SavageAUS Posted October 1, 2020 Share Posted October 1, 2020 Ok now take this with a grain of salt. I did NOT go through the full install but: Both Catalina and Big Sur booted into the install screen / recovery environment from USB using clover revision_ 5122-ocint-3009.3 + config changes from @Jief_Machak I personally would like to say thank you to Jief and the rest of the Clover team for getting this far before the GM release of Big Sur. I am also glad i could to be of some help. I am now using this as my primary boot loader / picker again. This was all done on my intel laptop, specs in signature. If you would like my EFI let me know and i will be happy to help. Next step for me is to try adapt this to my Ryzen hack. 1 1 Link to comment Share on other sites More sharing options...
iCanaro Posted October 1, 2020 Share Posted October 1, 2020 2 minutes ago, SavageAUS said: Next step for me is to try adapt this to my Ryzen hack. idem technical information @Jief_Machak With Clover 5120 (OcQuirks.efi - Ocquirks.plist - OpenRuntime.efi) rev. 24, I was able to start catalina and high sierra my ryzen 3950x on MSI X570 Unify Now with Clover 5122-ocint-3009.3 the way to inject kernel patches has remained the same as previous Clover or has taken oc's method of inserting such patches??? 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 1, 2020 Share Posted October 1, 2020 1 minute ago, iCanaro said: has taken oc's method of inserting such patches??? Yes, currently kext injection and patch are delegated to OC. Is it that that prevents you to boot ? 5 Link to comment Share on other sites More sharing options...
iCanaro Posted October 1, 2020 Share Posted October 1, 2020 this is great news!!! In fact, the AMD kernel patches for Clover are not up to date, while OC's patches are up to date, so if you can now use those, I'll update the config and test try it yourself @fabiosun 1 1 1 Link to comment Share on other sites More sharing options...
Guest Posted October 1, 2020 Share Posted October 1, 2020 (edited) @iCanaroI have tested both (clover experimental patches and the same I am using with success in opencore) I have not followed new clover boot loader progress but I think for my AMD platform problem is related to EFI drivers TRX40 is a bit different from others AMD platform but if some of you have had success with this @Jief_Machak release it is a good start to put some efforts to understand also for me Edited October 1, 2020 by Guest Link to comment Share on other sites More sharing options...
PG7 Posted October 1, 2020 Share Posted October 1, 2020 22 minutes ago, iCanaro said: this is great news!!! In fact, the AMD kernel patches for Clover are not up to date, while OC's patches are up to date, so if you can now use those, I'll update the config and test try it yourself @fabiosun Too bad I don't have a platform with an AMD processor to be able to help in this part ... 2 Link to comment Share on other sites More sharing options...
SavageAUS Posted October 1, 2020 Share Posted October 1, 2020 30 minutes ago, iCanaro said: this is great news!!! In fact, the AMD kernel patches for Clover are not up to date, while OC's patches are up to date, so if you can now use those, I'll update the config and test try it yourself @fabiosun I’m up for the challenge.....maybe lol. First I need to modify my Clover config for AMD then adjust quirks then I’ll try adding in the kernel patches from OC and see how it goes on my build. 1 1 Link to comment Share on other sites More sharing options...
jsl2000 Posted October 1, 2020 Share Posted October 1, 2020 44 minutes ago, Jief_Machak said: Yes, currently kext injection and patch are delegated to OC. Is it that that prevents you to boot ? In previous version of Clover KernelToPatch for AMD CPUs is quite different from Kernel/Patch in OpenCore. We need fine modification to make it work. Do you mean with current Clover we do not need modification of this patch ? 1 Link to comment Share on other sites More sharing options...
SavageAUS Posted October 1, 2020 Share Posted October 1, 2020 Can anyone share a config.plist for clover for AMD. I’m not sure where to place the kernel patches. My first attempt got stuck pretty soon after selecting boot drive. I’ll also recheck my quirks. 1 Link to comment Share on other sites More sharing options...
iCanaro Posted October 1, 2020 Share Posted October 1, 2020 26 minutes ago, SavageAUS said: Can anyone share a config.plist for clover for AMD. I’m not sure where to place the kernel patches. My first attempt got stuck pretty soon after selecting boot drive. I’ll also recheck my quirks. idem 1 Link to comment Share on other sites More sharing options...
SavageAUS Posted October 1, 2020 Share Posted October 1, 2020 1 minute ago, iCanaro said: idem I had to google what “idem” means lol. 1 1 Link to comment Share on other sites More sharing options...
iCanaro Posted October 1, 2020 Share Posted October 1, 2020 idem = same, equal same 1 Link to comment Share on other sites More sharing options...
Guest Posted October 1, 2020 Share Posted October 1, 2020 (edited) if you try to modify and add to test one kernel patch you will understand how to add and if you see in my log the patches are loaded for proper system..so that injection works Edited October 1, 2020 by Guest typo Link to comment Share on other sites More sharing options...
PG7 Posted October 1, 2020 Share Posted October 1, 2020 2 hours ago, SavageAUS said: Quelqu'un peut-il partager un config.plist pour le trèfle pour AMD. Je ne sais pas où placer les correctifs du noyau. Ma première tentative est restée bloquée peu de temps après avoir sélectionné le lecteur de démarrage. Je revérifierai également mes bizarreries. 1 hour ago, iCanaro said: idem test ! config-test Ryzen.plist 1 Link to comment Share on other sites More sharing options...
