DarwinDumper

[sir mac alot]

removing paragon extfs solved the empty bootloaders file issue.



it would be great if there was a way to set the save location.



thanks again blackosx.

[blackosx]

Thanks for reporting back sir mac alot.



I've since installed Paragon ExtFS v9.0.0 trial here on my iMac running 10.8.3 to see if I can re-create the issues. I don't have any EXT4 devices handy so I've formatted a 2GB flash drive (using Disk Utility) as EXT4 and executing the diskutil list -plist command shows no error and it completed fine... hmmm what can I do to recreate the issue ?



Did the command fail without a device connected?



it would be great if there was a way to set the save location.

For the command line option this should be relatively straightforward. However, for the user interface it's not as easy. I have an idea for an implementing fixed paths choices, for example the users' Home, Desktop or Documents folder. Otherwise I'll have to include another app like CocoaDialog or Pashua to present the user with the interface which I am hesitant to do right now.. maybe I can implement it via HTML5 / Javascript - I'll have to check?

[blackosx]

v2.6.8 -> 2.6.9



- Set ownership/permission of dumps folder to user and group ID when launched and not assume user ID of 501.

- Minor internal code cleanups.

- Don't show error in command line when attempting to read non-existent efi vars.

- Revise reading user settings from prefs to avoid non-existent items being reported in system.log.

- Revise archiving to only archive dump folder and not full path in some cases.

- Fix issue creating dump folders when app is in a folder containing spaces.

- More fixes for when app is in a folder containing spaces.



Download available on bitbucket but DarwinDumper v2.6.8 should notify you an update is available.

[blackosx]

Request to users of Ivy Bridge CPU's



I have an idea for adding to DarwinDumper a check for 100Mhz sequential increments of the CPU performance states from I/O Registry. I have a script which works for ACPI_SMC_PlatformPlugin but I need to examine a few dumps when OS X loads X86PlatformPlugin, which happens when using an Ivy Bridge CPU.



If possible, could anyone using an Ivy Bridge CPU please run the following command in terminal and post the result?

ioreg -lw0 | grep CPUPStates



Thanks in advance.

[fau7i]

Here is for i5-3570K stock clock.







