chris1111 Posted April 7, 2015 Author Share Posted April 7, 2015 incredible! bit complicated but good! thx Chris! Thats Hackintosh DELL Precision 690 Yosemite For now! 1 Link to comment Share on other sites More sharing options...
mymac999 Posted April 11, 2015 Share Posted April 11, 2015 Hi, I tried the USB installer on my Dell Insoiron 1720 (T7250, nvidia 8600m gt, alps touchpad) both with and without a dsdt in the extras folder. There seem to be some issues with my alps touchpad - the ApplePS2Controller times out, then voodoops2mouse is loaded, then Darwin SYstem Bootstrapper is loaded and a panic type 14=page fault is displayed. Is the installer in this thread suitable for a notebook installation or for desktop only? I used it with the Install Yosemite 10.10.20 app. There's a different thread here for the dell Inspiron but I can't find the USB installer app used there (2570 v7) - it's on maintenance. Thanks for any help! Link to comment Share on other sites More sharing options...
chris1111 Posted April 11, 2015 Author Share Posted April 11, 2015 Hi, I tried the USB installer on my Dell Insoiron 1720 (T7250, nvidia 8600m gt, alps touchpad) both with and without a dsdt in the extras folder. There seem to be some issues with my alps touchpad - the ApplePS2Controller times out, then voodoops2mouse is loaded, then Darwin SYstem Bootstrapper is loaded and a panic type 14=page fault is displayed. Is the installer in this thread suitable for a notebook installation or for desktop only? I used it with the Install Yosemite 10.10.20 app. There's a different thread here for the dell Inspiron but I can't find the USB installer app used there (2570 v7) - it's on maintenance. Thanks for any help! This installer works with Installer OS Yosemite.app 10.10.2 YES! Your could Play with the Extra Folder Link to comment Share on other sites More sharing options...
mjames21 Posted June 2, 2015 Share Posted June 2, 2015 Awesome, thank you for the guide, works great!! Precision 690 w/2 3ghz dual core Xeon, 16GB RAM. I have to use PCIRootUID=4 boot option in order for the graphics card to work... So if I change the PCI Root UID in the DSDT to Zero, this should fix the problem of having to use the boot option above? Thanks again! 1 Link to comment Share on other sites More sharing options...
chris1111 Posted June 3, 2015 Author Share Posted June 3, 2015 Awesome, thank you for the guide, works great!! Precision 690 w/2 3ghz dual core Xeon, 16GB RAM. I have to use PCIRootUID=4 boot option in order for the graphics card to work... So if I change the PCI Root UID in the DSDT to Zero, this should fix the problem of having to use the boot option above? Thanks again! Great ! Really happy for you 1 Link to comment Share on other sites More sharing options...
Rocky12 Posted July 1, 2015 Share Posted July 1, 2015 Hi Chris! did u try El Capitan on dell 690 Link to comment Share on other sites More sharing options...
chris1111 Posted July 1, 2015 Author Share Posted July 1, 2015 Hi Chris! did u try El Capitan on dell 690 No! not for now Link to comment Share on other sites More sharing options...
Rocky12 Posted July 1, 2015 Share Posted July 1, 2015 im trying to install but everytime with kernel panic ioplatformexpert.cpp Link to comment Share on other sites More sharing options...
chris1111 Posted July 2, 2015 Author Share Posted July 2, 2015 im trying to install but everytime with kernel panic ioplatformexpert.cpp You need to Put in Extra / Extensions The Original AppleACPIPlatform.kext from the BasesSystem / System /Library /Extensions Link to comment Share on other sites More sharing options...
Rocky12 Posted July 2, 2015 Share Posted July 2, 2015 ok i'm trying to do like that if it can help Link to comment Share on other sites More sharing options...
chris1111 Posted July 2, 2015 Author Share Posted July 2, 2015 ok i'm trying to do like that if it can help You try El Capitan Link to comment Share on other sites More sharing options...
Rocky12 Posted July 3, 2015 Share Posted July 3, 2015 hola chica El Capitano Dell 690 Thanks Chris your idea was great to Put the AppleACPIPlatform.kext in Extra / Extension 1 Link to comment Share on other sites More sharing options...
chris1111 Posted July 3, 2015 Author Share Posted July 3, 2015 hola chica El Capitano Dell 690 Thanks Chris your idea was great to Put the AppleACPIPlatform.kext in Extra / Extension I know thats working Link to comment Share on other sites More sharing options...
chris1111 Posted August 5, 2015 Author Share Posted August 5, 2015 Update 10.10.4 No Probleme 1 Link to comment Share on other sites More sharing options...
chris1111 Posted September 3, 2015 Author Share Posted September 3, 2015 Soon Complete Guide Clover EFI Mode ESP I made a super Installer for Yosemite and Post Installation Advantage is imessage working boot time 3 sec and all of the future to using the super Clover EFI Boot Manager 1 Link to comment Share on other sites More sharing options...
chris1111 Posted September 5, 2015 Author Share Posted September 5, 2015 Complete Guide Clover Boot Manager Mode ESP here http://www.insanelymac.com/forum/topic/307920-guide-clover-dell-precision-690-workstation/ 1 Link to comment Share on other sites More sharing options...
