RehabMan
RehabMan
Posted
Posted

Depends on whether or not the kext has changed in a way that the patches don't work. ;)

History is already an indication...



So far, each version released since 10.11.5 has required new and/or different patches. And an update from 10.11.5 to 10.11.6, using 10.11.5 patches would result in a "partial patch" (10.11.6 beta4 requires two additional patches).

  • Like 4
Link to comment
Share on other sites
magnifico
magnifico
Posted
Posted

History is already an indication...



So far, each version released since 10.11.5 has required new and/or different patches. And an update from 10.11.5 to 10.11.6, using 10.11.5 patches would result in a "partial patch" (10.11.6 beta4 requires two additional patches).

Hello Rehab you are ready to edit the script for the future upgrade?

Link to comment
Share on other sites
RehabMan
RehabMan
Posted
Posted

Hello Rehab you are ready to edit the script for the future upgrade?

When Pike provides the information required for such updates, the plist files that drive the script can be updated.

The script itself is generic and can apply patches from any plist.



Of course, such patches cannot be created before the update arrives, as that would require someone with the ability to predict the patches that will be needed in a kext that is not currently available. I don't see how that is possible (predicting the future would be quite useful, but unfortunately, impossible).

  • Like 1
Link to comment
Share on other sites
magnifico
magnifico
Posted
Posted

When Pike provides the information required for such updates, the plist files that drive the script can be updated.

The script itself is generic and can apply patches from any plist.



Of course, such patches cannot be created before the update arrives, as that would require someone with the ability to predict the patches that will be needed in a kext that is not currently available. I don't see how that is possible (predicting the future would be quite useful, but unfortunately, impossible).

for now let's enjoy 11.5, then you will see the future



PS:however, I am using the kext generated by the script in the folder 10.11 and goes very well  :yes:  :yes:

Link to comment
Share on other sites
RehabMan
RehabMan
Posted
Posted

for now let's enjoy 11.5, then you will see the future



PS:however, I am using the kext generated by the script in the folder 10.11 and goes very well  :yes:  :yes:

The plists in the repo currently support 10_11_5, 10_11_6_beta4, and 10_12_dp1.

Link to comment
Share on other sites
maclocus
maclocus
Posted
Posted

Guys, can anybody look at my config.plist.



I get this message in boot.log:



0:102  0:000  Clover load options size = 4 bytes

0:102  0:000  Found Plist String = , parse XML in LoadOptions

0:102  0:000  Xml in load options is bad   <===========================

0:110  0:008  Using OEM config.plist at path: EFI\CLOVER\config.plist

0:110  0:000  EFI\CLOVER\config.plist loaded: Success


And I have looked at it but can't find where the mistake is!
Suppose some read blindness

Thanks!

Link to comment
Share on other sites
Slice
Slice
Posted
Posted



Guys, can anybody look at my config.plist.



I get this message in boot.log:



0:102  0:000  Clover load options size = 4 bytes

0:102  0:000  Found Plist String = , parse XML in LoadOptions

0:102  0:000  Xml in load options is bad

0:110  0:008  Using OEM config.plist at path: EFI\CLOVER\config.plist

0:110  0:000  EFI\CLOVER\config.plist loaded: Success


And I have looked at it but can't find where the mistake is!
Suppose some read blindness

Thanks!




It is not a mistake. It is a feature that poor documented.

BOOTxxx entry in NVRAM can contain a name for plist (xml) file. If it happens then Clover can use it as alternative to config.plist.

Else common config.plist will be used.

Link to comment
Share on other sites
Needy
Needy
Posted
Posted

Guys, can anybody look at my config.plist.



I get this message in boot.log:



0:102  0:000  Clover load options size = 4 bytes

0:102  0:000  Found Plist String = , parse XML in LoadOptions

0:102  0:000  Xml in load options is bad   <===========================

0:110  0:008  Using OEM config.plist at path: EFI\CLOVER\config.plist

0:110  0:000  EFI\CLOVER\config.plist loaded: Success



And I have looked at it but can't find where the mistake is!

Suppose some read blindness



Thanks!



attachicon.gifconfig.plist.zip

Hello there,



This file is a sample configuration with all the possible options, however the options are commented out with the # key and some of them have incorrect values. In order to make it a valid config file remove the # from the entries you would like to use and remove the entire entries you don't need.



Furthermore, if you want to work in a more user friendly environment use the Clover Configurator tool to generate the desired config file.



Best of luck.

Link to comment
Share on other sites
Slice
Slice
Posted
Posted

Hi, i use UHD resolution where 64x64 is to small, i've found the files on my USB-Stick not the latest but it should work.

I change the size by the theme.plist



SelectionSmallWidth

94



Here the files, which need some improvements

attachicon.gifSelectionSmallWidth.zip

OK, implemented in 3605.

But I want to warn you to apply your patches to most recent clover revision. It was hard for me to see what you changed.

Link to comment
Share on other sites
droples
droples
Posted
Posted

Your laptop has UEFI, why not give it a try ?

What does UEFI? The question was about a specific assembly Boot5. On a my laptop I can use any variant of the loading- legacy (boot6,boot7) or UEFI.

