Matgen84 Posted January 27, 2019 Share Posted January 27, 2019 12 minutes ago, meaganmargaret said: Yes, you are right, I need BootChimeDxe.efi, right? Can someone upload the latest build of BootChimeDxe.efi? I would greatly appreciate it. Thanks! In attachement AudioPkg-R1-RELEASE.zip Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 (edited) Ok I am still not getting a sound when MacOS loads after Clover menu. Could it be because of my sound.wav file? Could someone that has thins working test it? 1. I have AudioDxe and BootChimeDxe in the drivers64UEFI. 2. I have sound.wav in EFI folder, where the BOOT and CLOVER folder is located. sound.wav Edited January 27, 2019 by Pavo Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 (edited) 16 minutes ago, meaganmargaret said: I think you need to use this and put in the root of your EFI folder and remove sound.wav from everywhere else..... bootchime.wav Ok removed sound.wav and put bootchime.wav inside the EFI folder, again where BOOT and CLOVER folders are and still not getting sound when MacOS is selected in Clover menu after hitting Enter. Ok made some progress. I moved the bootchime.wav file to the root of the ESP, where the EFI folder is located and getting this now. Edited January 27, 2019 by Pavo Link to comment Share on other sites More sharing options...
Matgen84 Posted January 27, 2019 Share Posted January 27, 2019 Hi There is a issue with PlayAsync on my system: <key>GUI</key> <dict> <key>PlayAsync</key> <true/> I've a sound before enter Clover GUI. After, no keyboard, no mouse. Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 How do I fix the BootChimeDxe: Unsupported sample rate for file: 22255 Hz? Link to comment Share on other sites More sharing options...
yapan4 Posted January 27, 2019 Share Posted January 27, 2019 (edited) 2 hours ago, Sherlocks said: support? what is it? 나의 LG-F800S 의 Tapatalk에서 보냄 https://www.insanelymac.com/forum/topic/329777-clover-problems-report-features-request/?do=findComment&comment=2647232 2 hours ago, Pavo said: Its not Clover that needs to support that CPU, its MacOS that needs too support it. I am pretty sure that if you use a iMacPro1,1 SMBIOS you will get closest to that support. Long story here https://www.insanelymac.com/forum/topic/333229-help-installing-highsierra-on-xeon-w-2175-and-asus-ws-c422-mobo/ https://www.insanelymac.com/forum/topic/335193-help-installing-mojave-on-xeon-w-2175-and-asus-ws-c422-mobo/ macOS support Xeon W-21xx series CPU, he is native to her Edited January 27, 2019 by yapan4 Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 8 minutes ago, yapan4 said: https://www.insanelymac.com/forum/topic/329777-clover-problems-report-features-request/?do=findComment&comment=2647232 Long story here https://www.insanelymac.com/forum/topic/333229-help-installing-highsierra-on-xeon-w-2175-and-asus-ws-c422-mobo/ https://www.insanelymac.com/forum/topic/335193-help-installing-mojave-on-xeon-w-2175-and-asus-ws-c422-mobo/ macOS support Xeon W-21xx series CPU, he is native to her But these are not a "Clover" issue, this is more of patching issue from what I can tell. Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 (edited) I made some progress, I can get it to work for Clover GUI but I am still not able to get a chime sound when hitting enter on the macOS partition to boot. I am using the same file that I put in themes folder but renamed it to bootchime.wave instead of sound.wav that is in themes folder. Edited January 27, 2019 by Pavo Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 6 minutes ago, meaganmargaret said: Are you using PlayAsync? If so, don't.....that's what got me that error....soon as I turned it off, the message went away. And if the message is really referencing BootChime.wav that I gave you, here's one that IS, for sure, 48000 khz.....I just redid it, tested it and it works for me..... bootchime.wav Thanks I am not using any settings in config for Playsync. This is how it's working now. Link to comment Share on other sites More sharing options...
yapan4 Posted January 27, 2019 Share Posted January 27, 2019 (edited) 43 minutes ago, Pavo said: But these are not a "Clover" issue, this is more of patching issue from what I can tell. Yes, I meant Clover bootloader - BOOTX64.efi or CLOVERX64.efi ...or also AptioMemoryFix.efi Edited January 27, 2019 by yapan4 Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 (edited) 28 minutes ago, meaganmargaret said: Are you using PlayAsync? If so, don't.....that's what got me that error....soon as I turned it off, the message went away. And if the message is really referencing BootChime.wav that I gave you, here's one that IS, for sure, 48000 khz.....I just redid it, tested it and it works for me..... bootchime.wav Tried your latest uploaded sound file and the message isn't there but still not getting chime before the Apple Logo after hitting enter in MacOS drive to boot in Clover menu, also removed the sound.wav file from themes folder because I do not want any chime before Clover GUI, I want chime right before Apple Logo if it is possible. Edited January 27, 2019 by Pavo Link to comment Share on other sites More sharing options...
