tluck Posted October 9, 2020 Share Posted October 9, 2020 (edited) why the latest commit to ignore OpenRuntime.efi? caused an issue for me. I understand skiping OcQuirks.efi (as that is built-in now). But seems that many will need either OpenRuntime OR AptioMemoryFix or the other options? $ ls -l /opt/Source/Clover/CloverPackage/CloverV2/EFI/CLOVER/drivers/off/UEFI/MemoryFix total 184 -rw-rw-r-- 1 tluck wheel 30432 Oct 9 10:18 AptioMemoryFix.efi -rw-rw-r-- 1 tluck wheel 7232 Oct 9 10:18 OpenRuntime.efi -rw-rw-r-- 1 tluck wheel 23072 Oct 9 10:18 OsxAptioFix3Drv.efi -rw-rw-r-- 1 tluck wheel 23040 Oct 9 10:18 OsxAptioFixDrv.efi -rw-rw-r-- 1 tluck wheel 3840 Oct 9 10:18 OsxLowMemFixDrv.efi DirIterOpen(&self.getCloverDir(), Path, &DirIter); while (DirIterNext(&DirIter, 2, L"*.efi", &DirEntry)) { Skip = (DirEntry->FileName[0] == L'.'); for (size_t i=0; i<gSettings.DisabledDriverArray.size(); i++) { if (StrStr(DirEntry->FileName, gSettings.DisabledDriverArray[i].wc_str()) != NULL) { Skip = TRUE; // skip this break; } } if (Skip) { continue; } if ( LStringW(DirEntry->FileName).containsIC("OcQuirks") ) { continue; } if ( LStringW(DirEntry->FileName).containsIC("AptioMemoryFix") ) { continue; } if ( LStringW(DirEntry->FileName).containsIC("OpenRuntime") ) { continue; } and what about this - isn't skip with harsh warning better than a panic? + it might be good to mention when a driver is present but skipped? if ( OSTYPE_IS_OSX(LoaderType) || OSTYPE_IS_OSX_RECOVERY(LoaderType) || OSTYPE_IS_OSX_INSTALLER(LoaderType) ) { { EFI_HANDLE Interface = NULL; Status = gBS->LocateProtocol(&gAptioMemoryFixProtocolGuid, NULL, &Interface ); if ( !EFI_ERROR(Status) ) { panic("Remove AptioMemoryFix.efi and OcQuirks.efi from your driver folder\n"); } } Edited October 9, 2020 by tluck Link to comment Share on other sites More sharing options...
iCanaro Posted October 9, 2020 Share Posted October 9, 2020 maybe that's why the last Clover I compiled, on the Z370 I don't get any and they immediately go into kernel panic Link to comment Share on other sites More sharing options...
maclinuxG4 Posted October 9, 2020 Share Posted October 9, 2020 (edited) I test with as config.plist with mojave ( and r5123.pkg): I lost screen display, and no change is anymore possible (including applications) by the way i get as so quick message in red color that i could saw it, but it seem that radeon.kext are not load. it may be some other @tluck: interesting, because OcQuirks, AptionMemoryFix OpenRuntime for all mac os , excepted big sur if anyone has the answer So who could you confirm this point ? or may i wrong ? Edited October 9, 2020 by maclinuxG4 Link to comment Share on other sites More sharing options...
fusion71au Posted October 9, 2020 Share Posted October 9, 2020 13 hours ago, Jief_Machak said: Make files with what ? @Everyone : duplicated settings are now ignored from Quirks section. @Jief_Machak, @Slice, As I mentioned in my previous post, the recent commit r5123_641b75e will cause problems for users migrating from old Clover because of backwards incompatibility with their old config.plist settings. Old Clover KernelAndKextPatches settings matched to OC 0.6.1 Kernel/Quirks OC AppleCpuPmCfgLock = Clover's AppleIntelCPUPM (power management for Sandy/IvyBridge CPUs needing patched AppleIntelCPUPowerManagement.kext, not Clover's KernelPm which enables Kernel Power Management for Haswell and newer CPUs) OC AppleXcpmCfgLock = Clover's KernelPm (not KernelXCPM which was for IvyBridge CPUs according to old Clover wiki @SourceForge). In order to boot with r5123_641b75e or newer on my NUC6i5SYH, I have to replace config.plist/KernelAndKextPatches/KernelPm=Yes with config.plist/KernelAndKextPatches/KernelXCPM=Yes, otherwise early boot hang due to locked kernel msrs... Spoiler 1 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 9, 2020 Share Posted October 9, 2020 @tluck OpenRuntime.efi prevent linux to boot. I didn't see OpenRuntime.efi being used but maybe I didn't look close enough. The panic isn't suppose to happen, as the driver was ignored. But yes, a warning system would be good, but we do with what we have. Comment out these line and without changing anything else. If it makes your config working, it'll prove that Openruntime is used. 3 minutes ago, fusion71au said: As I mentioned in my previous post, the recent commit r5123_641b75e will cause problems for users migrating from old Clover because of backwards incompatibility with their old config.plist settings. If we made a mistake, we'll correct it... Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 9, 2020 Share Posted October 9, 2020 3 hours ago, tluck said: skip with harsh warning better than a panic By the way, skip won't work because you'll get a crash in OpenCore if that protocol exists before calling OcMain. Link to comment Share on other sites More sharing options...