Boot6





:100  0:100  MemLog inited, TSC freq: 1995467027
0:100  0:000  LegacyRegion2: Chipset/proc: 0x01048086
0:100  0:000   Next Generation Core processors (PAM 0x80-0x86)
0:100  0:000   Test PAM1=(0x41=90, 0x5a=00, 0x81=11, 0x91=00) at chipset 01048086
0:100  0:000  , Install = Success
0:114  0:014  VGA Pci.Hdr.Command=0 - not enabled
0:114  0:000  BiosVideoDriverBindingStart!
0:114  0:000  BiosVideoCheckForVbe
0:114  0:000  EdidOverride not found
0:126  0:012   Edid1+
0:126  0:000   found Detail Timing 1920x1080
0:126  0:000  timing string after 0xFE:AUO

0:126  0:000  timing string after 0xFE:B156HW01 V5

0:139  0:012   Edid0+
0:139  0:000   found Detail Timing 1920x1080
0:139  0:000  ... already present
0:139  0:000  timing string after 0xFE:AUO

0:139  0:000  timing string after 0xFE:B156HW01 V5

0:139  0:000     0 1280x1024 attr=9B - ok, edid-
0:140  0:000     1 1024x768 attr=9B - ok, edid-, 1024x768, working, highest, pref=1
0:140  0:000     2 640x480 attr=9B - ok, edid-, 640x480, working
0:140  0:000     3 800x600 attr=9B - ok, edid-, 800x600, working
0:140  0:000  BV new mode: 1 1024x768
0:268  0:128   SetMode pref 1 (1) = Success
0:495  0:226  VGA Pci.Hdr.Command=0 - not enabled
0:668  0:173  VGA Pci.Hdr.Command=0 - not enabled
0:674  0:005  VGA Pci.Hdr.Command=0 - not enabled
2:120  1:446  VGA Pci.Hdr.Command=0 - not enabled
2:199  0:079
2:199  0:000  Now is 11.7.2016,  16:17:52 (GMT)
2:199  0:000  Starting Clover rev 3604 on CLOVER EFI
2:199  0:000  Build with: [Args: ./ebuild.sh -n 5 -t XCLANG -mc --no-usb | Command: build -D DISABLE_USB_SUPPORT -D USE_BIOS_BLOCKIO -D USE_LOW_EBDA -p Clover/Clover.dsc -a X64 -b RELEASE -t XCLANG -n 5 | OS: 10.10.5 | XCODE: 7.2]
2:199  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0x0,0x0)\HD(1,GPT,F61211C5-87B9-4CDD-BE33-9DC9BD4A478E,0x28,0x64000) @1F4A1C18
2:199  0:000  SelfDirPath = \EFI\CLOVER





Boot7





0:100  0:100  MemLog inited, TSC freq: 1995468627
0:100  0:000  LegacyRegion2: Chipset/proc: 0x01048086
0:100  0:000   Next Generation Core processors (PAM 0x80-0x86)
0:100  0:000   Test PAM1=(0x41=90, 0x5a=00, 0x81=11, 0x91=00) at chipset 01048086
0:100  0:000  , Install = Success
0:115  0:015  VGA Pci.Hdr.Command=0 - not enabled
0:115  0:000  BiosVideoDriverBindingStart!
0:115  0:000  BiosVideoCheckForVbe
0:115  0:000  EdidOverride not found
0:127  0:012   Edid1+
0:127  0:000   found Detail Timing 1920x1080
0:127  0:000  timing string after 0xFE:AUO

0:127  0:000  timing string after 0xFE:B156HW01 V5

0:139  0:012   Edid0+
0:139  0:000   found Detail Timing 1920x1080
0:139  0:000  ... already present
0:139  0:000  timing string after 0xFE:AUO

0:139  0:000  timing string after 0xFE:B156HW01 V5

0:140  0:000     0 1280x1024 attr=9B - ok, edid-
0:140  0:000     1 1024x768 attr=9B - ok, edid-, 1024x768, working, highest, pref=1
0:140  0:000     2 640x480 attr=9B - ok, edid-, 640x480, working
0:140  0:000     3 800x600 attr=9B - ok, edid-, 800x600, working
0:140  0:000  BV new mode: 1 1024x768
0:269  0:128   SetMode pref 1 (1) = Success
0:269  0:000  VGA Pci.Hdr.Command=0 - not enabled
0:345  0:075  VGA Pci.Hdr.Command=0 - not enabled
0:353  0:007  VGA Pci.Hdr.Command=0 - not enabled
0:354  0:001  Found supported controller for BiosBlockIO class=010601
0:354  0:000  Int13Extensions: INT 13 41 DL=80 : CF=0 BX=AA55 CX=0001
0:354  0:000  GetDriveParameters: INT 13 48 DL=80 : CF=0 AH=00
0:354  0:000  BlockSize = 512  LastBlock = 500118191
0:355  0:000  Int13Extensions: INT 13 41 DL=81 : CF=0 BX=AA55 CX=0001
0:355  0:000  GetDriveParameters: INT 13 48 DL=81 : CF=0 AH=00
0:355  0:000  BlockSize = 512  LastBlock = 1465149167
0:427  0:072  VGA Pci.Hdr.Command=0 - not enabled
0:694  0:267
0:694  0:000  Now is 11.7.2016,  15:30:4 (GMT)
0:694  0:000  Starting Clover rev 3604 on CLOVER EFI
0:694  0:000  Build with: [Args: ./ebuild.sh -n 5 -t XCLANG -mc --no-usb | Command: build -D DISABLE_USB_SUPPORT -D USE_BIOS_BLOCKIO -D USE_LOW_EBDA -p Clover/Clover.dsc -a X64 -b RELEASE -t XCLANG -n 5 | OS: 10.10.5 | XCODE: 7.2]
0:694  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1F,0x2)\VenHw(CF31FAC5-C24E-11D2-85F3-00A0C93EC93B,80)\HD(1,GPT,F61211C5-87B9-4CDD-BE33-9DC9BD4A478E,0x28,0x64000) @1F829E98
0:694  0:000  SelfDirPath = \EFI\CLOVER
0:694  0:000  Total Memory Slots Count = 4