Last login: Fri Mar 22 23:33:03 on console

localhost:~ iMac13$ ioreg -lw0 | grep CPUPStates

| | | "CPUPStates" = (({"BusMasterLatency"=10,"PState"=0,"Status"=11008,"Frequency"=4201,"Control"=11008,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=1,"Status"=10752,"Frequency"=4200,"Control"=10752,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=2,"Status"=10496,"Frequency"=4100,"Control"=10496,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=3,"Status"=10240,"Frequency"=4000,"Control"=10240,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=4,"Status"=9984,"Frequency"=3900,"Control"=9984,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=5,"Status"=9728,"Frequency"=3800,"Control"=9728,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=6,"Status"=9472,"Frequency"=3700,"Control"=9472,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=7,"Status"=9216,"Frequency"=3600,"Control"=9216,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=8,"Status"=8960,"Frequency"=3500,"Control"=8960,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=9,"Status"=8704,"Frequency"=3400,"Control"=8704,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=10,"Status"=8448,"Frequency"=3300,"Control"=8448,"TransitionLatency"=10,"Power"=73888},{"BusMasterLatency"=10,"PState"=11,"Status"=8192,"Frequency"=3200,"Control"=8192,"TransitionLatency"=10,"Power"=70832},{"BusMasterLatency"=10,"PState"=12,"Status"=7936,"Frequency"=3100,"Control"=7936,"TransitionLatency"=10,"Power"=67832},{"BusMasterLatency"=10,"PState"=13,"Status"=7680,"Frequency"=3000,"Control"=7680,"TransitionLatency"=10,"Power"=64887},{"BusMasterLatency"=10,"PState"=14,"Status"=7424,"Frequency"=2900,"Control"=7424,"TransitionLatency"=10,"Power"=61997},{"BusMasterLatency"=10,"PState"=15,"Status"=7168,"Frequency"=2800,"Control"=7168,"TransitionLatency"=10,"Power"=59161},{"BusMasterLatency"=10,"PState"=16,"Status"=6912,"Frequency"=2700,"Control"=6912,"TransitionLatency"=10,"Power"=56379},{"BusMasterLatency"=10,"PState"=17,"Status"=6656,"Frequency"=2600,"Control"=6656,"TransitionLatency"=10,"Power"=53650},{"BusMasterLatency"=10,"PState"=18,"Status"=6400,"Frequency"=2500,"Control"=6400,"TransitionLatency"=10,"Power"=50975},{"BusMasterLatency"=10,"PState"=19,"Status"=6144,"Frequency"=2400,"Control"=6144,"TransitionLatency"=10,"Power"=48351},{"BusMasterLatency"=10,"PState"=20,"Status"=5888,"Frequency"=2300,"Control"=5888,"TransitionLatency"=10,"Power"=45780},{"BusMasterLatency"=10,"PState"=21,"Status"=5632,"Frequency"=2200,"Control"=5632,"TransitionLatency"=10,"Power"=43260},{"BusMasterLatency"=10,"PState"=22,"Status"=5376,"Frequency"=2100,"Control"=5376,"TransitionLatency"=10,"Power"=40792},{"BusMasterLatency"=10,"PState"=23,"Status"=5120,"Frequency"=2000,"Control"=5120,"TransitionLatency"=10,"Power"=38374},{"BusMasterLatency"=10,"PState"=24,"Status"=4864,"Frequency"=1900,"Control"=4864,"TransitionLatency"=10,"Power"=36007},{"BusMasterLatency"=10,"PState"=25,"Status"=4608,"Frequency"=1800,"Control"=4608,"TransitionLatency"=10,"Power"=33689},{"BusMasterLatency"=10,"PState"=26,"Status"=4352,"Frequency"=1700,"Control"=4352,"TransitionLatency"=10,"Power"=31421},{"BusMasterLatency"=10,"PState"=27,"Status"=4096,"Frequency"=1600,"Control"=4096,"TransitionLatency"=10,"Power"=29202},{"BusMasterLatency"=10,"PState"=28,"Status"=3840,"Frequency"=1500,"Control"=3840,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=29,"Status"=3584,"Frequency"=1400,"Control"=3584,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=30,"Status"=3328,"Frequency"=1300,"Control"=3328,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=31,"Status"=3072,"Frequency"=1200,"Control"=3072,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=32,"Status"=2816,"Frequency"=1100,"Control"=2816,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=33,"Status"=2560,"Frequency"=1000,"Control"=2560,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=34,"Status"=2304,"Frequency"=900,"Control"=2304,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=35,