Clover General discussion

SavageAUS · October 2, 2021

Are you all right, sir?
On 5140.1, Ubuntu shows the same as before.

You might want to check the debug logs for both versions.

The icon shows up just fine but trying to boot it gives a black screen. I’ll look into more later.
Have you booted Ubuntu? Or just looked at the icon?

Sent from my iPhone using Tapatalk

SavageAUS · October 2, 2021

I'm sorry.
I just checked the boot.
As you can see, Grub2.04 booted and Ubuntu20.04 ran as usual.
Is your Linux loader ok?
Or, preparing a bootable stub may work. (cp /boot/EFI/arch_grub/grubx64.efi /boot/EFI/boot/bootx64.efi)

My Arch Linux boots fine from EFI I’ll check my config when I get a chance but I swear nothing has changed.

Sent from my iPhone using Tapatalk

Jief_Machak · October 2, 2021

16 hours ago, Slice said:

Successfully booted by the version.

There is non-significant memory difference with stock 5140

2133 is better then 2132 🤪

There is manufacturer 0 instead of NoName.

Which Clover version is the first screen, and which is the second ?

Jief_Machak · October 2, 2021

17 hours ago, yapan4 said:

...and my two cents

yapan4_1001_2.zip 34.14 kB · 0 downloads

Sorry, the last version I've sent contains debug code that overwrite memory modules info.

New version : CloverX64-2021-10-02-12-25-13-83b9323-dirty-jief.zip

20 hours ago, MifJpnAlphaPlus said:

Clock are same...

Thanks for testing. But are you saying it's ok for you ?

PG7 · October 2, 2021

CloverX64-2021-10-02-12-25-13-83b9323-dirty-jief_efi.png.4789b94294985e0be2f8fa1891ac0126.png 437780830_commit83593a5ab91c1a9485d1ce167ad13e035b75aeb2.png.6c8b29a63860794cdb8303c99b7cd0dc.png

Il y a 59 minutes, Jief_Machak a dit :

Nouvelle version : CloverX64-2021-10-02-12-25-13-83b9323-sale-jief.zip

démarrage ok

2021-10-02_10-10_BOOTX64.EFI-CloverX64-2021-10-02-12-25-13-83b9323-dirty-jief.efi.log

commettre/83593a5ab91c1a9485d1ce167ad13e035b75aeb2 2021-10-02_10-20_BOOTX64.EFI-commit: 83593a5ab91c1a9485d1ce167ad13e035b75aeb2.log

Edited October 2, 2021 by PG7

yapan4 · October 2, 2021

yapan4_1002.zip

SavageAUS · October 2, 2021

I stand corrected, tonight Arch Linux decided to boot with no changes.

Will keep testing to see what went wrong.

MacKonsti · October 2, 2021

Hello everyone! @Slice I understand you are busy with fixes for Monterey mate, but I come back to you regarding the non-automatic selection with countdown of the drive when doing the security update to my Catalina with r5139.

Since you had mentioned that it was fixed, please check these logs when you have time:

Updated to latest Catalina security update
r5139 used with debug=true
first boot selected "Data" partition OK with countdown
second reboot selected "Data" partition OK without countdown
third reboot selected normal partition OK with countdown.

Hope the logs will be helpful...

Also as I have a hard time to follow the developments for Monterey and the new requirements in settings, parameters and files for Clover r5140+ (not even sure I found what BLC is that is mentioned by @Jief_Machak ) please if a kind soul manages to install from scrath, kindly post a guide with a link of steps and parameters/files needed -- that would be appreciated !

r5139-Catalina-Update-Automatic-Select-Bug.zip

SavageAUS · October 2, 2021

BLC = Boot Loader Chooser.
Can choose to boot different version of clover or OpenCore etc.

Sent from my iPhone using Tapatalk

Slice · October 3, 2021

19 hours ago, Jief_Machak said:

There is manufacturer 0 instead of NoName.

Which Clover version is the first screen, and which is the second ?

Very simple question. 2132 is for your version, 2133 is for my version.

And the manufacture depends on Trust.

Slice · October 3, 2021

@Jief_Machak

             XBool b = true;
               if ( !super::validate(xmlLiteParser, xmlPath, keyPos, generateErrors) ) b = false;

Why not

             XBool b = super::validate(xmlLiteParser, xmlPath, keyPos, generateErrors);

Is it the same?

