powermapler
powermapler
Posted
Posted

@powermapler, if you are using Clover in native UEFI mode, then you may try this:

- set Clover option as first one in boot order in UEFI/BIOS screen

- set your legacy windows drive as second one in boot order in UEFI/BIOS screen

- set Boot/Legacy=LegacyBiosDefault in Clover's config.plist



And then selecting any legacy entry in your Clover main menu should boot your legacy windows.



Yes, that actually worked! I could have sworn I had played around with that earlier without it doing anything, but this time I also added a "1" for LegacyBiosDefaultEntry. Either way it works now. Thank you!  :D

Link to comment
Share on other sites
JorgeMax
JorgeMax
Posted
Posted
Friends. I've tried everything! "PatchVBios = True", "PatchVBiosBytes" (All modes patched resolution), and nothing works.



Arrow always the resolution to 1024x768, during startup and Clover Boot System.



I removed the two: "PatchVBios = True" and "PatchVBiosBytes" the config.plist, since they do not allow DVI and VGA ports (with adapter) function.



See the picture:




Nor also says the "CsmVideoDxe-64.efi" gives me the same lack of signal in DVI and VGA ports. And errors in the video, when I use the two outputs: HDMI + DVI at the same time.

Link to comment
Share on other sites
crusher
crusher
Posted
Posted



Your config.plist looks OK to me.



The main problem is the interaction between Clover and legacy Windows.  The BIOS on some machines can't boot legacy Windows from Clover at all and others need Clover installed with the "Bios Block" option.



Windows can also be very finicky about where its booted from eg if I try to boot legacy Windows installed on my SSD from Clover installed on a separate disk, I get a BCD error so @asradu's point is valid about installs on different disks.



In your current situation, using F8 to boot Windows with its own boot loader on one drive and OSX with Clover on the other drive is probably the best work-around.



If you do decide to reformat your Windows disk, then I highly recommend installing Windows in UEFI mode.  On my desktop rig, I have the followng installed

/dev/disk0
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:     FDisk_partition_scheme                        *120.0 GB   disk0
   1:               Windows_NTFS System Reserved         104.9 MB   disk0s1
   2:               Windows_NTFS WIN7_X64SSD             119.9 GB   disk0s2
/dev/disk1
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *1.0 TB     disk1
   1:                        EFI EFI                     209.7 MB   disk1s1
   2:                  Apple_HFS OSX Mavericks           250.0 GB   disk1s2
   3:       Microsoft Basic Data WIN7_X64HDD             250.1 GB   disk1s3
   4:       Microsoft Basic Data DATA                    499.8 GB   disk1s4
/dev/disk2
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *120.0 GB   disk2
   1:                        EFI EFI                     209.7 MB   disk2s1
   2:                  Apple_HFS OSX Lion WD             60.0 GB    disk2s2
   3:                  Apple_HFS OSX Yosemite WD         50.7 GB    disk2s3
   4:                 Apple_Boot Recovery HD             650.0 MB   disk2s4
   5:                  Apple_HFS Install OS X Mavericks  8.1 GB     disk2s5

I can give preference in the BIOS to boot Clover from disk2 and I can still boot my UEFI WIN7_X64 on disk1 from Clover's main menu.



attachicon.gifClover Main Menu Boot UEFI Windows.png







Try running this command in terminal....

bdmesg | grep GUID

I get output like this ...

18:282  0:003   12. Volume 'EFI', GUID = CEE0B900-F6CD-459F-AD9A-23F4F8889EEC - no nvram.plist - skipping!
18:282  0:000   13. Volume 'OSX Mavericks', GUID = 9EF4C4CE-7D12-432A-B667-6EEC117B9F8E Modified = 2014-7-31 5:22:27 (3685497747000 ms) - newer - will use this one
18:327  0:044   14. Volume 'WIN7_X64HDD', GUID = 5901E794-8336-483F-A28A-8B8ED0F9FBC1 - no nvram.plist - skipping!
18:360  0:032   15. Volume 'DATA', GUID = 9FFA0207-9C7C-463B-B9E1-574EB8E2E46D - no nvram.plist - skipping!
18:360  0:000   16. Volume 'EFI', GUID = 961B1B77-3246-46CD-9865-BE224E5FC39B - no nvram.plist - skipping!
18:360  0:000   17. Volume 'OSX Lion WD', GUID = 1F4BE787-10E3-4BC4-8CC2-328D914F226D Modified = 2014-7-20 7:43:57 (3684555837000 ms) - older - skipping!
18:406  0:046   18. Volume 'OSX Yosemite WD', GUID = 7A5D8AE6-670B-4EDB-8994-44639B53FD2D Modified = 2014-7-31 0:37:16 (3685480636000 ms) - older - skipping
[attachment=145594:Clover Main Menu Boot UEFI Windows.png]



For me same

/dev/disk0
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *120.0 GB   disk0
   1:                        EFI EFI                     209.7 MB   disk0s1
   2:                  Apple_HFS Mavericks SSD           119.2 GB   disk0s2
/dev/disk1
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *250.1 GB   disk1
   1:                        EFI EFI                     209.7 MB   disk1s1
   2:                  Apple_HFS Macintosh SSD           249.2 GB   disk1s2
   3:                 Apple_Boot Recovery HD             650.0 MB   disk1s3
/dev/disk2
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:     FDisk_partition_scheme                        *240.1 GB   disk2
   1:               Windows_NTFS System Reserved         367.0 MB   disk2s1
   2:               Windows_NTFS Wundows 8.1 SSD         239.7 GB   disk2s2
/dev/disk3
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *500.1 GB   disk3
   1:                        EFI EFI                     209.7 MB   disk3s1
   2:                  Apple_HFS Data                    200.0 GB   disk3s2
   3:       Microsoft Basic Data Storage                 299.8 GB   disk3s3
/dev/disk4
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *320.1 GB   disk4
   1:                        EFI EFI                     209.7 MB   disk4s1
   2:                  Apple_HFS Mac OS X                160.0 GB   disk4s2
   3:       Microsoft Basic Data WINDOWS                 159.7 GB   disk4s3

and bdmesg

1:404  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
1:467  0:061    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = B364746E-0E70-4A01-94D7-C8AB11383FFF
1:467  0:000    Volume 'Mac OS X', LegacyOS '', LegacyIcon(s) '<null string>', GUID = A002F3D8-3B76-42D2-A5A2-9812AA8198AA
2:123  0:000    Volume 'WINDOWS', LegacyOS '', LegacyIcon(s) '<null string>', GUID = C7385942-47C5-4735-8669-0A7F48EA3AC6
2:126  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:128  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:128  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:129  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:130  0:000    Volume 'Legacy HD1', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = <null guid>
2:130  0:000    Volume 'Legacy HD2', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = <null guid>
2:144  0:013    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = FEEE106F-E831-4D19-B184-865E44835B42
2:145  0:000    Volume 'Macintosh SSD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF
2:146  0:000    Volume 'Recovery HD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26
2:165  0:018    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 311429F1-F02D-4ECF-9D88-1279E445BA30
2:166  0:000    Volume 'Data', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 8BB21494-4700-49C8-838F-3D82A2BD6095
2:166  0:000    Volume 'Legacy HD3', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = 9A305228-83D9-4556-A5F8-365BDEA35847
2:174  0:007    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 81C0C004-4A64-4E66-9CD6-DA141C591BA7
2:175  0:000    Volume 'Mavericks SSD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = C2441E72-2E2D-45A0-ACCD-D1D614121B14
2:175  0:000    1. Volume 'EFI', GUID = B364746E-0E70-4A01-94D7-C8AB11383FFF - no nvram.plist - skipping!
2:175  0:000    2. Volume 'Mac OS X', GUID = A002F3D8-3B76-42D2-A5A2-9812AA8198AA - no nvram.plist - skipping!
2:177  0:002    3. Volume 'WINDOWS', GUID = C7385942-47C5-4735-8669-0A7F48EA3AC6 - no nvram.plist - skipping!
2:177  0:000   10. Volume 'EFI', GUID = FEEE106F-E831-4D19-B184-865E44835B42 - no nvram.plist - skipping!
2:177  0:000   11. Volume 'Macintosh SSD', GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF - no nvram.plist - skipping!
2:181  0:003   12. Volume 'Recovery HD', GUID = 4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26 - no nvram.plist - skipping!
2:182  0:000   13. Volume 'EFI', GUID = 311429F1-F02D-4ECF-9D88-1279E445BA30 - no nvram.plist - skipping!
2:182  0:000   14. Volume 'Data', GUID = 8BB21494-4700-49C8-838F-3D82A2BD6095 - no nvram.plist - skipping!
2:203  0:021   16. Volume 'EFI', GUID = 81C0C004-4A64-4E66-9CD6-DA141C591BA7 - no nvram.plist - skipping!
2:203  0:000   17. Volume 'Mavericks SSD', GUID = C2441E72-2E2D-45A0-ACCD-D1D614121B14 - no nvram.plist - skipping!
7:444  0:000    * GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF

