vusun123 Posted June 9, 2015 Share Posted June 9, 2015 Apple changed alot of kext, and how they work, including USB kexts. That results in my MBP now can only use 1 USB 3.0, the other can't fired up. Link to comment Share on other sites More sharing options...
macq Posted June 9, 2015 Share Posted June 9, 2015 hi, i attempted installing from usb. made the usb install as follows; restored os install system, copied packages, copied basesystem.dmg, chunklist, and payloads,installed clover 3221, when i boot i get the lapic kernel panic, if i choose cpus=1 then hangs at fakesmckey loading.... booted with -x -v rootless=0 any hints ,suggestions. specs in sign.. yosemite boots fine 1 Link to comment Share on other sites More sharing options...
benmacfreak Posted June 9, 2015 Share Posted June 9, 2015 well i tried since 4am last night to get it to boot on my Dell Inspiron N5110 laptop and my tower PC..the laptop has intel 6 series chipset and it won't load. I used clover 3221 (special edition). it wont boot past FakeSMC loading..it halts i tried 2 config.plists..nothing works.. Link to comment Share on other sites More sharing options...
RTUYJRYFJ Posted June 9, 2015 Share Posted June 9, 2015 hi guys, El Captain installs just fine on the machine from my signature (just added new FakeSMC to Other folder and "rootless=0" bootflag to clover) El Captain installed just above Yosemite.HDMI audio works(280x) and other important things works. But here are some problems: 1. with Emu 0204 usb audio card ----- sound glitches and dissappearings, make this card unusable 2. Google Chrome Browser works very slow (Safari works normal) Link to comment Share on other sites More sharing options...
alfa147x Posted June 9, 2015 Share Posted June 9, 2015 GIGABYTE GA-Z77X-UP5 TH LGA 1155 Intel Z77 Thunderbolt Motherboard Intel Core i7-3770K Ivy Bridge 3.5GHz (3.9GHz Turbo) HD 4000 Graphics Asus GTX670 Top (GTX670-DC2T-2GD5) Almost have everything working. Wifi / BT and USB sound work out of the box. The only issue is with my GPU. I can only get it to boot with "nv_disable=1". I attempted to use the WebDriver-346.01.02f04.pkg drivers via Pacifist with no luck. 1 Link to comment Share on other sites More sharing options...
Sinclair70 Posted June 9, 2015 Share Posted June 9, 2015 Hi everyone, just installed El C with Clover Boot, USB, using DiskmakerX renaming the install to Yosemite, look good, Z77X-UD5H, GTX660, Network work, try FCPX, work nice. Don't forget to add a folder 10.11 in Clover/KEXT and put your Kext from Yosemite. BUT, WHERE are the F..k system folder now, and Extensions ? I want to patch AppleHDA for sound for ALC898, just CAN'T. (SORRY for my Stupid Question i forget RootLess, Solution Boot with rootless=0, Thank Netkas) Link to comment Share on other sites More sharing options...
alfa147x Posted June 9, 2015 Share Posted June 9, 2015 Hi everyone, just installed El C with Clover Boot, USB, using DiskmakerX renaming the install to Yosemite, look good, Z77X-UD5H, GTX660, Network work, try FCPX, work nice. Don't forget to add a folder 10.11 in Clover/KEXT and put your Kext from Yosemite. BUT, WHERE are the F..k system folder now, and Extensions ? I want to patch AppleHDA for sound for ALC898, just CAN'T. How were you able to get your GTX 660 working? Any tips? Link to comment Share on other sites More sharing options...
Sinclair70 Posted June 9, 2015 Share Posted June 9, 2015 hi alfa147x, i use clover 3215, and in bios disable video from mainboard, select only init PEG. In clover -> Un-select any injector Video, NO nvidia, NO AMD, NO Intel, don't forget adding in KEXT/10.11 Link to comment Share on other sites More sharing options...
alfa147x Posted June 9, 2015 Share Posted June 9, 2015 hi alfa147x, i use clover 3215, and in bios disable video from mainboard, select only init PEG. In clover -> Un-select any injector Video, NO nvidia, NO AMD, NO Intel, don't forget adding in KEXT/10.11 Thanks for the info. All of that looks like what I have. In kext/10.11 what file should I add. I have fakeSMC right now. Anything else? Link to comment Share on other sites More sharing options...