Slice · October 3, 2021

New commit 542b

0:161  0:000  === [ Get Smbios ] ==============================
0:161  0:000  Type 16 Index = 0
0:161  0:000  Total Memory Slots Count = 4
0:161  0:000  Type 17 Index = 0
0:161  0:000  Ignoring insane frequency value 0MHz
0:161  0:000  Type 17 Index = 1
0:161  0:000  SmbiosTable.Type17->SlotIndex = 1
0:161  0:000  SmbiosTable.Type17->ModuleSize = 4096MB
0:161  0:000  SmbiosTable.Type17->Type = 0MB
0:161  0:000  SmbiosTable.Type17->Frequency = 2133MHz
0:161  0:000  SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM1
0:161  0:000  SmbiosTable.Type17->Vendor = 0000
0:161  0:000  SmbiosTable.Type17->SerialNo = 00000000
0:161  0:000  SmbiosTable.Type17->PartNo =
0:161  0:000  Type 17 Index = 2

what is Type=0Mb?

Jief_Machak · October 3, 2021

2 hours ago, Slice said:

Very simple question. 2132 is for your version, 2133 is for my version.

This, I have no idea. It's not calculated, where does this number comes from ?

I improved the logs. Could you send me one ?

2 hours ago, Slice said:

And the manufacture depends on Trust.

For what I understood, if SMBIOS is trusted, the manufacturer comes from that, else it comes from what is detected. Is that right ? It yes, it could make sense that they are different, right ?

What do you have in your smbios.plist ?

Send me a log in that case.

1 hour ago, Slice said:

XBool b = super::validate(xmlLiteParser, xmlPath, keyPos, generateErrors);

Yes sure. Way more readable that way. I guess it comes from copy/paste before I used a bool.

12 minutes ago, Slice said:

New commit 542b

0:161  0:000  === [ Get Smbios ] ==============================
0:161  0:000  Type 16 Index = 0
0:161  0:000  Total Memory Slots Count = 4
0:161  0:000  Type 17 Index = 0
0:161  0:000  Ignoring insane frequency value 0MHz
0:161  0:000  Type 17 Index = 1
0:161  0:000  SmbiosTable.Type17->SlotIndex = 1
0:161  0:000  SmbiosTable.Type17->ModuleSize = 4096MB
0:161  0:000  SmbiosTable.Type17->Type = 0MB
0:161  0:000  SmbiosTable.Type17->Frequency = 2133MHz
0:161  0:000  SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM1
0:161  0:000  SmbiosTable.Type17->Vendor = 0000
0:161  0:000  SmbiosTable.Type17->SerialNo = 00000000
0:161  0:000  SmbiosTable.Type17->PartNo =
0:161  0:000  Type 17 Index = 2

what is Type=0Mb?

fixed.

Jief_Machak · October 3, 2021

2 hours ago, Jief_Machak said:

2 hours ago, Slice said:

New commit 542b

0:161  0:000  === [ Get Smbios ] ==============================
0:161  0:000  Type 16 Index = 0
0:161  0:000  Total Memory Slots Count = 4
0:161  0:000  Type 17 Index = 0
0:161  0:000  Ignoring insane frequency value 0MHz
0:161  0:000  Type 17 Index = 1
0:161  0:000  SmbiosTable.Type17->SlotIndex = 1
0:161  0:000  SmbiosTable.Type17->ModuleSize = 4096MB
0:161  0:000  SmbiosTable.Type17->Type = 0MB
0:161  0:000  SmbiosTable.Type17->Frequency = 2133MHz
0:161  0:000  SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM1
0:161  0:000  SmbiosTable.Type17->Vendor = 0000
0:161  0:000  SmbiosTable.Type17->SerialNo = 00000000
0:161  0:000  SmbiosTable.Type17->PartNo =
0:161  0:000  Type 17 Index = 2

what is Type=0Mb?

Expand

fixed.

I mean, type is the constant for DDR DDR2, etc. MB was just some left over text.

SavageAUS · October 3, 2021

With all of these recent discussions I’m seeing and commits to clover is 5140.1 stable to use or does it have bugs? Without going back pages and pages I don’t see where it all started or what it all relates too. Is it just memory mhz people are having issues with or more?

