bronxteck Posted March 28, 2017 Share Posted March 28, 2017 well escape key also does not function using the spacebar options. but esc works fine in option menu idk if thats related but it's been like that for a long while. probably since GUI sub menus was introduced. Link to comment Share on other sites More sharing options...
DemisesAngel Posted March 28, 2017 Share Posted March 28, 2017 I cannot figure out why Clover isn't using the nVidia Driver, yes it's installed, or why it's not using my countdown (timer) preferences on the boot selection screen. If I use the boot option of "nvda_drv=1" at the boot selection screen, then it is enabled and the appropriate kexts load (verified through kextstat). It has to be simple enough. <?xml version="1.0" encoding="UTF-8"?> <!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd"> <plist version="1.0"> <dict> <key>ACPI</key> <dict> <key>DSDT</key> <dict> <key>Debug</key> <false/> <key>DropOEM_DSM</key> <false/> <key>Fixes</key> <dict> <key>AddDTGP_0001</key> <true/> <key>AddHDMI_8000000</key> <true/> <key>AddPNLF_1000000</key> <true/> <key>DeleteUnused_400000</key> <true/> <key>FIX_ACST_4000000</key> <true/> <key>FIX_ADP1_800000</key> <true/> <key>FIX_RTC_20000</key> <true/> <key>FIX_S3D_2000000</key> <true/> <key>FIX_TMR_40000</key> <true/> <key>FIX_WAK_200000</key> <true/> <key>FixAirport_4000</key> <true/> <key>FixDarwin_0002</key> <true/> <key>FixDisplay_0100</key> <true/> <key>FixFirewire_0800</key> <true/> <key>FixHDA_8000</key> <true/> <key>FixHPET_0010</key> <true/> <key>FixIPIC_0040</key> <true/> <key>FixLAN_2000</key> <true/> <key>FixRegions_10000000</key> <true/> <key>FixSBUS_0080</key> <true/> <key>FixShutdown_0004</key> <true/> <key>FixUSB_1000</key> <true/> <key>NewWay_80000000</key> <true/> </dict> <key>Name</key> <string>DSDT.aml</string> <key>ReuseFFFF</key> <false/> </dict> <key>DropTables</key> <array> <dict> <key>Signature</key> <string>DMAR</string> </dict> <dict> <key>Signature</key> <string>SSDT</string> <key>TableId</key> <string>CpuPm</string> </dict> <dict> <key>Signature</key> <string>SSDT</string> <key>TableId</key> <string>Cpu0Ist</string> </dict> </array> <key>HaltEnabler</key> <true/> <key>SSDT</key> <dict> <key>DropOem</key> <true/> <key>Generate</key> <true/> </dict> </dict> <key>Boot</key> <dict> <key>Arguments</key> <string>darkwake=0 nvda_drv=1 kext-dev-mode=1 rootless=0</string> <key>CustomLogo</key> <false/> <key>Debug</key> <false/> <key>DefaultLoader</key> <string>BOOTX64.efi</string> <key>DefaultVolume</key> <string>Macintosh SSD</string> <key>Legacy</key> <string>PBR</string> <key>NeverHibernate</key> <true/> <key>Secure</key> <false/> <key>Timeout</key> <integer>10</integer> <key>XMPDetection</key> <string>Yes</string> </dict> <key>CPU</key> <dict> <key>UseARTFrequency</key> <false/> </dict> <key>Devices</key> <dict> <key>Audio</key> <dict> <key>Inject</key> <string>1</string> </dict> <key>USB</key> <dict> <key>AddClockID</key> <true/> <key>FixOwnership</key> <true/> <key>Inject</key> <true/> </dict> </dict> <key>GUI</key> <dict> <key>Language</key> <string>en:0</string> <key>Mouse</key> <dict> <key>DoubleClick</key> <integer>500</integer> <key>Enabled</key> <false/> <key>Mirror</key> <false/> <key>Speed</key> <integer>8</integer> </dict> <key>Scan</key> <true/> <key>ScreenResolution</key> <string>1920x1080</string> <key>Theme</key> <string>universe</string> </dict> <key>Graphics</key> <dict> <key>Inject</key> <dict> <key>ATI</key> <false/> <key>Intel</key> <false/> <key>NVidia</key> <false/> </dict> <key>NvidiaSingle</key> <false/> </dict> <key>KernelAndKextPatches</key> <dict> <key>AppleRTC</key> <true/> <key>AsusAICPUPM</key> <false/> <key>Debug</key> <false/> <key>KernelCpu</key> <false/> <key>KernelHaswellE</key> <false/> <key>KernelLapic</key> <false/> <key>KernelPm</key> <false/> <key>KextsToPatch</key> <array> <dict> <key>Comment</key> <string>t1-AppleHDA/Resources/xml>zml</string> <key>Disabled</key> <false/> <key>Find</key> <data> eG1sLnps </data> <key>Name</key> <string>AppleHDA</string> <key>Replace</key> <data> em1sLnps </data> </dict> <dict> <key>Comment</key> <string>t1-10.9-10.12-AppleHDA/Realtek ALC1150</string> <key>Disabled</key> <false/> <key>Find</key> <data> ixnUEQ== </data> <key>Name</key> <string>AppleHDA</string> <key>Replace</key> <data> AAnsEA== </data> </dict> <dict> <key>Comment</key> <string>t1-10.12-AppleHDA/Realtek ALC...</string> <key>Disabled</key> <false/> <key>Find</key> <data> ihnUEQ== </data> <key>Name</key> <string>AppleHDA</string> <key>Replace</key> <data> AAAAAA== </data> </dict> </array> </dict> <key>RtVariables</key> <dict> <key>ROM</key> <string>UseMacAddr0</string> </dict> <key>SMBIOS</key> <dict> <key>BiosReleaseDate</key> <string>10/12/2012</string> <key>BiosVendor</key> <string>Apple Inc.</string> <key>BiosVersion</key> <string>IM131.88Z.010A.B05.1210121459</string> <key>Board-ID</key> <string>[Removed to Post]</string> <key>BoardManufacturer</key> <string>Apple Inc.</string> <key>BoardSerialNumber</key> <string>[Removed to Post]</string> <key>BoardType</key> <integer>10</integer> <key>ChassisAssetTag</key> <string>iMac-Aluminum</string> <key>ChassisManufacturer</key> <string>Apple Inc.</string> <key>ChassisType</key> <string>13</string> <key>Family</key> <string>iMac</string> <key>Manufacturer</key> <string>Apple Inc.</string> <key>ProductName</key> <string>iMac13,2</string> <key>SerialNumber</key> <string>[Removed to Post]</string> <key>SmUUID</key> <string>[Removed to Post]</string> <key>Trust</key> <false/> <key>Version</key> <string>1.0</string> </dict> <key>SystemParameters</key> <dict> <key>InjectKexts</key> <string>Yes</string> <key>InjectSystemID</key> <true/> </dict> </dict> </plist> I apologize if this isn't appropriate, but I cannot start a new topic for my issue. Link to comment Share on other sites More sharing options...
artur_pt Posted March 28, 2017 Share Posted March 28, 2017 you mean AMD6000Controller? hello man u came from where Mars? look at earlier post if u don't understand what is write .. use google translator to get some idea good hack 3 Link to comment Share on other sites More sharing options...
artur_pt Posted March 28, 2017 Share Posted March 28, 2017 hello Slice i have problems building last snv version from clover 4045 this is the log .. xcode last update build.txt.zip full_log.txt.zip thanks for ur time Link to comment Share on other sites More sharing options...