and boot.log

0:100  0:100  MemLog inited, TSC freq: 3503441478
0:100  0:000
0:100  0:000  Now is 31.7.2014,  17:5:40 (GMT+2047)
0:100  0:000  Starting Clover rev 2780 on American Megatrends EFI
0:100  0:000  SelfDevicePath=PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000) @D17C3E18
0:100  0:000  SelfDirPath = \EFI\BOOT
0:100  0:000  UnicodeCollation Status=Success
0:100  0:000  Total Memory Slots Count = 4
0:100  0:000  Type 17 Index = 0
0:100  0:000  Ignoring insane frequency value 0MHz
0:100  0:000  SmbiosTable.Type17->Speed = 0
0:100  0:000  SmbiosTable.Type17->Size = 0
0:100  0:000  Type 17 Index = 1
0:100  0:000  SmbiosTable.Type17->Speed = 1333
0:100  0:000  SmbiosTable.Type17->Size = 8192
0:100  0:000  Type 17 Index = 2
0:100  0:000  Ignoring insane frequency value 0MHz
0:100  0:000  SmbiosTable.Type17->Speed = 0
0:100  0:000  SmbiosTable.Type17->Size = 0
0:100  0:000  Type 17 Index = 3
0:100  0:000  Ignoring insane frequency value 0MHz
0:100  0:000  SmbiosTable.Type17->Speed = 0
0:100  0:000  SmbiosTable.Type17->Size = 0
0:100  0:000  Boot status=0
0:100  0:000  Clover revision: 2780  running on To be filled by O.E.M.
0:100  0:000  ... with board Z77X-UD3H
0:100  0:000  Clover load options size = 4 bytes
0:104  0:004  Oem AMBO.plist not found at path: EFI\CLOVER\AMBO.plist
0:104  0:000  EFI\CLOVER\AMBO.plist not loaded with name from LoadOptions: Not Found
0:105  0:001  Using OEM config.plist at path: EFI\CLOVER\config.plist
0:106  0:000  EFI\CLOVER\config.plist loaded: Success
0:109  0:003  Found theme applestyle
0:112  0:003  Found theme BGM
0:117  0:005  Found theme BLACK
0:120  0:002  Found theme black_green
0:123  0:003  Found theme BLUEMAC
0:126  0:003  Found theme BOOTCAMP
0:128  0:002  Found theme gold_clover
0:132  0:003  Found theme ICLOVER
0:134  0:002  Found theme magnifico
0:136  0:002  Found theme METAL
0:140  0:003  Found theme MRENGLES
0:143  0:002  Found theme ORANGE
0:145  0:002  Found theme OS_BOX
0:147  0:002  Found theme OS_ONE
0:149  0:001  Found theme Shield
0:155  0:005  Found theme THINKPAD
0:157  0:002  Loading early settings
0:157  0:000  timeout set to 2
0:157  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
0:157  0:000  Default theme: gold_clover
0:157  0:000  Hiding entries with string Legacy HD3
0:157  0:000  Hiding entries with string BOOTX64.EFI
0:157  0:000  Hiding entries with string Legacy HD2
0:157  0:000  Hiding entries with string Data
0:157  0:000  Hiding entries with string Windows
0:157  0:000  Hiding entries with string Recovery HD
0:157  0:000  LoadDrivers() start
0:160  0:003  Loading CsmVideoDxe-64.efi
0:162  0:001   - driver needs connecting
0:162  0:000  Loading DataHubDxe-64.efi
0:183  0:021  Loading EmuVariableUefi-64.efi
0:184  0:001  EmuVariableUefi Initialize: VariableCommonInitialize = Success, orig services stored, install gEmuVariableControlProtocolGuid = Success
0:186  0:001  Loading FSInject-64.efi
0:187  0:001  Loading OsxAptioFixDrv-64.efi
0:189  0:001  Loading OsxFatBinaryDrv-64.efi
0:190  0:001  Loading PartitionDxe-64.efi
0:191  0:001   - driver needs connecting
0:191  0:000  Loading VBoxHfs-64.efi
0:193  0:001   - driver needs connecting
0:193  0:000  3 drivers needs connecting ...
0:193  0:000  PlatformDriverOverrideProtocol not found. Installing ... Success
0:193  0:000  Partition driver loaded:
0:193  0:000  Video driver loaded: disconnect Success
0:278  0:084  Searching for invalid DiskIo BY_DRIVER connects: not found, all ok
0:278  0:000  VideoBiosPatchNativeFromEdid:
0:278  0:000   Bios: nVidia, nv_data_table_offset: 0x267, nv_data_table: 0xC0269, std_vesa: 0xC411B, nv_mode_table: 0xC4120, mode_table_size: 0x10
0:278  0:000   VideoBiosPatchInit(LegacyRegion = Success) = Success
0:278  0:000   VideoBiosUnlock:  unlocked
0:279  0:001   Patching: BT_NVDA
0:279  0:000   Parse Edid: descriptor block 0 is timing descriptor (h_active: 1600, v_active: 900, h_sync_offset: 48, h_sync_width: 32, h_blanking: 160, v_blanking: 26, pixel_clock: 9775, v_sync_offset: 3, v_sync_width: 5)
0:280  0:000   patch 0: patched 1 time(s)
0:280  0:000   patch 1: patched 1 time(s)
0:281  0:000   patch 2: patched 1 time(s)
0:281  0:000   patch 3: patched 1 time(s)
0:281  0:000   VideoBiosLock: Success
0:302  0:020  CsmVideoDriverBindingStart
0:302  0:000  mixed support=40010
0:302  0:000  Controller is [030000]
0:302  0:000  Check for VBE
0:346  0:044   found Detail Timing 1600x900
0:350  0:004    0 640x480 attr=3BF - ok, edid+, 640x480, working, highest, pref=0
0:351  0:000    1 800x600 attr=3BF - ok, edid+, 800x600, working, highest, pref=1
0:352  0:000    2 1024x768 attr=3BF - ok, edid+, 1024x768, working, highest, pref=2
0:355  0:003    3 1600x900 attr=3BF - ok, edid+, working, highest, pref=3
0:355  0:000  CsmVideo: New mode: 3 1600x900 - set
1:027  0:671   - SetMode pref 3 (3) = Success
1:027  0:000  CsmVideoCheckForVbe - Success
1:027  0:000  CsmVideoDriverBindingStart end Success
1:027  0:000  CsmVideo: New mode: 2 1024x768 - blocking that switch
1:027  0:000  CsmVideo: New mode: 2 1024x768 - blocking that switch
1:028  0:000  CsmVideo: New mode: 2 1024x768 - blocking that switch
1:189  0:161  LoadDrivers() end
1:189  0:000  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
1:202  0:013  SetScreenResolution: 1920x1080 - not found!
1:202  0:000  Console modes reported: 4, available modes:
1:202  0:000    Mode 1: 80x25 (current mode)
1:202  0:000    Mode 3: 100x31
1:202  0:000    Mode 4: 128x30
1:202  0:000  reinit: self device path=PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)
1:202  0:000  new SelfHandle=D17C3E18
1:202  0:000  CPU Vendor = 756E6547 Model=306A9
1:202  0:000  The CPU supported turbo
1:202  0:000  BrandString = Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
1:202  0:000  MSR 0xE2 before patch 1E000403
1:202  0:000  MSR 0xE4              00010414
1:202  0:000  MSR 0xCE              00081010_F0012300
1:202  0:000  non-usable FLEX_RATIO = F0000
1:202  0:000  corrected FLEX_RATIO = E0000
1:202  0:000  MSR 0x1B0             00000000
1:202  0:000  FSBFrequency=105MHz
1:202  0:000  Corrected FSBFrequency=100MHz
1:202  0:000  Vendor/Model/Stepping: 0x756E6547/0x3A/0x9
1:202  0:000  Family/ExtFamily: 0x6/0x0
1:202  0:000  MaxDiv/MinDiv: 35.0/16
1:202  0:000  Turbo: 37/38/39/39
1:202  0:000  Features: 0xBFEBFBFF
1:202  0:000  Threads: 8
1:202  0:000  Cores: 4
1:202  0:000  FSB: 100 MHz
1:202  0:000  CPU: 3700 MHz
1:202  0:000  TSC: 3700 MHz
1:202  0:000  PIS: 400 MHz
1:202  0:000  PCI (00|00:00.00) : 8086 0150 class=060000
1:202  0:000  PCI (00|00:01.00) : 8086 0151 class=060400
1:202  0:000  PCI (00|01:00.00) : 10DE 1080 class=030000
1:202  0:000  Found NVidia model=MSi GeForce GTX 580
1:202  0:000  PCI (00|01:00.01) : 10DE 0E09 class=040300
1:202  0:000  PCI (00|00:14.00) : 8086 1E31 class=0C0330
1:202  0:000  PCI (00|00:16.00) : 8086 1E3A class=078000
1:202  0:000  PCI (00|00:16.01) : FFFF FFFF class=FFFFFF
1:202  0:000  PCI (00|00:1A.00) : 8086 1E2D class=0C0320
1:202  0:000  PCI (00|00:1B.00) : 8086 1E20 class=040300
1:202  0:000  PCI (00|00:1C.00) : 8086 1E10 class=060400
1:202  0:000  PCI (00|00:1C.04) : 8086 1E18 class=060400
1:202  0:000  PCI (00|03:00.00) : 1106 3432 class=0C0330
1:202  0:000  PCI (00|00:1C.05) : 8086 244E class=060401
1:202  0:000  PCI (00|04:00.00) : 8086 244E class=060401
1:203  0:000  PCI (00|05:00.00) : 168C 001A class=020000
1:203  0:000  PCI (00|00:1C.06) : 8086 1E1C class=060400
1:203  0:000  PCI (00|06:00.00) : 1969 1083 class=020000
1:203  0:000  PCI (00|00:1C.07) : 8086 1E1E class=060400
1:203  0:000  PCI (00|07:00.00) : 1B4B 9172 class=010601
1:203  0:000  PCI (00|00:1D.00) : 8086 1E26 class=0C0320
1:203  0:000  PCI (00|00:1F.00) : 8086 1E44 class=060100
1:203  0:000  PCI (00|00:1F.02) : 8086 1E02 class=010601
1:203  0:000  PCI (00|00:1F.03) : 8086 1E22 class=0C0500
1:203  0:000  PCI (00|00:1F.06) : FFFF FFFF class=FFFFFF
1:203  0:000  ScanSPD() start
1:203  0:000  SMBus CmdReg: 0x1
1:203  0:000  Scanning SMBus [8086:1E22], mmio: 0xF7515004, ioport: 0xF000, hostc: 0x1
1:224  0:020  SPD[1]: Type 11 @0x51
1:233  0:008  DDR speed 1333MHz
1:233  0:000  Slot: 1 Type 24 8192MB 1333MHz Vendor=Corsair PartNo=CMX8GX3M1A1600C11 SerialNo=0000000000000000
1:372  0:139  ScanSPD() end
1:372  0:000  Get Acpi Tables List from RSDT:
1:372  0:000   Found table: FACP  A M I len=132
1:372  0:000   Found table: APIC  A M I len=146
1:372  0:000   Found table: MCFG   len=60
1:372  0:000   Found table: HPET  A M I len=56
1:372  0:000   Found table: SSDT  SataTabl len=877
1:372  0:000   Found table: SSDT  Cpu0Ist len=2474
1:372  0:000   Found table: SSDT  CpuPm len=2706
1:372  0:000   Found table: BGRT  A M I len=56
1:372  0:000  Calibrated TSC frequency =3503441478 =3503MHz
1:372  0:000  Loading main settings
1:372  0:000  USB FixOwnership: true
1:372  0:000  Dropping 3 tables
1:372  0:000  Drop table 0 signature="DMAR" (52414D44)
1:372  0:000  set table: 52414D44,                0 to drop:
1:372  0:000  Drop table 1 signature="SSDT" (54445353) table-id="Cpu0Ist" (0074734930757043)
1:372  0:000  set table: 54445353,   74734930757043 to drop:  true
1:372  0:000
1:372  0:000  Drop table 2 signature="SSDT" (54445353) table-id="CpuPm" (0000006D50757043)
1:372  0:000  set table: 54445353,       6D50757043 to drop:  true
1:372  0:000
1:372  0:000  Config set Fixes will override FixMask mask!
1:372  0:000     final mask=9FCAE955
1:372  0:000  Config set EnableC6: +
1:372  0:000  Config set ChassisType=0xD
1:372  0:000  Config set FakeCPUID=0
1:372  0:000  KextsToPatch: 1 requested
1:372  0:000  KextToPatch 0: AppleAHCIPort (External icons patch) Kext bin patch, data len: 8
1:373  0:000  Oem smbios.plist not found at path: EFI\CLOVER\smbios.plist
1:373  0:000  smbios.plist not found, not overriding config.plist
1:373  0:000  found 18 volumes with blockIO
1:373  0:000   0. Volume:
1:373  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)
1:404  0:031    USB volume
1:404  0:000    USB volume
1:404  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
1:404  0:000   1. Volume:
1:404  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)\HD(1,GPT,B364746E-0E70-4A01-94D7-C8AB11383FFF,0x28,0x64000)
1:405  0:000    Result of bootcode detection: bootable <null string> (<null string>)
1:405  0:000    USB volume
1:405  0:000    USB volume
1:467  0:061    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = B364746E-0E70-4A01-94D7-C8AB11383FFF
1:467  0:000   2. Volume:
1:467  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)\HD(2,GPT,A002F3D8-3B76-42D2-A5A2-9812AA8198AA,0x64028,0x12A17558)
1:467  0:000    USB volume
1:467  0:000    USB volume
1:467  0:000    Volume 'Mac OS X', LegacyOS '', LegacyIcon(s) '<null string>', GUID = A002F3D8-3B76-42D2-A5A2-9812AA8198AA
1:467  0:000   3. Volume:
1:467  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)\HD(3,GPT,C7385942-47C5-4735-8669-0A7F48EA3AC6,0x12ABB800,0x12973000)
1:487  0:019    Result of bootcode detection: bootable <null string> (<null string>)
1:487  0:000    USB volume
1:487  0:000    USB volume
2:123  0:636    hiding this volume
2:123  0:000    Volume 'WINDOWS', LegacyOS '', LegacyIcon(s) '<null string>', GUID = C7385942-47C5-4735-8669-0A7F48EA3AC6
2:123  0:000   4. Volume:
2:123  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0xFFFF,0x0)
2:125  0:002    Result of bootcode detection: bootable <null string> (<null string>)
2:126  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:126  0:000   5. Volume:
2:126  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)
2:128  0:002    Result of bootcode detection: bootable <null string> (<null string>)
2:128  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:128  0:000   6. Volume:
2:128  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)
2:128  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:128  0:000   7. Volume:
2:128  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)
2:129  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:129  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:129  0:000   8. Volume:
2:129  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0xFFFF,0x0)\HD(1,MBR,0xD8A273CD,0x800,0xAF000)
2:130  0:000    Result of bootcode detection: bootable Windows (vista,win)
2:130  0:000    Volume 'Legacy HD1', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = <null guid>
2:130  0:000   9. Volume:
2:130  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0xFFFF,0x0)\HD(2,MBR,0xD8A273CD,0xAF800,0x1BE74000)
2:130  0:000    Result of bootcode detection: bootable Windows (vista,win)
2:130  0:000    hiding this volume
2:130  0:000    Volume 'Legacy HD2', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = <null guid>
2:130  0:000  10. Volume:
2:130  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)
2:131  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:144  0:013    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = FEEE106F-E831-4D19-B184-865E44835B42
2:144  0:000    This is SelfVolume !!
2:144  0:000  11. Volume:
2:145  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF,0x64028,0x1D02BA00)
2:145  0:000    Volume 'Macintosh SSD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF
2:145  0:000  12. Volume:
2:145  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(3,GPT,4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26,0x1D08FA28,0x135F20)
2:146  0:000    hiding this volume
2:146  0:000    Volume 'Recovery HD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26
2:146  0:000  13. Volume:
2:146  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)\HD(1,GPT,311429F1-F02D-4ECF-9D88-1279E445BA30,0x28,0x64000)
2:146  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:165  0:018    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 311429F1-F02D-4ECF-9D88-1279E445BA30
2:165  0:000  14. Volume:
2:165  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)\HD(2,GPT,8BB21494-4700-49C8-838F-3D82A2BD6095,0x64028,0x174876E8)
2:166  0:000    hiding this volume
2:166  0:000    Volume 'Data', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 8BB21494-4700-49C8-838F-3D82A2BD6095
2:166  0:000  15. Volume:
2:166  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)\HD(3,GPT,9A305228-83D9-4556-A5F8-365BDEA35847,0x1752B800,0x22E5A800)
2:166  0:000    Result of bootcode detection: bootable Windows (vista,win)
2:166  0:000    hiding this volume
2:166  0:000    Volume 'Legacy HD3', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = 9A305228-83D9-4556-A5F8-365BDEA35847
2:166  0:000  16. Volume:
2:166  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)\HD(1,GPT,81C0C004-4A64-4E66-9CD6-DA141C591BA7,0x28,0x64000)
2:167  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:174  0:007    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 81C0C004-4A64-4E66-9CD6-DA141C591BA7
2:174  0:000  17. Volume:
2:175  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)\HD(2,GPT,C2441E72-2E2D-45A0-ACCD-D1D614121B14,0x64028,0xDDFAC40)
2:175  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:175  0:000    Volume 'Mavericks SSD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = C2441E72-2E2D-45A0-ACCD-D1D614121B14
2:175  0:000  Searching volumes for latest nvram.plist ...
2:175  0:000    1. Volume 'EFI', GUID = B364746E-0E70-4A01-94D7-C8AB11383FFF - no nvram.plist - skipping!
2:175  0:000    2. Volume 'Mac OS X', GUID = A002F3D8-3B76-42D2-A5A2-9812AA8198AA - no nvram.plist - skipping!
2:177  0:002    3. Volume 'WINDOWS', GUID = C7385942-47C5-4735-8669-0A7F48EA3AC6 - no nvram.plist - skipping!
2:177  0:000   10. Volume 'EFI', GUID = FEEE106F-E831-4D19-B184-865E44835B42 - no nvram.plist - skipping!
2:177  0:000   11. Volume 'Macintosh SSD', GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF - no nvram.plist - skipping!
2:181  0:003   12. Volume 'Recovery HD', GUID = 4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26 - no nvram.plist - skipping!
2:182  0:000   13. Volume 'EFI', GUID = 311429F1-F02D-4ECF-9D88-1279E445BA30 - no nvram.plist - skipping!
