Clover General discussion

[MakAsus]

2 hours ago, miliuco said:

@Slice



More doubts for me as I am not a programmer and my skills are limited.
The value 0x803 seems to fit more closely with the sum of bitmasks (1+2+800) and, on the other hand, the value 0x380 (80+100+200) does not match what is expected.
However, the value I see on macOS is 03080000. So could it be that Clover or OpenCore save the value correctly and macOS saves it in the reverse order?



Please type a CsrActiveConfig value (use 0x prefix for hex):  0x803

Active values for 0x803 (2,051) :

CSR_ALLOW_UNTRUSTED_KEXTS      - 0x1 (1)
CSR_ALLOW_UNRESTRICTED_FS      - 0x2 (2)
CSR_ALLOW_UNAUTHENTICATED_ROOT - 0x800 (2,048)


Please type a CsrActiveConfig value (use 0x prefix for hex):  0x380

Active values for 0x380 (896) :

CSR_ALLOW_DEVICE_CONFIGURATION - 0x80 (128)
CSR_ALLOW_ANY_RECOVERY_OS      - 0x100 (256)
CSR_ALLOW_UNAPPROVED_KEXTS     - 0x200 (512)

(BitMask Decode script by corpnewt).

0x1 + 0x2 + 0x800 = 0x803 This is simple binary arithmetic. Take a regular calculator, click View > Programmer > Hexadecimal and add the values. 😉



2 hours ago, miliuco said:

@Slice



Config.plist has the right value:





But Hackintool and even nvram command in Terminal or IOReg have reverse order:









Since About This Hack gets the value from IOReg, the value is displayed as is.



let sipValue = run ("ioreg -fiw0 -p IODeviceTree -rn options | grep \"csr-active-config\" | awk '{print \"(0x\"substr($3,4,2) substr($3,2,2) substr($3,6,4)\")\"}' | tr -d '\n'")



What I don't know is why in config.plist it has to be the other way, I suppose Clover and OpenCore expect this value in Little Endian although in other places we see it as Big Endian.



<key>CsrActiveConfig</key>

<string>0x0803</string>

Edited January 11 by MakAsus

[Slice]

@miliuco

Clover, OpenCore and macOS think similar. The error is in application About_This_Hack.

0x0803 = <03080000> byte by byte.

0x0803 != 0x03080000

[miliuco]

1 hour ago, Slice said:

Clover, OpenCore and macOS think similar. The error is in application About_This_Hack.

0x0803 = <03080000> byte by byte.

0x0803 != 0x03080000

Ok, understood, thanks.

[matxpa]

Just now, Slice said:

@miliuco

Clover, OpenCore and macOS think similar. The error is in application About_This_Hack.

0x0803 = <03080000> byte by byte.

0x0803 != 0x03080000



No, I'm sur the error comes from Apple and System commands "ioreg" and "nvram", isn't it ?



 ioreg -fiw0 -p IODeviceTree -rn options | grep "csr-active-config"

      "csr-active-config" = <03080000>



nvram csr-active-config

csr-active-config %03%08%00%00



nvram csr-active-config | sed 's/%//g'

csr-active-config 03080000

nvram csr-active-config | awk '{print "0x"$2}' | sed 's/%//g'

0x03080000



<03 08 00 00> is the reverted hex value of <08 03 00 00> but is 0x803 a real hex value, may be Hackintool Calc is wrong too ?









And what you'd like to see :



ioreg -fiw0 -p IODeviceTree -rn options | grep "csr-active-config" | awk '{print "(0x"substr($3,4,2) substr($3,2,2) substr($3,6,4)")"}'

(0x08030000)

as you can see with ETH





@Jief_Machak & @Slice  it's Clover r5157 (1947d48) at 20240110-20h48 XCODE15 RELEASE and a working BCM94360  (as BCM worked fine with r5157 (a9b0654) (20231112-03h48), r5157 (1914496) (20231116-19h14)  and r5157 (bdb7a95) (20231116-22h10)



ioreg -fiw0 -p IODeviceTree -rn options | grep "csr-active-config" | awk '{print "(0x"substr($3,4,2) substr($3,2,2) substr($3,6,4)")"}' | sed 's/0*)$/)/g'

(0x0803)



nvram csr-active-config | sed 's/%//g' | awk '{print "(0x"substr($2,4,2) substr($2,2,2)")"}' | sed 's/0)$/)/g'

(0x803)

nvram csr-active-config | sed 's/%//g' | awk '{print "(0x"substr($2,3,2) substr($2,1,2)")"}' | sed -e 's/x0/x/g' -e 's/0)$/)/g'

(0x803)



Regards

[Slice]

Thanks for confirmation the Clover works.