"Status"=2048,"Frequency"=800,"Control"=2048,"TransitionLatency"=10,"Power"=0}),({"BusMasterLatency"=10,"PState"=0,"Status"=11008,"Frequency"=4201,"Control"=11008,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=1,"Status"=10752,"Frequency"=4200,"Control"=10752,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=2,"Status"=10496,"Frequency"=4100,"Control"=10496,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=3,"Status"=10240,"Frequency"=4000,"Control"=10240,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=4,"Status"=9984,"Frequency"=3900,"Control"=9984,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=5,"Status"=9728,"Frequency"=3800,"Control"=9728,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=6,"Status"=9472,"Frequency"=3700,"Control"=9472,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=7,"Status"=9216,"Frequency"=3600,"Control"=9216,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=8,"Status"=8960,"Frequency"=3500,"Control"=8960,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=9,"Status"=8704,"Frequency"=3400,"Control"=8704,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=10,"Status"=8448,"Frequency"=3300,"Control"=8448,"TransitionLatency"=10,"Power"=73888},{"BusMasterLatency"=10,"PState"=11,"Status"=8192,"Frequency"=3200,"Control"=8192,"TransitionLatency"=10,"Power"=70832},{"BusMasterLatency"=10,"PState"=12,"Status"=7936,"Frequency"=3100,"Control"=7936,"TransitionLatency"=10,"Power"=67832},{"BusMasterLatency"=10,"PState"=13,"Status"=7680,"Frequency"=3000,"Control"=7680,"TransitionLatency"=10,"Power"=64887},{"BusMasterLatency"=10,"PState"=14,"Status"=7424,"Frequency"=2900,"Control"=7424,"TransitionLatency"=10,"Power"=61997},{"BusMasterLatency"=10,"PState"=15,"Status"=7168,"Frequency"=2800,"Control"=7168,"TransitionLatency"=10,"Power"=59161},{"BusMasterLatency"=10,"PState"=16,"Status"=6912,"Frequency"=2700,"Control"=6912,"TransitionLatency"=10,"Power"=56379},{"BusMasterLatency"=10,"PState"=17,"Status"=6656,"Frequency"=2600,"Control"=6656,"TransitionLatency"=10,"Power"=53650},{"BusMasterLatency"=10,"PState"=18,"Status"=6400,"Frequency"=2500,"Control"=6400,"TransitionLatency"=10,"Power"=50975},{"BusMasterLatency"=10,"PState"=19,"Status"=6144,"Frequency"=2400,"Control"=6144,"TransitionLatency"=10,"Power"=48351},{"BusMasterLatency"=10,"PState"=20,"Status"=5888,"Frequency"=2300,"Control"=5888,"TransitionLatency"=10,"Power"=45780},{"BusMasterLatency"=10,"PState"=21,"Status"=5632,"Frequency"=2200,"Control"=5632,"TransitionLatency"=10,"Power"=43260},{"BusMasterLatency"=10,"PState"=22,"Status"=5376,"Frequency"=2100,"Control"=5376,"TransitionLatency"=10,"Power"=40792},{"BusMasterLatency"=10,"PState"=23,"Status"=5120,"Frequency"=2000,"Control"=5120,"TransitionLatency"=10,"Power"=38374},{"BusMasterLatency"=10,"PState"=24,"Status"=4864,"Frequency"=1900,"Control"=4864,"TransitionLatency"=10,"Power"=36007},{"BusMasterLatency"=10,"PState"=25,"Status"=4608,"Frequency"=1800,"Control"=4608,"TransitionLatency"=10,"Power"=33689},{"BusMasterLatency"=10,"PState"=26,"Status"=4352,"Frequency"=1700,"Control"=4352,"TransitionLatency"=10,"Power"=31421},{"BusMasterLatency"=10,"PState"=27,"Status"=4096,"Frequency"=1600,"Control"=4096,"TransitionLatency"=10,"Power"=29202},{"BusMasterLatency"=10,"PState"=28,"Status"=3840,"Frequency"=1500,"Control"=3840,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=29,"Status"=3584,"Frequency"=1400,"Control"=3584,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=30,"Status"=3328,"Frequency"=1300,"Control"=3328,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=31,"Status"=3072,"Frequency"=1200,"Control"=3072,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=32,"Status"=2816,"Frequency"=1100,"Control"=2816,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=33,"Status"=2560,"Frequency"=1000,"Control"=2560,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=34,"Status"=2304,"Frequency"=900,"Control"=2304,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=35,"Status"=2048,"Frequency"=800,"Control