2:182  0:000   14. Volume 'Data', GUID = 8BB21494-4700-49C8-838F-3D82A2BD6095 - no nvram.plist - skipping!
2:203  0:021   16. Volume 'EFI', GUID = 81C0C004-4A64-4E66-9CD6-DA141C591BA7 - no nvram.plist - skipping!
2:203  0:000   17. Volume 'Mavericks SSD', GUID = C2441E72-2E2D-45A0-ACCD-D1D614121B14 - no nvram.plist - skipping!
2:206  0:003   nvram.plist not found!
2:206  0:000  PutNvramPlistToRtVars: nvram.plist not found
2:206  0:000  Invalidating BuiltinIcons...
2:208  0:001  Using theme 'gold_clover' (EFI\CLOVER\themes\gold_clover)
2:208  0:000  OS main and drive as badge
2:208  0:000  Font EFI\CLOVER\font\(null) is not loaded, using default
2:208  0:000  Font 0 prepared WxH=7x12 CharWidth=7
2:208  0:000  Choosing theme gold_clover
2:208  0:000  Custom entries start
2:208  0:000  Custom entries finish
2:208  0:000  Scanning loaders...
2:208  0:000   0: 'Whole Disc Boot' no file system
2:208  0:000   1: 'EFI'
2:223  0:015   2: 'Mac OS X'
2:233  0:009   3: 'WINDOWS' hidden
2:233  0:000   4: 'Whole Disc Boot' no file system
2:233  0:000   5: 'Whole Disc Boot' no file system
2:233  0:000   6: 'Whole Disc Boot' no file system
2:233  0:000   7: 'Whole Disc Boot' no file system
2:233  0:000   8: 'Legacy HD1' no file system
2:233  0:000   9: 'Legacy HD2' no file system
2:233  0:000  10: 'EFI'
2:241  0:008    hiding entry: \EFI\BOOT\BOOTX64.efi
2:241  0:000  11: 'Macintosh SSD'
2:248  0:006  Check if volume Is Hibernated:
2:248  0:000  Check sleep image 'by signature':
2:253  0:005  read prefs \Library\Preferences\SystemConfiguration\com.apple.PowerManagement.plist status=Not Found
2:253  0:000  using default sleep image name = \private\var\vm\sleepimage
2:258  0:004  Reading first 512 bytes of sleepimage ...
2:258  0:000   OurBlockIoRead: Lba=1764398, Offset=2EC873000 (BlockSize=512)
2:258  0:000   sig lion: F1E0BE9D
2:258  0:000   sig snow: 0
2:258  0:000   no valid sleep image offset was found
2:258  0:000  Reading completed -> Success
2:258  0:000   sleepimage offset could not be acquired
2:258  0:000   hibernated: no - sign
2:262  0:004    Icon 17 (icons\vol_internal_hfs.icns) not found
2:262  0:000    Theme path EFI\CLOVER\themes\gold_clover, ThemeDir=D108A318
2:263  0:000  found PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF,0x64028,0x1D02BA00)\System\Library\CoreServices\boot.efi
2:274  0:011  12: 'Recovery HD' hidden
2:274  0:000  13: 'EFI'
2:283  0:008  14: 'Data' hidden
2:283  0:000  15: 'Legacy HD3' no file system
2:283  0:000  16: 'EFI'
2:940  0:657  17: 'Mavericks SSD'
2:945  0:004  Check if volume Is Hibernated:
2:945  0:000  Check sleep image 'by signature':
2:952  0:007  read prefs \Library\Preferences\SystemConfiguration\com.apple.PowerManagement.plist status=Success
2:952  0:000  SleepImage name from pref: ImageVolume = 'Mavericks SSD', ImageName = '\private\var\vm\sleepimage'
2:957  0:004  Reading first 512 bytes of sleepimage ...
2:957  0:000   OurBlockIoRead: Lba=235BB48, Offset=46B769000 (BlockSize=512)
2:957  0:000   sig lion: 0
2:957  0:000   sig snow: 0
2:957  0:000   no valid sleep image offset was found
2:957  0:000  Reading completed -> Success
2:957  0:000   sleepimage offset could not be acquired
2:957  0:000   hibernated: no - sign
2:963  0:005  found PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)\HD(2,GPT,C2441E72-2E2D-45A0-ACCD-D1D614121B14,0x64028,0xDDFAC40)\System\Library\CoreServices\boot.efi
3:019  0:056  Custom legacy start
3:019  0:000  Custom legacy end
3:019  0:000  Scanning legacy ...
3:019  0:000   0: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   1: 'EFI' (<null string>) not legacy
3:019  0:000   2: 'Mac OS X' (<null string>) not legacy
3:019  0:000   3: 'WINDOWS' (<null string>) not legacy
3:019  0:000   4: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   5: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   6: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   7: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   8: 'Legacy HD1' (vista,win) add legacy
3:021  0:002   added 'Boot Windows from Legacy HD1' OSType=2 Icon=vista,win
3:021  0:000   9: 'Legacy HD2' (vista,win) hidden
3:021  0:000  10: 'EFI' (<null string>) not legacy
3:021  0:000  11: 'Macintosh SSD' (<null string>) not legacy
3:021  0:000  12: 'Recovery HD' (<null string>) not legacy
3:021  0:000  13: 'EFI' (<null string>) not legacy
3:021  0:000  14: 'Data' (<null string>) not legacy
3:021  0:000  15: 'Legacy HD3' (vista,win) hidden
3:021  0:000  16: 'EFI' (<null string>) not legacy
3:021  0:000  17: 'Mavericks SSD' (<null string>) not legacy
3:021  0:000  Custom tool start
3:021  0:000  Custom tool end
3:024  0:003  found tool \EFI\CLOVER\tools\Shell64U.efi
3:024  0:000  Checking EFI partition Volume 1 for Clover
3:024  0:000  Checking EFI partition Volume 10 for Clover
3:025  0:000   Found Clover
3:027  0:001  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
3:027  0:000  FindBootOptionForFile: D17C3E18, \EFI\CLOVER\CLOVERX64.EFI
3:027  0:000  BootOrder: 6: Boot0009, Boot000C, Boot000D, Boot000E, Boot000F, Boot0008
3:027  0:000   Searching for: PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)\EFI\CLOVER\CLOVERX64.EFI (Len: 130)
3:027  0:000   and for: HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)\EFI\CLOVER\CLOVERX64.EFI (Len: 102)
3:028  0:000  FindBootOptionForFile: Not found.
3:028  0:000  Checking EFI partition Volume 13 for Clover
3:028  0:000  Checking EFI partition Volume 16 for Clover
3:034  0:006  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
3:047  0:013  GetEfiBootDeviceFromNvram: efi-boot-device-data not found
3:047  0:000  EfiBootVolume not found
3:047  0:000  Searching for DefaultVolume 'MacHDD' ...
3:047  0:000  Default boot entry not found
3:047  0:000  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
3:047  0:000  DefaultIndex=-1 and MainMenu.EntryCount=9
3:047  0:000  Use anime=gold_clover_logo frames=180
3:969  0:921   found 180 frames of the anime
4:627  0:657  Found Mouse device:
4:628  0:001  GUI ready
6:585  1:956  StartLoader() start
6:585  0:000  Finally: Bus=100098kHz CPU=3503MHz
6:585  0:000  Loading boot.efi
6:797  0:212  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
6:811  0:013  insert table 9 for dev 0:0
6:811  0:000  insert table 9 for dev 0:0
6:811  0:000  Channels: 2
6:811  0:000  Interleave: 0 2 1 3 4 6 5 7 8 10 9 11 12 14 13 15 16 18 17 19 20 22 21 23
6:811  0:000  SMBIOS Type 17 Index = 0 => 0 0:
6:811  0:000  BANK0 DIMM0 EMPTY
6:811  0:000  SMBIOS Type 17 Index = 1 => 2 2:
6:811  0:000  BANK1 DIMM0 EMPTY
6:811  0:000  SMBIOS Type 17 Index = 2 => 1 1:
6:811  0:000  BANK0 DIMM1 1333MHz 8192MB
6:811  0:000  mTotalSystemMemory = 8192
6:811  0:000  SMBIOS Type 17 Index = 3 => 3 3:
6:811  0:000  BANK1 DIMM1 EMPTY
6:811  0:000  NumberOfMemoryDevices = 4
6:811  0:000  Type20[0]->End = 0x7FFFFF, Type17[2] = 0x2000
6:811  0:000  Table 131 is present, CPUType=10
6:811  0:000  Change to: 704
6:811  0:000  RSDT 0xDE08D028
6:811  0:000  FADT from RSDT: 0xDE08D0E8
6:811  0:000  XSDT 0xDE08D070
6:811  0:000  FADT from XSDT: 0xDE0979F8
6:811  0:000  Xsdt reallocation done
6:811  0:000  old FADT length=F4
6:811  0:000  Found OperationRegion(GNVS, SystemMemory, DE0AAE18, ...)
6:811  0:000  Found OperationRegion(MCHT, SystemMemory, FED10000, ...)
6:811  0:000  Found OperationRegion(RCRB, SystemMemory, FED1C000, ...)
6:811  0:000  Found OperationRegion(CPSB, SystemMemory, DDF7EF98, ...)
6:811  0:000  Found OperationRegion(IGDM, SystemMemory, 0, ...)
6:811  0:000  Found OperationRegion(TMMB, SystemMemory, FED40000, ...)
6:811  0:000  Found OperationRegion(TVID, SystemMemory, FED40F00, ...)
6:811  0:000  Found OperationRegion(TPMR, SystemMemory, FED40000, ...)
6:814  0:002  DSDT found in Clover volume OEM folder: EFI\CLOVER\ACPI\patched\DSDT.aml
6:815  0:001  page is allocated, write DSDT into
6:815  0:000  Apply DsdtFixMask=0x9FCAE955 new way
6:815  0:000     drop _DSM mask=0x0000
6:815  0:000  ========= Auto patch DSDT Starting ========
6:815  0:000  VideoCard devID=0x108010DE
6:815  0:000  DisplayADR1[0] = 0x10000, DisplayADR2[0] = 0x0
6:815  0:000  Display 0 is  notPCIE
6:815  0:000  USBADR[0] = 0x140000 and PCIe = 0xFFFE
6:815  0:000  USBADR[1] = 0x1A0000 and PCIe = 0xFFFE
7:118  0:302  USBADR[2] = 0x1C0004 and PCIe = 0x0
7:118  0:000  USBADR[3] = 0x1D0000 and PCIe = 0xFFFE
7:118  0:000  first CPU found at 8260 offset 8263
7:118  0:000  score candidate at 825C
7:118  0:000  score inserted in acpi_cpu_score _PR_
7:118  0:000  Found ACPI CPU: CPU0 And CPU1 And CPU2 And CPU3 And CPU4 And CPU5 And CPU6 And CPU7
  within the score: _PR_
7:118  0:000  Found PCIROOTUID = 0
7:118  0:000  Start RTC Fix
7:118  0:000  found RTC Length not match, Maybe will case CMOS reset will patch it.
7:118  0:000  found RTC had IRQNoFlag will move -3 bytes
7:118  0:000  ...len=ADA4
7:118  0:000  new size written to 2292 shift=0 len=ADA4
7:119  0:000  len after correct outers ADA4
7:119  0:000  Start PIC Fix
7:119  0:000  PIC size=A5 at 213E
7:119  0:000  found CRS at 2152 size 8D
7:119  0:000  found PIC had IRQNoFlag will move -3 bytes
7:119  0:000  Fix Device PIC size -3
7:119  0:000  Start HPET Fix
7:119  0:000  Start Display0 Fix
7:119  0:000  Found internal video device FFFF@473F, unusable
7:119  0:000  Creating DSM for NVIDIA card
7:119  0:000  patch Display #0 of Vendor=0x10DE in DSDT new way
7:119  0:000  Start NetWork Fix
7:120  0:000  found NetWork device [0x001C0006:0] at 45BA and Name is PXSX
7:120  0:000  NetworkADR1=1C0006 NetworkADR2=0
7:120  0:000  network DSM created, size=86
7:120  0:000  patch HDEF in DSDT
7:120  0:000  Start HDA Fix
7:120  0:000  found HDA device NAME(_ADR,0x001B0000) And Name is HDEF
7:120  0:000  NewName HDEF already present, renaming impossibble
7:120  0:000  _DSM already exists, patch HDA will not be applied
7:121  0:000  Start Add IMEI
7:121  0:000  Start HDMI3 Fix
7:121  0:000  have no HDMI device while HDMIADR2=1
7:121  0:000  HDMIADR1=10000 HDMIADR2=1
7:121  0:000    with default properties
7:121  0:000   deleting device CRT_
7:121  0:000   deleting device DVI_
7:121  0:000   deleting device SPKR
7:122  0:000   deleting device ECP_
7:122  0:000   deleting device LPT_
7:122  0:000   deleting device FDC0
7:122  0:000   deleting device ECP1
7:122  0:000   deleting device LPT1
7:123  0:000  Start PNLF Fix
7:123  0:000  found PWRB at 4B21
7:123  0:000  Start _S3D Fix
7:123  0:000  OperationRegion (GNVS...) corrected to addr=0xDE0AAE18
7:123  0:000  OperationRegion (MCHT...) corrected to addr=0xFED10000
7:123  0:000    indirect name=SRCB
7:123  0:000  OperationRegion (RCRB...) corrected to addr=0xFED1C000
7:123  0:000  OperationRegion (CPSB...) corrected to addr=0xDDF7EF98
7:123  0:000    indirect name=ASLB
7:123  0:000  ... value not defined
7:123  0:000  OperationRegion (IGDM...) corrected to addr=0x0
7:123  0:000  OperationRegion (TMMB...) corrected to addr=0xFED40000
7:123  0:000  OperationRegion (TVID...) corrected to addr=0xFED40F00
7:123  0:000  OperationRegion (TPMR...) corrected to addr=0xFED40000
7:123  0:000  Start ADP1 fix
7:123  0:000  no device(AC) exists
7:123  0:000  Start SHUTDOWN Fix len=AE64
7:123  0:000  ========= Auto patch DSDT Finished ========
7:123  0:000  Attempting to drop "SSDT" (54445353) "   CpuPm" (0000006D50757043) L=2706
7:123  0:000  Drop tables from Xsdt, SIGN=SSDT TableID=CpuPm Length=2706
7:123  0:000   Xsdt has tables count=8
7:123  0:000   Table: SSDT  CpuPm  2706 dropped
7:123  0:000  corrected XSDT length=92
7:123  0:000  Attempting to drop "SSDT" (54445353) " Cpu0Ist" (0074734930757043) L=2474
7:123  0:000  Drop tables from Xsdt, SIGN=SSDT TableID=Cpu0Ist Length=2474
7:123  0:000   Xsdt has tables count=7
7:123  0:000   Table: SSDT  Cpu0Ist  2474 dropped
7:123  0:000  corrected XSDT length=84
7:123  0:000  Patch table: SSDT  SataTabl
7:123  0:000   SSDT len = 0x36D
7:123  0:000  Drop tables from Xsdt, SIGN=XXXX TableID= Length=0
7:123  0:000   Xsdt has tables count=6
7:123  0:000  corrected XSDT length=84
7:123  0:000  Inserting SSDT.aml from EFI\CLOVER\ACPI\patched ... Success
7:126  0:002   CPUBase=0 and ApicCPUBase=1 ApicCPUNum=8
7:126  0:000  Maximum control=23
7:126  0:000  Turbo control=27
7:126  0:000  P-States: min 0x7, max 0x27
7:126  0:000  SSDT with CPU P-States generated successfully
7:126  0:000  SSDT with CPU C-States generated successfully
7:126  0:000  EdidDiscovered size=128
7:126  0:000  00 | 00 FF FF FF FF FF FF 00 10 AC 49 A0 53 48 34 32
7:126  0:000  16 | 31 13 01 03 0E 2C 19 78 EE EE 95 A3 54 4C 99 26
7:126  0:000  32 | 0F 50 54 A5 4B 00 71 4F 81 80 A9 C0 01 01 01 01
7:126  0:000  48 | 01 01 01 01 01 01 2F 26 40 A0 60 84 1A 30 30 20
7:126  0:000  64 | 35 00 BB F9 10 00 00 1A 00 00 00 FF 00 43 32 34
7:126  0:000  80 | 39 4E 39 43 33 32 34 48 53 0A 00 00 00 FC 00 44
7:126  0:000  96 | 45 4C 4C 20 49 4E 32 30 31 30 4E 0A 00 00 00 FD
7:126  0:000  112 | 00 38 4C 1E 53 11 00 0A 20 20 20 20 20 20 00 98
7:126  0:000  mem_detected 1610612736
7:126  0:000  read_nVidia_ROM
7:126  0:000  Using PRAMIN fixups
7:328  0:201  patch_nvidia_rom
7:328  0:000  version 70.10.17.00.01
7:328  0:000  nVidia MSi GeForce GTX 580  1536MB NVC8 [10DE:1080] ::
7:328  0:000  PciRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)
7:328  0:000  devprop_add_nvidia_template
7:328  0:000  default_NVCAP: 04000000-00000300-1C000000-00000007-00000000
7:328  0:000  USB Controller [8086:1E31] :: PciRoot(0x0)\Pci(0x14,0x0)
7:328  0:000  USB Controller [8086:1E2D] :: PciRoot(0x0)\Pci(0x1A,0x0)
7:328  0:000  USB Controller [1106:3432] :: PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)
7:328  0:000  USB Controller [8086:1E26] :: PciRoot(0x0)\Pci(0x1D,0x0)
7:328  0:000  stringlength = 3320
7:329  0:000  CurrentMode: Width=1600 Height=900
7:329  0:000  FSInjection: using kexts path: 'EFI\CLOVER\kexts\10.10'
7:333  0:004  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.10
7:335  0:002    Extra kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext
7:341  0:005    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\ACPISensors.kext
7:345  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\CPUSensors.kext
7:348  0:003    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\GPUSensors.kext
7:354  0:005    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\LPCSensors.kext
7:363  0:009    Extra kext: EFI\CLOVER\kexts\10.10\GenericUSBXHCI.kext
7:368  0:005    Extra kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext
7:377  0:008    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\ALXEthernet.kext
7:384  0:007    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleBCM5701Ethernet.kext
7:391  0:006    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleIntel8254XEthernet.kext
7:395  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleUSBEthernet.kext
7:399  0:003    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleUSBGigEthernet.kext
7:403  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleYukon2.kext
7:411  0:007    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\Intel82574L.kext
7:415  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\IOEthernetAVBController.kext
7:419  0:003    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\nvenet.kext
7:423  0:004    Extra kext: EFI\CLOVER\kexts\10.10\VoodooHDA.kext
7:444  0:020  SetStartupDiskVolume:
7:444  0:000    * Volume: 'Macintosh SSD'
7:444  0:000    * LoaderPath: '<null string>'
7:444  0:000    * DevPath: Macintosh SSD
7:444  0:000    * GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF
7:444  0:000    * efi-boot-device: <array><dict><key>IOMatch</key><dict><key>IOProviderClass</key><string>IOMedia</string><key>IOPropertyMatch</key><dict><key>UUID</key><string>235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF</string></dict></dict></dict></array>
7:444  0:000  Custom boot is disabled
7:444  0:000  Failed to initialize boot screen: Aborted!
7:444  0:000  Closing log

