarlyUserSettings ] ==============================
0:150  0:000  timeout set to 3
0:150  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
0:150  0:000  KextsToPatch: 1 requested
0:150  0:000   - [00]: com.apple.driver.usb.AppleUSBXHCIPCI (change 15 port limit to 26 in XHCI kext (100-series)) :: MatchOS: 10.12.x :: BinPatch :: data len: 7
0:150  0:000  Default theme: Shield
0:150  0:000  === [ LoadDrivers ] =======================================
0:151  0:001  Loading AppleImageCodec-64.efi  status=Success
0:163  0:011  Loading AppleKeyAggregator-64.efi  status=Success
0:170  0:007  Loading AppleUITheme-64.efi  status=Success
0:179  0:008  Loading CsmVideoDxe-64.efi  status=Success
0:187  0:008   - driver needs connecting
0:187  0:000  Loading DataHubDxe-64.efi  status=Success
0:196  0:008  Loading EmuVariableUefi-64.efi  status=Success
0:203  0:007  EmuVariableUefi Initialize: VariableCommonInitialize = Success, orig services stored, install gEmuVariableControlProtocolGuid = Success
0:204  0:000  Loading Fat-64.efi  status=Success
0:211  0:007   - driver needs connecting
0:211  0:000  Loading FirmwareVolume-64.efi  status=Success
0:219  0:007  Loading FSInject-64.efi  status=Success
0:227  0:007  Loading OsxAptioFixDrv-64.efi  status=Success
0:234  0:007  Loading OsxFatBinaryDrv-64.efi  status=Success
0:242  0:008  Loading PartitionDxe-64.efi  status=Success
0:251  0:008   - driver needs connecting
0:251  0:000  Loading SMCHelper-64.efi  status=Success
0:259  0:007  Loading VBoxHfs-64.efi  status=Success
0:267  0:008   - driver needs connecting
0:268  0:001  4 drivers needs connecting ...
0:268  0:000  PlatformDriverOverrideProtocol->GetDriver overriden
0:268  0:000  Partition driver loaded:
0:268  0:000  Video driver loaded: disconnect Success
0:345  0:077  Searching for invalid DiskIo BY_DRIVER connects: not found, all ok
0:483  0:138  CsmVideoDriverBindingStart
0:483  0:000  mixed support=40010
0:483  0:000  Controller is [030000]
0:483  0:000  Check for VBE
0:587  0:103   found Detail Timing 2560x1440
0:587  0:000   found Detail Timing 2560x1440
0:604  0:017    0 640x480 attr=3BF - ok, edid+, 640x480, working, highest, pref=0
0:607  0:002    1 800x600 attr=3BF - ok, edid+, 800x600, working, highest, pref=1
0:610  0:002    2 1024x768 attr=3BF - ok, edid+, 1024x768, working, highest, pref=2
0:613  0:002    3 1280x1024 attr=3BF - ok, edid+, working, highest, pref=3
0:630  0:017    4 1600x1200 attr=3BF - ok, edid+, working, highest, pref=4
0:635  0:004    5 2560x1440 attr=3BF - ok, edid+, working, highest, pref=5
0:638  0:002    6 1280x800 attr=3BF - ok, edid-
0:638  0:000  CsmVideo: New mode: 5 2560x1440 - set
1:179  0:541   - SetMode pref 5 (5) = Success
1:179  0:000  CsmVideoCheckForVbe - Success
1:180  0:000  CsmVideoDriverBindingStart end Success
1:180  0:000  CsmVideo: New mode: 2 1024x768 - set
1:371  0:191  CsmVideo: New mode: 2 1024x768EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
1:718  0:346  === [ InitScreen ] ========================================
1:718  0:000  SetScreenResolution: 1920x1080 - not found!
1:718  0:000  Console modes reported: 4, available modes:
1:718  0:000   - [01]: 80x25
1:718  0:000   - [02]: 80x50
1:718  0:000   - [03]: 100x31
1:718  0:000   - [04]: 128x40 (current mode)
1:718  0:000  SetScreenResolution: 1024x768 - already set
1:718  0:000  reinit: self device path=PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FF3EF174-38AA-44B7-A131-898CFDE5166D,0x28,0x64000)
1:722  0:004  Using embedded font: Success
1:722  0:000  === [ GetMacAddress ] =====================================
1:722  0:000  MAC address of LAN #0= 4C:CC:6A:F9:80:C4:
1:722  0:000  === [ ScanSPD ] ===========================================
1:723  0:000  === [ GetAcpiTablesList ] =================================
1:723  0:000  Get Acpi Tables List from RSDT:
1:723  0:000   - [00]: FACP  A M I  len=132
1:723  0:000   - [01]: APIC  A M I  len=222
1:723  0:000   - [02]: FPDT  A M I  len=68
1:723  0:000   - [03]: FIDT  A M I len=156
1:723  0:000   - [04]: SSDT  AMD ALIB len=35916
1:723  0:000   - [05]: SSDT  AMD CPU len=8420
1:723  0:000   - [06]: CRAT  AMD CRAT len=3920
1:723  0:000   - [07]: CDIT  AMD CDIT len=41
1:723  0:000   - [08]: SSDT  AMD AOD len=6098
1:723  0:000   - [09]: MCFG  A M I len=60
1:723  0:000   - [10]: HPET  A M I len=56
1:723  0:000   - [11]: SSDT  FCHZP len=36
1:723  0:000   - [12]: UEFI   len=66
1:723  0:000   - [13]: IVRS  AMD IVRS len=48
1:723  0:000   - [14]: SSDT  AMD PT len=248
1:723  0:000   - [15]: SSDT  CPMCMN len=5732
1:723  0:000  Calibrated TSC Frequency = 3600565200 = 3600MHz
1:723  0:000  === [ GetUserSettings ] ===================================
1:723  0:000  USB FixOwnership: yes
1:723  0:000   - final DSDT Fix mask=00000000
1:723  0:000  PatchesDSDT: 5 requested
1:723  0:000   - [00]: (change XHC0 to XHC1) lenToFind: 4, lenToReplace: 4
1:723  0:000   - [01]: (PTXH to XHC1) lenToFind: 4, lenToReplace: 4
1:723  0:000   - [02]: (change _OSI to XOSI) lenToFind: 4, lenToReplace: 4
1:723  0:000    patch disabled at config
1:723  0:000   - [03]: (change XHCI to XHC) lenToFind: 4, lenToReplace: 4
1:723  0:000    patch disabled at config
1:723  0:000   - [04]: (change XHC1 to XHC) lenToFind: 4, lenToReplace: 4
1:723  0:000    patch disabled at config
1:723  0:000  ChassisType: 0x13
1:723  0:000  Converted CustomUUID 80F24F84-F3AB-4DC1-8949-223E4E951B48
1:730  0:006  === [ ScanVolumes ] =======================================
1:730  0:000  Found 4 volumes with blockIO
1:730  0:000  - [00]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)
1:730  0:000  - [01]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FF3EF174-38AA-44B7-A131-898CFDE5166D,0x28,0x64000)
1:731  0:000          Result of bootcode detection: bootable unknown (legacy)
1:737  0:006          This is SelfVolume !!
1:737  0:000  - [02]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,6EF18343-A588-4547-A9CF-4E680C6BCD76,0x64028,0xDDFAC40)
1:737  0:000  - [03]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(3,GPT,B0DB51FF-00D2-4D9B-BD56-2BDE08496D02,0xDE5EC68,0x135F20)
1:746  0:008  Loading nvram.plist from Vol 'EFI' - loaded, size=2462
1:752  0:005  === [ PutNvramPlistToRtVars ] =============================
1:752  0:000   Adding Key: EFILoginHiDPI: Size = 4, Data: 00 00 00 00
1:752  0:000   Skipping EmuVariableUefiPresent
1:752  0:000   Skipping OsxAptioFixDrv-RelocBase
1:752  0:000   Adding Key: SystemAudioVolume: Size = 1, Data: 30