Sent from my iPhone using Tapatalk

Slice · October 3, 2021

4 hours ago, Jief_Machak said:

This, I have no idea. It's not calculated, where does this number comes from ?

I improved the logs. Could you send me one ?

For what I understood, if SMBIOS is trusted, the manufacturer comes from that, else it comes from what is detected. Is that right ? It yes, it could make sense that they are different, right ?

What do you have in your smbios.plist ?

Send me a log in that case.

Yes sure. Way more readable that way. I guess it comes from copy/paste before I used a bool.

fixed.

I have no SMBIOS.plist. There is SMBIOS section in config.plist and almost all commented out.

config.plist.zip bootlog-6238.txt.zip

SMBIOS/DMI is always dynamic data created by BIOS or by the bootloader.

SMBIOS->Trust=true if we suppose BIOS makes good data. Trust=false if we read SPD and use it to fill SMBIOS data.

Jief_Machak · October 3, 2021

Your SMBIOS says 2133MHz and Manufacturer=0000.

Your SPD says 2132MHz and Manufacturer=NoName.

So it looks like it is supposed to change with SMBIOS->trust true or false.

Is there anything wrong ?

Slice · October 3, 2021

Nothing wrong in my case. May be someone has a conflict between SMBIOS and SPD.

Jief_Machak · October 3, 2021

2 hours ago, Slice said:

Nothing wrong in my case.

Ah ok. I though, when you said this following :

16 hours ago, Slice said:

Very simple question. 2132 is for your version, 2133 is for my version.

And the manufacture depends on Trust.

that something is not right.

maclinuxG4 · October 5, 2021

i could use wget instead curl for download, but the isl.forge.inria.fr is down

(no htps, no answer)

Slice · October 5, 2021

See here https://github.com/Meinersbur/isl/releases

May be change the script to this address?

Jief_Machak · October 5, 2021

3 hours ago, MifJpnAlphaPlus said:

"Please commit your changes or stash them before you merge".

To cancel your modification, you can just do a “git reset --hard”

Matgen84 · October 5, 2021

2 hours ago, Slice said:

See here https://github.com/Meinersbur/isl/releases

May be change the script to this address?

@Slice the modification of builgcc10.sh will be commited ASAP. Right.

Thanks

Slice · October 5, 2021

3 hours ago, MifJpnAlphaPlus said:

Hmmm.
configure doesn't exist.
It is using autoreconf.
I can't solve it.🥲

I make the script to create gcc11.2.0 and successfully.

But I don't know how to download good ISL version.

Old site is down. Meinersbur provide sources without configure.

I downloaded from Ubuntu but I can make download from script. I placed isl-0.24 into Clover release 5140 but again I can't download it from script.

So the method is follow:

1. ./build_gcc11.sh

it failed because of no isl.

2. Download isl-0.24.tar.xz manually from Clover release 5140

3. place it into ~/src/tools/download/

4. ./build_gcc11.sh

Yes! It now will work.

But then I encounter next problem

[GENFW] CLOVERX64
Section 1 .text mCoffOffset=576(0x240) mCoffOffsetNew=576(0x240) diff=0(0x0), size=1306432
Section 7 .eh_frame mCoffOffset=1307008(0x13f180) mCoffOffsetNew=1545792(0x179640) diff=238784(0x3a4c0), size=0
Section 3 .data mCoffOffset=1545792(0x179640) mCoffOffsetNew=1307008(0x13f180) diff=-238784(0xfffc5b40), size=238704
Section 5 .ctors mCoffOffset=1545712(0x1795f0) mCoffOffsetNew=1545728(0x179600) diff=16(0x10), size=8
GenFw: ERROR 3000: Invalid
  /Users/sergey/src/CloverBootloader/Build/Clover/RELEASE_GCC53/X64/rEFIt_UEFI/refit/DEBUG/CLOVERX64.dll: Bad definition for symbol '__cxa_pure_virtual'@0 or unsupported symbol type.  For example, absolute and undefined symbols are not supported.
make: *** [/Users/sergey/src/CloverBootloader/Build/Clover/RELEASE_GCC53/X64/rEFIt_UEFI/refit/OUTPUT/CLOVERX64.efi] Error 1

@Jief_Machak May be you know what is it.

Jief_Machak · October 5, 2021

This the error handler when a pure virtual function (a function with no implementation) is called.

i don’t why it’s now generated, but it’s possible to define it ourself.