Look my VIDEO for boot system.

Link to comment
Share on other sites
joe75
joe75
Posted
Posted

and boot.log

0:100  0:100  MemLog inited, TSC freq: 3503441478
0:100  0:000
0:100  0:000  Now is 31.7.2014,  17:5:40 (GMT+2047)
0:100  0:000  Starting Clover rev 2780 on American Megatrends EFI
0:100  0:000  SelfDevicePath=PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000) @D17C3E18
0:100  0:000  SelfDirPath = \EFI\BOOT
0:100  0:000  UnicodeCollation Status=Success
0:100  0:000  Total Memory Slots Count = 4
0:100  0:000  Type 17 Index = 0
0:100  0:000  Ignoring insane frequency value 0MHz
0:100  0:000  SmbiosTable.Type17->Speed = 0
0:100  0:000  SmbiosTable.Type17->Size = 0
0:100  0:000  Type 17 Index = 1
0:100  0:000  SmbiosTable.Type17->Speed = 1333
0:100  0:000  SmbiosTable.Type17->Size = 8192
0:100  0:000  Type 17 Index = 2
0:100  0:000  Ignoring insane frequency value 0MHz
0:100  0:000  SmbiosTable.Type17->Speed = 0
0:100  0:000  SmbiosTable.Type17->Size = 0
0:100  0:000  Type 17 Index = 3
0:100  0:000  Ignoring insane frequency value 0MHz
0:100  0:000  SmbiosTable.Type17->Speed = 0
0:100  0:000  SmbiosTable.Type17->Size = 0
0:100  0:000  Boot status=0
0:100  0:000  Clover revision: 2780  running on To be filled by O.E.M.
0:100  0:000  ... with board Z77X-UD3H
0:100  0:000  Clover load options size = 4 bytes
0:104  0:004  Oem AMBO.plist not found at path: EFI\CLOVER\AMBO.plist
0:104  0:000  EFI\CLOVER\AMBO.plist not loaded with name from LoadOptions: Not Found
0:105  0:001  Using OEM config.plist at path: EFI\CLOVER\config.plist
0:106  0:000  EFI\CLOVER\config.plist loaded: Success
0:109  0:003  Found theme applestyle
0:112  0:003  Found theme BGM
0:117  0:005  Found theme BLACK
0:120  0:002  Found theme black_green
0:123  0:003  Found theme BLUEMAC
0:126  0:003  Found theme BOOTCAMP
0:128  0:002  Found theme gold_clover
0:132  0:003  Found theme ICLOVER
0:134  0:002  Found theme magnifico
0:136  0:002  Found theme METAL
0:140  0:003  Found theme MRENGLES
0:143  0:002  Found theme ORANGE
0:145  0:002  Found theme OS_BOX
0:147  0:002  Found theme OS_ONE
0:149  0:001  Found theme Shield
0:155  0:005  Found theme THINKPAD
0:157  0:002  Loading early settings
0:157  0:000  timeout set to 2
0:157  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
0:157  0:000  Default theme: gold_clover
0:157  0:000  Hiding entries with string Legacy HD3
0:157  0:000  Hiding entries with string BOOTX64.EFI
0:157  0:000  Hiding entries with string Legacy HD2
0:157  0:000  Hiding entries with string Data
0:157  0:000  Hiding entries with string Windows
0:157  0:000  Hiding entries with string Recovery HD
0:157  0:000  LoadDrivers() start
0:160  0:003  Loading CsmVideoDxe-64.efi
0:162  0:001   - driver needs connecting
0:162  0:000  Loading DataHubDxe-64.efi
0:183  0:021  Loading EmuVariableUefi-64.efi
0:184  0:001  EmuVariableUefi Initialize: VariableCommonInitialize = Success, orig services stored, install gEmuVariableControlProtocolGuid = Success
0:186  0:001  Loading FSInject-64.efi
0:187  0:001  Loading OsxAptioFixDrv-64.efi
0:189  0:001  Loading OsxFatBinaryDrv-64.efi
0:190  0:001  Loading PartitionDxe-64.efi
0:191  0:001   - driver needs connecting
0:191  0:000  Loading VBoxHfs-64.efi
0:193  0:001   - driver needs connecting
0:193  0:000  3 drivers needs connecting ...
0:193  0:000  PlatformDriverOverrideProtocol not found. Installing ... Success
0:193  0:000  Partition driver loaded:
0:193  0:000  Video driver loaded: disconnect Success
0:278  0:084  Searching for invalid DiskIo BY_DRIVER connects: not found, all ok
0:278  0:000  VideoBiosPatchNativeFromEdid:
0:278  0:000   Bios: nVidia, nv_data_table_offset: 0x267, nv_data_table: 0xC0269, std_vesa: 0xC411B, nv_mode_table: 0xC4120, mode_table_size: 0x10
0:278  0:000   VideoBiosPatchInit(LegacyRegion = Success) = Success
0:278  0:000   VideoBiosUnlock:  unlocked
0:279  0:001   Patching: BT_NVDA
0:279  0:000   Parse Edid: descriptor block 0 is timing descriptor (h_active: 1600, v_active: 900, h_sync_offset: 48, h_sync_width: 32, h_blanking: 160, v_blanking: 26, pixel_clock: 9775, v_sync_offset: 3, v_sync_width: 5)
0:280  0:000   patch 0: patched 1 time(s)
0:280  0:000   patch 1: patched 1 time(s)
0:281  0:000   patch 2: patched 1 time(s)
0:281  0:000   patch 3: patched 1 time(s)
0:281  0:000   VideoBiosLock: Success
0:302  0:020  CsmVideoDriverBindingStart
0:302  0:000  mixed support=40010
0:302  0:000  Controller is [030000]
0:302  0:000  Check for VBE
0:346  0:044   found Detail Timing 1600x900
0:350  0:004    0 640x480 attr=3BF - ok, edid+, 640x480, working, highest, pref=0
0:351  0:000    1 800x600 attr=3BF - ok, edid+, 800x600, working, highest, pref=1
0:352  0:000    2 1024x768 attr=3BF - ok, edid+, 1024x768, working, highest, pref=2
0:355  0:003    3 1600x900 attr=3BF - ok, edid+, working, highest, pref=3
0:355  0:000  CsmVideo: New mode: 3 1600x900 - set
1:027  0:671   - SetMode pref 3 (3) = Success
1:027  0:000  CsmVideoCheckForVbe - Success
1:027  0:000  CsmVideoDriverBindingStart end Success
1:027  0:000  CsmVideo: New mode: 2 1024x768 - blocking that switch
1:027  0:000  CsmVideo: New mode: 2 1024x768 - blocking that switch
1:028  0:000  CsmVideo: New mode: 2 1024x768 - blocking that switch
1:189  0:161  LoadDrivers() end
1:189  0:000  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
1:202  0:013  SetScreenResolution: 1920x1080 - not found!
1:202  0:000  Console modes reported: 4, available modes:
1:202  0:000    Mode 1: 80x25 (current mode)
1:202  0:000    Mode 3: 100x31
1:202  0:000    Mode 4: 128x30
1:202  0:000  reinit: self device path=PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)
1:202  0:000  new SelfHandle=D17C3E18
1:202  0:000  CPU Vendor = 756E6547 Model=306A9
1:202  0:000  The CPU supported turbo
1:202  0:000  BrandString = Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
1:202  0:000  MSR 0xE2 before patch 1E000403
1:202  0:000  MSR 0xE4              00010414
1:202  0:000  MSR 0xCE              00081010_F0012300
1:202  0:000  non-usable FLEX_RATIO = F0000
1:202  0:000  corrected FLEX_RATIO = E0000
1:202  0:000  MSR 0x1B0             00000000
1:202  0:000  FSBFrequency=105MHz
1:202  0:000  Corrected FSBFrequency=100MHz
1:202  0:000  Vendor/Model/Stepping: 0x756E6547/0x3A/0x9
1:202  0:000  Family/ExtFamily: 0x6/0x0
1:202  0:000  MaxDiv/MinDiv: 35.0/16
1:202  0:000  Turbo: 37/38/39/39
1:202  0:000  Features: 0xBFEBFBFF
1:202  0:000  Threads: 8
1:202  0:000  Cores: 4
1:202  0:000  FSB: 100 MHz
1:202  0:000  CPU: 3700 MHz
1:202  0:000  TSC: 3700 MHz
1:202  0:000  PIS: 400 MHz
1:202  0:000  PCI (00|00:00.00) : 8086 0150 class=060000
1:202  0:000  PCI (00|00:01.00) : 8086 0151 class=060400
1:202  0:000  PCI (00|01:00.00) : 10DE 1080 class=030000
1:202  0:000  Found NVidia model=MSi GeForce GTX 580
1:202  0:000  PCI (00|01:00.01) : 10DE 0E09 class=040300
1:202  0:000  PCI (00|00:14.00) : 8086 1E31 class=0C0330
1:202  0:000  PCI (00|00:16.00) : 8086 1E3A class=078000
1:202  0:000  PCI (00|00:16.01) : FFFF FFFF class=FFFFFF
1:202  0:000  PCI (00|00:1A.00) : 8086 1E2D class=0C0320
1:202  0:000  PCI (00|00:1B.00) : 8086 1E20 class=040300
1:202  0:000  PCI (00|00:1C.00) : 8086 1E10 class=060400
1:202  0:000  PCI (00|00:1C.04) : 8086 1E18 class=060400
1:202  0:000  PCI (00|03:00.00) : 1106 3432 class=0C0330
1:202  0:000  PCI (00|00:1C.05) : 8086 244E class=060401
1:202  0:000  PCI (00|04:00.00) : 8086 244E class=060401
1:203  0:000  PCI (00|05:00.00) : 168C 001A class=020000
1:203  0:000  PCI (00|00:1C.06) : 8086 1E1C class=060400
1:203  0:000  PCI (00|06:00.00) : 1969 1083 class=020000
1:203  0:000  PCI (00|00:1C.07) : 8086 1E1E class=060400
1:203  0:000  PCI (00|07:00.00) : 1B4B 9172 class=010601
1:203  0:000  PCI (00|00:1D.00) : 8086 1E26 class=0C0320
1:203  0:000  PCI (00|00:1F.00) : 8086 1E44 class=060100
1:203  0:000  PCI (00|00:1F.02) : 8086 1E02 class=010601
1:203  0:000  PCI (00|00:1F.03) : 8086 1E22 class=0C0500
1:203  0:000  PCI (00|00:1F.06) : FFFF FFFF class=FFFFFF
1:203  0:000  ScanSPD() start
1:203  0:000  SMBus CmdReg: 0x1
1:203  0:000  Scanning SMBus [8086:1E22], mmio: 0xF7515004, ioport: 0xF000, hostc: 0x1
1:224  0:020  SPD[1]: Type 11 @0x51
1:233  0:008  DDR speed 1333MHz
1:233  0:000  Slot: 1 Type 24 8192MB 1333MHz Vendor=Corsair PartNo=CMX8GX3M1A1600C11 SerialNo=0000000000000000
1:372  0:139  ScanSPD() end
1:372  0:000  Get Acpi Tables List from RSDT:
1:372  0:000   Found table: FACP  A M I len=132
1:372  0:000   Found table: APIC  A M I len=146
1:372  0:000   Found table: MCFG   len=60
1:372  0:000   Found table: HPET  A M I len=56
1:372  0:000   Found table: SSDT  SataTabl len=877
1:372  0:000   Found table: SSDT  Cpu0Ist len=2474
1:372  0:000   Found table: SSDT  CpuPm len=2706
1:372  0:000   Found table: BGRT  A M I len=56
1:372  0:000  Calibrated TSC frequency =3503441478 =3503MHz
1:372  0:000  Loading main settings
1:372  0:000  USB FixOwnership: true
1:372  0:000  Dropping 3 tables
1:372  0:000  Drop table 0 signature="DMAR" (52414D44)
1:372  0:000  set table: 52414D44,                0 to drop:
1:372  0:000  Drop table 1 signature="SSDT" (54445353) table-id="Cpu0Ist" (0074734930757043)
1:372  0:000  set table: 54445353,   74734930757043 to drop:  true
1:372  0:000
1:372  0:000  Drop table 2 signature="SSDT" (54445353) table-id="CpuPm" (0000006D50757043)
1:372  0:000  set table: 54445353,       6D50757043 to drop:  true
1:372  0:000
1:372  0:000  Config set Fixes will override FixMask mask!
1:372  0:000     final mask=9FCAE955
1:372  0:000  Config set EnableC6: +
1:372  0:000  Config set ChassisType=0xD
1:372  0:000  Config set FakeCPUID=0
1:372  0:000  KextsToPatch: 1 requested
1:372  0:000  KextToPatch 0: AppleAHCIPort (External icons patch) Kext bin patch, data len: 8
1:373  0:000  Oem smbios.plist not found at path: EFI\CLOVER\smbios.plist
1:373  0:000  smbios.plist not found, not overriding config.plist
1:373  0:000  found 18 volumes with blockIO
1:373  0:000   0. Volume:
1:373  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)
1:404  0:031    USB volume
1:404  0:000    USB volume
1:404  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
1:404  0:000   1. Volume:
1:404  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)\HD(1,GPT,B364746E-0E70-4A01-94D7-C8AB11383FFF,0x28,0x64000)
1:405  0:000    Result of bootcode detection: bootable <null string> (<null string>)
1:405  0:000    USB volume
1:405  0:000    USB volume
1:467  0:061    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = B364746E-0E70-4A01-94D7-C8AB11383FFF
1:467  0:000   2. Volume:
1:467  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)\HD(2,GPT,A002F3D8-3B76-42D2-A5A2-9812AA8198AA,0x64028,0x12A17558)
1:467  0:000    USB volume
1:467  0:000    USB volume
1:467  0:000    Volume 'Mac OS X', LegacyOS '', LegacyIcon(s) '<null string>', GUID = A002F3D8-3B76-42D2-A5A2-9812AA8198AA