1:752  0:000   Adding Key: SystemAudioVolumeDB: Size = 1, Data: F0
1:752  0:000   Adding Key: backlight-level: Size = 2, Data: FF FF
1:752  0:000   Adding Key: boot-gamma: Size = 170, Data: C3 15 00 00 82 23 00 00 05 E5 61 02 AA 00 00 00 00 00 00 00 0C 00 C0 00 F9 03 40 02 B5 08 41 07 16 14 43 0E 8C 20 C5 17 E1 2E 48 22 E4 3C CB 2E 0B 4C CF 3D C4 5C 53 4E DD 6D 1C 71 D7 8E 66 9A 65 B2 B2 C9 E9 D7 0C 00 C0 00 F9 03 40 02 B5 08 41 07 16 14 43 0E 8C 20 C5 17 E1 2E 48 22 E4 3C CB 2E 0B 4C CF 3D C4 5C 53 4E DD 6D 1C 71 D7 8E 66 9A 65 B2 B2 C9 E9 D7 0C 00 C0 00 F9 03 40 02 B5 08 41 07 16 14 43 0E 8C 20 C5 17 E1 2E 48 22 E4 3C CB 2E 0B 4C CF 3D C4 5C 53 4E DD 6D 1C 71 D7 8E 66 9A 65 B2 B2 C9 E9 D7
1:752  0:000   Adding Key: bootercfg: Size = 2, Data: 28 00
1:752  0:000   Adding Key: csr-active-config: Size = 4, Data: 67 00 00 00
1:752  0:000   Adding Key: fakesmc-key-#KEY-ui32: Size = 4, Data: 00 00 00 12
1:752  0:000   Adding Key: fakesmc-key-$Adr-ui32: Size = 4, Data: 00 00 03 00
1:752  0:000   Adding Key: fakesmc-key-$Num-ui8: Size = 1, Data: 01
1:752  0:000   Adding Key: fakesmc-key-BATP-flag: Size = 1, Data: 00
1:752  0:000   Adding Key: fakesmc-key-BBIN-ui8: Size = 1, Data: 01
1:752  0:000   Adding Key: fakesmc-key-BEMB-flag: Size = 1, Data: 00
1:752  0:000   Adding Key: fakesmc-key-BNum-ui8: Size = 1, Data: 00
1:752  0:000   Adding Key: fakesmc-key-EPCI-ui32: Size = 4, Data: 08 C0 F0 00
1:752  0:000   Adding Key: fakesmc-key-MSAc-ui16: Size = 2, Data: 00 00
1:752  0:000   Adding Key: fakesmc-key-MSFW-ui8: Size = 2, Data: 01 00
1:752  0:000   Adding Key: fakesmc-key-MSLD-ui8: Size = 1, Data: 00
1:752  0:000   Adding Key: fakesmc-key-MSPS-ui16: Size = 2, Data: 00 03
1:752  0:000   Adding Key: fakesmc-key-MSTc-ui8: Size = 1, Data: 00
1:752  0:000   Adding Key: fakesmc-key-MSWr-ui8: Size = 1, Data: 00
1:752  0:000   Adding Key: fakesmc-key-RBr -ch8*: Size = 8, Data: 6A 39 35 6A 39 35 61 00
1:752  0:000   Adding Key: fakesmc-key-REV -ch8*: Size = 6, Data: 02 33 0F 00 00 10
1:752  0:000   Adding Key: fakesmc-key-RMde-char: Size = 1, Data: 41
1:752  0:000   Adding Key: fakesmc-key-RPlt-ch8*: Size = 8, Data: 6A 39 35 00 00 00 00 00
1:752  0:000   Adding Key: flagstate: Size = 32, Data: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
1:752  0:000   Adding Key: fmm-computer-name: Size = 4, Data: 69 4D 61 63
1:752  0:000   Adding Key: nvda_drv: Size = 2, Data: 31 00
1:752  0:000   Adding Key: platform-uuid: Size = 16, Data: 0A C5 83 2E 08 C0 44 59 95 92 2F 2B B8 56 EF 72
1:752  0:000   Adding Key: prev-lang:kbd: Size = 4, Data: 65 6E 3A 30
1:752  0:000   Adding Key: security-mode: String: Size = 4, Val = 'none'
1:752  0:000   Adding Key: specialbootdevice: Size = 74, Data: 02 01 0C 00 D0 41 03 0A 00 00 00 00 01 01 06 00 00 17 03 12 0A 00 00 00 FF FF 00 00 04 01 2A 00 02 00 00 00 28 40 06 00 00 00 00 00 40 73 84 3B 00 00 00 00 C6 AC E6 D5 CC CD A4 49 AC 93 60 E1 F5 D6 60 36 02 02 7F FF 04 00
1:752  0:000  === [ InitTheme ] =========================================
1:758  0:006  Using theme 'Shield' (EFI\CLOVER\themes\Shield)
1:759  0:000  OS main and drive as badge
1:766  0:007  Loading font from ThemeDir: Success
1:766  0:000  Choosing theme Shield
1:766  0:000  after NVRAM boot-args=npci=0x3000 kext-dev-mode=1 ncl=262144
1:766  0:000  === [ Dump SMC keys from NVRAM ] ==========================
1:766  0:000  found AppleSMC protocol
1:767  0:000  === [ ScanLoader ] ========================================
1:767  0:000  - [01]: 'EFI'
1:884  0:117  - [02]: 'MacOS'
1:891  0:006          AddLoaderEntry for Volume Name=MacOS
1:898  0:007      Check if volume Is Hibernated:
1:898  0:000      Check sleep image 'by signature':
1:907  0:008      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
1:907  0:000      using default sleep image name = \private\var\vm\sleepimage
1:914  0:007      sleepimage not found -> Not Found
1:914  0:000      hibernated: no - sign
2:000  0:085  - [03]: 'Recovery HD'
2:001  0:001          AddLoaderEntry for Volume Name=Recovery HD
2:002  0:000      Check if volume Is Hibernated:
2:002  0:000      Check sleep image 'by signature':
2:002  0:000      using default sleep image name = \private\var\vm\sleepimage
2:002  0:000      sleepimage not found -> Not Found
2:002  0:000      hibernated: no - sign
2:007  0:005          AddLoaderEntry for Volume Name=Recovery HD
2:093  0:085  Scanning legacy ...
2:093  0:000  === [ AddCustomTool ] =====================================
2:099  0:006  found tool \EFI\CLOVER\tools\Shell64U.efi
2:099  0:000  Checking EFI partition Volume 1 for Clover
2:105  0:006   Found Clover
2:110  0:004  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
2:127  0:017  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
2:308  0:180  === [ GetEfiBootDeviceFromNvram ] =========================
2:308  0:000   - found entry 0. 'Boot macOS from MacOS', Volume 'MacOS', DevicePath 'PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,6EF18343-A588-4547-A9CF-4E680C6BCD76,0x64028,0xDDFAC40)\System\Library\CoreServices\boot.efii'
2:308  0:000  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
2:308  0:000  DefaultIndex=0 and MainMenu.EntryCount=9
2:839  0:530  GUI ready
3:939  1:099  Boot option Boot0000 not found
3:939  0:000  === [ StartLoader ] =======================================
3:939  0:000  Finally: ExternalClock=25MHz BusSpeed=100015kHz CPU=3601MHz PIS: hw.busfrequency=100000000Hz
3:939  0:000  Loading boot.efi  status=Success
4:024  0:085  GetOSVersion: 10.12.5 (16F73)
4:024  0:000  CSR_CFG: CSR_ALLOW_UNTRUSTED_KEXTS | CSR_ALLOW_UNRESTRICTED_FS | CSR_ALLOW_TASK_FOR_PID | CSR_ALLOW_UNRESTRICTED_DTRACE | CSR_ALLOW_UNRESTRICTED_NVRAM
4:024  0:000  Filtering KextPatches:
4:024  0:000   - [00]: com.apple.driver.usb.AppleUSBXHCIPCI (change 15 port limit to 26 in XHCI kext (100-series)) :: BinPatch :: [OS: 10.12.5 | MatchOS: 10.12.x | MatchBuild: All] ==> allowed
4:024  0:000  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
4:207  0:182  === [ PatchSmbios ] =======================================
4:207  0:000  insert table 9 for dev 0:0
4:207  0:000  insert table 9 for dev 0:1
4:207  0:000  insert table 9 for dev 0:0
4:207  0:000  Trusting SMBIOS...
4:207  0:000  Detected alternating SMBIOS channel banks
4:207  0:000  Channels: 2
4:207  0:000  Interleave: 0 2 1 3 4 6 5 7 8 10 9 11 12 14 13 15 16 18 17 19 20 22 21 23
4:207  0:000   partNum=Unknown
4:207  0:000  SMBIOS Type 17 Index = 0 => 0 0:
4:207  0:000  BANK 0 DIMM0 EMPTY