1Revenger1 Posted October 9, 2020 Share Posted October 9, 2020 (edited) Technically, you should be able to use the OpenCore patches right for AMD patches? Since you're using OC to do patching. I think you need to hook up the masking stuff and Skip/Count since the patches do use those. Edited October 9, 2020 by 1Revenger1 1 Link to comment Share on other sites More sharing options...
stevezheng Posted October 9, 2020 Share Posted October 9, 2020 19 hours ago, fusion71au said: @Slice, @stevezheng, About recent commit 641b75e based on the above post. AFAIK, OC AppleCpuPmCfgLock = Clover's AppleIntelCPUPM OC AppleXcpmCfgLock = Clover's KernelPm Please confirm with OC 0.6.1 Configuration.pdf. After a closer look, I agree that Clover's KernelPM functions more similar to OC's AppleXcpmCfgLock. Still needs a closer look, as I didn't figure out what Clover's KernelXCPM does (maybe enable XCPM on old platforms such as Haswell?). The definition for Clover's KernelPm is at here: https://github.com/CloverHackyColor/CloverBootloader/blob/f312117030cc0e7f903b12da26cc1aeea03caff7/rEFIt_UEFI/Platform/kernel_patcher.cpp#L917 The definition for OpenCore's AppleXcpmCfgLock is at here: https://github.com/acidanthera/OpenCorePkg/blob/ecbed230e0786c8aa250504c6fe72924260d92fc/Library/OcAppleKernelLib/CommonPatches.c#L203 I can see they both play with _xcpm_core_scope_msrs and patch them. But maybe Clover's KernelPm does more than zero out 0xE2 MSR, more tests are needed. I also agree that OC's AppleCpuPmCfgLock is a replacement for Clover's AppleIntelCPUPM. The definition of Clover's AppleIntelCPUPM is at here: https://github.com/CloverHackyColor/CloverBootloader/blob/f312117030cc0e7f903b12da26cc1aeea03caff7/rEFIt_UEFI/Platform/kext_patcher.cpp#L473 And for OpenCore: https://github.com/acidanthera/OpenCorePkg/blob/ecbed230e0786c8aa250504c6fe72924260d92fc/Library/OcAppleKernelLib/CommonPatches.c#L42 They all patch with nops, and check registers with value 0xC9, 0xB9, etc. CC @Slice 1 Link to comment Share on other sites More sharing options...
iCanaro Posted October 9, 2020 Share Posted October 9, 2020 57 minutes ago, 1Revenger1 said: Technically, you should be able to use the OpenCore patches right for AMD patches? Since you're using OC to do patching. I think you need to hook up the masking stuff and Skip/Count since the patches do use those. this is very important to be able to have Clover working on AMD and especially for Big Sur There was no evolution for "traditional" kernel patches with Clover, development went ahead on the method used with OC 1 Link to comment Share on other sites More sharing options...
tluck Posted October 10, 2020 Share Posted October 10, 2020 5 hours ago, Jief_Machak said: By the way, skip won't work because you'll get a crash in OpenCore if that protocol exists before calling OcMain. ok. 5 hours ago, Jief_Machak said: @tluck OpenRuntime.efi prevent linux to boot. I didn't see OpenRuntime.efi being used but maybe I didn't look close enough. The panic isn't suppose to happen, as the driver was ignored. But yes, a warning system would be good, but we do with what we have. Comment out these line and without changing anything else. If it makes your config working, it'll prove that Openruntime is used. If we made a mistake, we'll correct it... regardless I/we need OpenRuntime.efi or another "memory fix" alternative. or instant panic for macOS. i reverted your last commit and built clover. so with OpenRuntime.efi - boots as usual. without it - instant panic. Link to comment Share on other sites More sharing options...