Henry2010 Posted March 29, 2017 Share Posted March 29, 2017 (edited) I have updated to 10.12.4 and my 6670 doesn't flicker. But I have to stay at clover 3974. Any version after that will give me a black screen after a verbose boot. So this is related to the graphic card? (reading previous posts now) Thanks. Here is my current Clover config https://pastebin.com/Btq9wj2q EDIT OK, just removed all ATI FB patch codes and clover 4035 works now, with GPU recognized as 6xxx again. still no flicker (?). how can I reproduce this problem to help? Edited March 29, 2017 by Henry2010 Link to comment Share on other sites More sharing options...
bb1045 Posted March 29, 2017 Share Posted March 29, 2017 I just want to upgrade install macOS 10.12.4 from 10.11.6, but I not found the install entry in Clover GUI. boot.efi not found in macOS Install Data dir on 10.12.4, It was moved to: /macOS Install Data/Locked Files/Boot Files/ I added this path to loader.c, and rebuild clover, it works good. Link to comment Share on other sites More sharing options...
Philip Petev Posted March 29, 2017 Share Posted March 29, 2017 hello Slice i have problems building last snv version from clover 4045 this is the log .. xcode last update build.txt.zip thanks for ur time That doesn't seems to be the full log. Link to comment Share on other sites More sharing options...
artur_pt Posted March 29, 2017 Share Posted March 29, 2017 That doesn't seems to be the full log. hello another log full_log.txt.zip thanks for ur time Link to comment Share on other sites More sharing options...
droples Posted March 29, 2017 Share Posted March 29, 2017 This is a problem of compiling a clover on systems with XCODE-8.3. If I use Xcode-8.2.1 then there is no problem. iMac-Droplets-2:clover droplets$ ./ebuild.sh -fr -D NO_GRUB_DRIVERS_EMBEDDED -D EXIT_USBKB=1 TOOLCHAIN_DIR: /Users/droplets/src/edk2/clover/../../opt/local NASM_PREFIX: /Users/droplets/src/edk2/clover/../../opt/local/bin/ NASM_VER: 2.12.02 Initializing workspace Loading previous configuration from /Users/droplets/src/edk2/Conf/BuildEnv.sh WORKSPACE: /Users/droplets/src/edk2 EDK_TOOLS_PATH: /Users/droplets/src/edk2/BaseTools CONF_PATH: /Users/droplets/src/edk2/Conf Running edk2 build for CloverX64 using the command: build -D NO_GRUB_DRIVERS_EMBEDDED -D EXIT_USBKB=1 -D USE_LOW_EBDA -p Clover/Clover.dsc -a X64 -b RELEASE -t XCODE5 -n 9 Build environment: Darwin-16.5.0-x86_64-i386-64bit Build start time: 22:21:16, Mar.28 2017 WORKSPACE = /Users/droplets/src/edk2 ECP_SOURCE = /Users/droplets/src/edk2/EdkCompatibilityPkg EDK_SOURCE = /Users/droplets/src/edk2/EdkCompatibilityPkg EFI_SOURCE = /Users/droplets/src/edk2/EdkCompatibilityPkg EDK_TOOLS_PATH = /Users/droplets/src/edk2/BaseTools CONF_PATH = /Users/droplets/src/edk2/Conf Architecture(s) = X64 Build target = RELEASE Toolchain = XCODE5 Active Platform = /Users/droplets/src/edk2/Clover/Clover.dsc Flash Image Definition = /Users/droplets/src/edk2/Clover/Clover.fdf Processing meta-data ......... done! Building ... /Users/droplets/src/edk2/MdePkg/Library/BasePcdLibNull/BasePcdLibNull.inf [X64] Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseDebugLibNull/BaseDebugLibNull.inf [X64] Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseMemoryLib/BaseMemoryLib.inf [X64] [CC] PcdLib Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseLib/BaseLib.inf [X64] [CC] DebugLib Building ... /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/BasePrintLib.inf [X64] Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseReportStatusCodeLibNull/BaseReportStatusCodeLibNull.inf [X64] [CC] SetMem Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseIoLibIntrinsic/BaseIoLibIntrinsic.inf [X64] [CC] ScanMem64Wrapper Building ... /Users/droplets/src/edk2/MdeModulePkg/Library/DxeCoreMemoryAllocationLib/DxeCoreMemoryAllocationLib.inf [X64] /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:713:23: error: cannot compile this va_arg expression yet Width = VA_ARG (VaListMarker, UINTN); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:719:27: error: cannot compile this va_arg expression yet Precision = VA_ARG (VaListMarker, UINTN); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:812:21: error: cannot compile this va_arg expression yet Value = VA_ARG (VaListMarker, int); ^~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:81: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:818:21: error: cannot compile this va_arg expression yet Value = VA_ARG (VaListMarker, INT64); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:909:28: error: cannot compile this va_arg expression yet ArgumentString = VA_ARG (VaListMarker, CHAR8 *); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:927:23: error: cannot compile this va_arg expression yet Character = VA_ARG (VaListMarker, UINTN) & 0xffff; ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:937:21: error: cannot compile this va_arg expression yet TmpGuid = VA_ARG (VaListMarker, GUID *); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:970:21: error: cannot compile this va_arg expression yet TmpTime = VA_ARG (VaListMarker, TIME *); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeo[CC] ScanMem32Wrapper f (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:994:20: error: cannot compile this va_arg expression yet Status = VA_ARG (VaListMarker, RETURN_STATUS); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ 9 errors generated. make: *** [/Users/droplets/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BasePrintLib/BasePrintLib/OUTPUT/PrintLibInternal.obj] Error 1 Building ... /Users/droplets/src/edk2/MdePkg/Library/DxeCoreEntryPoint/DxeCoreEntryPoint.inf [X64] [CC] CheckSum [CC] BaseReportStatusCodeLib [CC] IoLibMmioBuffer [CC] ScanMem16Wrapper [CC] SwitchStack [CC] ScanMem8Wrapper [CC] DxeCoreEntryPoint [CC] SwapBytes64 [CC] ZeroMemWrapper [CC] MemoryAllocationLib [CC] IoHighLevel [CC] CompareMemWrapper [CC] IoLibGcc [CC] DxeCoreMemoryProfileLibNull [CC] SetMem64Wrapper [CC] IoLib [NASM] IoFifo [SLINK] BasePcdLibNull Building ... /Users/droplets/src/edk2/MdePkg/Library/UefiRuntimeServicesTableLib/UefiRuntimeServicesTableLib.inf [X64] [SLINK] BaseDebugLibNull Building ... /Users/droplets/src/edk2/MdePkg/Library/UefiDevicePathLib/UefiDevicePathLib.inf [X64] [CC] UefiRuntimeServicesTableLib [SLINK] UefiRuntimeServicesTableLib Building ... /Users/droplets/src/edk2/MdePkg/Library/UefiBootServicesTableLib/UefiBootServicesTableLib.inf [X64] [CC] DevicePathUtilities [CC] UefiBootServicesTableLib [SLINK] UefiBootServicesTableLib Building ... /Users/droplets/src/edk2/MdePkg/Library/BasePeCoffExtraActionLibNull/BasePeCoffExtraActionLibNull.inf [X64] [CC] PeCoffExtraActionLib [SLINK] BaseReportStatusCodeLibNull Building ... /Users/droplets/src/edk2/MdePkg/Library/DxeCoreHobLib/DxeCoreHobLib.inf [X64] [SLINK] PeCoffExtraActionLibNull Building ... /Users/droplets/src/edk2/MdePkg/Library/UefiLib/UefiLib.inf [X64] [SLINK] DxeCoreEntryPoint Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseCacheMaintenanceLib/BaseCacheMaintenanceLib.inf [X64] [CC] HobLib [SLINK] DxeCoreHobLib [CC] SwapBytes32 Building ... /Users/droplets/src/edk2/MdePkg/Library/BaseUefiDecompressLib/BaseUefiDecompressLib.inf [X64] [CC] X86Cache [SLINK] BaseCacheMaintenanceLib Building ... /Users/droplets/src/edk2/MdePkg/Library/BasePerformanceLibNull/BasePerformanceLibNull.inf [X64] [CC] UefiLibPrint [CC] DevicePathToText [CC] SwapBytes16 [SLINK] DxeCoreMemoryAllocationLib Building ... /Users/droplets/src/edk2/Clover/Library/VBoxPeCoffLib/VBoxPeCoffLib.inf [X64] [CC] PerformanceLib [CC] LongJump [SLINK] BasePerformanceLibNull Building ... /Users/droplets/src/edk2/MdePkg/Library/BasePeCoffGetEntryPointLib/BasePeCoffGetEntryPointLib.inf [X64] [CC] UefiNotTiano [CC] SetMem32Wrapper [CC] SetJump [CC] SetMem16Wrapper [CC] RShiftU64 [CC] PeCoffGetEntryPoint [CC] BaseUefiDecompressLib [SLINK] BasePeCoffGetEntryPointLib Building ... /Users/droplets/src/edk2/MdePkg/Library/DxeExtractGuidedSectionLib/DxeExtractGuidedSectionLib.inf [X64] [SLINK] BaseUefiDecompressLib [CC] SetMemWrapper Building ... /Users/droplets/src/edk2/Clover/Library/DuetTimerLib/DuetTimerLib.inf [X64] [CC] RRotU64 [CC] CopyMemWrapper [CC] RRotU32 [CC] UefiDriverModel [SLINK] BaseIoLibIntrinsic Building ... /Users/droplets/src/edk2/MdePkg/Library/DxeServicesLib/DxeServicesLib.inf [X64] [CC] IsZeroBufferWrapper [CC] BasePeCoff [CC] MultU64x64 [CC] DxeExtractGuidedSectionLib [CC] PeCoffLoaderEx /Users/droplets/src/edk2/MdePkg/Library/UefiLib/Console.c:426:20: error: cannot compile this va_arg expression yet while ((String = VA_ARG (Args, CHAR16 *)) != NULL) { ^~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Library/UefiLib/Console.c:499:20: error: cannot compile this va_arg expression yet [SLINK] DxeExtractGuidedSectionLib while ((String = VA_ARG (Args, CHAR16 *)) != NULL && NumberOfLines > 0) { ^~~~~~~~~~~~~~~~~~~~~~~ /Users/droplets/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ 2 errors generated. Building ... /Users/droplets/src/edk2/MdeModulePkg/Library/DebugAgentLibNull/DebugAgentLibNull.inf [X64] make: *** [/Users/droplets/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/UefiLib/UefiLib/OUTPUT/Console.obj] Error 1 build.py... : error 7000: Failed to execute command make tbuild [/Users/droplets/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/UefiLib/UefiLib] build.py... : error 7000: Failed to execute command make tbuild [/Users/droplets/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BasePrintLib/BasePrintLib] build.py... : error F002: Failed to build module /Users/droplets/src/edk2/MdePkg/Library/UefiLib/UefiLib.inf [X64, XCODE5, RELEASE] - Failed - Build end time: 22:21:32, Mar.28 2017 Build total time: 00:00:16 iMac-Droplets-2:clover droplets$ 2 Link to comment Share on other sites More sharing options...
PMheart Posted March 29, 2017 Share Posted March 29, 2017 I think this is related to the new compiler... Well, back to Xcode 8.2.1 for now. Link to comment Share on other sites More sharing options...
Zenith432 Posted March 29, 2017 Share Posted March 29, 2017 (edited) Stay tuned Edit: Rev 4046 I think this is related to the new compiler... Well, back to Xcode 8.2.1 for now. Edited March 29, 2017 by Zenith432 4 Link to comment Share on other sites More sharing options...
Philip Petev Posted March 29, 2017 Share Posted March 29, 2017 @Zenith432: nice, but those changes break the compilation with Xcode 8.2.1. Just tested it on OS X 10.11.6, it complaints about unknown warning option (-Wno-address-of-packed-member). Running edk2 build for CloverX64 using the command:build -D NO_GRUB_DRIVERS_EMBEDDED -D CHECK_FLAGS -D USE_LOW_EBDA -p Clover/Clover.dsc -a X64 -b RELEASE -t XCODE5 -n 9Build environment: Darwin-15.6.0-x86_64-i386-64bitBuild start time: 20:30:00, Mar.29 2017WORKSPACE = /Users/philip/src/edk2ECP_SOURCE = /Users/philip/src/edk2/EdkCompatibilityPkgEDK_SOURCE = /Users/philip/src/edk2/EdkCompatibilityPkgEFI_SOURCE = /Users/philip/src/edk2/EdkCompatibilityPkgEDK_TOOLS_PATH = /Users/philip/src/edk2/BaseToolsCONF_PATH = /Users/philip/src/edk2/ConfArchitecture(s) = X64Build target = RELEASEToolchain = XCODE5Active Platform = /Users/philip/src/edk2/Clover/Clover.dscFlash Image Definition = /Users/philip/src/edk2/Clover/Clover.fdfProcessing meta-data ........ done!Building ... /Users/philip/src/edk2/MdePkg/Library/BasePcdLibNull/BasePcdLibNull.inf [X64]Building ... /Users/philip/src/edk2/MdePkg/Library/BaseDebugLibNull/BaseDebugLibNull.inf [X64]Building ... /Users/philip/src/edk2/MdePkg/Library/BaseMemoryLib/BaseMemoryLib.inf [X64][CC] PcdLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/BaseLib/BaseLib.inf [X64][sLINK] BasePcdLibNull[CC] DebugLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/BasePrintLib/BasePrintLib.inf [X64][sLINK] BaseDebugLibNull[CC] SetMemBuilding ... /Users/philip/src/edk2/MdePkg/Library/BaseReportStatusCodeLibNull/BaseReportStatusCodeLibNull.inf [X64][CC] ScanMem64Wrapper[CC] ScanMem32WrapperBuilding ... /Users/philip/src/edk2/MdePkg/Library/BaseIoLibIntrinsic/BaseIoLibIntrinsic.inf [X64][CC] ScanMem16Wrapper[CC] CheckSum[CC] ScanMem8WrapperBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/DxeCoreMemoryAllocationLib/DxeCoreMemoryAllocationLib.inf [X64][CC] SwitchStack[CC] BaseReportStatusCodeLib[sLINK] BaseReportStatusCodeLibNull[CC] ZeroMemWrapperBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxeCoreEntryPoint/DxeCoreEntryPoint.inf [X64][CC] IoLibMmioBufferBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiRuntimeServicesTableLib/UefiRuntimeServicesTableLib.inf [X64][CC] SwapBytes64Building ... /Users/philip/src/edk2/MdePkg/Library/UefiDevicePathLib/UefiDevicePathLib.inf [X64]Building ... /Users/philip/src/edk2/MdePkg/Library/UefiBootServicesTableLib/UefiBootServicesTableLib.inf [X64][CC] CompareMemWrapper[CC] SwapBytes32[CC] SetMem64Wrapper[CC] DxeCoreEntryPoint[CC] UefiRuntimeServicesTableLib[CC] SwapBytes16[sLINK] DxeCoreEntryPointBuilding ... /Users/philip/src/edk2/MdePkg/Library/BasePeCoffExtraActionLibNull/BasePeCoffExtraActionLibNull.inf [X64][sLINK] UefiRuntimeServicesTableLib[CC] UefiBootServicesTableLib[CC] SetMem32Wrapper[sLINK] UefiBootServicesTableLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxeCoreHobLib/DxeCoreHobLib.inf [X64][CC] IoHighLevel[CC] LongJump[CC] MemoryAllocationLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiLib/UefiLib.inf [X64][CC] PeCoffExtraActionLib[CC] SetMem16Wrapper[CC] SetJump[sLINK] PeCoffExtraActionLibNullBuilding ... /Users/philip/src/edk2/MdePkg/Library/BaseCacheMaintenanceLib/BaseCacheMaintenanceLib.inf [X64][CC] IoLibGcc[CC] DxeCoreMemoryProfileLibNull[CC] SetMemWrapper[sLINK] DxeCoreMemoryAllocationLib[CC] RShiftU64Building ... /Users/philip/src/edk2/MdePkg/Library/BaseUefiDecompressLib/BaseUefiDecompressLib.inf [X64][CC] IoLib[CC] HobLib[CC] CopyMemWrapper[CC] X86Cache[CC] RRotU64[sLINK] DxeCoreHobLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/BasePerformanceLibNull/BasePerformanceLibNull.inf [X64][sLINK] BaseCacheMaintenanceLib[CC] DevicePathUtilities[CC] IsZeroBufferWrapperBuilding ... /Users/philip/src/edk2/Clover/Library/VBoxPeCoffLib/VBoxPeCoffLib.inf [X64][CC] UefiLibPrint[CC] RRotU32[CC] PerformanceLib[CC] MultU64x64[sLINK] BasePerformanceLibNullBuilding ... /Users/philip/src/edk2/MdePkg/Library/BasePeCoffGetEntryPointLib/BasePeCoffGetEntryPointLib.inf [X64][CC] MemLibGeneric[CC] MultU64x32[CC] UefiNotTiano[CC] PrintLibInternal[CC] MultS64x64[NASM] IoFifo[CC] MemLibGuid[sLINK] BaseIoLibIntrinsicBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxeExtractGuidedSectionLib/DxeExtractGuidedSectionLib.inf [X64][CC] PeCoffGetEntryPoint[sLINK] BasePeCoffGetEntryPointLib[CC] PrintLib[CC] ModU64x32Building ... /Users/philip/src/edk2/Clover/Library/DuetTimerLib/DuetTimerLib.inf [X64][sLINK] BasePrintLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxeServicesLib/DxeServicesLib.inf [X64][CC] LShiftU64[CC] BaseUefiDecompressLib[sLINK] BaseUefiDecompressLibBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/DebugAgentLibNull/DebugAgentLibNull.inf [X64][CC] CopyMem[sLINK] BaseMemoryLib[CC] LRotU64Building ... /Users/philip/src/edk2/MdeModulePkg/Library/CpuExceptionHandlerLibNull/CpuExceptionHandlerLibNull.inf [X64][CC] DxeExtractGuidedSectionLib[sLINK] DxeExtractGuidedSectionLib[CC] UefiDriverModel[CC] DebugAgentLibNullBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiMemoryAllocationLib/UefiMemoryAllocationLib.inf [X64][CC] LRotU32[sLINK] DebugAgentLibNull[CC] X86TimerLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxeHobLib/DxeHobLib.inf [X64][sLINK] DuetTimerLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiDriverEntryPoint/UefiDriverEntryPoint.inf [X64][CC] BasePeCoff[CC] LowBitSet64[CC] CpuExceptionHandlerLibNull[sLINK] CpuExceptionHandlerLibNullBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiRuntimeLib/UefiRuntimeLib.inf [X64][CC] PeCoffLoaderEx[sLINK] VBoxPeCoffLib[CC] LowBitSet32[CC] DxeServicesLibBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/VarCheckLib/VarCheckLib.inf [X64][sLINK] DxeServicesLib[CC] MemoryAllocationLib[CC] Console[sLINK] UefiMemoryAllocationLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/BaseSynchronizationLib/BaseSynchronizationLib.inf [X64][CC] HighBitSet64[CC] HobLib[CC] DriverEntryPoint[sLINK] DxeHobLib[sLINK] UefiDriverEntryPointBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxeServicesTableLib/DxeServicesTableLib.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Library/TpmMeasurementLibNull/TpmMeasurementLibNull.inf [X64][CC] HighBitSet32Building ... /Users/philip/src/edk2/MdeModulePkg/Library/AuthVariableLibNull/AuthVariableLibNull.inf [X64][CC] RuntimeLib[CC] DevicePathToText[CC] InternalGetSpinLockProperties[sLINK] UefiRuntimeLibBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/VarCheckUefiLib/VarCheckUefiLib.inf [X64][CC] GetPowerOfTwo64[CC] GccInline[CC] TpmMeasurementLibNull[CC] DxeServicesTableLib[sLINK] DxeServicesTableLibBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/DxeCapsuleLibNull/DxeCapsuleLibNull.inf [X64][CC] GetPowerOfTwo32[sLINK] TpmMeasurementLibNullBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/DxeSecurityManagementLib/DxeSecurityManagementLib.inf [X64][CC] AuthVariableLibNull[CC] SynchronizationGcc[sLINK] AuthVariableLibNull[CC] DivU64x64Remainder[sLINK] BaseSynchronizationLib[CC] VarCheckLib[sLINK] VarCheckLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/DxePcdLib/DxePcdLib.inf [X64][CC] DivU64x32RemainderBuilding ... /Users/philip/src/edk2/Clover/Library/UefiHiiServicesLib/UefiHiiServicesLib.inf [X64][CC] DxeCapsuleLibNull[sLINK] DxeCapsuleLibNullBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/UefiHiiLib/UefiHiiLib.inf [X64][CC] UefiLib[CC] DivU64x32Building ... /Users/philip/src/edk2/MdeModulePkg/Library/CustomizedDisplayLib/CustomizedDisplayLib.inf [X64][sLINK] UefiLib[CC] VarCheckUefiLibNullClassBuilding ... /Users/philip/src/edk2/Clover/Library/LzmaCustomDecompressLib/LzmaCustomDecompressLib.inf [X64][sLINK] VarCheckUefiLib[CC] DivS64x64Remainder[CC] UefiHiiServicesLibBuilding ... /Users/philip/src/edk2/Clover/Library/GenericBdsLib/GenericBdsLib.inf [X64][CC] DxeSecurityManagementLib[sLINK] DxeSecurityManagementLib[sLINK] UefiHiiServicesLibBuilding ... /Users/philip/src/edk2/Clover/Library/OsxBdsPlatformLib/PlatformBds.inf [X64][CC] ARShiftU64Building ... /Users/philip/src/edk2/MdePkg/Library/BasePciCf8Lib/BasePciCf8Lib.inf [X64][CC] LzmaDecompress[CC] DxePcdLib[CC] BitField[sLINK] DxePcdLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/BasePciLibCf8/BasePciLibCf8.inf [X64][CC] DevicePath[CC] CpuDeadLoop[CC] CustomizedDisplayLib[CC] Cpu[CC] PciLib[sLINK] BasePciLibCf8Building ... /Users/philip/src/edk2/Clover/Library/MemLogLibDefault/MemLogLibDefault.inf [X64][CC] PciCf8Lib[sLINK] BasePciCf8Lib[CC] LinkedListBuilding ... /Users/philip/src/edk2/Clover/Library/VideoBiosPatchLib/VideoBiosPatchLib.inf [X64][CC] BdsPlatform[CC] Performance[CC] MemLogLib[sLINK] MemLogLibDefaultBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiScsiLib/UefiScsiLib.inf [X64][CC] VideoBiosPatchLib[CC] PlatformData[sLINK] DuetBdsBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiUsbLib/UefiUsbLib.inf [X64][CC] CustomizedDisplayLibInternal[CC] AutoGen[CC] LzFind[sLINK] CustomizedDisplayLibBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/UefiSortLib/UefiSortLib.inf [X64][CC] BdsConnect[CC] Hid[CC] UefiScsiLib[sLINK] UefiScsiLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiFileHandleLib/UefiFileHandleLib.inf [X64][CC] 915resolution[CC] HiiLib[CC] UefiSortLib[CC] UsbDxeLib[sLINK] UefiSortLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiApplicationEntryPoint/UefiApplicationEntryPoint.inf [X64][sLINK] UefiUsbLibBuilding ... /Users/philip/src/edk2/ShellPkg/Library/UefiShellLib/UefiShellLib.inf [X64][CC] HiiString[CC] edid[sLINK] VideoBiosPatchLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/UefiMemoryLib/UefiMemoryLib.inf [X64][CC] ApplicationEntryPoint[sLINK] UefiApplicationEntryPoint[CC] UefiFileHandleLib[sLINK] UefiFileHandleLibBuilding ... /Users/philip/src/edk2/Clover/Library/OpensslLib/OpensslLibNull.inf [X64][CC] BdsMisc[CC] HiiLanguageBuilding ... /Users/philip/src/edk2/MdeModulePkg/Library/DxeNetLib/DxeNetLib.inf [X64][CC] DevicePathFromText[sLINK] UefiHiiLibBuilding ... /Users/philip/src/edk2/MdePkg/Library/BaseCpuLib/BaseCpuLib.inf [X64][CC] ScanMem64Wrapper[CC] OpensslLibNull[CC] SafeString/Applications/Xcode.app/Contents/Developer/Toolchains/XcodeDefault.xctoolchain/usr/bin/libtool: file: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/Library/OpensslLib/OpensslLibNull/OUTPUT/OpensslLibNull.obj has no symbolswarning: /Applications/Xcode.app/Contents/Developer/Toolchains/XcodeDefault.xctoolchain/usr/bin/libtool: warning for library: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/Library/OpensslLib/OpensslLibNull/OUTPUT/OpensslLib.lib the table of contents is empty (no object file members in the library define global symbols)[sLINK] OpensslLib[CC] UefiDevicePathLib[sLINK] UefiDevicePathLib[CC] ScanMem32Wrapper[CC] ScanMem16Wrapper[CC] LzmaDec[CC] BdsConsole[ASM] CpuSleep[CC] ScanMem8Wrapper[CC] GuidedSectionExtraction[sLINK] LzmaDecompressLib[CC] ZeroMemWrapper[CC] String[CC] DxeNetLib[ASM] CpuFlushTlb[CC] CompareMemWrapper[CC] FilePaths[sLINK] BaseCpuLib[CC] UefiShellLib[sLINK] UefiShellLib[CC] SetMem64Wrapper[CC] SetMem32Wrapper/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/X64/Thunk16.iii:300: warning: absolute address can not be RIP-relative[NASM] Thunk16[CC] SetMem16Wrapper[CC] Non-existing[CC] NetBuffer[sLINK] DxeNetLib[CC] SetMemWrapper[CC] Math64[CC] Unaligned[CC] CopyMemWrapper[CC] X86WriteIdtr[CC] BdsBoot[CC] X86WriteGdtr[CC] IsZeroBufferWrapper[CC] X86Thunk[CC] String[CC] X86ReadIdtr[CC] MemLibGeneric[CC] AutoGen[CC] X86ReadGdtr[sLINK] GenericBdsLib[CC] X86Msr[CC] MemLibGuid[CC] X86GetInterruptState[CC] MemLib[sLINK] UefiMemoryLib[CC] X86FxSave[CC] X86FxRestore[CC] X86EnablePaging64[CC] X86EnablePaging32[CC] X86DisablePaging64[CC] X86DisablePaging32[CC] X86RdRand[CC] GccInline[ASM] SwitchStack[ASM] SetJump[ASM] LongJump[ASM] EnableDisableInterrupts[ASM] DisablePaging64[ASM] CpuId[ASM] CpuIdEx[ASM] EnableCache[ASM] DisableCache[ASM] RdRand[CC] ChkStkGcc/Applications/Xcode.app/Contents/Developer/Toolchains/XcodeDefault.xctoolchain/usr/bin/libtool: warning same member name (LongJump.obj) in output file used for input files: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/X64/LongJump.obj and: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/LongJump.obj (due to use of basename, truncation, blank padding or duplicate input files)/Applications/Xcode.app/Contents/Developer/Toolchains/XcodeDefault.xctoolchain/usr/bin/libtool: warning same member name (SetJump.obj) in output file used for input files: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/SetJump.obj and: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/X64/SetJump.obj (due to use of basename, truncation, blank padding or duplicate input files)/Applications/Xcode.app/Contents/Developer/Toolchains/XcodeDefault.xctoolchain/usr/bin/libtool: warning same member name (SwitchStack.obj) in output file used for input files: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/SwitchStack.obj and: /Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BaseLib/BaseLib/OUTPUT/X64/SwitchStack.obj (due to use of basename, truncation, blank padding or duplicate input files)[sLINK] BaseLibBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/OsxDxeIpl/DxeIpl.inf [X64]Building ... /Users/philip/src/edk2/Clover/CloverEFI/OsxDxeCore/DxeMain.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Universal/PCD/Dxe/Pcd.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Universal/WatchdogTimerDxe/WatchdogTimer.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Core/RuntimeDxe/RuntimeDxe.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Universal/MonotonicCounterRuntimeDxe/MonotonicCounterRuntimeDxe.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Universal/Variable/EmuRuntimeDxe/EmuVariableRuntimeDxe.inf [X64][CC] DxeInitBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/FaultTolerantWriteDxe/FaultTolerantWriteDxe.inf [X64]Building ... /Users/philip/src/edk2/MdeModulePkg/Universal/Variable/RuntimeDxe/VariableRuntimeDxe.inf [X64][CC] WatchdogTimer[CC] MonotonicCounter[CC] Crc32[CC] InitVariable[CC] Pcd[CC] AutoGen[sLINK] WatchdogTimer[CC] CoreSectionExtraction[CC] AutoGen[sLINK] MonotonicCounterRuntimeDxe[CC] Reclaim[DLINK1] WatchdogTimer[MTOC] WatchdogTimer[CC] LegacyTable[DLINK1] MonotonicCounterRuntimeDxe[CC] Runtime[MTOC] MonotonicCounterRuntimeDxe[GENFW] WatchdogTimerBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/CapsuleRuntimeDxe/CapsuleRuntimeDxe.inf [X64][GENFW] MonotonicCounterRuntimeDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/MemoryTest/NullMemoryTestDxe/NullMemoryTestDxe.inf [X64][CC] AutoGen[sLINK] RuntimeDxe[CC] HobGeneration[DLINK1] RuntimeDxe[MTOC] RuntimeDxe[CC] FtwMisc[CC] CapsuleService[CC] NullMemoryTest[GENFW] RuntimeDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/SecurityStubDxe/SecurityStubDxe.inf [X64][CC] EmuVariable[CC] Debug[CC] AutoGen[CC] SaveLongModeContext[sLINK] NullMemoryTestDxe[CC] Image[CC] AutoGen[CC] UpdateWorkingBlock[sLINK] EmuVariableRuntimeDxe[DLINK1] NullMemoryTestDxe[CC] Service[MTOC] NullMemoryTestDxe[CC] SecurityStub[CC] EnterDxeCore[DLINK1] EmuVariableRuntimeDxe[MTOC] EmuVariableRuntimeDxe[CC] AutoGen[GENFW] NullMemoryTestDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/Console/ConPlatformDxe/ConPlatformDxe.inf [X64][sLINK] CapsuleRuntimeDxe[GENFW] EmuVariableRuntimeDxe[CC] AutoGenBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/Console/ConSplitterDxe/ConSplitterDxe.inf [X64][sLINK] PcdDxe[DLINK1] CapsuleRuntimeDxe[CC] DebugImageInfo[CC] Defer3rdPartyImageLoad[MTOC] CapsuleRuntimeDxe[DLINK1] PcdDxe[MTOC] PcdDxe[CC] Paging[CC] FaultTolerantWrite[GENFW] CapsuleRuntimeDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/HiiDatabaseDxe/HiiDatabaseDxe.inf [X64][CC] ComponentName[GENFW] PcdDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/SetupBrowserDxe/SetupBrowserDxe.inf [X64][CC] AutoGen[sLINK] SecurityStubDxe[CC] AutoGen[sLINK] DxeIpl[CC] FaultTolerantWriteDxe[CC] Stall[DLINK1] SecurityStubDxe[MTOC] SecurityStubDxe[DLINK1] DxeIpl[MTOC] DxeIpl[CC] ConSplitterGraphics[GENFW] SecurityStubDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/DisplayEngineDxe/DisplayEngineDxe.inf [X64][CC] HiiDatabaseEntry[GENFW] DxeIpl[CC] AutoGenBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/GraphicsConsoleDxe/GraphicsConsoleDxe.inf [X64][CC] ConPlatform[sLINK] FaultTolerantWriteDxe[CC] SetWatchdogTimer[DLINK1] FaultTolerantWriteDxe[CC] ComponentName[MTOC] FaultTolerantWriteDxe[CC] AutoGen[sLINK] ConPlatformDxe[GENFW] FaultTolerantWriteDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/DevicePathDxe/DevicePathDxe.inf [X64][CC] ComponentName[DLINK1] ConPlatformDxe[CC] InstallConfigurationTable[MTOC] ConPlatformDxe[GENFW] ConPlatformDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/SmbiosDxe/SmbiosDxe.inf [X64][CC] LaffStd[CC] DevicePath[CC] Library[CC] AutoGen[CC] Variable[sLINK] DevicePathDxe[DLINK1] DevicePathDxe[MTOC] DevicePathDxe[CC] Image[GENFW] DevicePathDxeBuilding ... /Users/philip/src/edk2/DuetPkg/SmbiosGenDxe/SmbiosGen.inf [X64][CC] VariableDxe[CC] SmbiosDxe[CC] GraphicsConsole[CC] ImageEx[CC] DriverSupport[CC] AutoGen[CC] AutoGen[CC] Measurement[sLINK] GraphicsConsoleDxe[sLINK] SmbiosDxe[DLINK1] SmbiosDxe[DLINK1] GraphicsConsoleDxe[MTOC] SmbiosDxe[MTOC] GraphicsConsoleDxe[CC] SmbiosGen[CC] TcgMorLockDxe[GENFW] SmbiosDxeBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/OsxEfiLdr/EfiLdr.inf [X64][CC] Notify[GENFW] GraphicsConsoleDxeBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/OsxBdsDxe/BdsDxe.inf [X64][CC] AutoGen[sLINK] SmbiosGenDxe[CC] VarCheck[DLINK1] SmbiosGenDxe[CC] EfiLoader[MTOC] SmbiosGenDxe[CC] Locate[GENFW] SmbiosGenDxeBuilding ... /Users/philip/src/edk2/MdeModulePkg/Universal/EbcDxe/EbcDxe.inf [X64][CC] ConSplitter[CC] HwErrRecSupport[CC] VariableExLib[CC] Debug[CC] AutoGen[VFR] BdsDxe[sLINK] ConSplitterDxe[CC] AutoGen[CC] EbcDebuggerHook[sLINK] VariableRuntimeDxe[DLINK1] ConSplitterDxe[MTOC] ConSplitterDxe[CC] DeviceManagerVfr[DLINK1] VariableRuntimeDxe[CC] Setup[MTOC] VariableRuntimeDxe[CC] FormDisplay[GENFW] ConSplitterDxeBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/UefiCpuPkg/CpuIo2Dxe/CpuIo2Dxe.inf [X64][CC] PeLoader[VFR] BdsDxe[GENFW] VariableRuntimeDxeBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/CpuDxe/Cpu.inf [X64][CC] Handle[CC] DriverHealthVfr[CC] Support[CC] CpuIo2Dxe[CC] AutoGen[sLINK] EfiLoader[CC] AutoGen[sLINK] CpuIo2Dxe[DLINK1] EfiLoader[MTOC] EfiLoader[DLINK1] CpuIo2Dxe[CC] ProcessOptions[MTOC] CpuIo2Dxe/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/CloverEFI/CpuDxe/Cpu/OUTPUT/X64/CpuInterrupt.iii:30: warning: absolute address can not be RIP-relative/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/CloverEFI/CpuDxe/Cpu/OUTPUT/X64/CpuInterrupt.iii:31: warning: absolute address can not be RIP-relative/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/CloverEFI/CpuDxe/Cpu/OUTPUT/X64/CpuInterrupt.iii:32: warning: absolute address can not be RIP-relative/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/CloverEFI/CpuDxe/Cpu/OUTPUT/X64/CpuInterrupt.iii:36: warning: absolute address can not be RIP-relative/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/CloverEFI/CpuDxe/Cpu/OUTPUT/X64/CpuInterrupt.iii:37: warning: absolute address can not be RIP-relative/Users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/CloverEFI/CpuDxe/Cpu/OUTPUT/X64/CpuInterrupt.iii:38: warning: absolute address can not be RIP-relative[GENFW] EfiLoaderBuilding ... /Users/philip/src/edk2/PcAtChipsetPkg/8259InterruptControllerDxe/8259.inf [X64][NASM] CpuInterrupt[GENFW] CpuIo2DxeBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/AcpiReset/Reset.inf [X64][CC] EbcExecute[CC] Gcd[CC] 8259[CC] DeviceManager[CC] Reset[CC] Cpu[VFR] BdsDxe[CC] AutoGen[CC] IfrParse[sLINK] Legacy8259[CC] EbcInt[CC] AutoGen[sLINK] AcpiReset[CC] BootManagerVfr[CC] AutoGen[CC] Pool[DLINK1] Legacy8259[sLINK] Cpu[DLINK1] AcpiReset[MTOC] Legacy8259[MTOC] AcpiReset[DLINK1] Cpu[MTOC] Cpu[CC] ConfigRouting[GENFW] Legacy8259Building ... /Users/philip/src/edk2/MdeModulePkg/Universal/Metronome/Metronome.inf [X64][GENFW] AcpiResetBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/PcatRealTimeClockRuntimeDxe/PcatRealTimeClockRuntimeDxe.inf [X64][CC] EbcSupport[GENFW] CpuBuilding ... /Users/philip/src/edk2/PcAtChipsetPkg/8254TimerDxe/8254Timer.inf [X64][CC] BootManager[CC] Metronome[VFR] BdsDxe[CC] PcRtcEntry[CC] Timer[CC] AutoGen[CC] FE[sLINK] Metronome[CC] InputHandler[DLINK1] Metronome[ASM] EbcLowLevel[MTOC] Metronome[CC] AutoGen[sLINK] Timer[CC] Page[GENFW] MetronomeBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/PciRootBridgeDxe/PciRootBridge.inf [X64][DLINK1] Timer[MTOC] Timer[CC] AutoGen[CC] AutoGen[sLINK] DisplayEngine[sLINK] EbcDxe[CC] FileExplorer[CC] PcRtc[DLINK1] DisplayEngine[CC] String[GENFW] TimerBuilding ... /Users/philip/src/edk2/Clover/CloverEFI/OsxPciBusNoEnumerationDxe/PciBusNoEnumeration.inf [X64][DLINK1] EbcDxe[MTOC] EbcDxe[CC] MemData[MTOC] DisplayEngine[GENFW] DisplayEngineBuilding ... /Users/philip/src/edk2/MdeModulePkg/Bus/Pci/NvmExpressDxe/NvmExpressDxe.inf [X64][GENFW] EbcDxe[CC] AutoGenBuilding ... /Users/philip/src/edk2/IntelFrameworkModulePkg/Universal/DataHubDxe/DataHubDxe.inf [X64][sLINK] PcRtc[DLINK1] PcRtc[MTOC] PcRtc[CC] PciPowerManagement[GENFW] PcRtcBuilding ... /Users/philip/src/edk2/Clover/Protocols/DriverOverride/DriverOverride.inf [X64][CC] PcatPciRootBridge[CC] FwVolBlock[CC] DataHub[CC] BootMaint[CC] PcatPciRootBridgeDevicePath[CC] DriverOverride[CC] FwVolWrite[CC] AutoGen[sLINK] DataHubDxe[CC] AutoGen[CC] PciRomTable[sLINK] DriverOverride[CC] NvmExpressBlockIo[DLINK1] DataHubDxe[MTOC] DataHubDxe[DLINK1] DriverOverride[CC] BBSsupport[MTOC] DriverOverride[CC] FwVolRead[GENFW] DataHubDxeBuilding ... /Users/philip/src/edk2/Clover/FileSystems/VBoxFsDxe/VBoxHfs.inf [X64][CC] Expression[CC] ComponentName[GENFW] DriverOverride[CC] PciDriverOverrideBuilding ... /Users/philip/src/edk2/Clover/FileSystems/VBoxFsDxe/VBoxIso9660.inf [X64][CC] PcatPciRootBridgeIoerror: unknown warning option '-Wno-address-of-packed-member' [-Werror,-Wunknown-warning-option]make: *** [/users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/FileSystems/VBoxFsDxe/VBoxHfs/OUTPUT/fsw_hfs.obj] Error 1build.py... : error 7000: Failed to execute command make tbuild [/users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/FileSystems/VBoxFsDxe/VBoxHfs]build.py... : error 7000: Failed to execute command make tbuild [/users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/FileSystems/VBoxFsDxe/VBoxIso9660]build.py... : error 7000: Failed to execute command make tbuild [/users/philip/src/edk2/Build/Clover/RELEASE_XCODE5/X64/Clover/FileSystems/VBoxFsDxe/VBoxExt2]build.py... : error F002: Failed to build module /Users/philip/src/edk2/Clover/FileSystems/VBoxFsDxe/VBoxHfs.inf [X64, XCODE5, RELEASE]- Failed -Build end time: 20:30:20, Mar.29 2017Build total time: 00:00:19o_Ops, ./ebuild.sh exited with error(s), aborting.. 