arcade33 Posted June 18, 2016 Share Posted June 18, 2016 I'm not really understanding what you are doing to your installation be honest. Do you have El Capitan installed already? @GhostRaider your kexts are working very well is a very good job i'm on el capitan 10.6 beta 2 and no problem think you do the same job for SIERRA i'm a tester of CHRIS1111 H.M.F. French Forum I downloaded El Cap. from AppStore. then i downloaded Clover Speical edition.i made USB through Clover followed all the guide.[i did all this in Yosemite ] I deleted AppleIntelHDGraphicsFB.kext from S/L/E [uSB] When i am booting USB of El Cap. I am not able to see installer! Edit: Do you have any idea why this is happening? My specs. Intel core i5 430m Intel Graphic device id is 42/46 vendor id 0086 640GB HDD 5200rpm 4GB of RAM what you see , nothing ????? you don't see Clover you use this installer ???? : http://www.insanelymac.com/forum/files/file/471-clover-v23k-special-edition-v3/ in your config.plist have you deactivate intel <key>Graphics</key> <dict> <key>Inject</key> <dict> <key>ATI</key> <false/> <key>Intel</key> <false/> <key>NVidia</key> <false/> </dict> Link to comment Share on other sites More sharing options...
GhostRaider Posted June 18, 2016 Author Share Posted June 18, 2016 I downloaded El Cap. from AppStore. then i downloaded Clover Speical edition.i made USB through Clover followed all the guide.[i did all this in Yosemite ] I deleted AppleIntelHDGraphicsFB.kext from S/L/E [uSB] When i am booting USB of El Cap. I am not able to see installer! Edit: Do you have any idea why this is happening? My specs. Intel core i5 430m Intel Graphic device id is 42/46 vendor id 0086 640GB HDD 5200rpm 4GB of RAM You must remove all Intel HD Graphics kexts from the USB installer. Not just the framebuffer. On the config.plist file, inject intel must be disabled or false and patchVbios must be enabled or true. That should let you see the install screen. @GhostRaider your kexts are working very well is a very good job i'm on el capitan 10.6 beta 2 and no problem think you do the same job for SIERRA i'm a tester of CHRIS1111 H.M.F. French Forum Thanks, happy hackintoshing Link to comment Share on other sites More sharing options...
iAnkit Posted June 18, 2016 Share Posted June 18, 2016 @GhostRaider your kexts are working very well is a very good job i'm on el capitan 10.6 beta 2 and no problem think you do the same job for SIERRA i'm a tester of CHRIS1111 H.M.F. French Forum what you see , nothing ????? you don't see Clover I see Clover Screen what i do is i open "option" add these boot args cpus=1 -v Then i change Macbookpro6,2 to 3,2 in SMBIOS because its was not detecting my usb. and after that it boots.. and after that screen goes black.! @GhostRaider your kexts are working very well is a very good job i'm on el capitan 10.6 beta 2 and no problem think you do the same job for SIERRA i'm a tester of CHRIS1111 H.M.F. French Forum what you see , nothing ????? you don't see Clover you use this installer ???? : http://www.insanelymac.com/forum/files/file/471-clover-v23k-special-edition-v3/ in your config.plist have you deactivate intel <key>Graphics</key> <dict> <key>Inject</key> <dict> <key>ATI</key> <false/> <key>Intel</key> <false/> <key>NVidia</key> <false/> </dict> ok let me do... will report back thanks Link to comment Share on other sites More sharing options...
arcade33 Posted June 18, 2016 Share Posted June 18, 2016 I see Clover Screen what i do is i open "option" add these boot args cpus=1 -v Then i change Macbookpro6,2 to 3,2 in SMBIOS because its was not detecting my usb. and after that it boots.. and after that screen goes black.! ok let me do... will report back thanks don't forget : patchVbios must be enabled or true Link to comment Share on other sites More sharing options...
iAnkit Posted June 20, 2016 Share Posted June 20, 2016 don't forget : patchVbios must be enabled or true thank you so much for the help. It worked!!! finally el cap Link to comment Share on other sites More sharing options...
arcade33 Posted June 20, 2016 Share Posted June 20, 2016 thank you so much for the help. It worked!!! finally el cap happy for you but you you can thanks GhostRaider Link to comment Share on other sites More sharing options...
arcade33 Posted June 20, 2016 Share Posted June 20, 2016 @GhostRaider ok , i try today with SIERRA !!! ( with kexts 10.11.5 ) the kext are loaded , i get all working , no lags , but i don't get transparency on menu bar and dock can you say what i must edit in KEXT FRAMEBUFER i don't want that you lose your time with me 1 Link to comment Share on other sites More sharing options...
rioeduardo Posted June 20, 2016 Share Posted June 20, 2016 Hi @Arcade, It's a coincidence or not. I am about to ask the same thing with you. Hi @GhostRaider, Has apple made a big change? Because when I installed El Capitan Developer Preview 1, I could still use Intel HD Graphics QECI 10.10 from Yosemite. But now when I install Sierra Developer Preview 1, I can still not use Intel HD Graphics QECI 10.11 from El Capitan. Please help. Thanks, Rio Link to comment Share on other sites More sharing options...
arcade33 Posted June 20, 2016 Share Posted June 20, 2016 Hi @Arcade, It's a coincidence or not. I am about to ask the same thing with you. Hi @GhostRaider, Has apple made a big change? Because when I installed El Capitan Developer Preview 1, I could still use Intel HD Graphics QECI 10.10 from Yosemite. But now when I install Sierra Developer Preview 1, I can still not use Intel HD Graphics QECI 10.11 from El Capitan. Please help. Thanks, Rio hello @ rio what is your spec ( notebook ) Link to comment Share on other sites More sharing options...
