vit9696 Posted June 15, 2016 Author Share Posted June 15, 2016 Added a dirty 10.12 hack to trunk, no desire to look for a proper solution at the moment. Worked for me in a vm, hopefully works on real hardware as well. Good luck & happy testing Also added denskop's patch. 4 Link to comment Share on other sites More sharing options...
insanelyDeepak Posted June 15, 2016 Share Posted June 15, 2016 Added a dirty 10.12 hack to trunk, no desire to look for a proper solution at the moment. Worked for me in a vm, hopefully works on real hardware as well. Good luck & happy testing Also added denskop's patch. unfortunately now at work , will surely test when at home , nice speed BTW Link to comment Share on other sites More sharing options...
justvisiting Posted June 15, 2016 Share Posted June 15, 2016 Hello, Being a noob to Apple Dev, I am making this guide. I had to stop because it is late. I will continue with your feedback. Thanks. ===== AppleALC: An open source kernel extension enabling native OS X HD audio for unsupported codecs without any filesystem modifications https://github.com/vit9696/AppleALC Assumption: - Working OSX Install, 10.8 - 10.11 - Audio chipset vendor and ID is known - Clover boot loader - no modding of /System/Library/Extensions/ audio kexts *** QUESTION: What other assumptions? Installing Binary 1) Browse to https://github.com/vit9696/AppleALC/releases 2) Download the version of your choice, preferably the latest release zip unless you are debugging . e.g Version 1.0.11 -> 1.0.11.RELEASE.zip The download links are below each versions release notes. Open the zip file to get AppleALC.kext 3) (Assuming Clover boot loader) mount your EFI boot partition: Terminal: - diskutil /dev/disk0 (internal, physical): #: TYPE NAME SIZE IDENTIFIER 0: GUID_partition_scheme *120.0 GB disk0 1: EFI EFI 209.7 MB disk0s1 2: Apple_HFS MacOS 119.2 GB disk0s2 3: Apple_Boot Recovery HD 650.0 MB disk0s3 - mkdir /Volumes/EFI && sudo mount_msdos /dev/disk0s1 /Volumes/EFI 4) in Finder, drag the AppleALC.kext into /Volumes/EFI/EFI/CLOVER/kexts/Other *** QUESTION: Do we need to enable a dev-mode or disable security? how? Do we need to do anything else to ‘activate AppleALC’? 5) Reboot your system and log in 6) Apple -> System Preferences -> Sound -> Input or Output tab ==> do you see your sound card? if yes, enjoy. if no. boo hoo. Compiling From Source A) Set Up Xcode 1) Register as a developer for free: developer.apple.com 2) Download and install Xcode: developer.apple.com/download 3) Install and start Xcode 4) Xcode -> Open Developer Tools -> More Developer Tools to open web browser window to Apple Dev site - Download “Hardware IO Tools” for Xcode - Open zip archive to get “Hardware IO Tools” folder - Applications -> Xcode (Show Package Contents) -> Contents -> Applications - drag contents of “Hardware IO Tools” folder into above Xcode Applications folder - This will let you run IORegistryExplorer from Xcode’s Open Developer Tools menu. You might need to restart Xcode. - Make alias of IORegisterExplorer by right click -> Make Alias & copy file to your local Applications directory for conveniently starting this utility without Xcode 5) Download latest release source code of AppleALC from https://github.com/vit9696/AppleALC/releases e.g. Version 1.0.11 -> 1.0.11.zip 6) open the zipped source code file to get AppleALC folder. e.g AppleALC-1.0.11 folder Link to comment Share on other sites More sharing options...
Riley Freeman Posted June 15, 2016 Share Posted June 15, 2016 Added a dirty 10.12 hack to trunk, no desire to look for a proper solution at the moment. Worked for me in a vm, hopefully works on real hardware as well. Good luck & happy testing Also added denskop's patch. Dirty hack works here! No more hang on the X79. No audio though. I couldn't find denskop's patch in the 898 plist so I added it manually, rebuilt the kext and got working audio. Guess you missed that one Link to comment Share on other sites More sharing options...
mendietinha Posted June 15, 2016 Share Posted June 15, 2016 Dirty hack works here! No more hang on the X79. No audio though. I couldn't find denskop's patch in the 898 plist so I added it manually, rebuilt the kext and got working audio. Guess you missed that one can you provide the kext with the dirty hack please? no xcode here. no space :/ Link to comment Share on other sites More sharing options...