"=2048,"TransitionLatency"=10,"Power"=0}),({"BusMasterLatency"=10,"PState"=0,"Status"=11008,"Frequency"=4201,"Control"=11008,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=1,"Status"=10752,"Frequency"=4200,"Control"=10752,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=2,"Status"=10496,"Frequency"=4100,"Control"=10496,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=3,"Status"=10240,"Frequency"=4000,"Control"=10240,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=4,"Status"=9984,"Frequency"=3900,"Control"=9984,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=5,"Status"=9728,"Frequency"=3800,"Control"=9728,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=6,"Status"=9472,"Frequency"=3700,"Control"=9472,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=7,"Status"=9216,"Frequency"=3600,"Control"=9216,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=8,"Status"=8960,"Frequency"=3500,"Control"=8960,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=9,"Status"=8704,"Frequency"=3400,"Control"=8704,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=10,"Status"=8448,"Frequency"=3300,"Control"=8448,"TransitionLatency"=10,"Power"=73888},{"BusMasterLatency"=10,"PState"=11,"Status"=8192,"Frequency"=3200,"Control"=8192,"TransitionLatency"=10,"Power"=70832},{"BusMasterLatency"=10,"PState"=12,"Status"=7936,"Frequency"=3100,"Control"=7936,"TransitionLatency"=10,"Power"=67832},{"BusMasterLatency"=10,"PState"=13,"Status"=7680,"Frequency"=3000,"Control"=7680,"TransitionLatency"=10,"Power"=64887},{"BusMasterLatency"=10,"PState"=14,"Status"=7424,"Frequency"=2900,"Control"=7424,"TransitionLatency"=10,"Power"=61997},{"BusMasterLatency"=10,"PState"=15,"Status"=7168,"Frequency"=2800,"Control"=7168,"TransitionLatency"=10,"Power"=59161},{"BusMasterLatency"=10,"PState"=16,"Status"=6912,"Frequency"=2700,"Control"=6912,"TransitionLatency"=10,"Power"=56379},{"BusMasterLatency"=10,"PState"=17,"Status"=6656,"Frequency"=2600,"Control"=6656,"TransitionLatency"=10,"Power"=53650},{"BusMasterLatency"=10,"PState"=18,"Status"=6400,"Frequency"=2500,"Control"=6400,"TransitionLatency"=10,"Power"=50975},{"BusMasterLatency"=10,"PState"=19,"Status"=6144,"Frequency"=2400,"Control"=6144,"TransitionLatency"=10,"Power"=48351},{"BusMasterLatency"=10,"PState"=20,"Status"=5888,"Frequency"=2300,"Control"=5888,"TransitionLatency"=10,"Power"=45780},{"BusMasterLatency"=10,"PState"=21,"Status"=5632,"Frequency"=2200,"Control"=5632,"TransitionLatency"=10,"Power"=43260},{"BusMasterLatency"=10,"PState"=22,"Status"=5376,"Frequency"=2100,"Control"=5376,"TransitionLatency"=10,"Power"=40792},{"BusMasterLatency"=10,"PState"=23,"Status"=5120,"Frequency"=2000,"Control"=5120,"TransitionLatency"=10,"Power"=38374},{"BusMasterLatency"=10,"PState"=24,"Status"=4864,"Frequency"=1900,"Control"=4864,"TransitionLatency"=10,"Power"=36007},{"BusMasterLatency"=10,"PState"=25,"Status"=4608,"Frequency"=1800,"Control"=4608,"TransitionLatency"=10,"Power"=33689},{"BusMasterLatency"=10,"PState"=26,"Status"=4352,"Frequency"=1700,"Control"=4352,"TransitionLatency"=10,"Power"=31421},{"BusMasterLatency"=10,"PState"=27,"Status"=4096,"Frequency"=1600,"Control"=4096,"TransitionLatency"=10,"Power"=29202},{"BusMasterLatency"=10,"PState"=28,"Status"=3840,"Frequency"=1500,"Control"=3840,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=29,"Status"=3584,"Frequency"=1400,"Control"=3584,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=30,"Status"=3328,"Frequency"=1300,"Control"=3328,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=31,"Status"=3072,"Frequency"=1200,"Control"=3072,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=32,"Status"=2816,"Frequency"=1100,"Control"=2816,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=33,"Status"=2560,"Frequency"=1000,"Control"=2560,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=34,"Status"=2304,"Frequency"=900,"Control"=2304,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=35,"Status"=2048,"Frequency"=800,"Control"=2048,"TransitionLatency"=10,"Power