4:207  0:000   partNum=CMK16GX4M2B3200C16
4:207  0:000  SMBIOS Type 17 Index = 1 => 1 2:
4:207  0:000  BANK 1 DIMM0 3066MHz 8192MB
4:207  0:000   partNum=Unknown
4:207  0:000  SMBIOS Type 17 Index = 2 => 2 1:
4:207  0:000  BANK 0 DIMM1 EMPTY
4:207  0:000   partNum=CMK16GX4M2B3200C16
4:207  0:000  SMBIOS Type 17 Index = 3 => 3 3:
4:207  0:000  BANK 1 DIMM1 3066MHz 8192MB
4:207  0:000  mTotalSystemMemory = 16384
4:207  0:000  NumberOfMemoryDevices = 4
4:207  0:000  Type20[0]->End = 0xFFFFFF, Type17[3] = 0x4000
4:207  0:000  === [ PatchACPI ] =========================================
4:207  0:000  RSDT 0xDD347028
4:207  0:000  FADT from RSDT: 0xDD347148
4:207  0:000  XSDT 0xDD347090
4:207  0:000  FADT from XSDT: 0xDD34D0D8
4:207  0:000  Xsdt reallocation done
4:207  0:000  old FADT length=114
4:210  0:002  Apply DsdtFixMask=0x00000000
4:210  0:000     drop _DSM mask=0x0000
4:210  0:000  === [ FixBiosDsdt ] =======================================
4:210  0:000  USBADR[0] = 0x10003 and PCIe = 0x0
4:210  0:000  USBADR[1] = 0x10003 and PCIe = 0x2
4:210  0:000  VideoCard devID=0x118710DE
4:210  0:000  DisplayADR1[0] = 0x30001, DisplayADR2[0] = 0x0
4:210  0:000  USBADR[2] = 0x70001 and PCIe = 0x3
4:263  0:052  Patching DSDT:
4:263  0:000   - [change XHC0 to XHC1]: pattern 58484330, patched at: [ (2752) (1601) (1E3A) ]
4:263  0:000   - [PTXH to XHC1]: pattern 50545848, patched at: [ (1E5E) (1ECD) ]
4:263  0:000   - [change _OSI to XOSI]: disabled
4:263  0:000   - [change XHCI to XHC]: disabled
4:263  0:000   - [change XHC1 to XHC]: disabled
4:263  0:000  first CPU found at 3F67 offset 3F6B
4:263  0:000  score candidate at 3E5A
4:263  0:000  score inserted in acpi_cpu_score _PR_
4:263  0:000  Found ACPI CPU: P000 | P001 | P002 | P003 | P004 | P005 | P006 | P007 | P008 | P009 | P00A | P00B | P00C | P00D | P00E | P00F , within the score: _PR_
4:263  0:000  Found PCIROOTUID = 0
4:263  0:000  === [ ACPIDropTables ] ====================================
4:263  0:000  === [ PatchAllSSDT ] ======================================
4:263  0:000  Patch table: SSDT  AMD ALIB len=0x8C4C
4:263  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
4:263  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
4:263  0:000  2. [change _OSI to XOSI]: disabled
4:263  0:000  3. [change XHCI to XHC]: disabled
4:263  0:000  4. [change XHC1 to XHC]: disabled
4:263  0:000  Patch table: SSDT  AMD CPU len=0x20E4
4:263  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
4:263  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
4:263  0:000  2. [change _OSI to XOSI]: disabled
4:263  0:000  3. [change XHCI to XHC]: disabled
4:263  0:000  4. [change XHC1 to XHC]: disabled
4:263  0:000  Patch table: SSDT  AMD AOD len=0x17D2
4:263  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
4:263  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
4:263  0:000  2. [change _OSI to XOSI]: disabled
4:263  0:000  3. [change XHCI to XHC]: disabled
4:263  0:000  4. [change XHC1 to XHC]: disabled
4:263  0:000  Patch table: SSDT  FCHZP len=0x24
4:263  0:000  0. [change XHC0 to XHC1]: pattern 58484330, the patch is too large!
4:263  0:000  1. [PTXH to XHC1]: pattern 50545848, the patch is too large!
4:263  0:000  2. [change _OSI to XOSI]: disabled
4:263  0:000  3. [change XHCI to XHC]: disabled
4:263  0:000  4. [change XHC1 to XHC]: disabled
4:263  0:000  Patch table: SSDT  AMD PT len=0xF8
4:263  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
4:263  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
4:263  0:000  2. [change _OSI to XOSI]: disabled
4:263  0:000  3. [change XHCI to XHC]: disabled
4:263  0:000  4. [change XHC1 to XHC]: disabled
4:263  0:000  Patch table: SSDT  CPMCMN len=0x1664
4:263  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
4:263  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
4:264  0:000  2. [change _OSI to XOSI]: disabled
4:264  0:000  3. [change XHCI to XHC]: disabled
4:264  0:000  4. [change XHC1 to XHC]: disabled
4:264  0:000  Drop tables from Xsdt, SIGN=XXXX TableID= Length=0
4:264  0:000   Xsdt has tables count=16
4:264  0:000  CPUBase=0 and ApicCPUBase=1 ApicCPUNum=16
4:264  0:000  === [ RestSetup macOS ] ===================================
4:264  0:000  EdidDiscovered size=128
4:264  0:000  ------- EDID Table
4:264  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  15  C3
4:264  0:000  010  |  83  23  05  E5  61  02  14  17  01  03
4:264  0:000  020  |  80  3C  22  78  EA  27  95  A9  54  4F
4:264  0:000  030  |  9E  26  0A  50  54  A1  08  00  D1  00
4:264  0:000  040  |  D1  C0  A9  40  81  80  81  40  81  C0
4:264  0:000  050  |  01  01  01  01  56  5E  00  A0  A0  A0
4:264  0:000  060  |  29  50  30  20  35  00  55  50  21  00
4:264  0:000  070  |  00  1A  21  39  00  00  A3  A0  1C  50
4:264  0:000  080  |  78  08  35  10  55  50  21  00  00  1C
4:264  0:000  090  |  00  00  00  FD  00  3B  3D  1F  59  19
4:264  0:000  100  |  00  0A  20  20  20  20  20  20  00  00
4:264  0:000  110  |  00  FC  00  45  56  32  37  33  36  57
4:264  0:000  120  |  0A  20  20  20  20  20  00  FB
4:264  0:000  mem_detected 1605220958208Mb
4:264  0:000  read_nVidia_ROM
4:264  0:000  Using PRAMIN fixups
4:468  0:203  PROM
4:747  0:279  ERROR: Unable to locate nVidia Video BIOS
4:747  0:000   there are no ROM loaded and no VBIOS read from hardware
4:747  0:000  nVidia MSI GeForce GTX 760  -1096810496MB NVE4 [10DE:1187] :: PciRoot(0x0)\Pci(0x3,0x1)\Pci(0x0,0x0) => device #1
4:747  0:000  Nvidia: VideoPorts: undefined, default to: 2
4:747  0:000  default NVCAP: 04000000-00000300-0C000000-00000007-00000000
4:747  0:000   RCBA disabled; cannot use it
4:747  0:000  stringlength = 3270
4:748  0:000  CurrentMode: Width=1024 Height=768
4:748  0:000  Beginning FSInjection
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: DAF31798
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: DAF31798
4:753  0:005  Use origin smbios table type 1 guid.
4:756  0:003  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\Other
4:757  0:001    Extra kext: EFI\CLOVER\kexts\Other\FakeSMC.kext
4:769  0:012    Extra kext: EFI\CLOVER\kexts\Other\RealtekRTL8111.kext
4:783  0:013    Extra kext: EFI\CLOVER\kexts\Other\patched_10.12_AppleRTC.kext
4:794  0:011    Extra kext: EFI\CLOVER\kexts\Other\System.kext
4:802  0:007    Extra kext: EFI\CLOVER\kexts\Other\VoodooHDA.kext
4:817  0:015  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.12
4:820  0:003  Custom boot is disabled