Riley Freeman Posted June 15, 2016 Share Posted June 15, 2016 Here you go. Latest commit now seems to have all of the codecs updated for 10.12 now. Great work vit9696 Actually, I've just gotten Sierra installed on the laptop and the ALC269 there isn't working (it is in El Cap). So maybe we need another fix. Update: I've been getting some kernel panics referencing AppleALC when booting into Sierra on the X79 and laptop with this kext. Maybe the hack is a little dirty after all? AppleALC.kext.zip 3 Link to comment Share on other sites More sharing options...
vit9696 Posted June 15, 2016 Author Share Posted June 15, 2016 Here you go. Latest commit now seems to have all of the codecs updated for 10.12 now. Great work vit9696 Actually, I've just gotten Sierra installed on the laptop and the ALC269 there isn't working (it is in El Cap). So maybe we need another fix. Update: I've been getting some kernel panics referencing AppleALC when booting into Sierra on the X79 and laptop with this kext. Maybe the hack is a little dirty after all? We need panic logs with keepsyms=1 in boot-args and as much info as possible to prove your words and have data to work with. I can/will not do anything based on speculation Please understand that. 4 Link to comment Share on other sites More sharing options...
Riley Freeman Posted June 15, 2016 Share Posted June 15, 2016 We need panic logs with keepsyms=1 in boot-args and as much info as possible to prove your words and have data to work with. I can/will not do anything based on speculation Please understand that. No worries. Just need to know the right process. Hopefully this is what you need. Update: added one from the X79 as well. panic.zip x79panic.zip Link to comment Share on other sites More sharing options...
insanelyDeepak Posted June 15, 2016 Share Posted June 15, 2016 @vt9696 it's working without any hangs but for ALC887 its require to zeroing 8A19D411 (198b binpatch Codec only ) so i did source code missing it .. now Siri can take all my commands with all my Layouts ( Jokes apart ) Build Version Here AppleALC.kext.zip 3 Link to comment Share on other sites More sharing options...
MattsCreative Posted June 15, 2016 Share Posted June 15, 2016 it works so far without any kp thanks Link to comment Share on other sites More sharing options...
pico joe Posted June 15, 2016 Share Posted June 15, 2016 Great jobs @vit9696, insanelyDeepak & all of Dev ... 1 Link to comment Share on other sites More sharing options...
Kynyo Posted June 15, 2016 Share Posted June 15, 2016 Latest one working brilliant! Thank you to all developers! Link to comment Share on other sites More sharing options...
mendietinha Posted June 15, 2016 Share Posted June 15, 2016 amazing job, guys! all good in macOS Sierra! Link to comment Share on other sites More sharing options...
midi-sama Posted June 15, 2016 Share Posted June 15, 2016 on the original AppleALC, macOS booted up but no sound, now with the new build (from the last page) either i get a kp (on normal boot) or if it boots up, i get no sound at all (ALC275 Inject 3). someone to check if it's only me (someone with the same codec), please. thanks eitherway ill try to compile mine if I could dl the Xcode 8 Or nah! too big and not so much space :/ too bad Link to comment Share on other sites More sharing options...
insanelyDeepak Posted June 15, 2016 Share Posted June 15, 2016 on the original AppleALC, macOS booted up but no sound, now with the new build (from the last page) either i get a kp (on normal boot) or if it boots up, i get no sound at all (ALC275 Inject 3). someone to check if it's only me (someone with the same codec), please. thanks eitherway ill try to compile mine if I could dl the Xcode 8 Zeroing is missing for 275 ( i think) i just added it for alc887 not for other codec if you want i can do it?? Link to comment Share on other sites More sharing options...
midi-sama Posted June 15, 2016 Share Posted June 15, 2016 Zeroing is missing for 275 ( i think) i just added it for alc887 not for other codec if you want i can do it?? Yeah sure, but before doing that, shall I just test it by zeroing it from clover? if it works then it's good and I'll report back so that you add it too! Really appreciated! Thanks. 1 Link to comment Share on other sites More sharing options...
insanelyDeepak Posted June 15, 2016 Share Posted June 15, 2016 Yeah sure, but before doing that, shall I just test it by zeroing it from clover? if it works then it's good and I'll report back so that you add it too! Really appreciated! Thanks. Definitely, confim it so dev can update source 1 Link to comment Share on other sites More sharing options...