1:467  0:000   3. Volume:
1:467  0:000    PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)\USB(0x1,0x0)\USB(0x4,0x0)\HD(3,GPT,C7385942-47C5-4735-8669-0A7F48EA3AC6,0x12ABB800,0x12973000)
1:487  0:019    Result of bootcode detection: bootable <null string> (<null string>)
1:487  0:000    USB volume
1:487  0:000    USB volume
2:123  0:636    hiding this volume
2:123  0:000    Volume 'WINDOWS', LegacyOS '', LegacyIcon(s) '<null string>', GUID = C7385942-47C5-4735-8669-0A7F48EA3AC6
2:123  0:000   4. Volume:
2:123  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0xFFFF,0x0)
2:125  0:002    Result of bootcode detection: bootable <null string> (<null string>)
2:126  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:126  0:000   5. Volume:
2:126  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)
2:128  0:002    Result of bootcode detection: bootable <null string> (<null string>)
2:128  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:128  0:000   6. Volume:
2:128  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)
2:128  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:128  0:000   7. Volume:
2:128  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)
2:129  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:129  0:000    Volume 'Whole Disc Boot', LegacyOS '', LegacyIcon(s) 'legacy', GUID = <null guid>
2:129  0:000   8. Volume:
2:129  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0xFFFF,0x0)\HD(1,MBR,0xD8A273CD,0x800,0xAF000)
2:130  0:000    Result of bootcode detection: bootable Windows (vista,win)
2:130  0:000    Volume 'Legacy HD1', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = <null guid>
2:130  0:000   9. Volume:
2:130  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0xFFFF,0x0)\HD(2,MBR,0xD8A273CD,0xAF800,0x1BE74000)
2:130  0:000    Result of bootcode detection: bootable Windows (vista,win)
2:130  0:000    hiding this volume
2:130  0:000    Volume 'Legacy HD2', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = <null guid>
2:130  0:000  10. Volume:
2:130  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)
2:131  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:144  0:013    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = FEEE106F-E831-4D19-B184-865E44835B42
2:144  0:000    This is SelfVolume !!
2:144  0:000  11. Volume:
2:145  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF,0x64028,0x1D02BA00)
2:145  0:000    Volume 'Macintosh SSD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF
2:145  0:000  12. Volume:
2:145  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(3,GPT,4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26,0x1D08FA28,0x135F20)
2:146  0:000    hiding this volume
2:146  0:000    Volume 'Recovery HD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26
2:146  0:000  13. Volume:
2:146  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)\HD(1,GPT,311429F1-F02D-4ECF-9D88-1279E445BA30,0x28,0x64000)
2:146  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:165  0:018    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 311429F1-F02D-4ECF-9D88-1279E445BA30
2:165  0:000  14. Volume:
2:165  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)\HD(2,GPT,8BB21494-4700-49C8-838F-3D82A2BD6095,0x64028,0x174876E8)
2:166  0:000    hiding this volume
2:166  0:000    Volume 'Data', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 8BB21494-4700-49C8-838F-3D82A2BD6095
2:166  0:000  15. Volume:
2:166  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x3,0xFFFF,0x0)\HD(3,GPT,9A305228-83D9-4556-A5F8-365BDEA35847,0x1752B800,0x22E5A800)
2:166  0:000    Result of bootcode detection: bootable Windows (vista,win)
2:166  0:000    hiding this volume
2:166  0:000    Volume 'Legacy HD3', LegacyOS 'Windows', LegacyIcon(s) 'vista,win', GUID = 9A305228-83D9-4556-A5F8-365BDEA35847
2:166  0:000  16. Volume:
2:166  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)\HD(1,GPT,81C0C004-4A64-4E66-9CD6-DA141C591BA7,0x28,0x64000)
2:167  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:174  0:007    Volume 'EFI', LegacyOS '', LegacyIcon(s) '<null string>', GUID = 81C0C004-4A64-4E66-9CD6-DA141C591BA7
2:174  0:000  17. Volume:
2:175  0:000    PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)\HD(2,GPT,C2441E72-2E2D-45A0-ACCD-D1D614121B14,0x64028,0xDDFAC40)
2:175  0:000    Result of bootcode detection: bootable <null string> (<null string>)
2:175  0:000    Volume 'Mavericks SSD', LegacyOS '', LegacyIcon(s) '<null string>', GUID = C2441E72-2E2D-45A0-ACCD-D1D614121B14
2:175  0:000  Searching volumes for latest nvram.plist ...
2:175  0:000    1. Volume 'EFI', GUID = B364746E-0E70-4A01-94D7-C8AB11383FFF - no nvram.plist - skipping!
2:175  0:000    2. Volume 'Mac OS X', GUID = A002F3D8-3B76-42D2-A5A2-9812AA8198AA - no nvram.plist - skipping!
2:177  0:002    3. Volume 'WINDOWS', GUID = C7385942-47C5-4735-8669-0A7F48EA3AC6 - no nvram.plist - skipping!
2:177  0:000   10. Volume 'EFI', GUID = FEEE106F-E831-4D19-B184-865E44835B42 - no nvram.plist - skipping!
2:177  0:000   11. Volume 'Macintosh SSD', GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF - no nvram.plist - skipping!
2:181  0:003   12. Volume 'Recovery HD', GUID = 4CFFB8A9-678F-4BDA-9CD0-1C7C6214BA26 - no nvram.plist - skipping!
2:182  0:000   13. Volume 'EFI', GUID = 311429F1-F02D-4ECF-9D88-1279E445BA30 - no nvram.plist - skipping!
2:182  0:000   14. Volume 'Data', GUID = 8BB21494-4700-49C8-838F-3D82A2BD6095 - no nvram.plist - skipping!
2:203  0:021   16. Volume 'EFI', GUID = 81C0C004-4A64-4E66-9CD6-DA141C591BA7 - no nvram.plist - skipping!
2:203  0:000   17. Volume 'Mavericks SSD', GUID = C2441E72-2E2D-45A0-ACCD-D1D614121B14 - no nvram.plist - skipping!
2:206  0:003   nvram.plist not found!
2:206  0:000  PutNvramPlistToRtVars: nvram.plist not found
2:206  0:000  Invalidating BuiltinIcons...
2:208  0:001  Using theme 'gold_clover' (EFI\CLOVER\themes\gold_clover)
2:208  0:000  OS main and drive as badge
2:208  0:000  Font EFI\CLOVER\font\(null) is not loaded, using default
2:208  0:000  Font 0 prepared WxH=7x12 CharWidth=7
2:208  0:000  Choosing theme gold_clover
2:208  0:000  Custom entries start
2:208  0:000  Custom entries finish
2:208  0:000  Scanning loaders...
2:208  0:000   0: 'Whole Disc Boot' no file system
2:208  0:000   1: 'EFI'
2:223  0:015   2: 'Mac OS X'
2:233  0:009   3: 'WINDOWS' hidden
2:233  0:000   4: 'Whole Disc Boot' no file system
2:233  0:000   5: 'Whole Disc Boot' no file system
2:233  0:000   6: 'Whole Disc Boot' no file system
2:233  0:000   7: 'Whole Disc Boot' no file system
2:233  0:000   8: 'Legacy HD1' no file system
2:233  0:000   9: 'Legacy HD2' no file system
2:233  0:000  10: 'EFI'
2:241  0:008    hiding entry: \EFI\BOOT\BOOTX64.efi
2:241  0:000  11: 'Macintosh SSD'
2:248  0:006  Check if volume Is Hibernated:
2:248  0:000  Check sleep image 'by signature':
2:253  0:005  read prefs \Library\Preferences\SystemConfiguration\com.apple.PowerManagement.plist status=Not Found
2:253  0:000  using default sleep image name = \private\var\vm\sleepimage
2:258  0:004  Reading first 512 bytes of sleepimage ...
2:258  0:000   OurBlockIoRead: Lba=1764398, Offset=2EC873000 (BlockSize=512)
2:258  0:000   sig lion: F1E0BE9D
2:258  0:000   sig snow: 0
2:258  0:000   no valid sleep image offset was found
2:258  0:000  Reading completed -> Success
2:258  0:000   sleepimage offset could not be acquired
2:258  0:000   hibernated: no - sign
2:262  0:004    Icon 17 (icons\vol_internal_hfs.icns) not found
2:262  0:000    Theme path EFI\CLOVER\themes\gold_clover, ThemeDir=D108A318
2:263  0:000  found PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(2,GPT,235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF,0x64028,0x1D02BA00)\System\Library\CoreServices\boot.efi
2:274  0:011  12: 'Recovery HD' hidden
2:274  0:000  13: 'EFI'
2:283  0:008  14: 'Data' hidden
2:283  0:000  15: 'Legacy HD3' no file system
2:283  0:000  16: 'EFI'
2:940  0:657  17: 'Mavericks SSD'
2:945  0:004  Check if volume Is Hibernated:
2:945  0:000  Check sleep image 'by signature':
2:952  0:007  read prefs \Library\Preferences\SystemConfiguration\com.apple.PowerManagement.plist status=Success
2:952  0:000  SleepImage name from pref: ImageVolume = 'Mavericks SSD', ImageName = '\private\var\vm\sleepimage'
2:957  0:004  Reading first 512 bytes of sleepimage ...
2:957  0:000   OurBlockIoRead: Lba=235BB48, Offset=46B769000 (BlockSize=512)
2:957  0:000   sig lion: 0
2:957  0:000   sig snow: 0
2:957  0:000   no valid sleep image offset was found
2:957  0:000  Reading completed -> Success
2:957  0:000   sleepimage offset could not be acquired
2:957  0:000   hibernated: no - sign
2:963  0:005  found PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0xFFFF,0x0)\HD(2,GPT,C2441E72-2E2D-45A0-ACCD-D1D614121B14,0x64028,0xDDFAC40)\System\Library\CoreServices\boot.efi
3:019  0:056  Custom legacy start
3:019  0:000  Custom legacy end
3:019  0:000  Scanning legacy ...
3:019  0:000   0: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   1: 'EFI' (<null string>) not legacy
3:019  0:000   2: 'Mac OS X' (<null string>) not legacy
3:019  0:000   3: 'WINDOWS' (<null string>) not legacy
3:019  0:000   4: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   5: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   6: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   7: 'Whole Disc Boot' (legacy) not legacy
3:019  0:000   8: 'Legacy HD1' (vista,win) add legacy
3:021  0:002   added 'Boot Windows from Legacy HD1' OSType=2 Icon=vista,win
3:021  0:000   9: 'Legacy HD2' (vista,win) hidden
3:021  0:000  10: 'EFI' (<null string>) not legacy
3:021  0:000  11: 'Macintosh SSD' (<null string>) not legacy
3:021  0:000  12: 'Recovery HD' (<null string>) not legacy
3:021  0:000  13: 'EFI' (<null string>) not legacy
3:021  0:000  14: 'Data' (<null string>) not legacy
3:021  0:000  15: 'Legacy HD3' (vista,win) hidden
3:021  0:000  16: 'EFI' (<null string>) not legacy
3:021  0:000  17: 'Mavericks SSD' (<null string>) not legacy
3:021  0:000  Custom tool start
3:021  0:000  Custom tool end
3:024  0:003  found tool \EFI\CLOVER\tools\Shell64U.efi
3:024  0:000  Checking EFI partition Volume 1 for Clover
3:024  0:000  Checking EFI partition Volume 10 for Clover
3:025  0:000   Found Clover
3:027  0:001  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
3:027  0:000  FindBootOptionForFile: D17C3E18, \EFI\CLOVER\CLOVERX64.EFI
3:027  0:000  BootOrder: 6: Boot0009, Boot000C, Boot000D, Boot000E, Boot000F, Boot0008
3:027  0:000   Searching for: PciRoot(0x0)\Pci(0x1F,0x2)\Sata(0x1,0xFFFF,0x0)\HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)\EFI\CLOVER\CLOVERX64.EFI (Len: 130)
3:027  0:000   and for: HD(1,GPT,FEEE106F-E831-4D19-B184-865E44835B42,0x28,0x64000)\EFI\CLOVER\CLOVERX64.EFI (Len: 102)
