deeveedee Posted February 15, 2021 Share Posted February 15, 2021 @mrjayviper Now it makes sense! Forgive my slow understanding! If all of your real Macs are running the same version of Catalina, I would expect installation of CLOVER in the USB EFI to behave the same on each Mac. If you find otherwise, I'd love to know. 1 Link to comment Share on other sites More sharing options...
Vyzantion Posted February 15, 2021 Share Posted February 15, 2021 Sorry if I post in the wrong place, this seems to be the best place to post. I have managed to update Clover to 5130 in the EFI partition of the Hackintosh using the Clover app. I have also tried to update Clover on the EFI of the installation pen drive with Big Sur 11.2 , but it failed to do so, saying to check if the partition is writable. 1 Link to comment Share on other sites More sharing options...
Matgen84 Posted February 15, 2021 Share Posted February 15, 2021 2 hours ago, Vyzantion said: Sorry if I post in the wrong place, this seems to be the best place to post. I have managed to update Clover to 5130 in the EFI partition of the Hackintosh using the Clover app. I have also tried to update Clover on the EFI of the installation pen drive with Big Sur 11.2 , but it failed to do so, saying to check if the partition is writable. No problems with Big Sur 11.3 Beta 1 (Clover PKG). Do you try to update Clover EFI Folder pen drive, with Clover 5130 PKG instead of Clover.app ! 2 Link to comment Share on other sites More sharing options...
Vyzantion Posted February 15, 2021 Share Posted February 15, 2021 3 hours ago, Matgen84 said: No problems with Big Sur 11.3 Beta 1 (Clover PKG). Do you try to update Clover EFI Folder pen drive, with Clover 5130 PKG instead of Clover.app ? No, as I said, I used the Clover app . Link to comment Share on other sites More sharing options...
Slice Posted February 15, 2021 Share Posted February 15, 2021 1 hour ago, Vyzantion said: No, as I said, I used the Clover app . Clover.app was not updated for BigSur. Try pkg. 2 Link to comment Share on other sites More sharing options...
Vyzantion Posted February 15, 2021 Share Posted February 15, 2021 2 hours ago, Slice said: Clover.app was not updated for BigSur. Try pkg. If I manage to download Big Sur 11.2.1 installer to put it on the pen drive, would you recommend using the Clover pkg or the Clover app ? Link to comment Share on other sites More sharing options...
LockDown Posted February 15, 2021 Share Posted February 15, 2021 PKG. They already said it twice 2 2 Link to comment Share on other sites More sharing options...
kushwavez Posted February 18, 2021 Share Posted February 18, 2021 I'm trying to fix the hibernationmode=25 on my Lenovo X1C6 (notebook 1) with Clover v5130. The problem is I don't know how. There are some things in config.plist/Boot about it: StrictHibernate, HibernationFixup, RtcHibernateAware, and SignatureFixup (?). What should I enable? HibernationFixup doesn't help, If I put the notebook to hibernated state, at start I get CMOS failure (with and without HibernationFixup). I have to use RTCMemoryFixup to fix that, but it says then hibernation will not work (and it does not indeed) Link to comment Share on other sites More sharing options...
Matgen84 Posted February 18, 2021 Share Posted February 18, 2021 48 minutes ago, kushwavez said: I'm trying to fix the hibernationmode=25 on my Lenovo X1C6 (notebook 1) with Clover v5130. The problem is I don't know how. There are some things in config.plist/Boot about it: StrictHibernate, HibernationFixup, RtcHibernateAware, and SignatureFixup (?). What should I enable? HibernationFixup doesn't help, If I put the notebook to hibernated state, at start I get CMOS failure (with and without HibernationFixup). I have to use RTCMemoryFixup to fix that, but it says then hibernation will not work (and it does not indeed) Do you try via Terminal: pmset -a hibernatemode 25 Link to comment Share on other sites More sharing options...
Matgen84 Posted February 18, 2021 Share Posted February 18, 2021 (edited) Hi all users @Slice I update my Z390 config to Big Sur 11.3 Beta 2. Now I can only boot from USB, no more from my hard disk: the two EFI Folder are the same Clover r5130. Does anyone have some ideas ! Please. Edited February 18, 2021 by Matgen84 Link to comment Share on other sites More sharing options...
yapan4 Posted February 18, 2021 Share Posted February 18, 2021 @Matgen84 Hmm... it is interesting. And what happens when you boot from HDD? Link to comment Share on other sites More sharing options...
Matgen84 Posted February 18, 2021 Share Posted February 18, 2021 1 minute ago, yapan4 said: @Matgen84 Hmm... it is interesting. And what happens when you boot from HDD? @yapan4 After Clover GUI, I've an underscore at the top left of the screen followed by black screen. Link to comment Share on other sites More sharing options...
kushwavez Posted February 18, 2021 Share Posted February 18, 2021 (edited) 46 minutes ago, Matgen84 said: Do you try via Terminal: pmset -a hibernatemode 25 Of course, that is what I meant when wrote "hibernationmode=25", just a mistype @Slice could you help me about this? Edited February 18, 2021 by kushwavez 1 Link to comment Share on other sites More sharing options...
Slice Posted February 18, 2021 Share Posted February 18, 2021 StrictHibernate=YES SignatureFixup =NO Hibernation also depends on FakeSMC+SMCHelper or VirtualSMC.kext+VirtualSMC.efi There is also Lilu plugin called HibernationFixup. But nothing helped me with my Dell Latitude E6430. I tried all possible combinations, quirks, settings, patches and so on. No result. 1 Link to comment Share on other sites More sharing options...
yapan4 Posted February 18, 2021 Share Posted February 18, 2021 (edited) @Matgen84 The config.plist file (or CloverX64.efi or BOOTX64.efi) may be corrupted. Try to recreate the EFI folder. Edited February 18, 2021 by yapan4 Link to comment Share on other sites More sharing options...