Slice Posted October 10, 2020 Share Posted October 10, 2020 No! if ( LStringW(DirEntry->FileName).containsIC("OpenRuntime") ) { continue; } The driver is needed for macOS. It performs all Quirks. May be for linux we have to filter one Quirk. But I don't know exactly which one. 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 10, 2020 Share Posted October 10, 2020 (edited) 47 minutes ago, Slice said: It performs all Quirks. I really don't think all of them. Look at OpenRuntime.c, it wraps few things. There is one that is needed, for tluck for example. We have to find which one and do it in Clover. Needing OpenRuntime.efi will be a nightmare. Let's do it more subtle. @tluck Could you share your efi folder ? I'd like to reproduce the issue locally. EDIT : I meant : sharing the Clover folder is enough, I think. The one that is able to boot with OpenRuntime.efi, and NOT able without it. Edited October 10, 2020 by Jief_Machak Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 10, 2020 Share Posted October 10, 2020 (edited) @tluck Could you try this : CloverX64-20201010090401-2fddd11-dirty-jief.zip ? Edited October 10, 2020 by Jief_Machak Link to comment Share on other sites More sharing options...
Matgen84 Posted October 10, 2020 Share Posted October 10, 2020 8 hours ago, stevezheng said: After a closer look, I agree that Clover's KernelPM functions more similar to OC's AppleXcpmCfgLock. Still needs a closer look, as I didn't figure out what Clover's KernelXCPM does (maybe enable XCPM on old platforms such as Haswell?). The definition for Clover's KernelPm is at here: https://github.com/CloverHackyColor/CloverBootloader/blob/f312117030cc0e7f903b12da26cc1aeea03caff7/rEFIt_UEFI/Platform/kernel_patcher.cpp#L917 The definition for OpenCore's AppleXcpmCfgLock is at here: https://github.com/acidanthera/OpenCorePkg/blob/ecbed230e0786c8aa250504c6fe72924260d92fc/Library/OcAppleKernelLib/CommonPatches.c#L203 I can see they both play with _xcpm_core_scope_msrs and patch them. But maybe Clover's KernelPm does more than zero out 0xE2 MSR, more tests are needed. I also agree that OC's AppleCpuPmCfgLock is a replacement for Clover's AppleIntelCPUPM. The definition of Clover's AppleIntelCPUPM is at here: https://github.com/CloverHackyColor/CloverBootloader/blob/f312117030cc0e7f903b12da26cc1aeea03caff7/rEFIt_UEFI/Platform/kext_patcher.cpp#L473 And for OpenCore: https://github.com/acidanthera/OpenCorePkg/blob/ecbed230e0786c8aa250504c6fe72924260d92fc/Library/OcAppleKernelLib/CommonPatches.c#L42 They all patch with nops, and check registers with value 0xC9, 0xB9, etc. CC @Slice Thanks @stevezheng @Slice In "converting common proprieties from Clover to Opencore" (Dortania Guide), I see that : Clover's KernelXCPM is replaced by OC's AppleXcpmExtraMsrs What do you think about ! Please. 1 Link to comment Share on other sites More sharing options...
Slice Posted October 10, 2020 Share Posted October 10, 2020 12 minutes ago, Matgen84 said: Thanks @stevezheng @Slice In "converting common proprieties from Clover to Opencore" (Dortania Guide), I see that : Clover's KernelXCPM is replaced by OC's AppleXcpmExtraMsrs What do you think about ! Please. looks like true 1 Link to comment Share on other sites More sharing options...
jsl2000 Posted October 10, 2020 Share Posted October 10, 2020 1 hour ago, Jief_Machak said: @tluck Could you try this : CloverX64-20201010090401-2fddd11-dirty-jief.zip ? It got error message of different key values: KernelPm vs. AppleXcpmCfgLock even both were True in my config.plist. Link to comment Share on other sites More sharing options...
Slice Posted October 10, 2020 Share Posted October 10, 2020 5 hours ago, tluck said: ok. regardless I/we need OpenRuntime.efi or another "memory fix" alternative. or instant panic for macOS. i reverted your last commit and built clover. so with OpenRuntime.efi - boots as usual. without it - instant panic. As well as me. 1 Link to comment Share on other sites More sharing options...