Anyway record like <03080000> means a set of bytes from low to big.

First byte is 03, second is 08, third is 00 etc.

Your script is wrong.

0x0803 means as usual 03 is first byte, 08 is second byte.

[Slice]

Same as decimal numbers

1357 (one thousand three hundreds fifty seven).

7 is low digit

5 means 5*10

3 means 3*100

1 means 1*1000

For hex numbers all is the same

0x0803 means

3*1

0*16

8*256

From right to left.



[PG7]

2 hours ago, matxpa said:









hello, can you pass me this Clover r5157

Thank you and good day

Edited January 11 by PG7

[Slice]

On 1/8/2024 at 12:15 PM, MakAsus said:

Yes SMBIOS->Trust = false.

I understand so we didn't come to final solution. And I also just want so that it becomes as it was earlier in Clover and as it is in OpenCore now. The last release in which I saw the correct memory map, it seems to me, was v5.0 r5119.

What if you set "true"?

[matxpa]

23 minutes ago, PG7 said:

hello, can you pass me this Clover r5157

Thank you and good day

@PG7



Hi, below is r5157 (aka 5156+++)



CloverX64_r5157_20240110-20h48_1947d48_XCODE15_RELEASE_master_local.efi

(rename it to BOOTX64.efi and  CLOVERX64.efi, but you know that ...)



Regards

Edited January 11 by matxpa

[Slice]

@MakAsus and other having problems with Memory shown in SystemProfilier.

As well try to set

SMBIOS->Memory->Channels=2

By default this value = 1

[matxpa]

2 hours ago, Slice said:

Thanks for confirmation the Clover works.

Anyway record like <03080000> means a set of bytes from low to big.

First byte is 03, second is 08, third is 00 etc.

Your script is wrong.

0x0803 means as usual 03 is first byte, 08 is second byte.

@Slice

Your script is wrong., may be but which one ?

"ioreg' and/or "nram" aren't my script(s) (but surely macOS components), they both return <03080000> value where 1st byte is at 1st place, second byte 2nd place and so on and <08030000> is the reverted value

ATH displays a formatted, ">" replaced with ")" & "<" replaced with "(0x", third word from "ioreg" returned value :      "csr-active-config" = <03080000>

Regards

Edited January 11 by matxpa

[Slice]

3 minutes ago, matxpa said:

@Slice

Your script is wrong., may be but which one ?

"ioreg' and/or "nram" aren't my script(s), they both return <03080000> value where 1st byte is at 1st place, second byte 2nd place and so on and <08030000> is the reverted value

ATH displays a formatted, ">" replaced with ")" & "<" replaced with "(0x", third word from "ioreg" returned value :      "csr-active-config" = <03080000>

Regards

Again

"csr-active-config" = <03080000> is right

But About_This_Hack shows 0x03080000 which is wrong.

https://www.insanelymac.com/forum/topic/284656-clover-general-discussion/?do=findComment&comment=2815397



[miliuco]

@matxpa

If the key is to show 08030000 instead of 0x0803000 as @Slice says (I'm not sure of understand completely this statement), it's easy to remove 0x in the tooltip:

 if sipValue.length == 12 && !sipValue.contains("(0x\">\"g)") { osSipInfo += "(" + "\(sipValue.dropFirst(3))\n" } else { osSipInfo += "\n"}

What do you think about it?



Spoiler



[MakAsus]

2 hours ago, Slice said:

What if you set "true"?

1 hour ago, Slice said:

@MakAsus and other having problems with Memory shown in SystemProfilier.

As well try to set

SMBIOS->Memory->Channels=2

By default this value = 1



I changed my config file:


	<dict>
		<key>Memory</key>
		<dict>
			<key>Channels</key>
			<integer>2</integer>
		</dict>
		<key>Trust</key>
		<true/>
	</dict>

and nothing has changed.

preboot.log

Edited January 11 by MakAsus

[jsl2000]

On 1/11/2024 at 9:19 AM, MakAsus said:

I compiled CloverBootloader commit 1947d48 which also works fine. I also compiled About This Hack.app Version 1.1.0 (1400). If anyone needs it, I can add it to my GitHub repository.

Thanks and please add them to your GitHub ASAP !