gengik84 Posted June 15, 2016 Share Posted June 15, 2016 Work in MasOS Sierra Thank you guys... Link to comment Share on other sites More sharing options...
midi-sama Posted June 15, 2016 Share Posted June 15, 2016 Definitely, confim it so dev can update source Weirdly I get the AppleHDA loaded, but no audio, I added 8A19D411 zeroing but nothing happened. Either way, if you make the kext with that patch lemme try it too! Thanks Link to comment Share on other sites More sharing options...
justvisiting Posted June 15, 2016 Share Posted June 15, 2016 I am looking for an explanation for the various audio layout-ids and platforms. I have not found an authoritative site or description. If you have any information, it would be greatly appreciated. Thanks. Link to comment Share on other sites More sharing options...
savvas Posted June 15, 2016 Share Posted June 15, 2016 Weirdly I get the AppleHDA loaded, but no audio, I added 8A19D411 zeroing but nothing happened. Either way, if you make the kext with that patch lemme try it too! Thanks You should DISABLE this patch, cause it seems that on 272 analogue situatian as on 282. SO disable this zeroing and try using this one. PS: stop , which codec you have? 272 or 275? AppleALC.kext.zip 2 Link to comment Share on other sites More sharing options...
midi-sama Posted June 15, 2016 Share Posted June 15, 2016 I am looking for an explanation for the various audio layout-ids and platforms. I have not found an authoritative site or description. If you have any information, it would be greatly appreciated. Thanks. I hope I understand what you want but here it is: To know what layout to use with a multilayout codec (like ALC269): Open the kext (Show Contents) > Contents > Plugins > Open PinConfigs.kext (Show Contents) > Contents > Info.plist You'll find there all supported Codecs and their layout IDs, and check the Name given, mostly it describes the patch used, like on ALC269 with many revisions, you'll see ALC269 VC v1 or VB v2 ... and so on, once you get the one that you use (*mostly* it should have the same name as the patch you used with Mirone or toleda or whatever you used) take note of the layout ID and use it in clover. If it works, it's good, if not try another You should DISABLE this patch, cause it seems that on 272 analogue situatian as on 282. SO disable this zeroing and try using this one. PS: stop , which codec you have? 272 or 275? ALC275, will try your patch now anyway and btw, all clover patches are disabled now Link to comment Share on other sites More sharing options...
Riley Freeman Posted June 15, 2016 Share Posted June 15, 2016 You should DISABLE this patch, cause it seems that on 272 analogue situatian as on 282. SO disable this zeroing and try using this one. PS: stop , which codec you have? 272 or 275? Disabling the 8A19D411 patch here has fixed ALC269 Link to comment Share on other sites More sharing options...
justvisiting Posted June 15, 2016 Share Posted June 15, 2016 I hope I understand what you want but here it is: To know what layout to use with a multilayout codec (like ALC269): Open the kext (Show Contents) > Contents > Plugins > Open PinConfigs.kext (Show Contents) > Contents > Info.plist You'll find there all supported Codecs and their layout IDs, and check the Name given, mostly it describes the patch used, like on ALC269 with many revisions, you'll see ALC269 VC v1 or VB v2 ... and so on, once you get the one that you use (*mostly* it should have the same name as the patch you used with Mirone or toleda or whatever you used) take note of the layout ID and use it in clover. If it works, it's good, if not try another For a new codec, how do you know it is multilayout? If I have a linux codec dump, what word/term tells the layout that codec uses? Where is the description for each layout? e.g. "layout-id is this and this" I already have "developer one says copy developer 2 and experiment" but I don't have, "This is what a layout-id is and here is how it works". if that makes sense. Thanks Link to comment Share on other sites More sharing options...
vandroiy2012 Posted June 15, 2016 Share Posted June 15, 2016 For a new codec, how do you know it is multilayout? If I have a linux codec dump, what word/term tells the layout that codec uses? Where is the description for each layout? e.g. "layout-id is this and this" I already have "developer one says copy developer 2 and experiment" but I don't have, "This is what a layout-id is and here is how it works". if that makes sense. Thanks https://github.com/vit9696/AppleALC/wiki/Adding-codec-support#rules-to-add-resources Link to comment Share on other sites More sharing options...