Audio seems to be OK (VoodooHDA)

Link to comment
Share on other sites
gills83
gills83
Posted
Posted

:)



Hello all,

To finish with this story of "busratio=xx", force to note that the parameters Clover are not able to fix correctly the core AMD CPU, this flag reserved to chameleon even under Clover has an influence.
It mainly fixes the audio and certainly other bus, I no longer have audio stall with this flag.

So Slice has twisted and Bronya reason for this flag even under clover :)

I no longer have an audio stall with "busratio=35" which corresponds to the speed of the CPU (35x100)

The Clover CPUFrequency flag in Mhz has no influence and only a cosmetic value that does not influence the kernel.



cdt.


:)



I would also like to know if OpenGL graphics performance are worse on Sierra?
I noticed a noticeable decline in performance, is it due to Sierra or the core?
The owners of Intel CPU have noticed this drop or it is simply due to the system AMD or kernel?

From Mavericks to El Capitan for an HD 7950, OpenGL cinebench ranges from 85 to 90 fps depending on the speed of the CPU, for Sierra, the HD 7950 captures at 75 fps regardless of CPU speed.



I made this video capture Sreen Flow reduced but still at 60 fps, it is a 4k video 60 fps originally captured in 2 k with Sreen Flow 6, it is a good exercise to check the health of Your system is correct but there are a few lags, lags that I do not have with Mavericks doing the same exercise.



thanks



this vidéo:



https://www.partage-fichiers.com/upload/d4mtc7eu

Link to comment
Share on other sites
Sherlocks
Sherlocks
Posted
Posted

Clover log seems good step. But

I think if you have audio issue, try use busfrequency 100,000 khz in config.plist. maybe tsc calibration makes problem on rygen.



Similiar caae that intel skylake pentium,

If i use tsc calibration, audio is disappear with distorted sound after some seconds. So i have to use 100,000khz to avoid audio issue



Sorry my english





나의 LG-F800S 의 Tapatalk에서 보냄

Link to comment
Share on other sites
Bronya
Bronya
Posted
Posted



The new kernel dated on 2017-07-01 worked perfectly with EFI_4114 at 10.9.5.

Only it seemed not fully compatible with VoodooHDA.kext which resulted in interrupted sound output if booted by Clover.

No such a bug if booted by Bronya's 2667 boot file.



Hi !

Problem sound with new kernel 10.9.5 from Clover ?

Problem sound if use other my Clover , example ver 4101 ?

  • Like 1
Link to comment
Share on other sites
jsl
jsl
Posted
Posted

Hi !

Problem sound with new kernel 10.9.5 from Clover ?

Problem sound if use other my Clover , example ver 4101 ?

Clover_4114 can boot 10.10.5 to desktop, but too fast timer and very poor performance & sound output were found.

No such a bug for 10.9.5 with newest kernel dated on 2017-07-01.

Clover_4101 can not boot 10.10.5 to desktop, but it worked at 10.9.5 with good sound output in my Ryzen 1700X hackintosh after removal of one kext in /S/L/E.

Link to comment
Share on other sites
Bronya
Bronya
Posted
Posted

Hi !

Here 3 files !

Clover release 4101 , boot_chameleon, and kernel_maverick_10.9.5 !

Please try without flags "fsb=nn and busratio=nn" .

If no works , use flag for test .

And here results an pictures !

I will not make clover and kernel for new ver system , example 10.10.5 or 10.11 ... if you not will test  ...



boot_chameleon_ryzen_rc1.zip

efi_clover_4101_fix_rc7.zip

mach_kernel_10.9.5_21_July.zip

  • Like 2
Link to comment
Share on other sites
jsl
jsl
Posted
Posted

Hi !

Here 3 files !

Clover release 4101 , boot_chameleon, and kernel_maverick_10.9.5 !

Please try without flags "fsb=nn and busratio=nn" .

If no works , use flag for test .

And here results an pictures !

I will not make clover and kernel for new ver system , example 10.10.5 or 10.11 ... if you not will test  ...

Thanks for this new files.

Kernel_10.9.5 worked perfectly and no difference from previous kernel dated on 2017-07-01.

Boot_Chameleon_Ryzen_rc1 can detect correct CPU parameters & boot to desktop at 10.9.5, 10.10.5, and 10.11.5 with matched Ryzen kernels in my Phenom II x6 1405T hackintosh, but got black screen and reboot at 10.11.6 or 10.10.5 with flags (fsb=200 busratio=15) without matched Ryzen's kernels.

It also worked in Ryzen 1700X hackintosh at 10.9.5 to 10.12.6 without boot flags and its bug is unable to reboot which was fixed by previous Bronya 2892 version.

The disadvantage of Bronya 2892 version is boot flags (fsb=100 busratio) is essential and without these flags always got black screen then reboot.

Clover_4101_fix_rc7 can boot 10.9.5 & 10.12.6 correctly, but 10.10.5 still got too fast timer and very poor performance as previous version. Unable to boot 10.11.6 to desktop yet !

Hope these information may give you some good idea to fix these bug or disadvantage as soon as possible !



  • Like 2
Link to comment
Share on other sites
riden666
riden666
Posted
Posted

10.12.5

boot-args=npci=0x3000 kext-dev-mode=1 ncl=262144



Sound is OK.

hw.tbfrequency: 1000000000
hw.cpufrequency_max: 3601000000
hw.cpufrequency_min: 3601000000
hw.cpufrequency: 3601000000
hw.busfrequency_max: 400000000
hw.busfrequency_min: 400000000
hw.busfrequency: 400000000
machdep.tsc.frequency: 3600594361