"=0}),({"BusMasterLatency"=10,"PState"=0,"Status"=11008,"Frequency"=4201,"Control"=11008,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=1,"Status"=10752,"Frequency"=4200,"Control"=10752,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=2,"Status"=10496,"Frequency"=4100,"Control"=10496,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=3,"Status"=10240,"Frequency"=4000,"Control"=10240,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=4,"Status"=9984,"Frequency"=3900,"Control"=9984,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=5,"Status"=9728,"Frequency"=3800,"Control"=9728,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=6,"Status"=9472,"Frequency"=3700,"Control"=9472,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=7,"Status"=9216,"Frequency"=3600,"Control"=9216,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=8,"Status"=8960,"Frequency"=3500,"Control"=8960,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=9,"Status"=8704,"Frequency"=3400,"Control"=8704,"TransitionLatency"=10,"Power"=77000},{"BusMasterLatency"=10,"PState"=10,"Status"=8448,"Frequency"=3300,"Control"=8448,"TransitionLatency"=10,"Power"=73888},{"BusMasterLatency"=10,"PState"=11,"Status"=8192,"Frequency"=3200,"Control"=8192,"TransitionLatency"=10,"Power"=70832},{"BusMasterLatency"=10,"PState"=12,"Status"=7936,"Frequency"=3100,"Control"=7936,"TransitionLatency"=10,"Power"=67832},{"BusMasterLatency"=10,"PState"=13,"Status"=7680,"Frequency"=3000,"Control"=7680,"TransitionLatency"=10,"Power"=64887},{"BusMasterLatency"=10,"PState"=14,"Status"=7424,"Frequency"=2900,"Control"=7424,"TransitionLatency"=10,"Power"=61997},{"BusMasterLatency"=10,"PState"=15,"Status"=7168,"Frequency"=2800,"Control"=7168,"TransitionLatency"=10,"Power"=59161},{"BusMasterLatency"=10,"PState"=16,"Status"=6912,"Frequency"=2700,"Control"=6912,"TransitionLatency"=10,"Power"=56379},{"BusMasterLatency"=10,"PState"=17,"Status"=6656,"Frequency"=2600,"Control"=6656,"TransitionLatency"=10,"Power"=53650},{"BusMasterLatency"=10,"PState"=18,"Status"=6400,"Frequency"=2500,"Control"=6400,"TransitionLatency"=10,"Power"=50975},{"BusMasterLatency"=10,"PState"=19,"Status"=6144,"Frequency"=2400,"Control"=6144,"TransitionLatency"=10,"Power"=48351},{"BusMasterLatency"=10,"PState"=20,"Status"=5888,"Frequency"=2300,"Control"=5888,"TransitionLatency"=10,"Power"=45780},{"BusMasterLatency"=10,"PState"=21,"Status"=5632,"Frequency"=2200,"Control"=5632,"TransitionLatency"=10,"Power"=43260},{"BusMasterLatency"=10,"PState"=22,"Status"=5376,"Frequency"=2100,"Control"=5376,"TransitionLatency"=10,"Power"=40792},{"BusMasterLatency"=10,"PState"=23,"Status"=5120,"Frequency"=2000,"Control"=5120,"TransitionLatency"=10,"Power"=38374},{"BusMasterLatency"=10,"PState"=24,"Status"=4864,"Frequency"=1900,"Control"=4864,"TransitionLatency"=10,"Power"=36007},{"BusMasterLatency"=10,"PState"=25,"Status"=4608,"Frequency"=1800,"Control"=4608,"TransitionLatency"=10,"Power"=33689},{"BusMasterLatency"=10,"PState"=26,"Status"=4352,"Frequency"=1700,"Control"=4352,"TransitionLatency"=10,"Power"=31421},{"BusMasterLatency"=10,"PState"=27,"Status"=4096,"Frequency"=1600,"Control"=4096,"TransitionLatency"=10,"Power"=29202},{"BusMasterLatency"=10,"PState"=28,"Status"=3840,"Frequency"=1500,"Control"=3840,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=29,"Status"=3584,"Frequency"=1400,"Control"=3584,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=30,"Status"=3328,"Frequency"=1300,"Control"=3328,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=31,"Status"=3072,"Frequency"=1200,"Control"=3072,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=32,"Status"=2816,"Frequency"=1100,"Control"=2816,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=33,"Status"=2560,"Frequency"=1000,"Control"=2560,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=34,"Status"=2304,"Frequency"=900,"Control"=2304,"TransitionLatency"=10,"Power"=0},{"BusMasterLatency"=10,"PState"=35,"Status"=2048,"Frequency"=800,"Control"=2048,"TransitionLatency"=10,"Power"=0}))