Blaggah Posted February 21, 2016 Share Posted February 21, 2016 -----UPDATED----- Complete Guide Clover Boot Manager Mode ESP here ☟ http://www.insanelymac.com/forum/topic/307920-guide-clover-dell-precision-690-workstation/ DELL Precision 690 Workstation :: Specs :: Double Intel® Xeon® Processor E5335 (8M Cache, 2.00 GHz, 1333 MHz FSB) 16 Gig Ram Kingston DDR3 667 Mhz Graphics ASUS Geforce GT 610 2 gig (Silent Fan less) SSD Kingston 120 gig (OS X) / HDD WD 200 Gig sata (Windows 8) Downloads latest Bios from Officiel Site DELL.com ************************************************** What you need? USB drive 8 Gig Installer OS X Yosemite.app on Applications Folder Formate the USB one partition Mac OS Extend journalise / Guid and Run Installer to your USB Install OS X 10 to your SSD or HDD Reboot with the USB to your New Installation Now Install manually with kexwizard BCM5722D.kext now you need to do Maintenance with kexwizard Repaire and rebuild cache and now your safely reboot. and go to Apple menue and Install Update 10.10.2 and reboot again and complete the post installations with DELL Precision 690 postInstaller.pkg or complete manually your post installation and finishing with VoodooHDA-v2.8.2.x64.ML.pkg All files is available on the attaching Zip THIS IS THE RESULT Enjoy Credit and thanks to Chameleon Team for Chameleon v2.3svn r2570 And all dev for the kext and App janek202 Alex Auditore Développeurs : zef, Turbo, dfe, netkas, mackerintel, mercurysquad, fassl, Kabyl, Crazor, Dense, kaitek, iNDi, munky, DHP, JrCs, asereBLN, rekursor, mozodojo, meklort, AnV, valv, AzimutZ, Slice, cosmo1t, cparm, Conti, ErmaC Merci à : bumby, kalyway, Krazubu, Eddie11c, JaS, fassl, XyZ, SMF, flama, Galaxy, sckevyn, MasterChief, smith@@, blackosx, DHP, nawcom, scorpius, dmazar Packageurs : kalyway, AzimutZ, blackosx, ErmaC, scrax, JrCs Paquet construit par: ErmaC, traduction par: JrCs Copyright © 2008-2014 Credits to: - Pike R. Alpha - ErmaC - Bungo - blackosx - Micky1979 - crazybirdy - oldnapalm - janek202 - MinusZwei Packager chris1111 I've been looking at the Precision 690 for a very long time now and was wondering if the version of motherboard really is essential in order to run 2 quad core xeon cpus. One particular guy by the name of ATL Shogun from youtube has a video showing his Precision 690 in action and stated that you need the MY171 Rev. A02 motherboard or above in order to run 2 quad core cpus. Link to comment Share on other sites More sharing options...
chris1111 Posted February 21, 2016 Author Share Posted February 21, 2016 I've been looking at the Precision 690 for a very long time now and was wondering if the version of motherboard really is essential in order to run 2 quad core xeon cpus. One particular guy by the name of ATL Shogun from youtube has a video showing his Precision 690 in action and stated that you need the MY171 Rev. A02 motherboard or above in order to run 2 quad core cpus. Not need to quote the entire post New guide here Clover see http://www.insanelymac.com/forum/topic/307920-guide-clover-dell-precision-690-workstation/ 1 Link to comment Share on other sites More sharing options...
Blaggah Posted February 21, 2016 Share Posted February 21, 2016 Thanks chris1111, hopefully I'll get my hands on a nice 690 workstation. Link to comment Share on other sites More sharing options...
Toskache Posted February 27, 2016 Share Posted February 27, 2016 Would a System with two 2,3 GHZ INTEL XEON type E5345 also work? Link to comment Share on other sites More sharing options...
chris1111 Posted February 27, 2016 Author Share Posted February 27, 2016 Would a System with two 2,3 GHZ INTEL XEON type E5345 also work? Why not! depends more then the Graphics cards Link to comment Share on other sites More sharing options...
Blaggah Posted February 27, 2016 Share Posted February 27, 2016 I don't see why not because Chris got 2x quad xeon chips running on his and I've just got the same CPUs as him, just waiting on heatsink to upgrade mine. Link to comment Share on other sites More sharing options...
chris1111 Posted February 27, 2016 Author Share Posted February 27, 2016 I don't see why not because Chris got 2x quad xeon chips running on his and I've just got the same CPUs as him, just waiting on heatsink to upgrade mine. heatsink is a big big difference Link to comment Share on other sites More sharing options...
Blaggah Posted February 28, 2016 Share Posted February 28, 2016 I'm still waiting for seller from eBay to respond to my offer on the heatsink. As soon as it gets here i will do the removal of the old cpu and upgrade to the 2x xeon quad core chips just like you chris. Link to comment Share on other sites More sharing options...
chris1111 Posted February 28, 2016 Author Share Posted February 28, 2016 I'm still waiting for seller from eBay to respond to my offer on the heatsink. As soon as it gets here i will do the removal of the old cpu and upgrade to the 2x xeon quad core chips just like you chris. Dont forget to put a small fan to the low back computer Link to comment Share on other sites More sharing options...