Matgen84 Posted October 10, 2020 Share Posted October 10, 2020 (edited) 40 minutes ago, Slice said: As well as me. @Slice Is Openruntime always present in CloverPkg ? I don't find it in my last build. OcQuirks file is it unnecessary now? Maybe I mistaked somewhere. Sorry for my bad English, I don't understand what @tluck said. Edited October 10, 2020 by Matgen84 Link to comment Share on other sites More sharing options...
stevezheng Posted October 10, 2020 Share Posted October 10, 2020 2 hours ago, Matgen84 said: 2 hours ago, Matgen84 said: Thanks @stevezheng @Slice In "converting common proprieties from Clover to Opencore" (Dortania Guide), I see that : Clover's KernelXCPM is replaced by OC's AppleXcpmExtraMsrs What do you think about ! Please. I don't think AppleXcpmExtraMsrs exactly matches Clover's KernelXCPM, but I agree it can replace KernelXCPM. In Clover's KernelXCPM, kernel patcher will patch _cpuid_set_info accordingly based on platform and macOS version. In OpenCore's AppleXcpmExtraMsrs, it seems like a more general approach to patch xcpm_msr_applicable_cpus and write to MSR_MISC_PWR_MGMT, regardless of macOS version. There's a detailed document of OpenCore's AppleXcpmExtraMsrs at here: https://github.com/acidanthera/bugtracker/issues/365. According to that, the methods used by OpenCore and Clover are very different. OpenCore's AppleXcpmExtraMsrs may include the functionality of Clover's KernelXCPM and some other stuff discussed in that link. 1 Link to comment Share on other sites More sharing options...
iCanaro Posted October 10, 2020 Share Posted October 10, 2020 @Matgen84 which hack are you testing? If on the p8Z77 and you can get to desktop, would you pass me the Clover you use and the config? In my Z68 and Z97 systems I could not get to desktop with no Clover release after the 5122 Link to comment Share on other sites More sharing options...
maclinuxG4 Posted October 10, 2020 Share Posted October 10, 2020 i test a version of clover and i boot correctly with mojave. Plz see with slice thanks Link to comment Share on other sites More sharing options...
Matgen84 Posted October 10, 2020 Share Posted October 10, 2020 32 minutes ago, iCanaro said: @Matgen84 which hack are you testing? If on the p8Z77 and you can get to desktop, would you pass me the Clover you use and the config? In my Z68 and Z97 systems I could not get to desktop with no Clover release after the 5122 @iCanaro I only test Z390 system up to commits 2fddd11, to boot Big Sur. Sorry, I don't update P8Z77 since r5122 (648f5c3d3). IvyBridge is on my TODO list. 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 10, 2020 Share Posted October 10, 2020 42 minutes ago, iCanaro said: In my Z68 and Z97 systems I could not get to desktop with no Clover release after the 5122 Patience !! It will. 1 Link to comment Share on other sites More sharing options...
cyrhex Posted October 10, 2020 Share Posted October 10, 2020 15 hours ago, fusion71au said: @Jief_Machak, @Slice, As I mentioned in my previous post, the recent commit r5123_641b75e will cause problems for users migrating from old Clover because of backwards incompatibility with their old config.plist settings. Old Clover KernelAndKextPatches settings matched to OC 0.6.1 Kernel/Quirks OC AppleCpuPmCfgLock = Clover's AppleIntelCPUPM (power management for Sandy/IvyBridge CPUs needing patched AppleIntelCPUPowerManagement.kext, not Clover's KernelPm which enables Kernel Power Management for Haswell and newer CPUs) OC AppleXcpmCfgLock = Clover's KernelPm (not KernelXCPM which was for IvyBridge CPUs according to old Clover wiki @SourceForge). In order to boot with r5123_641b75e or newer on my NUC6i5SYH, I have to replace config.plist/KernelAndKextPatches/KernelPm=Yes with config.plist/KernelAndKextPatches/KernelXCPM=Yes, otherwise early boot hang due to locked kernel msrs... Hide contents now i know the reason why i recieving a kernel panic or instant reboot on my i5 2500 with b75m board using clover 5123 Link to comment Share on other sites More sharing options...
cyrhex Posted October 10, 2020 Share Posted October 10, 2020 got working 5123 in my catalina,,thnx to fusion71au 1 Link to comment Share on other sites More sharing options...