localhost:~ iMac13$





BTW, I use custom SSDT and drop the OEM one in config.plist. I don't know if it does really a matter.

[fau7i]

could you supply that SSDT, thanks



Of course...



Although this SSDT is OCed to 4.2, my CPU runs on stock clock currently. At any time, I can set it back.



http://dl.dropbox.com/u/73287739/Hackintosh/SSDT-i53570K_OC42.aml.zip

[blackosx]

Here is for i5-3570K stock clock.



BTW, I use custom SSDT and drop the OEM one in config.plist. I don't know if it does really a matter.

Thanks fau71.



Thinking about this out loud, anyone using a custom SSDT created will RevoGirl's ssdtPRGen script will have 100Mhz incremental steps correctly set so maybe this check could be pointless? hmmm..

[blackosx]

v2.6.9 -> 2.7.0



- Fix bug introduced in 2.6.9 where running one of the preconfigured 'p' options from the command line would not execute the archive option.

- Better handling of non-numeric characters in version number when checking for updates.

- Moved all temporary working files to own folder /tmp/DarwinDumper.

- Add check for root UID and if true assign UID and GID using contents of $HOME environment variable.

- Admin password entered in to UI for symlink of running dumps is now validated and handled accordingly.

- User cancellation of the UI password window now resets the dump status bars back to idle.

- UI checkFeedback timer now only initialises after a run button has been pressed.

- Changed UI dump title from Bootloader Config Files to Bootloader Configs & Drivers

- Added note about the Clover driver files dumped in the associated info page.

- Added Clover RC scripts dump option.

- Update JQueryUI and add theme to the macgap user interface for dialog box.

- Added handling of a non-writable reports folder to both the UI and command line.

- Fix full path for dumped loader config & driver files read from ESP after mounting. (Thanks Droplets).



v2.6.8 onwards should notify about the update. For older versions the download is available at Bitbucket from link on first page

[Slice]

I have no CPUPStates

MacBook:1 slice$ ioreg -lw0 | grep CPUPStates
MacBook:1 slice$

But my speedstep works fine

[blackosx]

Hi Slice



CPUStates are only present in ioreg when X86PlatformPlugin is loaded. I believe this only happens when using IvyBridge or newer CPU. In your sig I see i3-2120 which is SandyBridge so you will have ACPI_SMC_PlatformPlugin loaded in which case you'll have PerformanceStateArray.

[Fabio1971]

V.2.7.0

Lspci does not extract

possible Error



Fabio

[blackosx]

Hi Fabio71



I have not seen any problems with the LSPCi dump here.

Can you please provide me with terminal output of the LSPCI dump process?



Here's what to do:

1 - Load DarwinDumper

2 - Click the Symlink option in the left menu.

3 - In the window that slides down, Does the Status read 'Installed'? If not, click the 'Create Symlink' button, then once installed, Close the window and quit DarwinDumper.

4 - Load Terminal and type the following:

darwindumper -rd lspci



Please report back any errors.

[blackosx]

v2.7.0 -> 2.7.1



- Fix report css for warning sections.

- All dumps, HTML report and .zip archive options are now ticked by default when user prefs file does not exist.

- Adjust HTML report script to allow for when gEfiAppleNvramGuid variables are not used.

- Add detection for IODeviceTree/RevoEFI as an indicator for the RevoBoot loader.

- Renamed Clover RC scripts to RC Startup and Shutdown Scripts.

- Added UI dialog box to notify user that it's waiting for admin authentification.

- Added disabling/enabling of UI buttons to help control what user can and can't click.

- Update macgap UI to use jqueryUI 1.10.2 and replace smoothness theme for dark-hive.

- Update macgap UI to use jquery 1.9.1.

- Set recursive ownership of indexed, time stamped folder to user who began the dumps.

- Add revised /EFI/Clover search path for bootloader dump.

- Clover drivers dump now creates a single file listing all files. No files are copied.

- Re-arrange the user interface so that dumps are now split in to two groups; those which require root privileges and those that do not.

- Remove the run-as-root button, so there's now only a single run button. The user is asked for their password if required.

- Add detection for revised boot0 and boot0hfs. See http://sourceforge.n...boot/code/1560/ for further info.

- Change UI option description from 'Select No Dumps' to read 'Deselect All Dumps'.

- Revise descriptive names of MBR loader (Stage 0) codes.

- Add bdisk script to scan and interpret a disks partition tables.

- Add disk partition table view to html report.



Please report any issues.

[Fabio1971]

Hello blackosx



Sorry for the late reply (I was out for work)



Tested version DarwinDumper 2.7.1

Mountain Lion 10.8.3

everything ok

thanks



Fabio

[blackosx]

v2.7.1 -> 2.7.2



- Improve/Correct the disk partition scan output with help from JrCs.

- Added option to html report I/O Registry dump sub title bar for user to view Registry dump in separate browser tab.