Sherlocks Posted January 27, 2019 Share Posted January 27, 2019 Long story here https://www.insanelymac.com/forum/topic/333229-help-installing-highsierra-on-xeon-w-2175-and-asus-ws-c422-mobo/ https://www.insanelymac.com/forum/topic/335193-help-installing-mojave-on-xeon-w-2175-and-asus-ws-c422-mobo/ macOS support Xeon W-21xx series CPU, he is native to herupload your clover preboot or booted log.나의 LG-F800S 의 Tapatalk에서 보냄 Link to comment Share on other sites More sharing options...
LockDown Posted January 27, 2019 Share Posted January 27, 2019 night_sound.wav too Link to comment Share on other sites More sharing options...
Pavo Posted January 27, 2019 Share Posted January 27, 2019 (edited) Could the issue I am having be related to not getting Clover.SoundVolume nvram variable? Figure it out, finally got it working woot!!! Had to clear NVRAM variables using BootChimeCfg.efi Edited January 27, 2019 by Pavo 1 Link to comment Share on other sites More sharing options...
Andres ZeroCross Posted January 27, 2019 Share Posted January 27, 2019 Could the issue I am having be related to not getting Clover.SoundVolume nvram variable? Figure it out, finally got it working woot!!! Had to clear NVRAM variables using BootChimeCfg.efi It's default chime sound, you don't need bootchime.wav in root of efi if you used same sound With AudioDxe.efi and BootChimeDXE.efi then you will get same sound. Just use bootchime.wav if you want different sound then apple sound default chime.Sorry for bad englishSent from my Mi Note 2 using Tapatalk Link to comment Share on other sites More sharing options...
Andres ZeroCross Posted January 28, 2019 Share Posted January 28, 2019 5 hours ago, Matgen84 said: Hi There is a issue with PlayAsync on my system: <key>GUI</key> <dict> <key>PlayAsync</key> <true/> I've a sound before enter Clover GUI. After, no keyboard, no mouse. It's like freeze Issue. Make sure you use latest Clover (r4862 is good) 1. Make sure there are sound.wav and sound_night.wav ini your Theme Folder 2. Set PlayAsync=True Post the result Link to comment Share on other sites More sharing options...
Andres ZeroCross Posted January 28, 2019 Share Posted January 28, 2019 What???? I don't have PlayAsync enabled whatsoever! My chime works great! PlayAsync is not needed, and can actually interfere. Andres, you seem like you're scrambling all over the place......You don't understand.Play async is not related to boot chime after gui.It's about sound from theme folder.Sent from my Mi Note 2 using Tapatalk What???? I don't have PlayAsync enabled whatsoever! My chime works great! PlayAsync is not needed, and can actually interfere. Andres, you seem like you're scrambling all over the place......If you want play audio before GUI CLOVER and continue play in GUI CLOVER then you need to set PlayAsync = True.Boot chime while apple logo is different thing.Read more before comment...Sent from my Mi Note 2 using Tapatalk Link to comment Share on other sites More sharing options...
Andres ZeroCross Posted January 28, 2019 Share Posted January 28, 2019 (edited) 16 minutes ago, meaganmargaret said: Okay, fine. I'd love to know the use case for such a function.....but never mind, I'm out....... Let me explain detail for you 1. Officially @Slice don't want support BootChimeDxe.efi 2. BootChimeDxe.efi has built-in Chime sound,, to overide default sound you need to put "bootchime.wav" in root directory of EFI and THIS IS for audio playback when you PRESS enter at macOS partition or when you boot to your macOS partition. 3. sound.wav and sound_night.wav are for playback sound BEFORE or WHILE in GUI CLOVER 4. If you set PlayAsync=False while Sound.wav and Sound_night.wav in theme clover then you will hear sound before GUI CLOVER until finish. After sound finish then GUI CLOVER will be appeared. 5. If you set PlayAsync=True while sound.wav and sound_night.wav in Theme folder then music will be played before and while in GUI CLOVER. You won't spend your time to listen music until finish before reach CLOVER. So,, you only want to hear SOUND after select macOS partition, and it's only about BOOTCHIMEDXE.efi. It's not related to PlayAsync, Sound in Theme folder. So STOP mixed everythng here. Just put the configuartion as you wish,, but it's not same like other wish. I hope you understand. Sorry for bad english Edited January 28, 2019 by Andres ZeroCross 2 Link to comment Share on other sites More sharing options...