3:028  0:000  FindBootOptionForFile: Not found.
3:028  0:000  Checking EFI partition Volume 13 for Clover
3:028  0:000  Checking EFI partition Volume 16 for Clover
3:034  0:006  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
3:047  0:013  GetEfiBootDeviceFromNvram: efi-boot-device-data not found
3:047  0:000  EfiBootVolume not found
3:047  0:000  Searching for DefaultVolume 'MacHDD' ...
3:047  0:000  Default boot entry not found
3:047  0:000  EmuVariable UninstallEmulation: CloseEvent = Success, original var services restored
3:047  0:000  DefaultIndex=-1 and MainMenu.EntryCount=9
3:047  0:000  Use anime=gold_clover_logo frames=180
3:969  0:921   found 180 frames of the anime
4:627  0:657  Found Mouse device:
4:628  0:001  GUI ready
6:585  1:956  StartLoader() start
6:585  0:000  Finally: Bus=100098kHz CPU=3503MHz
6:585  0:000  Loading boot.efi
6:797  0:212  EmuVariable InstallEmulation: orig vars copied, emu.var.services installed, CreateEvent VirtualAddressChange = Success, CreateEvent ExitBootServices = Success, set Status=Success
6:811  0:013  insert table 9 for dev 0:0
6:811  0:000  insert table 9 for dev 0:0
6:811  0:000  Channels: 2
6:811  0:000  Interleave: 0 2 1 3 4 6 5 7 8 10 9 11 12 14 13 15 16 18 17 19 20 22 21 23
6:811  0:000  SMBIOS Type 17 Index = 0 => 0 0:
6:811  0:000  BANK0 DIMM0 EMPTY
6:811  0:000  SMBIOS Type 17 Index = 1 => 2 2:
6:811  0:000  BANK1 DIMM0 EMPTY
6:811  0:000  SMBIOS Type 17 Index = 2 => 1 1:
6:811  0:000  BANK0 DIMM1 1333MHz 8192MB
6:811  0:000  mTotalSystemMemory = 8192
6:811  0:000  SMBIOS Type 17 Index = 3 => 3 3:
6:811  0:000  BANK1 DIMM1 EMPTY
6:811  0:000  NumberOfMemoryDevices = 4
6:811  0:000  Type20[0]->End = 0x7FFFFF, Type17[2] = 0x2000
6:811  0:000  Table 131 is present, CPUType=10
6:811  0:000  Change to: 704
6:811  0:000  RSDT 0xDE08D028
6:811  0:000  FADT from RSDT: 0xDE08D0E8
6:811  0:000  XSDT 0xDE08D070
6:811  0:000  FADT from XSDT: 0xDE0979F8
6:811  0:000  Xsdt reallocation done
6:811  0:000  old FADT length=F4
6:811  0:000  Found OperationRegion(GNVS, SystemMemory, DE0AAE18, ...)
6:811  0:000  Found OperationRegion(MCHT, SystemMemory, FED10000, ...)
6:811  0:000  Found OperationRegion(RCRB, SystemMemory, FED1C000, ...)
6:811  0:000  Found OperationRegion(CPSB, SystemMemory, DDF7EF98, ...)
6:811  0:000  Found OperationRegion(IGDM, SystemMemory, 0, ...)
6:811  0:000  Found OperationRegion(TMMB, SystemMemory, FED40000, ...)
6:811  0:000  Found OperationRegion(TVID, SystemMemory, FED40F00, ...)
6:811  0:000  Found OperationRegion(TPMR, SystemMemory, FED40000, ...)
6:814  0:002  DSDT found in Clover volume OEM folder: EFI\CLOVER\ACPI\patched\DSDT.aml
6:815  0:001  page is allocated, write DSDT into
6:815  0:000  Apply DsdtFixMask=0x9FCAE955 new way
6:815  0:000     drop _DSM mask=0x0000
6:815  0:000  ========= Auto patch DSDT Starting ========
6:815  0:000  VideoCard devID=0x108010DE
6:815  0:000  DisplayADR1[0] = 0x10000, DisplayADR2[0] = 0x0
6:815  0:000  Display 0 is  notPCIE
6:815  0:000  USBADR[0] = 0x140000 and PCIe = 0xFFFE
6:815  0:000  USBADR[1] = 0x1A0000 and PCIe = 0xFFFE
7:118  0:302  USBADR[2] = 0x1C0004 and PCIe = 0x0
7:118  0:000  USBADR[3] = 0x1D0000 and PCIe = 0xFFFE
7:118  0:000  first CPU found at 8260 offset 8263
7:118  0:000  score candidate at 825C
7:118  0:000  score inserted in acpi_cpu_score _PR_
7:118  0:000  Found ACPI CPU: CPU0 And CPU1 And CPU2 And CPU3 And CPU4 And CPU5 And CPU6 And CPU7
  within the score: _PR_
7:118  0:000  Found PCIROOTUID = 0
7:118  0:000  Start RTC Fix
7:118  0:000  found RTC Length not match, Maybe will case CMOS reset will patch it.
7:118  0:000  found RTC had IRQNoFlag will move -3 bytes
7:118  0:000  ...len=ADA4
7:118  0:000  new size written to 2292 shift=0 len=ADA4
7:119  0:000  len after correct outers ADA4
7:119  0:000  Start PIC Fix
7:119  0:000  PIC size=A5 at 213E
7:119  0:000  found CRS at 2152 size 8D
7:119  0:000  found PIC had IRQNoFlag will move -3 bytes
7:119  0:000  Fix Device PIC size -3
7:119  0:000  Start HPET Fix
7:119  0:000  Start Display0 Fix
7:119  0:000  Found internal video device FFFF@473F, unusable
7:119  0:000  Creating DSM for NVIDIA card
7:119  0:000  patch Display #0 of Vendor=0x10DE in DSDT new way
7:119  0:000  Start NetWork Fix
7:120  0:000  found NetWork device [0x001C0006:0] at 45BA and Name is PXSX
7:120  0:000  NetworkADR1=1C0006 NetworkADR2=0
7:120  0:000  network DSM created, size=86
7:120  0:000  patch HDEF in DSDT
7:120  0:000  Start HDA Fix
7:120  0:000  found HDA device NAME(_ADR,0x001B0000) And Name is HDEF
7:120  0:000  NewName HDEF already present, renaming impossibble
7:120  0:000  _DSM already exists, patch HDA will not be applied
7:121  0:000  Start Add IMEI
7:121  0:000  Start HDMI3 Fix
7:121  0:000  have no HDMI device while HDMIADR2=1
7:121  0:000  HDMIADR1=10000 HDMIADR2=1
7:121  0:000    with default properties
7:121  0:000   deleting device CRT_
7:121  0:000   deleting device DVI_
7:121  0:000   deleting device SPKR
7:122  0:000   deleting device ECP_
7:122  0:000   deleting device LPT_
7:122  0:000   deleting device FDC0
7:122  0:000   deleting device ECP1
7:122  0:000   deleting device LPT1
7:123  0:000  Start PNLF Fix
7:123  0:000  found PWRB at 4B21
7:123  0:000  Start _S3D Fix
7:123  0:000  OperationRegion (GNVS...) corrected to addr=0xDE0AAE18
7:123  0:000  OperationRegion (MCHT...) corrected to addr=0xFED10000
7:123  0:000    indirect name=SRCB
7:123  0:000  OperationRegion (RCRB...) corrected to addr=0xFED1C000
7:123  0:000  OperationRegion (CPSB...) corrected to addr=0xDDF7EF98
7:123  0:000    indirect name=ASLB
7:123  0:000  ... value not defined
7:123  0:000  OperationRegion (IGDM...) corrected to addr=0x0
7:123  0:000  OperationRegion (TMMB...) corrected to addr=0xFED40000
7:123  0:000  OperationRegion (TVID...) corrected to addr=0xFED40F00
7:123  0:000  OperationRegion (TPMR...) corrected to addr=0xFED40000
7:123  0:000  Start ADP1 fix
7:123  0:000  no device(AC) exists
7:123  0:000  Start SHUTDOWN Fix len=AE64
7:123  0:000  ========= Auto patch DSDT Finished ========
7:123  0:000  Attempting to drop "SSDT" (54445353) "   CpuPm" (0000006D50757043) L=2706
7:123  0:000  Drop tables from Xsdt, SIGN=SSDT TableID=CpuPm Length=2706
7:123  0:000   Xsdt has tables count=8
7:123  0:000   Table: SSDT  CpuPm  2706 dropped
7:123  0:000  corrected XSDT length=92
7:123  0:000  Attempting to drop "SSDT" (54445353) " Cpu0Ist" (0074734930757043) L=2474
7:123  0:000  Drop tables from Xsdt, SIGN=SSDT TableID=Cpu0Ist Length=2474
7:123  0:000   Xsdt has tables count=7
7:123  0:000   Table: SSDT  Cpu0Ist  2474 dropped
7:123  0:000  corrected XSDT length=84
7:123  0:000  Patch table: SSDT  SataTabl
7:123  0:000   SSDT len = 0x36D
7:123  0:000  Drop tables from Xsdt, SIGN=XXXX TableID= Length=0
7:123  0:000   Xsdt has tables count=6
7:123  0:000  corrected XSDT length=84
7:123  0:000  Inserting SSDT.aml from EFI\CLOVER\ACPI\patched ... Success
7:126  0:002   CPUBase=0 and ApicCPUBase=1 ApicCPUNum=8
7:126  0:000  Maximum control=23
7:126  0:000  Turbo control=27
7:126  0:000  P-States: min 0x7, max 0x27
7:126  0:000  SSDT with CPU P-States generated successfully
7:126  0:000  SSDT with CPU C-States generated successfully
7:126  0:000  EdidDiscovered size=128
7:126  0:000  00 | 00 FF FF FF FF FF FF 00 10 AC 49 A0 53 48 34 32
7:126  0:000  16 | 31 13 01 03 0E 2C 19 78 EE EE 95 A3 54 4C 99 26
7:126  0:000  32 | 0F 50 54 A5 4B 00 71 4F 81 80 A9 C0 01 01 01 01
7:126  0:000  48 | 01 01 01 01 01 01 2F 26 40 A0 60 84 1A 30 30 20
7:126  0:000  64 | 35 00 BB F9 10 00 00 1A 00 00 00 FF 00 43 32 34
7:126  0:000  80 | 39 4E 39 43 33 32 34 48 53 0A 00 00 00 FC 00 44
7:126  0:000  96 | 45 4C 4C 20 49 4E 32 30 31 30 4E 0A 00 00 00 FD
7:126  0:000  112 | 00 38 4C 1E 53 11 00 0A 20 20 20 20 20 20 00 98
7:126  0:000  mem_detected 1610612736
7:126  0:000  read_nVidia_ROM
7:126  0:000  Using PRAMIN fixups
7:328  0:201  patch_nvidia_rom
7:328  0:000  version 70.10.17.00.01
7:328  0:000  nVidia MSi GeForce GTX 580  1536MB NVC8 [10DE:1080] ::
7:328  0:000  PciRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)
7:328  0:000  devprop_add_nvidia_template
7:328  0:000  default_NVCAP: 04000000-00000300-1C000000-00000007-00000000
7:328  0:000  USB Controller [8086:1E31] :: PciRoot(0x0)\Pci(0x14,0x0)
7:328  0:000  USB Controller [8086:1E2D] :: PciRoot(0x0)\Pci(0x1A,0x0)
7:328  0:000  USB Controller [1106:3432] :: PciRoot(0x0)\Pci(0x1C,0x4)\Pci(0x0,0x0)
7:328  0:000  USB Controller [8086:1E26] :: PciRoot(0x0)\Pci(0x1D,0x0)
7:328  0:000  stringlength = 3320
7:329  0:000  CurrentMode: Width=1600 Height=900
7:329  0:000  FSInjection: using kexts path: 'EFI\CLOVER\kexts\10.10'
7:333  0:004  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.10
7:335  0:002    Extra kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext
7:341  0:005    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\ACPISensors.kext
7:345  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\CPUSensors.kext
7:348  0:003    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\GPUSensors.kext
7:354  0:005    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\FakeSMC.kext\Contents\PlugIns\LPCSensors.kext
7:363  0:009    Extra kext: EFI\CLOVER\kexts\10.10\GenericUSBXHCI.kext
7:368  0:005    Extra kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext
7:377  0:008    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\ALXEthernet.kext
7:384  0:007    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleBCM5701Ethernet.kext
7:391  0:006    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleIntel8254XEthernet.kext
7:395  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleUSBEthernet.kext
7:399  0:003    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleUSBGigEthernet.kext
7:403  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\AppleYukon2.kext
7:411  0:007    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\Intel82574L.kext
7:415  0:004    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\IOEthernetAVBController.kext
7:419  0:003    Extra PlugIn kext: EFI\CLOVER\kexts\10.10\IONetworkingFamily.kext\Contents\PlugIns\nvenet.kext
7:423  0:004    Extra kext: EFI\CLOVER\kexts\10.10\VoodooHDA.kext
7:444  0:020  SetStartupDiskVolume:
7:444  0:000    * Volume: 'Macintosh SSD'
7:444  0:000    * LoaderPath: '<null string>'
7:444  0:000    * DevPath: Macintosh SSD
7:444  0:000    * GUID = 235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF
7:444  0:000    * efi-boot-device: <array><dict><key>IOMatch</key><dict><key>IOProviderClass</key><string>IOMedia</string><key>IOPropertyMatch</key><dict><key>UUID</key><string>235C5ABE-5BAA-4C63-88B7-5297FB0D0FBF</string></dict></dict></dict></array>
7:444  0:000  Custom boot is disabled
7:444  0:000  Failed to initialize boot screen: Aborted!
7:444  0:000  Closing log