- IORegistry viewer is now initiated on opening of the html report IORegistry outer header (green bar) rather than onload of the file. Alert message is now more informative about the local XMLHttpRequest issue. The error message when loading the file in Safari should no longer appear.

- Include disk partition dump in logfile.

- Update command line pre-configured options to work with changed practice of some dumps requiring and not requiring root privileges.

- Update faceless build to work with latest revisions.



Download Link



The disk partition view in the HTML report has been improved and in the case of a GPT and GPT/MBR setup, it now shows a more complete MBR partition Map along side the GPT partition Map . Here's a pic of my time machine disk.





Tested version DarwinDumper 2.7.1

Mountain Lion 10.8.3

everything ok

Thanks for coming back and confirming Fabio71.

[Andy Vandijck]

I have an idea.

How would you like to do video bios dumps with DarwinDumper?

I'm going to rewrite RadeonPCI so it can work on Lion and better.

RadeonDump can then dump the vbios of ATI, NVidia and Intel cards.

In case of ATI card detected it can then decode the vbios dump with radeon bios decoder.

Keep you posted when I am done with it

[Andy Vandijck]

I finished it.

I modified RadeonDump to put the first 4 characters of the file as the vendor (1002 for ATI, 8086 for Intel and 10DE for NVidia).

This way we can detect if it is an ATI rom and use radeon_bios_decode on it in case.

This tool requires root rights to load the kext.

I hope you implement it as video bios dump and decoding would be very cool in DarwinDumper (and handy for Clover people with ATI cards as they need their connector data).

Sources are included.

Enjoy

RadeonPCI_AnV_Dong.zip

[blackosx]

This will be a great addition to DarwinDumper.
I've just tested it here on my 5770 and it successfully dumped the rom and decoded it to show the following details:


ATOM BIOS Rom:
SubsystemVendorID: 0x1002 SubsystemID: 0x2543
IOBaseAddress: 0xe000
Filename: S3C01005.102
BIOS Bootup Message:
JUNIPER BIOS UCODEv:126

PCI ID: 1002:68b8
Connector at index 0
Type [@offset 44592]: DisplayPort (10)
Encoder [@offset 44596]: INTERNAL_UNIPHY2 (0x21)
i2cid [@offset 44720]: 0x91, OSX senseid: 0x2
Connector at index 1
Type [@offset 44602]: HDMI-A (11)
Encoder [@offset 44606]: INTERNAL_UNIPHY2 (0x21)
i2cid [@offset 44747]: 0x90, OSX senseid: 0x1
Connector at index 2
Type [@offset 44612]: DVI-I (2)
Encoder [@offset 44616]: INTERNAL_UNIPHY1 (0x20)
i2cid [@offset 44784]: 0x93, OSX senseid: 0x4
Connector at index 3
Type [@offset 44622]: DVI-I (2)
Encoder [@offset 44626]: INTERNAL_KLDSCP_DAC2 (0x16)
i2cid [@offset 44784]: 0x93, OSX senseid: 0x4
Connector at index 4
Type [@offset 44632]: DVI-I (2)
Encoder [@offset 44636]: INTERNAL_UNIPHY (0x1e)
i2cid [@offset 44821]: 0x92, OSX senseid: 0x3
Connector at index 5
Type [@offset 44642]: DVI-I (2)
Encoder [@offset 44646]: INTERNAL_KLDSCP_DAC1 (0x15)
i2cid [@offset 44821]: 0x92, OSX senseid: 0x3

Thank you for this contribution Andy

EDIT: Is it compatible with OS X 10.5 and 10.6 as well as newer?



EDIT2: Updated post to change forum tag from codebox (which no longer works) to code

Edited September 20, 2013 by blackosx

[Andy Vandijck]

This will be a great addition to DarwinDumper.