0:100  0:100  MemLog inited, TSC freq: 3600594360
0:100  0:000  CPU was calibrated without ACPI PM Timer: Intel ICH device was not found., use RTC
0:100  0:000
0:100  0:000  Now is 21.7.2017,  13:30:39 (GMT)
0:100  0:000  Starting Clover revision: 4101 on American Megatrends EFI
0:100  0:000  Build with: [Args: -D USE_LOW_EBDA -a X64 -b RELEASE -t XCODE5 -n 3 | OS: 10.9.5 | XCODE: 5.1.1]
0:100  0:000  SelfDevicePath=PciRoot(0x0)\Pci(0x7,0x1)\Pci(0x0,0x3)\USB(0x4,0x0)\HD(1,GPT,6139E608-49A3-4CC6-9686-7521EA53E3DD,0x28,0x64000) @DAF59618
0:100  0:000  SelfDirPath = \EFI\BOOT
0:100  0:000  === [ Get Smbios ] ========================================
0:100  0:000  Type 16 Index = 0
0:100  0:000  Total Memory Slots Count = 4
0:100  0:000  Type 17 Index = 0
0:100  0:000  Table has error information, checking
0:100  0:000  Found memory information in table 18/1, type=0x3, operation=0x2 syndrome=0x0
0:100  0:000  ...memory OK
0:100  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:100  0:000  SmbiosTable.Type17->Size = 0MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL A DIMM 0
0:100  0:000  SmbiosTable.Type17->Vendor = Unknown
0:100  0:000  SmbiosTable.Type17->SerialNumber = Unknown
0:100  0:000  SmbiosTable.Type17->PartNumber = Unknown
0:100  0:000  Type 17 Index = 1
0:100  0:000  Table has error information, checking
0:100  0:000  Found memory information in table 18/2, type=0x3, operation=0x2 syndrome=0x0
0:100  0:000  ...memory OK
0:100  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:100  0:000  SmbiosTable.Type17->Size = 8192MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL A DIMM 1
0:100  0:000  SmbiosTable.Type17->Vendor = Unknown
0:100  0:000  SmbiosTable.Type17->SerialNumber = 00000000
0:100  0:000  SmbiosTable.Type17->PartNumber = CMK16GX4M2B3200C16
0:100  0:000  Type 17 Index = 2
0:100  0:000  Table has error information, checking
0:100  0:000  Found memory information in table 18/3, type=0x3, operation=0x2 syndrome=0x0
0:100  0:000  ...memory OK
0:100  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:100  0:000  SmbiosTable.Type17->Size = 0MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL B DIMM 0
0:100  0:000  SmbiosTable.Type17->Vendor = Unknown
0:100  0:000  SmbiosTable.Type17->SerialNumber = Unknown
0:100  0:000  SmbiosTable.Type17->PartNumber = Unknown
0:100  0:000  Type 17 Index = 3
0:100  0:000  Table has error information, checking
0:100  0:000  Found memory information in table 18/4, type=0x3, operation=0x2 syndrome=0x0
0:100  0:000  ...memory OK
0:100  0:000  SmbiosTable.Type17->Speed = 3066MHz
0:100  0:000  SmbiosTable.Type17->Size = 8192MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = CHANNEL B DIMM 1
0:100  0:000  SmbiosTable.Type17->Vendor = Unknown
0:100  0:000  SmbiosTable.Type17->SerialNumber = 00000000
0:100  0:000  SmbiosTable.Type17->PartNumber = CMK16GX4M2B3200C16
0:100  0:000  Boot status=0
0:100  0:000  Running on: 'MS-7A37' with board 'B350M MORTAR (MS-7A37)'
0:100  0:000  === [ GetCPUProperties ] ==================================
0:100  0:000  CPU Vendor = 68747541 Model=800F11
0:100  0:000   The CPU supported SSE4.1
0:100  0:000  	Looking to disable C1E if is already enabled by the BIOS:
0:100  0:000  BrandString = AMD Ryzen 7 1800X Eight-Core Processor
0:100  0:000  CurrentSpeed: 3600
0:100  0:000  FSBFrequency = 10 MHz, DMI FSBFrequency = 100 MHz, Corrected FSBFrequency = 100 MHz
0:100  0:000  MaxDiv/MinDiv: 36.0/22
0:100  0:000  Turbo: 0/0/0/0
0:100  0:000  Features: 0x178BFBFF
0:100  0:000  Threads: 16
0:100  0:000  Cores: 8
0:100  0:000  FSB: 25 MHz
0:100  0:000  CPU: 3600 MHz
0:100  0:000  TSC: 3600 MHz
0:100  0:000  PIS: 100 MHz
0:100  0:000  === [ GetDevices ] ========================================
0:100  0:000  PCI (00|00:00.00) : 1022 1450 class=060000
0:100  0:000  PCI (00|00:01.00) : 1022 1452 class=060000
0:100  0:000  PCI (00|00:01.03) : 1022 1453 class=060400
0:100  0:000  PCI (00|03:00.00) : 1022 43BB class=0C0330
0:100  0:000  PCI (00|03:00.01) : 1022 43B7 class=010601
0:100  0:000  PCI (00|03:00.02) : 1022 43B2 class=060400
0:100  0:000  PCI (00|04:00.00) : 1022 43B4 class=060400
0:100  0:000  PCI (00|04:01.00) : 1022 43B4 class=060400
0:100  0:000  PCI (00|1E:00.00) : 10EC 8168 class=020000
0:100  0:000   - LAN: 0 Vendor=Realtek
0:100  0:000  PCI (00|04:04.00) : 1022 43B4 class=060400
0:100  0:000  PCI (00|1F:00.00) : 1B73 1100 class=0C0330
0:100  0:000  PCI (00|00:02.00) : 1022 1452 class=060000
0:100  0:000  PCI (00|00:03.00) : 1022 1452 class=060000
0:100  0:000  PCI (00|00:03.01) : 1022 1453 class=060400
0:100  0:000  PCI (00|20:00.00) : 1002 68B8 class=030000
0:100  0:000   - GFX: Model=ATI Radeon HD 5770 Series (ATI/AMD)
0:100  0:000   - RADEON_BIOS_0_SCRATCH = 0x00000004
0:100  0:000  PCI (00|20:00.01) : 1002 AA58 class=040300
0:100  0:000   - HDMI Audio:
0:100  0:000  PCI (00|00:04.00) : 1022 1452 class=060000
0:100  0:000  PCI (00|00:07.00) : 1022 1452 class=060000
0:100  0:000  PCI (00|00:07.01) : 1022 1454 class=060400
0:100  0:000  PCI (00|21:00.00) : 1022 145A class=130000
0:100  0:000  PCI (00|21:00.02) : 1022 1456 class=108000
0:100  0:000  PCI (00|21:00.03) : 1022 145C class=0C0330
0:100  0:000  PCI (00|00:08.00) : 1022 1452 class=060000
0:100  0:000  PCI (00|00:08.01) : 1022 1454 class=060400
0:100  0:000  PCI (00|22:00.00) : 1022 1455 class=130000
0:100  0:000  PCI (00|22:00.02) : 1022 7901 class=010601
0:100  0:000  PCI (00|22:00.03) : 1022 1457 class=040300
0:100  0:000  PCI (00|00:14.00) : 1022 790B class=0C0500
0:100  0:000  PCI (00|00:14.03) : 1022 790E class=060100
0:100  0:000  PCI (00|00:18.00) : 1022 1460 class=060000
0:100  0:000  PCI (00|00:18.01) : 1022 1461 class=060000
0:100  0:000  PCI (00|00:18.02) : 1022 1462 class=060000
0:100  0:000  PCI (00|00:18.03) : 1022 1463 class=060000
0:100  0:000  PCI (00|00:18.04) : 1022 1464 class=060000
0:100  0:000  PCI (00|00:18.05) : 1022 1465 class=060000
0:100  0:000  PCI (00|00:18.06) : 1022 1466 class=060000
0:100  0:000  PCI (00|00:18.07) : 1022 1467 class=060000
0:100  0:000  === [ GetDefaultSettings ] ================================
0:100  0:000  Clover load options size = 0 bytes
0:106  0:006  EFI\CLOVER\config.plist loaded: Success
0:106  0:000  === [ GetListOfThemes ] ===================================
0:109  0:002  - [00]: BGM
0:113  0:004  - [01]: embedded
0:116  0:002  - [01]: random
0:120  0:004  - [01]: Shield
0:125  0:004  === [ Found config plists ] ===============================
0:125  0:000  - config.plist
0:125  0:000  - config Kopie.plist
0:125  0:000  - config_pro61.plist
0:126  0:000  === [ GetEarlyUserSettings ] ==============================
0:126  0:000  timeout set to 3
0:126  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
0:126  0:000  KextsToPatch: 1 requested
0:126  0:000   - [00]: com.apple.driver.usb.AppleUSBXHCIPCI (change 15 port limit to 26 in XHCI kext (100-series)) :: MatchOS: 10.12.x :: BinPatch :: data len: 7
0:126  0:000  Default theme: Shield
0:126  0:000  === [ LoadDrivers ] =======================================
0:128  0:002  Loading AppleImageCodec-64.efi  status=Success
0:131  0:003  Loading AppleKeyAggregator-64.efi  status=Success
0:133  0:001  Loading AppleUITheme-64.efi  status=Success
0:135  0:002  Loading CsmVideoDxe-64.efi  status=Success
0:138  0:003   - driver needs connecting
0:138  0:000  Loading DataHubDxe-64.efi  status=Success
0:141  0:002  Loading EmuVariableUefi-64.efi  status=Success
0:143  0:001  EmuVariableUefi Initialize: VariableCommonInitialize = Success, orig services stored, install gEmuVariableControlProtocolGuid = Success
0:143  0:000  Loading Fat-64.efi  status=Success
0:146  0:003   - driver needs connecting
0:146  0:000  Loading FirmwareVolume-64.efi  status=Success
0:147  0:001  Loading FSInject-64.efi  status=Success
0:149  0:001  Loading OsxAptioFixDrv-64.efi  status=Success
0:150  0:001  Loading OsxFatBinaryDrv-64.efi  status=Success
0:154  0:004  Loading PartitionDxe-64.efi  status=Success
0:157  0:002   - driver needs connecting
0:157  0:000  Loading SMCHelper-64.efi  status=Success
0:159  0:002  Loading VBoxHfs-64.efi  status=Success
0:161  0:002   - driver needs connecting
0:161  0:000  4 drivers needs connecting ...
0:161  0:000  PlatformDriverOverrideProtocol->GetDriver overriden
0:161  0:000  Partition driver loaded:
0:161  0:000  Video driver loaded: disconnect Success
0:255  0:094  Searching for invalid DiskIo BY_DRIVER connects: not found, all ok