6:815 0:000 ========= Auto patch DSDT Starting ========
6:815 0:000 VideoCard devID=0x108010DE
6:815 0:000 DisplayADR1[0] = 0x10000, DisplayADR2[0] = 0x0
6:815 0:000 Display 0 is notPCIE



Anyone know why/where "Display 0 is notPCIE" is coming from in clovers dsdt patching?

Link to comment
Share on other sites
tinkythomas
tinkythomas
Posted
Posted

Hi,



I am dual booting Windows 8.1 and Mac OS X Mavericks in uefi mode and have added the Mouse key under GUI in config.plist. However my mouse doesn't work when the GUI loads. Do I need to add any additional drivers to drivers64uefi?



Any help will be appreciated. Everything else works, just want to use my mouse as my keyboard is bluetooth and isn't available until the OS loads.



Regards

Link to comment
Share on other sites
Slice
Slice
Posted
Posted

Hi,



I am dual booting Windows 8.1 and Mac OS X Mavericks in uefi mode and have added the Mouse key under GUI in config.plist. However my mouse doesn't work when the GUI loads. Do I need to add any additional drivers to drivers64uefi?



Any help will be appreciated. Everything else works, just want to use my mouse as my keyboard is bluetooth and isn't available until the OS loads.



Regards

May be this one will help you?

Screen Shot 2014-08-01 at 22.07.07.png

Yes, after installation you have to move it to drivers64UEFI



EDITED.

Be sure mouse enabled in config.plist and Speed is not zero.

Link to comment
Share on other sites
tinkythomas
tinkythomas
Posted
Posted

May be this one will help you?

attachicon.gifScreen Shot 2014-08-01 at 22.07.07.png

Yes, after installation you have to move it to drivers64UEFI



EDITED.

Be sure mouse enabled in config.plist and Speed is not zero.

Thank you for the reply. Those options aren't available with 'Install for UEFI booting only'. Do I add the driver after the initial installation? In doing so will it affect the current EFI installation?



Regards

Link to comment
Share on other sites
Slice
Slice
Posted
Posted

Thank you for the reply. Those options aren't available with 'Install for UEFI booting only'. Do I add the driver after the initial installation? In doing so will it affect the current EFI installation?



Regards

I am not clear why you want to install Clover "for UEFI only". I installed without this claim and have both method to boot legacy and UEFI and I see no negative profit for this.

Currently I am using UEFI boot.

The installer will place Mouse driver into folder /EFI/CLOVER/drivers64/ while you need it in folder /EFI/CLOVER/drivers64UEFI/ for UEFI boot.

It was proposed that UEFI Firmware always have this driver. In other case you may manually copy this driver from one folder to another one.

Link to comment
Share on other sites
tinkythomas
tinkythomas
Posted
Posted

I am not clear why you want to install Clover "for UEFI only". I installed without this claim and have both method to boot legacy and UEFI and I see no negative profit for this.

Currently I am using UEFI boot.

The installer will place Mouse driver into folder /EFI/CLOVER/drivers64/ while you need it in folder /EFI/CLOVER/drivers64UEFI/ for UEFI boot.

It was proposed that UEFI Firmware always have this driver. In other case you may manually copy this driver from one folder to another one.

Hi,



I chose that option because I have no need for legacy boot! Both Windows and Mac are booting UEFI only. Why do the developers offer that option if it's not required? Don't mean to offend but I'm just trying to explain why I installed for UEFI only!



Regards

Link to comment
Share on other sites
magnifico
magnifico
Posted
Posted

Hi,



I chose that option because I have no need for legacy boot! Both Windows and Mac are booting UEFI only. Why do the developers offer that option if it's not required? Don't mean to offend but I'm just trying to explain why I installed for UEFI only!