[Slice]

10 hours ago, MakAsus said:



I changed my config file:


	<dict>
		<key>Memory</key>
		<dict>
			<key>Channels</key>
			<integer>2</integer>
		</dict>
		<key>Trust</key>
		<true/>
	</dict>

and nothing has changed.

preboot.log 67.5 kB · 2 downloads

No effect is the bug.

[MakAsus]

3 hours ago, Slice said:

No effect is the bug.

It's a pity.

[matxpa]

15 hours ago, Slice said:

Again

"csr-active-config" = <03080000> is right

But About_This_Hack shows 0x03080000 which is wrong.

https://www.insanelymac.com/forum/topic/284656-clover-general-discussion/?do=findComment&comment=2815397



@Slice



Hi

I apologize, you're right to say that I'm wrong.

Regards

[matxpa]

16 hours ago, miliuco said:

@matxpa

If the key is to show 08030000 instead of 0x0803000 as @Slice says (I'm not sure of understand completely this statement), it's easy to remove 0x in the tooltip:

 if sipValue.length == 12 && !sipValue.contains("(0x\">\"g)") { osSipInfo += "(" + "\(sipValue.dropFirst(3))\n" } else { osSipInfo += "\n"}

What do you think about it?



  Reveal hidden contents





@miliuco



Hi



ioreg -fiw0 -p IODeviceTree -rn options | grep "csr-active-config" | awk '{print substr($NF,8,2) substr($NF,6,2) substr($NF,4,2) substr($NF,2,2)}' | sed -e 's/^0*/(0x/g' -e 's/0*$/)/g'

(0x803)

nvram csr-active-config | sed 's/%//g' | awk '{print substr($NF,8,2) substr($NF,6,2) substr($NF,4,2) substr($NF,2,2)}' | sed -e 's/^0*/(0x/g' -e 's/0*$/)/g'

(0x803)



Regards

Edited January 12 by matxpa

[rramon]

On 1/10/2024 at 8:03 PM, MakAsus said:

If you only have one Sonoma, then all the kexts can be put in the folder  EFI/CLOVER/kexts/Other, but even in this case, I think it’s more correct to put the problematic kexts in the folder  EFI/CLOVER/kexts/"system number". This will allow you, in an emergency, to boot into the installer of the previous version of the OS.
Mini-PCIE 12+6 Pin Adapter plugged directly on my motherboard, so no "classic" PCI-E It works exactly the same way for a friend of mine.
Otherwise, you set the value 0x0803, then you will fulfill the requirement for the root OCLP patch. I do not recommend disabling SIP completely; most programs will stop working. And you will need to find patches for each of them, and so Lilu and AMFIPass do everything you need automatically.
One last thing: I have never used OCPL from Clover before. Always from OpenCore. This is a much more difficult way requiring more power understanding each of the settings. In my case, the order to adding each kext was strictly important.
IOSkywalkFamily.kext should be below WhateverGreen.kext like on a picture:



Thanks for your thorough explanation, this helps so much! 👍



I have one last question regarding SIP:

just checked and my current setting is 0x67 (I‘m using Plist Editor Pro to edit my config.plist). Would this work with OCLP and if not, is 0x0803 similar in safety as 0x67 or more strict?


Thanks again

[miliuco]

@rramon

0x803 is mandatory for OCLP root patch. No patch with any other value.

[Slice]

0x867 will be logical sum of these two values.

42 minutes ago, miliuco said:

@rramon

0x803 is mandatory for OCLP root patch. No patch with any other value.

I doubt about any. But I can't check as I need no OCLP.

[LAbyOne]

1 hour ago, miliuco said:

@rramon

0x803 is mandatory for OCLP root patch. No patch with any other value.



Not true (in my case at least) as to run certain app i needed 867 and OCLP never failed



[rramon]

Hmm, I have a mid 2012 MacBook Pro 9,1 running fine with OCLP (Ventura) and completely disabled SIP - but I‘m not sure about Clover in combination with OCLP..



Does OCLP actually „know“ the 0x67 value?

Edited January 12 by rramon

[LAbyOne]

OCLP

Run after checking the minimum requirements to operate are met,

is just an application made to apply a bunch of patches to enable older hardware on most recent OS



the value suggested by Dortania being 803 is the CSR minimum needed configuration to apply patches



1 hour ago, rramon said:

Does OCLP actually „know“ the 0x67 value?



Who cares?

SIP is the one that take care of it not OCLP

you can use whatever CSR configuration if it integrates the minimum values required to modify the System