0:396  0:140  CsmVideoDriverBindingStart
0:396  0:000  mixed support=40010
0:396  0:000  Controller is [030000]
0:396  0:000  Check for VBE
0:429  0:033   found Detail Timing 2560x1440
0:429  0:000   found Detail Timing 2560x1440
0:437  0:007    0 1152x864 attr=BB - ok, edid-
0:437  0:000    1 1280x960 attr=BB - ok, edid+, working, highest, pref=1
0:438  0:000    2 640x480 attr=BB - ok, edid+, 640x480, working
0:438  0:000    3 800x600 attr=BB - ok, edid+, 800x600, working
0:438  0:000    4 1024x768 attr=BB - ok, edid+, 1024x768, working
0:438  0:000    5 1280x1024 attr=BB - ok, edid+, working, highest, pref=5
0:440  0:001    6 1400x1050 attr=BB - ok, edid-
0:441  0:001    7 1600x1200 attr=BB - ok, edid+, working, highest, pref=7
0:442  0:001    8 1792x1344 attr=BB - ok, edid-
0:444  0:001    9 1856x1392 attr=BB - ok, edid-
0:445  0:001   10 1920x1440 attr=BB - ok, edid-
0:445  0:000  CsmVideo: New mode: 7 1600x1200 - set
0:591  0:146   - SetMode pref 7 (7) = Success
0:591  0:000  CsmVideoCheckForVbe - Success
0:592  0:000  CsmVideoDriverBindingStart end Success
0:592  0:000  CsmVideo: New mode: 4 1024x768 - set
0:787  0:195  CsmVideo: New mode: 6 1400x1050 - set
1:155  0:368  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
1:342  0:187  === [ InitScreen ] ========================================
1:342  0:000  SetScreenResolution: 1920x1080 - not found!
1:342  0:000  Console modes reported: 4, available modes:
1:342  0:000   - [01]: 80x25 (current mode)
1:342  0:000   - [02]: 80x50
1:342  0:000   - [03]: 100x31
1:342  0:000   - [04]: 128x40
1:342  0:000  SetScreenResolution: 1400x1050 - already set
1:342  0:000  reinit: self device path=PciRoot(0x0)\Pci(0x7,0x1)\Pci(0x0,0x3)\USB(0x4,0x0)\HD(1,GPT,6139E608-49A3-4CC6-9686-7521EA53E3DD,0x28,0x64000)
1:343  0:000  Using embedded font: Success
1:343  0:000  === [ GetMacAddress ] =====================================
1:343  0:000  MAC address of LAN #0= 4C:CC:6A:F9:80:C4:
1:343  0:000  === [ ScanSPD ] ===========================================
1:344  0:000  === [ GetAcpiTablesList ] =================================
1:344  0:000  Get Acpi Tables List from RSDT:
1:344  0:000   - [00]: FACP  A M I  len=132
1:344  0:000   - [01]: APIC  A M I  len=222
1:344  0:000   - [02]: FPDT  A M I  len=68
1:344  0:000   - [03]: FIDT  A M I len=156
1:344  0:000   - [04]: SSDT  AMD ALIB len=35916
1:344  0:000   - [05]: SSDT  AMD CPU len=8420
1:344  0:000   - [06]: CRAT  AMD CRAT len=3920
1:344  0:000   - [07]: CDIT  AMD CDIT len=41
1:344  0:000   - [08]: SSDT  AMD AOD len=6098
1:344  0:000   - [09]: MCFG  A M I len=60
1:344  0:000   - [10]: HPET  A M I len=56
1:344  0:000   - [11]: SSDT  FCHZP len=36
1:344  0:000   - [12]: UEFI   len=66
1:344  0:000   - [13]: IVRS  AMD IVRS len=48
1:344  0:000   - [14]: SSDT  AMD PT len=248
1:344  0:000   - [15]: SSDT  CPMCMN len=5732
1:344  0:000  Calibrated TSC frequency =3600594360 =3600MHz
1:344  0:000  === [ GetUserSettings ] ===================================
1:344  0:000  USB FixOwnership: yes
1:344  0:000   - final DSDT Fix mask=00000000
1:344  0:000  PatchesDSDT: 2 requested
1:344  0:000   - [00]: (change XHC0 to XHC1) lenToFind: 4, lenToReplace: 4
1:344  0:000   - [01]: (PTXH to XHC1) lenToFind: 4, lenToReplace: 4
1:344  0:000  EnableC7: yes
1:344  0:000  EnableC6: yes
1:344  0:000  EnableC4: yes
1:344  0:000  EnableC2: yes
1:344  0:000  ChassisType: 0x13
1:344  0:000  Converted CustomUUID 80F24F84-F3AB-4DC1-8949-223E4E951B48
1:350  0:005  === [ ScanVolumes ] =======================================
1:350  0:000  Found 7 volumes with blockIO
1:350  0:000  - [00]: Volume: PciRoot(0x0)\Pci(0x7,0x1)\Pci(0x0,0x3)\USB(0x4,0x0)
1:352  0:002          USB volume
1:352  0:000  - [01]: Volume: PciRoot(0x0)\Pci(0x7,0x1)\Pci(0x0,0x3)\USB(0x4,0x0)\HD(1,GPT,6139E608-49A3-4CC6-9686-7521EA53E3DD,0x28,0x64000)
1:353  0:001          Result of bootcode detection: bootable unknown (legacy)
1:353  0:000          USB volume
1:360  0:007          This is SelfVolume !!
1:360  0:000  - [02]: Volume: PciRoot(0x0)\Pci(0x7,0x1)\Pci(0x0,0x3)\USB(0x4,0x0)\HD(2,GPT,AB7241AE-7833-4D4C-8E9F-B3C8553A8D0B,0x64028,0x730BFB0)
1:362  0:001          USB volume
1:362  0:000  - [03]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)
1:364  0:001  - [04]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FF3EF174-38AA-44B7-A131-898CFDE5166D,0x28,0x64000)
1:364  0:000          Result of bootcode detection: bootable unknown (legacy)
1:370  0:005  - [05]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,6EF18343-A588-4547-A9CF-4E680C6BCD76,0x64028,0xDDFAC40)
1:371  0:000  - [06]: Volume: PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(3,GPT,B0DB51FF-00D2-4D9B-BD56-2BDE08496D02,0xDE5EC68,0x135F20)
1:385  0:014  Loading nvram.plist from Vol 'EFI' - loaded, size=2462
1:388  0:003  === [ PutNvramPlistToRtVars ] =============================
1:388  0:000   Adding Key: EFILoginHiDPI: Size = 4, Data: 00 00 00 00
1:388  0:000   Skipping EmuVariableUefiPresent
1:388  0:000   Skipping OsxAptioFixDrv-RelocBase
1:388  0:000   Adding Key: SystemAudioVolume: Size = 1, Data: 30
1:388  0:000   Adding Key: SystemAudioVolumeDB: Size = 1, Data: F0
1:388  0:000   Adding Key: backlight-level: Size = 2, Data: FF FF
1:388  0:000   Adding Key: boot-gamma: Size = 170, Data: C3 15 00 00 82 23 00 00 05 E5 61 02 AA 00 00 00 00 00 00 00 0C 00 C0 00 F9 03 40 02 B5 08 41 07 16 14 43 0E 8C 20 C5 17 E1 2E 48 22 E4 3C CB 2E 0B 4C CF 3D C4 5C 53 4E DD 6D 1C 71 D7 8E 66 9A 65 B2 B2 C9 E9 D7 0C 00 C0 00 F9 03 40 02 B5 08 41 07 16 14 43 0E 8C 20 C5 17 E1 2E 48 22 E4 3C CB 2E 0B 4C CF 3D C4 5C 53 4E DD 6D 1C 71 D7 8E 66 9A 65 B2 B2 C9 E9 D7 0C 00 C0 00 F9 03 40 02 B5 08 41 07 16 14 43 0E 8C 20 C5 17 E1 2E 48 22 E4 3C CB 2E 0B 4C CF 3D C4 5C 53 4E DD 6D 1C 71 D7 8E 66 9A 65 B2 B2 C9 E9 D7
1:388  0:000   Adding Key: bootercfg: Size = 2, Data: 28 00
1:388  0:000   Adding Key: csr-active-config: Size = 4, Data: 67 00 00 00
1:388  0:000   Adding Key: fakesmc-key-#KEY-ui32: Size = 4, Data: 00 00 00 12
1:388  0:000   Adding Key: fakesmc-key-$Adr-ui32: Size = 4, Data: 00 00 03 00
1:388  0:000   Adding Key: fakesmc-key-$Num-ui8: Size = 1, Data: 01
1:388  0:000   Adding Key: fakesmc-key-BATP-flag: Size = 1, Data: 00
1:388  0:000   Adding Key: fakesmc-key-BBIN-ui8: Size = 1, Data: 01
1:388  0:000   Adding Key: fakesmc-key-BEMB-flag: Size = 1, Data: 00
1:388  0:000   Adding Key: fakesmc-key-BNum-ui8: Size = 1, Data: 00
1:388  0:000   Adding Key: fakesmc-key-EPCI-ui32: Size = 4, Data: 08 C0 F0 00
1:388  0:000   Adding Key: fakesmc-key-MSAc-ui16: Size = 2, Data: 00 00
1:388  0:000   Adding Key: fakesmc-key-MSFW-ui8: Size = 2, Data: 01 00
1:388  0:000   Adding Key: fakesmc-key-MSLD-ui8: Size = 1, Data: 00
1:388  0:000   Adding Key: fakesmc-key-MSPS-ui16: Size = 2, Data: 00 03
1:388  0:000   Adding Key: fakesmc-key-MSTc-ui8: Size = 1, Data: 00
1:388  0:000   Adding Key: fakesmc-key-MSWr-ui8: Size = 1, Data: 00
1:388  0:000   Adding Key: fakesmc-key-RBr -ch8*: Size = 8, Data: 6A 39 35 6A 39 35 61 00
1:388  0:000   Adding Key: fakesmc-key-REV -ch8*: Size = 6, Data: 02 33 0F 00 00 10
1:388  0:000   Adding Key: fakesmc-key-RMde-char: Size = 1, Data: 41
1:388  0:000   Adding Key: fakesmc-key-RPlt-ch8*: Size = 8, Data: 6A 39 35 00 00 00 00 00
1:388  0:000   Adding Key: flagstate: Size = 32, Data: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
1:388  0:000   Adding Key: fmm-computer-name: Size = 4, Data: 69 4D 61 63
1:388  0:000   Adding Key: nvda_drv: Size = 2, Data: 31 00
1:388  0:000   Adding Key: platform-uuid: Size = 16, Data: 0A C5 83 2E 08 C0 44 59 95 92 2F 2B B8 56 EF 72
1:388  0:000   Adding Key: prev-lang:kbd: Size = 4, Data: 65 6E 3A 30
1:388  0:000   Adding Key: security-mode: String: Size = 4, Val = 'none'
1:388  0:000   Adding Key: specialbootdevice: Size = 74, Data: 02 01 0C 00 D0 41 03 0A 00 00 00 00 01 01 06 00 00 17 03 12 0A 00 00 00 FF FF 00 00 04 01 2A 00 02 00 00 00 28 40 06 00 00 00 00 00 40 73 84 3B 00 00 00 00 C6 AC E6 D5 CC CD A4 49 AC 93 60 E1 F5 D6 60 36 02 02 7F FF 04 00
1:388  0:000  === [ InitTheme ] =========================================
1:390  0:001  Using theme 'Shield' (EFI\CLOVER\themes\Shield)
1:390  0:000  OS main and drive as badge
1:396  0:006  Loading font from ThemeDir: Success
1:396  0:000  Choosing theme Shield
1:396  0:000  after NVRAM boot-args=npci=0x3000 kext-dev-mode=1 ncl=262144
1:396  0:000  === [ Dump SMC keys from NVRAM ] ==========================
