Slice Posted January 22 Share Posted January 22 Not sure about words "BIG endian". Numbers, decimal or hexadecimal always written as Arabian numbers, right to left. So 2024 has 4 as low significant digit. 0x0803 has bit 0 at the right of the sequence. It is the sense of "Little Endian". Endian located at the end of the word, at the right. The most right digit has lowest significant. 1 Link to comment Share on other sites More sharing options...
tluck Posted January 22 Share Posted January 22 7 hours ago, Slice said: Impossible. May be you are using VirtualSMC which was declared as not Clover compatible? hmm. i am just reporting the facts as I see them! Note: I downloaded your 5157 build of Clover and replaced my BOOTX64.efi 5156 is fine and some of the new 5157 changes up this change works for me. -> the change in gma.cpp with IPGU_LESS seem to be problematic? not sure why kexts are not injected - i didnt track down the issue with kext injection yet. I use FakeSMC.kext - does the name kexts vs Kexts matter? $ ls -ld1 kexts/Other/* kexts/Other/ACPIBatteryManager.kext kexts/Other/ACPIPoller.kext kexts/Other/AX88179_178A.kext kexts/Other/AppleALC.kext kexts/Other/BlueTooth_Injector_T420.kext kexts/Other/EFICheckDisabler.kext kexts/Other/FakeSMC.kext kexts/Other/IOAHCIBlockStorageInjector.kext kexts/Other/Lilu.kext kexts/Other/USBInjectAll.kext kexts/Other/VoodooPS2Controller.kext kexts/Other/WhateverGreen.kext 1 Link to comment Share on other sites More sharing options...
Slice Posted January 22 Share Posted January 22 To clarify the question about Little and Big Endian let consider UUID. There is a big difference. Internally UUID represented as 128 bit value which consists of one 32bit value Data0, two 16bit values Data1, Data2, and eight 8bit values. For example {0x8BE4DF61, 0x93CA, 0x11D2, {0xAA, 0x0D, 0x00, 0xE0, 0x98, 0x03, 0x2B, 0x8C}}; But convert to string value requires arrangement is it Little Endian (as Microsoft, Intel and UEFI) or Big Endian (as Apple and FreeBSD AFAIK). So we'll obtain different strings "8BE4DF61-93CA-11D2-AA0D-00E098032B8C" or "61DFE48B-CA93-D211-AA0D-00E098032B8C" As Clover works from UEFI for macOS we have to convert string UUID from Little Endian (UEFI protocols) to Big Endian (Partitions UUID). 40 minutes ago, tluck said: hmm. i am just reporting the facts as I see them! Note: I downloaded your 5157 build of Clover and replaced my BOOTX64.efi 5156 is fine and some of the new 5157 changes up this change works for me. -> the change in gma.cpp with IPGU_LESS seem to be problematic? not sure why kexts are not injected - i didnt track down the issue with kext injection yet. I use FakeSMC.kext - does the name kexts vs Kexts matter? $ ls -ld1 kexts/Other/* kexts/Other/ACPIBatteryManager.kext kexts/Other/ACPIPoller.kext kexts/Other/AX88179_178A.kext kexts/Other/AppleALC.kext kexts/Other/BlueTooth_Injector_T420.kext kexts/Other/EFICheckDisabler.kext kexts/Other/FakeSMC.kext kexts/Other/IOAHCIBlockStorageInjector.kext kexts/Other/Lilu.kext kexts/Other/USBInjectAll.kext kexts/Other/VoodooPS2Controller.kext kexts/Other/WhateverGreen.kext Yes, may be IGPU_LESS influences on your case. Can you unset the define to check if this is the case? 1 Link to comment Share on other sites More sharing options...
Slice Posted January 22 Share Posted January 22 But why no kexts injected? All is fine for me and others. 1 Link to comment Share on other sites More sharing options...