Korni22 Posted June 9, 2015 Share Posted June 9, 2015 Installed with no problems with ozmosis. Would you mind telling me how you built the USB drive? Cause I did the "old" method (restoring Base*.dmg, copying the packages over) and I get still waiting for root device Link to comment Share on other sites More sharing options...
alfa147x Posted June 9, 2015 Share Posted June 9, 2015 Would you mind telling me how you built the USB drive? Cause I did the "old" method (restoring Base*.dmg, copying the packages over) and I get still waiting for root device Have you tried the createinstallmedia method? Link to comment Share on other sites More sharing options...
Sinclair70 Posted June 9, 2015 Share Posted June 9, 2015 Ok, running running now at 100 %, how i fix my audio, connect my SSD with 10.11, to my second mac with Yosemite, open terminal, and show all file, (with default write method), i use MultiB 7.3, select my audio ALC 898, and check the EFI option, because i use Clover. Reconnect the SSD, Boot and Voila Audio is coming back. Ok let's Resume : 1- Make a USB Boot using DiskMakerX4b4 (Change the El Capitain Install with Yosemite Install) 2 - Install Clover on the USB (like the same method for Yosemite, just add 10.11 in Kext 3- Install El Capitain, Boot with -x 4 - Install Clover in UEFI 5 - Add 10.11 in Kext and place your Kext for your MB 6 - Fix Audio with booting from Yosemite, Run Multib 7.3 and install Kext for your audio 7 - Select in Clover configurator : NO Inject Nvidia if you have Nvidia GTX Work for me on two board, Z77X-UD5H, and Z87-HD3, Same Video card. (Nvidia GTX660) Don't forget, El Capitain is not far away from Yosemite, if you success with Yosemite, try just harder with El Capitain. Link to comment Share on other sites More sharing options...
Korni22 Posted June 9, 2015 Share Posted June 9, 2015 Have you tried the createinstallmedia method? Sadly, this did not help sudo ~/Downloads/Install\ OS\ X\ 10.11\ Developer\ Beta.app/Contents/Resources/createinstallmedia --volume /Volumes/OS\ X\ Base\ System --applicationpath ~/Downloads/Install\ OS\ X\ 10.11\ Developer\ Beta.app Link to comment Share on other sites More sharing options...
alfa147x Posted June 9, 2015 Share Posted June 9, 2015 Ok, running running now at 100 %, how i fix my audio, connect my SSD with 10.11, to my second mac with Yosemite, open terminal, and show all file, (with default write method), i use MultiB 7.3, select my audio ALC 898, and check the EFI option, because i use Clover. Reconnect the SSD, Boot and Voila Audio is coming back. Ok let's Resume : 1- Make a USB Boot using DiskMakerX4b4 (Change the El Capitain Install with Yosemite Install) 2 - Install Clover on the USB (like the same method for Yosemite, just add 10.11 in Kext 3- Install El Capitain, Boot with -x 4 - Install Clover in UEFI 5 - Add 10.11 in Kext and place your Kext for your MB 6 - Fix Audio with booting from Yosemite, Run Multib 7.3 and install Kext for your audio 7 - Select in Clover configurator : NO Inject Nvidia if you have Nvidia GTX Work for me on two board, Z77X-UD5H, and Z87-HD3, Same Video card. Don't forget, El Capitain is not far away from Yosemite, if you success with Yosemite, try just harder with El Capitain. What video card? Sadly, this did not help sudo ~/Downloads/Install\ OS\ X\ 10.11\ Developer\ Beta.app/Contents/Resources/createinstallmedia --volume /Volumes/OS\ X\ Base\ System --applicationpath ~/Downloads/Install\ OS\ X\ 10.11\ Developer\ Beta.app Can you post a screenshot of how it fails? I would try placing the installer in your Applications folder. This is what mine looked like: sudo /Applications/Install\ OS\ X\ 10.11\ Developer\ Beta.app/Contents/Resources/createinstallmedia --volume /Volumes/Untitled --applicationpath /Applications//Install\ OS\ X\ 10.11\ Developer\ Beta.app --nointeraction Link to comment Share on other sites More sharing options...