1:396  0:000  found AppleSMC protocol
1:397  0:000  === [ ScanLoader ] ========================================
1:397  0:000  - [01]: 'EFI'
1:423  0:026  - [02]: 'OhneTitel'
1:428  0:004  - [04]: 'EFI'
1:473  0:044  - [05]: 'MacOS'
1:479  0:006          AddLoaderEntry for Volume Name=MacOS
1:487  0:007      Check if volume Is Hibernated:
1:487  0:000      Check sleep image 'by signature':
1:496  0:008      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
1:496  0:000      using default sleep image name = \private\var\vm\sleepimage
1:503  0:007      sleepimage not found -> Not Found
1:503  0:000      hibernated: no - sign
1:511  0:007  - [06]: 'Recovery HD'
1:513  0:001          AddLoaderEntry for Volume Name=Recovery HD
1:513  0:000      Check if volume Is Hibernated:
1:513  0:000      Check sleep image 'by signature':
1:513  0:000      using default sleep image name = \private\var\vm\sleepimage
1:513  0:000      sleepimage not found -> Not Found
1:513  0:000      hibernated: no - sign
1:515  0:001          AddLoaderEntry for Volume Name=Recovery HD
1:521  0:006  Scanning legacy ...
1:521  0:000  === [ AddCustomTool ] =====================================
1:521  0:000  found tool \EFI\CLOVER\tools\Shell64U.efi
1:521  0:000  Checking EFI partition Volume 1 for Clover
1:521  0:000   Found Clover
1:524  0:002  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
1:524  0:000  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
1:713  0:188  === [ GetEfiBootDeviceFromNvram ] =========================
1:713  0:000   - found entry 0. 'Boot macOS from MacOS', Volume 'MacOS', DevicePath 'PciRoot(0x0)\Pci(0x1,0x3)\Pci(0x0,0x1)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,6EF18343-A588-4547-A9CF-4E680C6BCD76,0x64028,0xDDFAC40)\System\Library\CoreServices\boot.efii'
1:713  0:000  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
1:713  0:000  DefaultIndex=0 and MainMenu.EntryCount=9
1:925  0:212  GUI ready
24:306  22:380  Boot option Boot0000 not found
24:306  0:000  === [ StartLoader ] =======================================
24:306  0:000  Finally: Bus=100016kHz CPU=3601MHz
24:306  0:000  Loading boot.efi  status=Success
24:397  0:091  GetOSVersion: 10.12.5 (16F73)
24:397  0:000  CSR_CFG: CSR_ALLOW_UNTRUSTED_KEXTS | CSR_ALLOW_UNRESTRICTED_FS | CSR_ALLOW_TASK_FOR_PID | CSR_ALLOW_UNRESTRICTED_DTRACE | CSR_ALLOW_UNRESTRICTED_NVRAM
24:397  0:000  Filtering KextPatches:
24:397  0:000   - [00]: com.apple.driver.usb.AppleUSBXHCIPCI (change 15 port limit to 26 in XHCI kext (100-series)) :: BinPatch :: [OS: 10.12.5 | MatchOS: 10.12.x | MatchBuild: All] ==> allowed
24:397  0:000  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
24:586  0:188  === [ PatchSmbios ] =======================================
24:586  0:000  insert table 9 for dev 0:0
24:586  0:000  insert table 9 for dev 0:1
24:586  0:000  insert table 9 for dev 0:0
24:587  0:000  Trusting SMBIOS...
24:587  0:000  Detected alternating SMBIOS channel banks
24:587  0:000  Channels: 2
24:587  0:000  Interleave: 0 2 1 3 4 6 5 7 8 10 9 11 12 14 13 15 16 18 17 19 20 22 21 23
24:587  0:000   partNum=Unknown
24:587  0:000  SMBIOS Type 17 Index = 0 => 0 0:
24:587  0:000  BANK 0 DIMM0 EMPTY
24:587  0:000   partNum=CMK16GX4M2B3200C16
24:587  0:000  SMBIOS Type 17 Index = 1 => 1 2:
24:587  0:000  BANK 1 DIMM0 3066MHz 8192MB
24:587  0:000   partNum=Unknown
24:587  0:000  SMBIOS Type 17 Index = 2 => 2 1:
24:587  0:000  BANK 0 DIMM1 EMPTY
24:587  0:000   partNum=CMK16GX4M2B3200C16
24:587  0:000  SMBIOS Type 17 Index = 3 => 3 3:
24:587  0:000  BANK 1 DIMM1 3066MHz 8192MB
24:587  0:000  mTotalSystemMemory = 16384
24:587  0:000  NumberOfMemoryDevices = 4
24:587  0:000  Type20[0]->End = 0xFFFFFF, Type17[3] = 0x4000
24:587  0:000  === [ PatchACPI ] =========================================
24:587  0:000  RSDT 0xDD347028
24:587  0:000  FADT from RSDT: 0xDD347148
24:587  0:000  XSDT 0xDD347090
24:587  0:000  FADT from XSDT: 0xDD34D0D8
24:587  0:000  Xsdt reallocation done
24:587  0:000  old FADT length=114
24:587  0:000  Apply DsdtFixMask=0x00000000
24:587  0:000     drop _DSM mask=0x0000
24:587  0:000  === [ FixBiosDsdt ] =======================================
24:587  0:000  USBADR[0] = 0x10003 and PCIe = 0x0
24:587  0:000  USBADR[1] = 0x10003 and PCIe = 0x2
24:587  0:000  VideoCard devID=0x68B81002
24:587  0:000  DisplayADR1[0] = 0x30001, DisplayADR2[0] = 0x0
24:588  0:000  USBADR[2] = 0x70001 and PCIe = 0x3
24:634  0:046  Patching DSDT:
24:634  0:000   - [change XHC0 to XHC1]: pattern 58484330, patched at: [ (2752) (1601) (1E3A) ]
24:634  0:000   - [PTXH to XHC1]: pattern 50545848, patched at: [ (1E5E) (1ECD) ]
24:634  0:000  first CPU found at 3F67 offset 3F6B
24:634  0:000  score candidate at 3E5A
24:634  0:000  score inserted in acpi_cpu_score _PR_
24:634  0:000  Found ACPI CPU: P000 | P001 | P002 | P003 | P004 | P005 | P006 | P007 | P008 | P009 | P00A | P00B | P00C | P00D | P00E | P00F , within the score: _PR_
24:634  0:000  Found PCIROOTUID = 0
24:634  0:000  === [ ACPIDropTables ] ====================================
24:634  0:000  === [ PatchAllSSDT ] ======================================
24:634  0:000  Patch table: SSDT  AMD ALIB len=0x8C4C
24:634  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
24:634  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
24:634  0:000  Patch table: SSDT  AMD CPU len=0x20E4
24:634  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
24:634  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
24:634  0:000  Patch table: SSDT  AMD AOD len=0x17D2
24:634  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
24:635  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
24:635  0:000  Patch table: SSDT  FCHZP len=0x24
24:635  0:000  0. [change XHC0 to XHC1]: pattern 58484330, the patch is too large!
24:635  0:000  1. [PTXH to XHC1]: pattern 50545848, the patch is too large!
24:635  0:000  Patch table: SSDT  AMD PT len=0xF8
24:635  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
24:635  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
24:635  0:000  Patch table: SSDT  CPMCMN len=0x1664
24:635  0:000  0. [change XHC0 to XHC1]: pattern 58484330, bin not found / already patched!
24:635  0:000  1. [PTXH to XHC1]: pattern 50545848, bin not found / already patched!
24:635  0:000  Drop tables from Xsdt, SIGN=XXXX TableID= Length=0
24:635  0:000   Xsdt has tables count=16
24:635  0:000  CPUBase=0 and ApicCPUBase=1 ApicCPUNum=16
24:635  0:000  SSDT with CPU C-States generated successfully
24:635  0:000  === [ RestSetup macOS ] ===================================
24:635  0:000  EdidDiscovered size=128
24:635  0:000  ------- EDID Table
24:635  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  15  C3
24:635  0:000  010  |  83  23  05  E5  61  02  14  17  01  03
24:635  0:000  020  |  80  3C  22  78  EA  27  95  A9  54  4F
24:635  0:000  030  |  9E  26  0A  50  54  A1  08  00  D1  00
24:635  0:000  040  |  D1  C0  A9  40  81  80  81  40  81  C0
24:635  0:000  050  |  01  01  01  01  56  5E  00  A0  A0  A0
24:635  0:000  060  |  29  50  30  20  35  00  55  50  21  00
24:635  0:000  070  |  00  1A  21  39  00  00  A3  A0  1C  50
24:635  0:000  080  |  78  08  35  10  55  50  21  00  00  1C
24:635  0:000  090  |  00  00  00  FD  00  3B  3D  1F  59  19
24:635  0:000  100  |  00  0A  20  20  20  20  20  20  00  00
24:635  0:000  110  |  00  FC  00  45  56  32  37  33  36  57
24:635  0:000  120  |  0A  20  20  20  20  20  00  FB
24:635  0:000  ATI injection not set
24:635  0:000   RCBA disabled; cannot use it
24:635  0:000  stringlength = 1740
24:635  0:000  CurrentMode: Width=1400 Height=1050
24:635  0:000  Beginning FSInjection
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: D86D7018
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: D86D7018
24:638  0:003  Use origin smbios table type 1 guid.
24:640  0:001  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\Other
24:640  0:000    Extra kext: EFI\CLOVER\kexts\Other\FakeSMC.kext
24:647  0:007    Extra kext: EFI\CLOVER\kexts\Other\RealtekRTL8111.kext
24:664  0:017    Extra kext: EFI\CLOVER\kexts\Other\GenericUSBXHCI.kext
24:675  0:010    Extra kext: EFI\CLOVER\kexts\Other\patched_10.12_AppleRTC.kext
24:684  0:009    Extra kext: EFI\CLOVER\kexts\Other\System.kext
24:687  0:002    Extra kext: EFI\CLOVER\kexts\Other\VoodooHDA.kext
24:699  0:011  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.12
24:702  0:002  Custom boot is disabled