MakAsus Posted January 22 Share Posted January 22 6 hours ago, MakAsus said: By the way, yes. This may be simpler, but what if someone needs a value other than 0x0000 for an OS below Sonoma, or a value other than 0x0803 for Sonoma (for example, if they don't have WiFi)? If I take out my Fenvi FV-HB1200, I no longer need the OSPL patch. Maybe I didn’t express myself quite correctly somewhere, I meant partial disabling of SIP. As for the values 0x803, I apparently missed when in Clover changed to BIG Endian. Made some minor fixes to the repository. No, I checked the source code and the correct value is still 0x0803. I returned it as it was. 1 Link to comment Share on other sites More sharing options...
jsl2000 Posted January 23 Share Posted January 23 On 1/17/2024 at 1:55 AM, Slice said: I propose this. And hope to success. Did anyone can update whose Monterey, Ventura, or Sonoma with legacy Clover 5156 or 5157 now ? Mine always failed up to now ! Link to comment Share on other sites More sharing options...
tluck Posted January 23 Share Posted January 23 11 hours ago, Slice said: Yes, may be IGPU_LESS influences on your case. Can you unset the define to check if this is the case? Ok I moved my kexts from Clover/OEM/boardID/kexts/Other to Clover/kexts/Other and kext inject from ESP worked with the latest 5157. I reverted the gma.cpp from the old commit and all is good now. Link to comment Share on other sites More sharing options...
Slice Posted January 23 Share Posted January 23 2 hours ago, tluck said: Ok I moved my kexts from Clover/OEM/boardID/kexts/Other to Clover/kexts/Other and kext inject from ESP worked with the latest 5157. I reverted the gma.cpp from the old commit and all is good now. So OEM/boardID cancel to work since some moment? Since join with OC? Link to comment Share on other sites More sharing options...
phi777 Posted January 23 Share Posted January 23 (edited) I have a problem with v5156 and v5157. When I copy it, as ususal, I can restart and boot without a problem. But after powering down and starting I am always getting "found dead pci device GFX0" and booting stops. Should I look into this blockskywalk thing? I am using latest ventura. Thank you for reading this. Edited January 23 by phi777 1 Link to comment Share on other sites More sharing options...
Slice Posted January 23 Share Posted January 23 BlockSkywalk works only for Sonoma. Your problem looks like BIOS problem. Or may be CPU cores synchronization. Make preboot.log I will see it. 2 Link to comment Share on other sites More sharing options...
phi777 Posted January 23 Share Posted January 23 (edited) Here they are, both are using the same config.plist preboot-v5155-good.log preboot-v5157-deadgfx0.log EDIT: I have attached one preboot, where I updated from 5155 to 5157 and restarted, without powering down the computer, which works. preboot-v5157-withoutPowerDown.log Edited January 23 by phi777 Link to comment Share on other sites More sharing options...
fabiosun Posted January 23 Share Posted January 23 @Slice Is it possible to block a kext using a config.plist parameter/section? IE For modern wireless patch done by OCLP app we need to use two old kext, AMFIpass.kext and some other things like SIP @0x0803 In this condition OSX is not able to update itself with delta update Now i can use a different Config,plist and very useful Clover feature in Boot Menu stage ( I press space and block unwanted kexts from there) Is it possible? or Could it be a wishlist feature to ask you and Jief? Thank you 1 Link to comment Share on other sites More sharing options...
tluck Posted January 23 Share Posted January 23 7 hours ago, Slice said: So OEM/boardID cancel to work since some moment? Since join with OC? Ok interesting. OEM/boardID/kexts works up to now. meaning some change in december for 5157. 1 Link to comment Share on other sites More sharing options...
MakAsus Posted January 23 Share Posted January 23 1 hour ago, mariosun said: @Slice Is it possible to block a kext using a config.plist parameter/section? IE For modern wireless patch done by OCLP app we need to use two old kext, AMFIpass.kext and some other things like SIP @0x0803 In this condition OSX is not able to update itself with delta update Now i can use a different Config,plist and very useful Clover feature in Boot Menu stage ( I press space and block unwanted kexts from there) Is it possible? or Could it be a wishlist feature to ask you and Jief? Thank you Yes, as far as I know, this is possible. Only instead of just block unwanted kexts, I put them in the EFI/CLOVER/kexts/14 folder By space they are locking and from there, but they don’t interfere with Ventura. 1 Link to comment Share on other sites More sharing options...