Riley Freeman Posted June 9, 2015 Share Posted June 9, 2015 USB-related KP on another machine now. What's the sha-1 of the InstallESD.dmg? I wonder if my copy is corrupt... Link to comment Share on other sites More sharing options...
jacoweb Posted June 9, 2015 Share Posted June 9, 2015 USB-related KP on another machine now. What's the sha-1 of the InstallESD.dmg? I wonder if my copy is corrupt... Same problem here, cant inject GenericUSBXHCI.kext. Panic.. Link to comment Share on other sites More sharing options...
crusher Posted June 9, 2015 Share Posted June 9, 2015 All works fine USB,Audio and all devices!!! But bad appearance Disk Utility... Link to comment Share on other sites More sharing options...
alfa147x Posted June 9, 2015 Share Posted June 9, 2015 USB-related KP on another machine now. What's the sha-1 of the InstallESD.dmg? I wonder if my copy is corrupt... MD5 (/Applications/Install OS X 10.11 Developer Beta.app/Contents/SharedSupport/InstallESD.dmg) = eb285ae2f647a873aa7c863099178052 1 Link to comment Share on other sites More sharing options...
chemary85 Posted June 9, 2015 Share Posted June 9, 2015 i3-530/MSI H55M-P32/GTX460/ALC888/RTL8111 and i3-380M/ASUS H55/AMD6370M/BCM4322/CX20585 succeeded. How do you did it in Asus¿? I have same AMD6370M and haven't graphics Enabler :/ Link to comment Share on other sites More sharing options...
PGHammer21B Posted June 10, 2015 Share Posted June 10, 2015 I used DiskMakerX (renamed app method from Yosemite days) followed by installing Clover SE latest version (from here) to both USB and HDD. Last remaining issue is graphics - nVidia GTX550Ti goes to sleep during boot; however, Visiontek AMD HD5450 iSilence does not. (Incidentally, both are supported out of the chute.) Hardware is unchanged from Yosemite (in fact, the two share a 500GB HDD in an even split. Clover confirms that El Cap does indeed use a rootless boot. (Via a message from the Darwin bootstrapped) Link to comment Share on other sites More sharing options...
crazybirdy Posted June 10, 2015 Share Posted June 10, 2015 hi, i attempted installing from usb. made the usb install as follows; restored os install system, copied packages, copied basesystem.dmg, chunklist, and payloads,installed clover 3221, when i boot i get the lapic kernel panic, if i choose cpus=1 then hangs at fakesmckey loading.... booted with -x -v rootless=0 any hints ,suggestions. specs in sign.. yosemite boots fine try hp kernel, don't need cpus=1. use fakesmc v6.14.1364 kernel(10.11.dp1.15A178w.HP_lapic_native).zip FakeSMC.v6.14.1364.zip [edit] create a folder... /System/Library/Kernels/ put it as /System/Library/Kernels/kernel Clover boot without cache. [edit] kernel used for Chameleon only if new one is ready, Clover not work now. 1 Link to comment Share on other sites More sharing options...
BNZfive Posted June 10, 2015 Share Posted June 10, 2015 Anyone with an idea on what would be causing a IOUSBHostFamily.kext kernel panic? Yes, I have searched the nets for this issue, there doesn't seem to be a consensus solve. Maybe there's something 10.11 specific. Using clover (Legacy) 3113 with fakesmc in "other" folder as there is no 10.11 folder for kexts. DSDT is in ACPI>Patched SSDT in in ACPI>Patched Config.plist attached config.plist.zip Link to comment Share on other sites More sharing options...
Pavo Posted June 10, 2015 Share Posted June 10, 2015 Anyone with an idea on what would be causing a IOUSBHostFamily.kext kernel panic? Yes, I have searched the nets for this issue, there doesn't seem to be a consensus solve. Maybe there's something 10.11 specific. Using clover (Legacy) 3113 with fakesmc in "other" folder as there is no 10.11 folder for kexts. DSDT is in ACPI>Patched SSDT in in ACPI>Patched Config.plist attached ALL USB devices are having issues with 10.11, they made alot of changes with all the USB kext Link to comment Share on other sites More sharing options...
BNZfive Posted June 10, 2015 Share Posted June 10, 2015 anyone tried a 10.10.3 USB rollback I'll give it a go EDIT: I replaced the 4 IOUSB kexts in EC with the 2 in YOS with a slimmer than slim chance of working it........... failed with exactly the same Kernel Panic Link to comment Share on other sites More sharing options...
enrobriaffej Posted June 10, 2015 Share Posted June 10, 2015 Got it running with surprisingly little work. Thank you to everyone in the community!Clover v3215 with CSM disabledDriver64UEFI:emuvariableuefi-64, hfsplus, osxaptiofixdrv-64 and partitiondxe-64Kexts:fakesmc (6.14.1364) and appleintele1000eBootflag:rootless=0 For the public beta i had to select 'inject nvidia' in the clover option menu before booting to the installer. Link to comment Share on other sites More sharing options...