  • Like 1
Link to comment
Share on other sites
Gigamaxx
Gigamaxx
Posted
Posted

Hi !

Here 3 files !

Clover release 4101 , boot_chameleon, and kernel_maverick_10.9.5 !

Please try without flags "fsb=nn and busratio=nn" .

If no works , use flag for test .

And here results an pictures !

I will not make clover and kernel for new ver system , example 10.10.5 or 10.11 ... if you not will test  ...



Hi Bronya, this clover is for Sierra test too?     Or is it for Mavericks, Yosemite, El Cap test?

  • Like 1
Link to comment
Share on other sites
Nameless One
Nameless One
Posted
Posted

What flag are you referring to for testing when things don't work?

Currently when I use the above cloverx64.efi to boot 10.12.5 I need to use -v in order to reach the desktop, without it the system just hangs part way through. Also I need to include busratio=37 or else the clock and all animations run way too fast and also Sierra will not load the Nvidia drivers at all (I don't use nvda_drv=1 but my previous cloverx64.efi didn't need it). I have forgotten which kernel version I am using, it has been a few weeks since I got my system installed and working but rc4 sounds familliar, is there anything within the files installed with the kernel to indicate which version it is?

Link to comment
Share on other sites
jsl
jsl
Posted
Posted

Thanks for this new 10.10.5 kernel which works with normal timer & Cinebench R15 performance by Bronya 2892 boot or Bronya 4101 Clover EFI !

Comparison to 10.9.5 kernel in Ryzen 1700X hackintosh there is significant slower to shutdown at 10.10.5.

Not sure it's due to kernel or Mac OS X version.

Link to comment
Share on other sites
  • 3 weeks later...
victorqueiroz
victorqueiroz
Posted
Posted (edited)

Thanks for this new files.

Kernel_10.9.5 worked perfectly and no difference from previous kernel dated on 2017-07-01.

Boot_Chameleon_Ryzen_rc1 can detect correct CPU parameters & boot to desktop at 10.9.5, 10.10.5, and 10.11.5 with matched Ryzen kernels in my Phenom II x6 1405T hackintosh, but got black screen and reboot at 10.11.6 or 10.10.5 with flags (fsb=200 busratio=15) without matched Ryzen's kernels.

It also worked in Ryzen 1700X hackintosh at 10.9.5 to 10.12.6 without boot flags and its bug is unable to reboot which was fixed by previous Bronya 2892 version.

The disadvantage of Bronya 2892 version is boot flags (fsb=100 busratio) is essential and without these flags always got black screen then reboot.

Clover_4101_fix_rc7 can boot 10.9.5 & 10.12.6 correctly, but 10.10.5 still got too fast timer and very poor performance as previous version. Unable to boot 10.11.6 to desktop yet !

Hope these information may give you some good idea to fix these bug or disadvantage as soon as possible !



How is the compatibility of this kernel to 10.8.4? I have a Ryzen 7 1700 and a ASUS B350 Prime + GTX 1050 ti but when I try to load installer through patched Chameleon I get stucked at the "Still waiting for root device" already tried PCIRootUID=1 and 0, also my USB is connected to a 2.0 port, on my mother board settings I already updated to AHCI and I try to change USB ports, nothing works, I don't know what to do anymore. That error was trying to install 10.9.1 dmg.



EDIT: I was able to create a new USB now with createinstallmedia and Clover EFI + clover patches of 10.9.5 but when I try to boot with 'npci=0x2000 -v kernel=mach_kernel' it just reboot after "++++++++". I already tried with literally all the flags described here in this topic but nothing works. Can somebody help me? I can't run macOS on my PC? Help me, please.


Edited by victorqueiroz
Link to comment
Share on other sites
jsl
jsl
Posted
Posted

How is the compatibility of this kernel to 10.8.4? I have a Ryzen 7 1700 and a ASUS B350 Prime + GTX 1050 ti but when I try to load installer through patched Chameleon I get stucked at the "Still waiting for root device" already tried PCIRootUID=1 and 0, also my USB is connected to a 2.0 port, on my mother board settings I already updated to AHCI and I try to change USB ports, nothing works, I don't know what to do anymore. That error was trying to install 10.9.1 dmg.



EDIT: I was able to create a new USB now with createinstallmedia and Clover EFI + clover patches of 10.9.5 but when I try to boot with 'npci=0x2000 -v kernel=mach_kernel' it just reboot after "++++++++". I already tried with literally all the flags described here in this topic but nothing works. Can somebody help me? I can't run macOS on my PC? Help me, please.

Post#125

http://www.insanelym...t-thread/page-7

Only 10.9.5 to 10.12.x were compatible with Bronya's kernels for each different versions.

Link to comment
Share on other sites
 Share
Go to topic listing
×
×
  • Create New...