1 Link to comment Share on other sites More sharing options...
droples Posted March 29, 2017 Share Posted March 29, 2017 Zenith432 Thanks you! XCODE8.3,Clover4046,gcc6.3,TC-XCode5 -The compilation was successful. Link to comment Share on other sites More sharing options...
Zenith432 Posted March 29, 2017 Share Posted March 29, 2017 (edited) @Zenith432: nice, but those changes break the compilation with Xcode 8.2.1. Just tested it on OS X 10.11.6, it complaints about unknown warning option (-Wno-address-of-packed-member). I'll try to find a way to make them coexist. In the meantime, need to remove -Wno-address-of-packed-member from FileSystems/VBoxFsDxe/VBox*.inf to make them compile under Xcode 8.2.1. EDIT: Ok Phillip, thanks to this it is resolved in Rev 4047 in a way that should make even Download-Fritz happy. Edited March 29, 2017 by Zenith432 5 Link to comment Share on other sites More sharing options...
Philip Petev Posted March 29, 2017 Share Posted March 29, 2017 Now it works with 8.2.1. Nice! Link to comment Share on other sites More sharing options...
Micky1979 Posted March 29, 2017 Share Posted March 29, 2017 Here too. I'm still in 10.12.3 with clang-800.0.42.1 and it works now as before 1 Link to comment Share on other sites More sharing options...
Micky1979 Posted March 29, 2017 Share Posted March 29, 2017 Hi, is anyone intrested in try this version of FileNVRAM.kext in Clover EFI? Requirement: 1) backup your existent nvram.plist (to be restored later) 2) boot from usb (for safety) 3) report (e.g. if if you can load web drivers using only the Nvidia manager or anything else) This kext is done for Clover and do not write anything on your hd, but that should be done by your rc script. FileNVRAM.kext.zip 4 Link to comment Share on other sites More sharing options...
PMheart Posted March 29, 2017 Share Posted March 29, 2017 (edited) Ok, but I still got this error with r4047... boot6 <-------------------------------------------------- TOOLCHAIN_DIR: /Users/vanilla/src/opt/local NASM_PREFIX: /Users/vanilla/src/opt/local/bin/ NASM_VER: 2.12.02 Initializing workspace Loading previous configuration from /Users/vanilla/src/edk2/Conf/BuildEnv.sh WORKSPACE: /Users/vanilla/src/edk2 EDK_TOOLS_PATH: /Users/vanilla/src/edk2/BaseTools CONF_PATH: /Users/vanilla/src/edk2/Conf Running edk2 build for CloverX64 using the command: build -D NO_GRUB_DRIVERS_EMBEDDED -D CHECK_FLAGS -D USE_LOW_EBDA -p Clover/Clover.dsc -a X64 -b RELEASE -t XCODE5 -n 5 Build environment: Darwin-16.6.0-x86_64-i386-64bit Build start time: 04:32:55, Mar.30 2017 WORKSPACE = /Users/vanilla/src/edk2 ECP_SOURCE = /Users/vanilla/src/edk2/EdkCompatibilityPkg EDK_SOURCE = /Users/vanilla/src/edk2/EdkCompatibilityPkg EFI_SOURCE = /Users/vanilla/src/edk2/EdkCompatibilityPkg EDK_TOOLS_PATH = /Users/vanilla/src/edk2/BaseTools CONF_PATH = /Users/vanilla/src/edk2/Conf Architecture(s) = X64 Build target = RELEASE Toolchain = XCODE5 Active Platform = /Users/vanilla/src/edk2/Clover/Clover.dsc Flash Image Definition = /Users/vanilla/src/edk2/Clover/Clover.fdf Processing meta-data .......... done! Building ... /Users/vanilla/src/edk2/MdePkg/Library/BasePcdLibNull/BasePcdLibNull.inf [X64] Building ... /Users/vanilla/src/edk2/MdePkg/Library/BaseDebugLibNull/BaseDebugLibNull.inf [X64] Building ... /Users/vanilla/src/edk2/MdePkg/Library/BaseMemoryLib/BaseMemoryLib.inf [X64] make: Nothing to be done for `tbuild'. Building ... /Users/vanilla/src/edk2/MdePkg/Library/BaseLib/BaseLib.inf [X64] make: Nothing to be done for `tbuild'. Building ... /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/BasePrintLib.inf [X64] make: Nothing to be done for `tbuild'. make: Nothing to be done for `tbuild'. Building ... /Users/vanilla/src/edk2/MdePkg/Library/BaseReportStatusCodeLibNull/BaseReportStatusCodeLibNull.inf [X64] Building ... /Users/vanilla/src/edk2/MdePkg/Library/BaseIoLibIntrinsic/BaseIoLibIntrinsic.inf [X64] make: Nothing to be done for `tbuild'. Building ... /Users/vanilla/src/edk2/MdeModulePkg/Library/DxeCoreMemoryAllocationLib/DxeCoreMemoryAllocationLib.inf [X64] Building ... /Users/vanilla/src/edk2/MdePkg/Library/DxeCoreEntryPoint/DxeCoreEntryPoint.inf [X64] Building ... /Users/vanilla/src/edk2/MdePkg/Library/UefiRuntimeServicesTableLib/UefiRuntimeServicesTableLib.inf [X64] /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:713:23: error: cannot compile this va_arg expression yet Width = VA_ARG (VaListMarker, UINTN); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:719:27: error: cannot compile this va_arg expression yet Precision = VA_ARG (VaListMarker, UINTN); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:812:21: error: cannot compile this va_arg expression yet Value = VA_ARG (VaListMarker, int); ^~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:81: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:818:21: error: cannot compile this va_arg expression yet Value = VA_ARG (VaListMarker, INT64); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:909:28: error: cannot compile this va_arg expression yet ArgumentString = VA_ARG (VaListMarker, CHAR8 *); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:927:23: error: cannot compile this va_arg expression yet Character = VA_ARG (VaListMarker, UINTN) & 0xffff; ^~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:937:21: error: cannot compile this va_arg expression yet TmpGuid = VA_ARG (VaListMarker, GUID *); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:970:21: error: cannot compile this