Matgen84 Posted February 18, 2021 Share Posted February 18, 2021 (edited) 11 minutes ago, yapan4 said: @Matgen84 The config.plist file (or CloverX64.efi or BOOTX64.efi) may be corrupted. Try to recreate the EFI folder. @yapan4 I think so. Very strange, I've not this problem with Big Sur 11.3 Beta 1, only when I update to Beta 2. @Slice @yapan4 I upload HDD Debug.log and USB Debug.log: the differences are curious despite I can't boot from HDD. Take a look, please HDD_2021-2-18_9-8-0_BOOTX64.EFI.log USB_2021-2-18_9-8-0_BOOTX64.EFI.log Edited February 18, 2021 by Matgen84 Link to comment Share on other sites More sharing options...
kushwavez Posted February 18, 2021 Share Posted February 18, 2021 9 minutes ago, Slice said: StrictHibernate=YES SignatureFixup =NO Hibernation also depends on FakeSMC+SMCHelper or VirtualSMC.kext+VirtualSMC.efi There is also Lilu plugin called HibernationFixup. But nothing helped me with my Dell Latitude E6430. I tried all possible combinations, quirks, settings, patches and so on. No result. Hmm.. I'll try one more time then I'll give up, thanks. This is the very last thing that isn't working on my X1C6, but after all hibernatemode=25 isn't the default value on real Macs too, so I don't really care about it. 1 Link to comment Share on other sites More sharing options...
yapan4 Posted February 18, 2021 Share Posted February 18, 2021 (edited) @Matgen84 Hmm... Looks like injecting of kernel collection is broken when you boot from HDD. Maybe try to completely reinstall again (EFI, beta2, clean NVRAM, etc....) Edited February 18, 2021 by yapan4 Link to comment Share on other sites More sharing options...
Matgen84 Posted February 18, 2021 Share Posted February 18, 2021 27 minutes ago, yapan4 said: @Matgen84 Hmm... Looks like injecting of kernel collection is broken when you boot from HDD. Maybe try to completely reinstall again (EFI, beta2, clean NVRAM, etc....) @yapan4 Thanks. I already try to clean NVRAM without any results. So I choose to replace HDD EFI Folder, by working USB EFI Folder. It's a very strange, and I don't understand why this happened. Everything worked well before. Link to comment Share on other sites More sharing options...
kushwavez Posted February 18, 2021 Share Posted February 18, 2021 (edited) Last when I had boot issues like you (restarts after selecting the OS) it had to do something with Quirks. If I remember correctly it was DisableLinkeditJettison? I had to enable it. But anyway leaving everything on default values like in config-sample.plist always worked for me. You can see the differences between your two config.plist with "diff" diff config1.plist config2.plist Edited February 18, 2021 by kushwavez Link to comment Share on other sites More sharing options...
Matgen84 Posted February 18, 2021 Share Posted February 18, 2021 7 minutes ago, kushwavez said: Last when I had boot issues like you (restarts before selecting the OS) it had to do something with Quirks. If I remember correctly it was DisableLinkeditJettison? I had to enable it. But anyway leaving everything on default values like in config-sample.plist always worked for me. You can see the differences between your two config.plist with "diff" diff config1.plist config2.plist Thanks. My two config.plist are exactly the same. I checked it out before posting my first post. Link to comment Share on other sites More sharing options...
kushwavez Posted February 18, 2021 Share Posted February 18, 2021 well, then that is indeed interesting 1 Link to comment Share on other sites More sharing options...
Slice Posted February 18, 2021 Share Posted February 18, 2021 @Jief_Machak Why there are double getData()? Size = valueTag->getData()->getData()->dataLenValue(); 1 Link to comment Share on other sites More sharing options...
PG7 Posted February 18, 2021 Share Posted February 18, 2021 11 hours ago, Matgen84 said: Hi all users @Slice I update my Z390 config to Big Sur 11.3 Beta 2. Now I can only boot from USB, no more from my hard disk: the two EFI Folder are the same Clover r5130. Does anyone have some ideas ! Please. I've already tested it on two of my laptops and it's 100% functional, but we certainly don't use the same generation of chipset! one is 5th generation Broadwell and the other is 3rd generation Ivy bridge Link to comment Share on other sites More sharing options...
1Revenger1 Posted February 18, 2021 Share Posted February 18, 2021 (edited) @kushwavez Not sure if it's possible in Clover, but I have hibernatemode=25 working in OpenCore on my Lenovo X1 Extreme There are a couple issues at hand for Thinkpad devices in general 1. RTC issues * I solve the RTC issues using RTCMemoryFixup.kext + HibernationFixup.kext * boot arg `rtcfx_exlude=80-AB`. This is the region in RTC which macOS will write to with hibernation information, though the Lenovo firmware really doesn't like it being written there. RTCMemoryFixup will block writes to that location, while HibernationFixup adds the hibernation info into NVRAM instead. * HibernateMode = NVRAM in config.plist 2. Black screen while trying to boot * This requires using the "ReservedMemory" feature of OpenCore * Address 569344 (Integer) * Type: RuntimeCode (String) * Size: 4096 (integer) I do not know if the ReservedMemory feature was ported over to Clover or not If you want a good reference btw for the x1c6, this uses the same settings I described above for hibernate support:https://github.com/tylernguyen/x1c6-hackintosh If there exists similar settings in Clover, should be able to set it up. Edited February 18, 2021 by 1Revenger1 2 Link to comment Share on other sites More sharing options...