I've just tested it here on my 5770 and it successfully dumped the rom and decoded it to show the following details:



ATOM BIOS Rom:
SubsystemVendorID: 0x1002 SubsystemID: 0x2543
IOBaseAddress: 0xe000
Filename: S3C01005.102
BIOS Bootup Message:
JUNIPER BIOS UCODEv:126

PCI ID: 1002:68b8
Connector at index 0
Type [@offset 44592]: DisplayPort (10)
Encoder [@offset 44596]: INTERNAL_UNIPHY2 (0x21)
i2cid [@offset 44720]: 0x91, OSX senseid: 0x2
Connector at index 1
Type [@offset 44602]: HDMI-A (11)
Encoder [@offset 44606]: INTERNAL_UNIPHY2 (0x21)
i2cid [@offset 44747]: 0x90, OSX senseid: 0x1
Connector at index 2
Type [@offset 44612]: DVI-I (2)
Encoder [@offset 44616]: INTERNAL_UNIPHY1 (0x20)
i2cid [@offset 44784]: 0x93, OSX senseid: 0x4
Connector at index 3
Type [@offset 44622]: DVI-I (2)
Encoder [@offset 44626]: INTERNAL_KLDSCP_DAC2 (0x16)
i2cid [@offset 44784]: 0x93, OSX senseid: 0x4
Connector at index 4
Type [@offset 44632]: DVI-I (2)
Encoder [@offset 44636]: INTERNAL_UNIPHY (0x1e)
i2cid [@offset 44821]: 0x92, OSX senseid: 0x3
Connector at index 5
Type [@offset 44642]: DVI-I (2)
Encoder [@offset 44646]: INTERNAL_KLDSCP_DAC1 (0x15)
i2cid [@offset 44821]: 0x92, OSX senseid: 0x3



Thank you for this contribution Andy



EDIT: Is it compatible with OS X 10.5 and 10.6 as well as newer?

Its built for 10.7 and above but can be recompiled for 10.5 and 10.6.

10.5 only 32-bit kext though but 64-bit app.

[Andy Vandijck]

I recompiled the kext and program for 10.5

@Blackosx: You should use the 10.5 RadeonDump binary and use the RadeonPCI 10.5 kext on 10.5 and RadeonPCI 10.7 kext on 10.6 and up (it should work).

Somebody: Please test that 10.6 hypothesis by using 10.5 RadeonDump and 10.7 RadeonPCI.kext on 10.6

Sources included

RadeonPCI_AnV_Dong_2.zip

[magnifico]

I recompiled the kext and program for 10.5

@Blackosx: You should use the 10.5 RadeonDump binary and use the RadeonPCI 10.5 kext on 10.5 and RadeonPCI 10.7 kext on 10.6 and up (it should work).

Somebody: Please test that 10.6 hypothesis by using 10.5 RadeonDump and 10.7 RadeonPCI.kext on 10.6

Sources included

Great Andy great

[blackosx]

I recompiled the kext and program for 10.5

@Blackosx: You should use the 10.5 RadeonDump binary and use the RadeonPCI 10.5 kext on 10.5 and RadeonPCI 10.7 kext on 10.6 and up (it should work).

Somebody: Please test that 10.6 hypothesis by using 10.5 RadeonDump and 10.7 RadeonPCI.kext on 10.6

Sources included

Thanks Andy, I'll take a look.

[blackosx]

v2.7.2 -> 2.7.3



- Add identification of Windows Recovery Environment to disk partition dump.

- Added vBIOS dumps and decoding of ATI ROM's. Andy Vandijck's RadeonPCI.kext & RadeonDump used to dump legacy ROM's. Script can also dump legacy ATY,bin_image ROM from ioreg, and find and extract GOP UEFI ROM from ACPI VFCT table (If present). Andy Vandijck's radeon_bios_decode tool is then used to decode ATI ROM's.

- Added BIOS flashrom log to HTML report.

- Added BIOS and VBIOS nav links to HTML report, and adjusted link spacing.

- Revised HTML report LSPCI sub header titles to be cleaner to read.

- Updated included pci.ids.gz file.

- Fixed problem from v2.7.2 where gatherDiskUtilLoaderinfo script would look for UID's text file when not asked for.

- Add Slice's genconfig tool to grab Clover's config that was used for the current boot (if booting with Clover and with rev1672 or newer). This is useful if the user has made changes at the GUI.

- Add check to bdisk script to ignore blank partition entries which have had the status byte set to active.



Please report any issues.



Download Link

[Fabio1971]

Tested version DarwinDumper 2.7.3

Mountain Lion 10.8.4

Great job



Fabio

[Andy Vandijck]

Tested also on ML 10.8.4

Works great