Andres ZeroCross Posted January 28, 2019 Share Posted January 28, 2019 (edited) 1 minute ago, meaganmargaret said: Good for you, you want to play music.sounds before and during Clover loading? Okay, great. Ah,, finally you understand. And @Matgen84 want to use audio from theme folder too. So you and matgen have different situation and different solution Edited January 28, 2019 by Andres ZeroCross 1 Link to comment Share on other sites More sharing options...
Matgen84 Posted January 28, 2019 Share Posted January 28, 2019 (edited) 5 hours ago, Andres ZeroCross said: It's like freeze Issue. Make sure you use latest Clover (r4862 is good) 1. Make sure there are sound.wav and sound_night.wav ini your Theme Folder 2. Set PlayAsync=True Post the result I use latest Clover r4864: Sound.wav is in my Theme folder (I use only daytime) As I said before I set PalyAsync=true I've a sound before enter Clover GUI. Once on Clover GUI, no keyboard, no mouse. All works well with PlayAsync=false (Realtek ALC892) Edited January 28, 2019 by Matgen84 Link to comment Share on other sites More sharing options...
Badruzeus Posted January 28, 2019 Share Posted January 28, 2019 26 minutes ago, Matgen84 said: I use latest Clover r4864: Sound.wav is in my Theme folder (I use only daytime) As I said before I set PalyAsync=true I've a sound before enter Clover GUI. Once on Clover GUI, no keyboard, no mouse. All works well with PlayAsync=false (Realtek ALC892) Any boot log? Do you have FileVault drivers installed, or PS2 / USB *.efi drivers for KB-Mouse? Using AptioMemory* or OsxAptio*? Link to comment Share on other sites More sharing options...
yapan4 Posted January 28, 2019 Share Posted January 28, 2019 (edited) 11 hours ago, Sherlocks said: upload your clover preboot or booted log. 나의 LG-F800S 의 Tapatalk에서 보냄 Note: temporary i use old 120Gb HDD for beta testing bootlog.txt Edited January 28, 2019 by yapan4 Link to comment Share on other sites More sharing options...
Slice Posted January 28, 2019 Share Posted January 28, 2019 2 hours ago, Matgen84 said: I use latest Clover r4864: Sound.wav is in my Theme folder (I use only daytime) As I said before I set PalyAsync=true I've a sound before enter Clover GUI. Once on Clover GUI, no keyboard, no mouse. All works well with PlayAsync=false (Realtek ALC892) There is a bug in AudioDxe-64.efi provided in Clover repo. If you want PlatAsync=true then you have to replace it by the driver from here AudioPkg-R1-RELEASE.zip I am working to fix the mistake. 2 1 Link to comment Share on other sites More sharing options...
Badruzeus Posted January 28, 2019 Share Posted January 28, 2019 1 minute ago, Slice said: There is a bug in AudioDxe-64.efi provided in Clover repo. If you want PlatAsync=true then you have to replace it by the driver from here AudioPkg-R1-RELEASE.zip I am working to fix the mistake. Actually, from r4843 (or earlier); provided AudioDxe-64.efi also made stuck at Apple logo if BootChimeDxe.efi is installed on \efi\clover\drivers64uefi. (Since you've suggested to not discuss about BootChimeDxe here so, I never reported this issue). Link to comment Share on other sites More sharing options...
Slice Posted January 28, 2019 Share Posted January 28, 2019 1 minute ago, Badruzeus said: Actually, from r4843 (or earlier); provided AudioDxe-64.efi also made stuck at Apple logo if BootChimeDxe.efi is installed on \efi\clover\drivers64uefi. (Since you've suggested to not discuss about BootChimeDxe here so, I never reported this issue). Moreover PlayAsync caused broken sound so why I implemented the switch YES/NO. Some mistakes already resolved in Goldfish repo and in Clover but not finally. 1 Link to comment Share on other sites More sharing options...