va_arg expression yet TmpTime = VA_ARG (VaListMarker, TIME *); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/PrintLibInternal.c:994:20: error: cannot compile this va_arg expression yet Status = VA_ARG (VaListMarker, RETURN_STATUS); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /Users/vanilla/src/edk2/MdePkg/Include/Base.h:672:124: note: expanded from macro 'VA_ARG' #define VA_ARG(Marker, TYPE) ((sizeof (TYPE) < sizeof (UINTN)) ? (TYPE)(__builtin_va_arg (Marker, UINTN)) : (TYPE)(__builtin_va_arg (Marker, TYPE))) ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ 9 errors generated. make: *** [/Users/vanilla/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BasePrintLib/BasePrintLib/OUTPUT/PrintLibInternal.obj] Error 1 build.py... : error 7000: Failed to execute command make tbuild [/Users/vanilla/src/edk2/Build/Clover/RELEASE_XCODE5/X64/MdePkg/Library/BasePrintLib/BasePrintLib] build.py... : error F002: Failed to build module /Users/vanilla/src/edk2/MdePkg/Library/BasePrintLib/BasePrintLib.inf [X64, XCODE5, RELEASE] - Failed - Build end time: 04:33:09, Mar.30 2017 Build total time: 00:00:14 [EDIT] Well, still this error in r4046, everything seems the same as the previous r4045 here... Note: Both r4047 and r4046 were compiled with Xcode 8.3 (but failed) [EDIT 2] Oops. Forgot to apply the patches of EDK2! Now everything works, thanks @Zenith432! Edited March 29, 2017 by PMheart Link to comment Share on other sites More sharing options...
Sherlocks Posted March 29, 2017 Share Posted March 29, 2017 Hi, is anyone intrested in try this version of FileNVRAM.kext in Clover EFI? Requirement: 1) backup your existent nvram.plist (to be restored later) 2) boot from usb (for safety) 3) report (e.g. if if you can load web drivers using only the Nvidia manager or anything else) This kext is done for Clover and do not write anything on your hd, but that should be done by your rc script. hello micky first, thank you for great kext. i want to accurately know it how i can use it. should remove all rc script? and only use your kext? i can test brightness value in my laptop 1 Link to comment Share on other sites More sharing options...
Micky1979 Posted March 29, 2017 Share Posted March 29, 2017 Hi Sherlocks. The kext does not write anything, so you still need the rc scripts. Yes, brightness setting here show up.. 1 Link to comment Share on other sites More sharing options...
tluck Posted March 29, 2017 Share Posted March 29, 2017 Hi, is anyone intrested in try this version of FileNVRAM.kext in Clover EFI? Requirement: 1) backup your existent nvram.plist (to be restored later) 2) boot from usb (for safety) 3) report (e.g. if if you can load web drivers using only the Nvidia manager or anything else) This kext is done for Clover and do not write anything on your hd, but that should be done by your rc script. @Micky1979 - what does this kext do specifically? what do I look for ? happy to test. should I presume this kext is just for a machine where one needs EmuVariable? Link to comment Share on other sites More sharing options...
Sherlocks Posted March 29, 2017 Share Posted March 29, 2017 Hi Sherlocks. The kext does not write anything, so you still need the rc scripts. Yes, brightness setting here show up..Okay.Q. When normal boot, read nvram.plist in ESP, now rc script make nvram.plist when reboot or shutdown. Like you mention 1, backup nvram, what means it? Remove? Q. If remove nvram.plist in ESP until reboot or shutdown, when reboot or shutdown rc script automately make nvram.plist. no choice nvram clear. Need to disable rc script. No relate? Q. Can i check debug result? Just check nvram -p in terminal? What is NVRAM.kext's goal? Thanks in advance 나의 LG-F410S 의 Tapatalk에서 보냄 Link to comment Share on other sites More sharing options...
Micky1979 Posted March 29, 2017 Share Posted March 29, 2017 It's my fork of meklor's FileNVRAM. I'm writing from my smartphone so I cannot link the source, but just search my repo and you will see it. Yes this should be used with legacy bioses, but you can use that as well in UEFI if you want emulated nvram Lol. The fact is that you can have more vanilla vars in nvram, like preferred networks, power management, audio volume etc. Also you can use the nvram command line as you wish. The kext is usually read write and you can make it read-only with -FileNVRAMro flag (automatically set in code for this test). So you still need the rc script working. It's a test for now. 1 Link to comment Share on other sites More sharing options...
artur_pt Posted March 29, 2017 Share Posted March 29, 2017 Stay tuned Edit: Rev 4046 hello very good work the last 2 builds working with last xcode .. thanks Link to comment Share on other sites More sharing options...
Micky1979 Posted March 29, 2017 Share Posted March 29, 2017 Okay. Q. When normal boot, read nvram.plist in ESP, now rc script make nvram.plist when reboot or shutdown. Like you mention 1, backup nvram, what means it? Remove? no, just save for later. Q. If remove nvram.plist in ESP until reboot or shutdown, when reboot or shutdown rc script automately make nvram.plist. no choice nvram clear. Need to disable rc script. No relate? Yes, it's the same, so that you should do nothing *as always. Booting with this kext, to clean the nvram you have to use in Terminal: nvram -c ... but this way everythings in nvram will be lost (why I suggested you to backup your nvram.plist to do this test: later you can restore your original configuration). *Off course, you have to use the rc script since the kext has the File I/O disabled for this test. Q. Can i check debug result? Just check nvram -p in terminal? What is NVRAM.kext's goal? yes. like in a real mac @Micky1979 - what does this kext do specifically? what do I look for ? happy to test. should I presume this kext is just for a machine where one needs EmuVariable? Really depend if you are happy with your nvram vars (but with this kext you can have additional vanilla ones), and this is anyway an emulation that does not require the emuvariable. Nothing will be written to your real nvram. I need only someone helping making this working in Clover. Actually the kext apparently remove already present variables, but this is just the part 1, and I need to know if you can set what you want. part 2 will be keep bootloader settings. Also this is a evaluation test. P.S. only now I take the time to answer your questions. Link to comment Share on other sites More sharing options...