PG7 Posted October 1, 2020 Share Posted October 1, 2020 (edited) Dell Vostro 2520 BigSur Beta 9 upgrade = Opencore Clover Error Inthernet ! intel i5-3210M intel HD4000 SSD 256go 8go RAM Cirrus CS4213 = VoodooHDA NO microphone !!! = ALC no Work Atheros AR9285 = No Actived Realtek RTL8111 Bootloader = Powered by Clover revision 5122-ocint-3009.2 Spoiler Spoiler Spoiler r5122 Dell Vostro 2520 BigSur beta 9 1-10-20.zip Edited October 1, 2020 by PG7 2 Link to comment Share on other sites More sharing options...
iCanaro Posted October 1, 2020 Share Posted October 1, 2020 great idea @PG7 but so far all attempts to start with Clover 5122-ocint3009.3 have failed debug_5122-ocint3009.3_Catalina.log.zip I can start Catalina with Clover 5120 - OcQuirks rev24 debug_5120_ocquirks24_catalina.log.zip 1 1 Link to comment Share on other sites More sharing options...
PG7 Posted October 1, 2020 Share Posted October 1, 2020 (edited) 15 minutes ago, iCanaro said: great idea @PG7 but so far all attempts to start with Clover 5122-ocint3009.3 have failed debug_5122-ocint3009.3_Catalina.log.zip I can start Catalina with Clover 5120 - OcQuirks rev24 debug_5120_ocquirks24_catalina.log.zip send your functional EFI du Ryzen to Catalina Edited October 1, 2020 by PG7 1 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 1, 2020 Share Posted October 1, 2020 58 minutes ago, iCanaro said: great idea @PG7 but so far all attempts to start with Clover 5122-ocint3009.3 have failed debug_5122-ocint3009.3_Catalina.log.zip I can start Catalina with Clover 5120 - OcQuirks rev24 debug_5120_ocquirks24_catalina.log.zip @iCanaro : if you have a working OpenCore configuration that doesn't work with latest Clover, we'll make it work. We'll do tests through the EFI we share. Basically : if OC works, I should be able to have Clover to work because Clover is using OC inside. Contact me in 3/4 days. I won't be available before then. One thing you can do in the meantime : take the folder we share (remember ? it contains OpenCore AND Clover). Configure it to work with OC (config in config-oc.plist). Once it works : commit and contact me. 4 Link to comment Share on other sites More sharing options...
iCanaro Posted October 1, 2020 Share Posted October 1, 2020 7 minutes ago, Jief_Machak said: Configure it to work with OC (config in config-oc.plist) my AMD ryzen hack is working with OC from December 2019 no hurry, when you're available I'll make you available via mega or if I can, github, my OC EFI 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 1, 2020 Share Posted October 1, 2020 Hi everyone, could you try these efis. It's the exact same, but compiled with the integrated script. Debug version and release version. No need to try every operating system. If everyone can do 1 test... that'll be good enough. CLOVERX64_debug.efi CLOVERX64_release.efi 2 1 Link to comment Share on other sites More sharing options...
PG7 Posted October 1, 2020 Share Posted October 1, 2020 8 minutes ago, Jief_Machak said: Salut à tous, pourriez-vous essayer ces efis. C'est exactement la même chose, mais compilé avec le script intégré. Version de débogage et version de publication. Pas besoin d'essayer tous les systèmes d'exploitation. Si tout le monde peut faire 1 test ... ce sera assez bien. CLOVERX64_debug.efi CLOVERX64_release.efi Work 100% release ! Spoiler 1 Link to comment Share on other sites More sharing options...
JorgeMax Posted October 1, 2020 Share Posted October 1, 2020 Release: Spoiler Debug: Spoiler The release version, I have a freeze on startup (both with VirtualSMC and FakeSMC) The debug version, starts normal, but my processor is not shown in the "system information" 1 Link to comment Share on other sites More sharing options...
Common_Sense Posted October 1, 2020 Share Posted October 1, 2020 (edited) It almost works now, thank you so much Jief_Machak! The one thing that does not work perfect is USB. I rely on FakePCIID_XHCIMux.kext and FakePCIID.kext to make USB work 100% and I think somehow Clover does not load them both, perhaps it tries to load them in the wrong order and therefore does not load FakePCIID_XHCIMux.kext? I use USBInjectAll.kext as well but I think it is loading as it should. Other than that everything is identical in OC and Clover. EDIT: It works to create kext dependencies in Clover by creating a directory called PlugIns inside the Contents directory of the kext. Just drop the kext that depends on the kext inside that directory and they will load after the kext they depend on. Edited October 2, 2020 by Common_Sense Link to comment Share on other sites More sharing options...
chris1111 Posted October 1, 2020 Share Posted October 1, 2020 (edited) 24 minutes ago, JorgeMax said: Release: Hide contents Same for me Release and Debug work don't know why log is empty? Spoiler Nothing in LOG bdmesg-5122-ocint.3 commit 08add4995.txt.zip Edited October 1, 2020 by chris1111 Debug work Link to comment Share on other sites More sharing options...
SavageAUS Posted October 2, 2020 Share Posted October 2, 2020 (edited) 5 hours ago, Jief_Machak said: Hi everyone, could you try these efis. It's the exact same, but compiled with the integrated script. Debug version and release version. No need to try every operating system. If everyone can do 1 test... that'll be good enough. CLOVERX64_debug.efi CLOVERX64_release.efi Release - Stuck on STARTBS debug-release.log Debug - Boots Big Sur and Catalina fine. debug.log Edited October 2, 2020 by SavageAUS 1 1 Link to comment Share on other sites More sharing options...