Regards



because not everyone has a mainboard UEFI BIOS, and he is giving you only a board, relax..please

Link to comment
Share on other sites
tinkythomas
tinkythomas
Posted
Posted

because not everyone has a mainboard UEFI BIOS, and he is giving you only a board, relax..please

Apologies, wasn't my intention to come across as being antagonistic.



I have now placed UsbMouseDXE-64 in /EFI/CLOVER/drivers64UEFI but my mouse still doesn't work. It's enabled in config.plist and the pointer speed is set to 8.



Any further assistance would be greatly appreciated.

Link to comment
Share on other sites
jamiethemorris
jamiethemorris
Posted
Posted

Apologies, wasn't my intention to come across as being antagonistic.



I have now placed UsbMouseDXE-64 in /EFI/CLOVER/drivers64UEFI but my mouse still doesn't work. It's enabled in config.plist and the pointer speed is set to 8.



Any further assistance would be greatly appreciated.

You are using a USB mouse, right? I don't know what the specs are on your PC, but if it's a laptop you need the PS2mouse driver. Otherwise, I don't know. I don't think the mouse has ever worked in the Clover menu on my Vivobook.

Link to comment
Share on other sites
HackBook Pro
HackBook Pro
Posted
Posted

I am having a strange problem with Clover on my system.  It's an Intel P35-based motherboard, so that means it uses a BIOS and not UEFI.



The problem is that when I boot Clover (chainloaded from GRUB 2), the USB... "resets'.  I don't know how else to describe it.  I have a Saitek Cyborg keyboard and a Razer Lachesis mouse; they both have lights on them.  When Clover boots up, the lights on the keyboard start flickering (in my mind, the USB is "resetting").  Once it's loaded, the light on the mouse is off, and it doesn't work.  If I plug in another mouse, that works, but my Razer does not (even if I unplug it and plug it back in).  The keyboard correctly lights up and works fine.



When I boot up an OS, the Razer mouse still doesn't work (this time, unplugging and replugging does make it work).  It's almost as if Clover is somehow "turning off" my mouse.



So, why doesn't my Razer mouse work in Clover?  And why doesn't it work when Clover boots up the OS (unless I unplug it and re-plug it)?

Link to comment
Share on other sites
mac09hack
mac09hack
Posted
Posted

I have placed a DSDT.ami from a Chameleon build but when I boot the disk loaded Clover, it fails at DSMOS. If i remove the DSDT  from ACPI patched, the disk will boot up.



Is there something else I need to do to get a known good DSDT to work?

Link to comment
Share on other sites
oSxFr33k
oSxFr33k
Posted
Posted

Is there an option to dibble nvda drivers in clover?  I want to do this for one of my Laptops during the install and temporally until I install the web drivers.  I googled searched maybe not properly but unable to find and answer.  From Clover Configurator I don't see an option for it under boot or disable drivers etc.



I read that chameleon offers it by adding this command at boot.  nv_disable=1, is that all I need to do at the Clover boot is at that option?



Thanks

Link to comment
Share on other sites
fusion71au
fusion71au
Posted
Posted

It looks like the latest Clover revisions break loading of config.plist from the OEM folders if the folder name has a space.



I use EFI/Clover/OEM folders to load different config.plists for my laptop and desktop (so I can use the same Yosemite Installer USB for both rigs)....






With Clover r2793 on my laptop XPS M1530, the config.plist does not load from /EFI/Clover/OEM/XPS M1530 but /EFI/Clover ....

12:599  0:000  Starting Clover rev 2793 on CLOVER EFI
12:599  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x0,0x0)\HD(1,MBR,0x00000000,0x2,0x1E93E8B) @DE729418
12:599  0:000  SelfDirPath = \EFI\CLOVER
12:600  0:000  UnicodeCollation Status=Success
12:600  0:000  Total Memory Slots Count = 2
12:600  0:000  Type 17 Index = 0
12:600  0:000  SmbiosTable.Type17->Speed = 667
12:600  0:000  SmbiosTable.Type17->Size = 2048
12:600  0:000  Type 17 Index = 1
12:600  0:000  SmbiosTable.Type17->Speed = 667
12:600  0:000  SmbiosTable.Type17->Size = 2048
12:600  0:000  Boot status=0
12:600  0:000  Clover revision: 2793  running on XPS M1530
12:600  0:000  ... with board
12:600  0:000  Clover load options size = 0 bytes
12:648  0:048  Using OEM config.plist at path: EFI\CLOVER\config.plist
12:649  0:000  EFI\CLOVER\config.plist loaded: Success

With Clover r2758 it is working from EFI\CLOVER\OEM\XPS M1530 ....


12:319  0:000  Starting Clover rev 2758 on CLOVER EFI
12:319  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,895CF5E7-C789-4906-B18A-72857DC11AEC,0x28,0x64000) @DE5EF298
12:319  0:000  SelfDirPath = \EFI\CLOVER
12:319  0:000  UnicodeCollation Status=Success
12:319  0:000  Total Memory Slots Count = 2
12:319  0:000  Type 17 Index = 0
12:319  0:000  SmbiosTable.Type17->Speed = 667
12:319  0:000  SmbiosTable.Type17->Size = 2048
12:319  0:000  Type 17 Index = 1
12:319  0:000  SmbiosTable.Type17->Speed = 667
12:319  0:000  SmbiosTable.Type17->Size = 2048
12:319  0:000  Boot status=0
12:319  0:000  Clover revision: 2758  running on XPS M1530
12:319  0:000  ... with board
12:319  0:000  Clover load options size = 0 bytes
12:344  0:025  Using OEM config.plist at path: EFI\CLOVER\OEM\XPS M1530 \config.plist
12:345  0:000  EFI\CLOVER\OEM\XPS M1530 \config.plist loaded: Success

Oddly enough, for my desktop, the config.plist loads properly from /EFI/Clover/OEM/P55A-UD3 folder using Clover r2793 ....


14:629  0:000  Starting Clover rev 2793 on CLOVER EFI
14:629  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1A,0x7)\USB(0x4,0x0)\HD(1,MBR,0x00000000,0x2,0x1E93E8B) @DDBCE518
14:629  0:000  SelfDirPath = \EFI\CLOVER
14:630  0:000  UnicodeCollation Status=Success
14:630  0:000  Total Memory Slots Count = 4
14:630  0:000  Type 17 Index = 0
14:630  0:000  SmbiosTable.Type17->Speed = 1333
14:630  0:000  SmbiosTable.Type17->Size = 2048
14:630  0:000  Type 17 Index = 1
14:630  0:000  Ignoring insane frequency value 0MHz
14:630  0:000  SmbiosTable.Type17->Speed = 0
14:630  0:000  SmbiosTable.Type17->Size = 0
14:630  0:000  Type 17 Index = 2
14:630  0:000  SmbiosTable.Type17->Speed = 1333
14:630  0:000  SmbiosTable.Type17->Size = 2048
14:630  0:000  Type 17 Index = 3
14:630  0:000  Ignoring insane frequency value 0MHz
14:630  0:000  SmbiosTable.Type17->Speed = 0
14:630  0:000  SmbiosTable.Type17->Size = 0
14:630  0:000  Boot status=0
14:630  0:000  Clover revision: 2793  running on P55A-UD3
14:630  0:000  ... with board P55A-UD3
14:630  0:000  Clover load options size = 0 bytes
14:691  0:061  Using OEM config.plist at path: EFI\CLOVER\OEM\P55A-UD3\config.plist
14:692  0:000  EFI\CLOVER\OEM\P55A-UD3\config.plist loaded: Success

Maybe because there is no space in the folder name for that system.



Edit

Fixed.  I actually had to add a space at the end of the folder name ie "XPS M1530 " and now loading from the OEM folder.  Thanks Slice :).

Link to comment
Share on other sites
jamiethemorris
jamiethemorris
Posted
Posted

Anyone know why I can't get Clover to boot on my new BIOS? I flashed the latest UEFI beta BIOS for my board so I could take advantage of my new GOP VBIOS. unfortunately, it won't boot anything except Windows 8. Secureboot is disabled, I tried "Other OS," "Windows 8," Windows 8 WHQL," etc. But no matter what it only boots Windows. Everything else leads to a blinking cursor. I did manage to boot an Arch Linux install drive but that's it. My regular Arch disk and my Clover disk do not boot.

Link to comment
Share on other sites
Slice
Slice
Posted
Posted

It looks like the latest Clover revisions break loading of config.plist from the OEM folders if the folder name has a space.

With Clover r2758 it is working from EFI\CLOVER\OEM\XPS M1530 ....


12:344  0:025  Using OEM config.plist at path: EFI\CLOVER\OEM\XPS M1530 \config.plist
12:345  0:000  EFI\CLOVER\OEM\XPS M1530 \config.plist loaded: Success

Maybe because there is no space in the folder name for that system.

Try to exclude ending space from the name "XPS M1530 "

  • Like 1
Link to comment
Share on other sites
oSxFr33k
oSxFr33k
Posted
Posted

Hi Slice,



Does clover automatically patch MSR 0xE2 lock for Haswell?   This is so weird because this Laptop should need the fix and its running fine without it.  It is an Asus G750JX-DB71.  Over at the Asus Rog Forum they are either patching the kernel or Bios.  This is my second Laptop and I did not patch the Bios this time, and I was able to install OSX mavericks and boot into without any issues what so ever.





Dmesg says found "another" boot volume is that referring to Windows 8?

I wonder now if they have been patching the Bios for nothing?



NVDAStartup: Web

IOPPF - Found another boot volume.IOPPF: XCPM mode

Link to comment
Share on other sites
faithie999
faithie999
Posted
Posted

   need some help.

hardware:  MSI B75A-S40    8gb mem, UEFI booting.



created a usb installer using clover 2774 and yosemite public beta 1.  i used the config.plist from my working mavericks install on the same computer.

successfully installed Yosemite beta to a spare HD.



i installed clover 2774 to the yosemite HD, then copied my EFI folder from the USB stick to the yosemite HD/EFI partition.



upon reboot, just got black screen/apple logo/no progress indicator.  the hard disk access light on the front panel flashed briefly then went out.

tried booting in safe mode.  boot proceeded, setup assistant started, but hung (spinning gear wheel) at the end of the setup--on the "Setting up your mac" screen.



i rebooted, again in safe mode, got the sign-in screen, entered my password, but hung at that screen (spinning gearwheel and spinning beach ball).



booted in verbose mode--after just a couple of lines of verbose messages, got the message:  AptioDrvFix--requested memory exceeds our allocated relocation block

then message that boot would halt for 30 secs, after which nothing happened.



i've attached my config.plist.



i did create a 10.10 folder within the kexts folder on the yosemite HD, and copied the kexts into it from the 10.9 folder on my mavericks HD.



any suggestions?



thanks





EDIT:  turns out that the clover 2774 install on the yosemite HD will not boot my mavericks install, either.  same symptoms: booting in normal mode, lack of gearwheel below the apple logo, no HD access light.  in verbose mode, same error message from AptioDrvFix about requested memory exceeds our allocation block.

config.plist.zip

Link to comment
Share on other sites
jamiethemorris
jamiethemorris
Posted
Posted

   need some help.

hardware:  MSI B75A-S40    8gb mem, UEFI booting.



created a usb installer using clover 2774 and yosemite public beta 1.  i used the config.plist from my working mavericks install on the same computer.

successfully installed Yosemite beta to a spare HD.



i installed clover 2774 to the yosemite HD, then copied my EFI folder from the USB stick to the yosemite HD/EFI partition.



upon reboot, just got black screen/apple logo/no progress indicator.  the hard disk access light on the front panel flashed briefly then went out.

tried booting in safe mode.  boot proceeded, setup assistant started, but hung (spinning gear wheel) at the end of the setup--on the "Setting up your mac" screen.



i rebooted, again in safe mode, got the sign-in screen, entered my password, but hung at that screen (spinning gearwheel and spinning beach ball).



booted in verbose mode--after just a couple of lines of verbose messages, got the message:  AptioDrvFix--requested memory exceeds our allocated relocation block

then message that boot would halt for 30 secs, after which nothing happened.



i've attached my config.plist.



i did create a 10.10 folder within the kexts folder on the yosemite HD, and copied the kexts into it from the 10.9 folder on my mavericks HD.



any suggestions?



thanks





EDIT:  turns out that the clover 2774 install on the yosemite HD will not boot my mavericks install, either.  same symptoms: booting in normal mode, lack of gearwheel below the apple logo, no HD access light.  in verbose mode, same error message from AptioDrvFix about requested memory exceeds our allocation block.

Have you tried LowMemFix instead of AptioDrvFix?





I figured out my issue with Clover not booting with the new BIOS. Turns out there's just something wrong with the U1J version and it just won't boot anything except Windows. I found U1K on TweakTown and it's working fine now.

Link to comment
Share on other sites
 Share
Go to topic listing
×
×
  • Create New...