Slice Posted January 23 Share Posted January 23 7 hours ago, phi777 said: Here they are, both are using the same config.plist preboot-v5155-good.log 50.2 kB · 1 download preboot-v5157-deadgfx0.log 49.91 kB · 2 downloads The logs are almost same. But I wonder if 5155 works and 5156 no. There is no differences which may prevent old working config to be working with new Clover. Test latest version CLOVERX64.efi.zip 1 1 Link to comment Share on other sites More sharing options...
fabiosun Posted January 23 Share Posted January 23 3 minutes ago, MakAsus said: Yes, as far as I know, this is possible. Only instead of just block unwanted kexts, I put them in the EFI/CLOVER/kexts/14 folder By space they are locking and from there, but they don’t interfere with Ventura. Yes this is how it works but i need for sonoma Using OCLP i use different kext as you know if you patch WIFI in OCLP patched condition i cant update to new sonoma beta So i use a second config where i enable sip and disable the usual block Then manually i block the two kexts i have in other or in 14 folder If it was possible to declare in config a kext block as we can do with Skywalk it would be possible only to change config.plist (unvaluable clover feature) 1 Link to comment Share on other sites More sharing options...
Slice Posted January 23 Share Posted January 23 50 minutes ago, tluck said: Ok interesting. OEM/boardID/kexts works up to now. meaning some change in december for 5157. May be boardID changed? Because now it injected after OS choose. I will check. No, the feature was in 5155. 1 Link to comment Share on other sites More sharing options...
fabiosun Posted January 23 Share Posted January 23 7 minutes ago, mariosun said: Yes this is how it works but i need for sonoma Using OCLP i use different kext as you know if you patch WIFI in OCLP patched condition i cant update to new sonoma beta So i use a second config where i enable sip and disable the usual block Then manually i block the two kexts i have in other or in 14 folder If it was possible to declare in config a kext block as we can do with Skywalk it would be possible only to change config.plist (unvaluable clover feature) A simple solution is to use BootloaderChooser and use two different EFI but Kext blocking in config.plist would be a perfect solution (and i think Clover has this feature in its code) 1 Link to comment Share on other sites More sharing options...
MakAsus Posted January 23 Share Posted January 23 11 minutes ago, mariosun said: Yes this is how it works but i need for sonoma Using OCLP i use different kext as you know if you patch WIFI in OCLP patched condition i cant update to new sonoma beta So i use a second config where i enable sip and disable the usual block Then manually i block the two kexts i have in other or in 14 folder If it was possible to declare in config a kext block as we can do with Skywalk it would be possible only to change config.plist (unvaluable clover feature) Yes. It also works the way you described. Link to comment Share on other sites More sharing options...
fabiosun Posted January 23 Share Posted January 23 4 minutes ago, MakAsus said: Yes. It also works the way you described. Explain how Please I would like to block thiese kext in blue: 1 Link to comment Share on other sites More sharing options...
Slice Posted January 23 Share Posted January 23 1 hour ago, tluck said: Ok interesting. OEM/boardID/kexts works up to now. meaning some change in december for 5157. Probably commit 956cfc1ad4b45acda7a4d99c7118bd23e1f55e40? 1 Link to comment Share on other sites More sharing options...
MakAsus Posted January 23 Share Posted January 23 (edited) 30 minutes ago, mariosun said: Explain how Please I would like to block thiese kext in blue: Please, here are the screenshots: As a result, I booted into pure Sonoma, with SIP enabled. Edited January 23 by MakAsus 2 Link to comment Share on other sites More sharing options...
fabiosun Posted January 23 Share Posted January 23 Ok @MakAsus this is how it works and i use in this way as you say with pictures 45 minutes ago, mariosun said: Then manually i block the two kexts i have in other or in 14 folder but i would like to know if we can add those kexts blocking feature inside our second config-1 plist: In my picture a whishlist feature request In this way i would change only the config.plist I hope i have explained in a more clear way! 1 Link to comment Share on other sites More sharing options...
MakAsus Posted January 23 Share Posted January 23 (edited) 10 minutes ago, mariosun said: Ok @MakAsus this is how it works and i use in this way as you say with pictures but i would like to know if we can add those kexts blocking feature inside our second config-1 plist: In my picture a whishlist feature request In this way i would change only the config.plist I hope i have explained in a more clear way! I assume this has not been implemented. However, no one is stopping you from temporarily moving these Kexts to the off folder. I'm not a programmer and I can't do this. Edited January 23 by MakAsus 2 Link to comment Share on other sites More sharing options...
miliuco Posted January 23 Share Posted January 23 @MakAsus You boot Sonoma with SIP enabled but is the Fenvi wifi working in this way? 1 Link to comment Share on other sites More sharing options...