rioeduardo Posted June 20, 2016 Share Posted June 20, 2016 hello @ rio what is your spec ( notebook ) Hello @arcade, My spec is HP Probook 4420s Intel Core i3-M350 2.27 GHz 8GB 1067 MHz DDR3 what's yours? Thanks, Rio 1 Link to comment Share on other sites More sharing options...
arcade33 Posted June 20, 2016 Share Posted June 20, 2016 i have a ACER ASPIRE 5733 do you have a dsdt.aml for your battery icon in the menu bar ?? Link to comment Share on other sites More sharing options...
rioeduardo Posted June 20, 2016 Share Posted June 20, 2016 i have a ACER ASPIRE 5733 do you have a dsdt.aml for your battery icon in the menu bar ?? Yes If you want, I can upload it for you 1 Link to comment Share on other sites More sharing options...
vanmoo Posted June 20, 2016 Share Posted June 20, 2016 Hey @Arcade33 i got stuck when booting macOS sierra usb,, ive deleted the AppleIntelHDGraphicsFB.kext but i didnt show the install screen.. Please help me. Link to comment Share on other sites More sharing options...
rioeduardo Posted June 20, 2016 Share Posted June 20, 2016 Hey @Arcade33 i got stuck when booting macOS sierra usb,, ive deleted the AppleIntelHDGraphicsFB.kext but i didnt show the install screen.. Please help me. Hi @RiskyRis, Please boot with verbose mode and post it here. So we can help you by reading the log. Thanks, Rio Link to comment Share on other sites More sharing options...
vanmoo Posted June 20, 2016 Share Posted June 20, 2016 @Arcade33 nope, it worked now,, hahaha.... Link to comment Share on other sites More sharing options...
arcade33 Posted June 20, 2016 Share Posted June 20, 2016 @Arcade33 nope, it worked now,, hahaha.... ????????????? @Arcade33 nope, it worked now,, hahaha.... what installer you are using to do your USB STICK ??, 1 Link to comment Share on other sites More sharing options...
vanmoo Posted June 20, 2016 Share Posted June 20, 2016 ????????????? what installer you are using to do your USB STICK ??, Oh nooo,, i think it workedd, but it got stuck againn ??, im using manual restore (via disk utility and so on) And now i got beach ball spinning,, with log busy timeout[0], (240s), kextd wait(0): `AppleACPICPU`, pci8086, 44` can you please help me, the insta screen still cant be reached.. Link to comment Share on other sites More sharing options...
arcade33 Posted June 20, 2016 Share Posted June 20, 2016 Oh nooo,, i think it workedd, but it got stuck againn , im using manual restore (via disk utility and so on) And now i got beach ball spinning,, with log busy timeout[0], (240s), kextd wait(0): `AppleACPICPU`, pci8086, 44` can you please help me, the insta screen still cant be reached.. see the first page of this post and use the new installer V3 from CHRIS 1111 i think that your FAKESMC is not the later Link to comment Share on other sites More sharing options...
vanmoo Posted June 20, 2016 Share Posted June 20, 2016 see the first page of this post and use the new installer V3 from CHRIS 1111 i think that your FAKESMC is not the later Okayy, ill use chris111 clover v3 ? Link to comment Share on other sites More sharing options...
millencolin Posted June 20, 2016 Share Posted June 20, 2016 Why not install the framebuffer kext from Mavericks onto El Capitan? You are allowed to do that. Update: i install the framebuffer and its clear as day, but now its 4 divided screens that are clear and great quality.... any tips on how to get rid of this as it seems to be my only issue right now, i have tried dual link 0 and 1 in clover setting and nothing... all the frame buffers from 10.10 and or 10.11 seem to give me bad picture but Mavericks bring up clear but divided into four screen... should i be patching manually, with the intel patcher or not reccomended... Thanks Alen Link to comment Share on other sites More sharing options...
arcade33 Posted June 27, 2016 Share Posted June 27, 2016 hello i extract from linux mint like that : sudo intel_reg_dumper ( Attach Files ) and i get this error in the last Intel HD Graphics Patcher.app somebody , can help me , i don't understand !!! thanks dump.zip Link to comment Share on other sites More sharing options...
Moorre Posted June 29, 2016 Share Posted June 29, 2016 @arcade33, hi! You have a: PCH_LVDS: 0x80300302 (enabled, pipe A, 18 bit, 1 channel) so you can try the patch by Clover on-the-fly. I've attached the example files few posts upper. Or rename your file to "dump.txt" Link to comment Share on other sites More sharing options...
arcade33 Posted June 29, 2016 Share Posted June 29, 2016 @arcade33, hi! You have a: PCH_LVDS: 0x80300302 (enabled, pipe A, 18 bit, 1 channel) so you can try the patch by Clover on-the-fly. I've attached the example files few posts upper. Or rename your file to "dump.txt" thank you for your reply i take a look of your patch CLOVER on the fly i've tried with dump.txt two days ago , it dint't work thanks so much Link to comment Share on other sites More sharing options...
Moorre Posted June 30, 2016 Share Posted June 30, 2016 @arcade33, you don't need a dump now. You have LVDS enabled so all ok. Just try Clover's on-the-fly patches. One of the combonations should work. Try from the first by this guide #1 post. Link to comment Share on other sites More sharing options...
Alexzhang Posted July 9, 2016 Share Posted July 9, 2016 So, has anyone got it worked perfectly in Sierra? I mean fully transparent menu bar and dock. I'm hesitating because I wonder whether I should install Sierra immediately. Link to comment Share on other sites More sharing options...
