mokeev1995
mokeev1995
Posted
Posted

Can somebody tell me why is Clover better? I have the following setup



Inspiron N5110 (2430M)

500GB HDD (GPT) (3 Partition , first windows, 2nd mac, third for Data+TimeMachine)

ALPS TouchPoint

Chameleon 2.2 svn2283

8GB RAM (Dual Channel)

Front Camera

USB (All incl. 3.0)

eSATA (Not tested but USB plugged in WORKS)

Everything works!!



I have installed Yosmitie and i have everything working from TouchPad Scroll, Full Sleep, Brightness Control,HW Sensors. Its to-date perfect setup for me. I never had to made DSDT or SSDT,  i used whats available. Just made a TimeMachine backup and now i transffered that to external HD, i can reformat this drive and install again the same backup and everything works flawlessly fine.





What else would someone need? Why bother for Clover? Whats so special about it? (Sorry , i didnt had time to go through all of the threads - i am short on time, my apologizes)





Anyone could tell me what i am missing? (PS: I have the stable Mac Yosmitie 10.10.5 , never crashed, never hung, never heat up and i am using almost 20-25 apps at a single time)





Looking forward.!!



clover uses built in EFI if exists or emulates it with rEFIt

chameleon/chimera only emulates EFI



if your system has (U)EFI  it's better to use clover instead of  chameleon or chimera

Link to comment
Share on other sites
ezee
ezee
Posted
Posted

I have basically used AppleHDA "kexts for El-capitan" and copied the two zlib in it and put that inside S/L/E

http://www.mediafire.com/download/yuzzdeypjedng1a/AppleHDA.kext.zip



I have to buy a WLAN card to get it wifi working. Which one do you all recommend? There are range of Atheros card with matching interface, can I go with anyone of them? I would prefer card with BT 4 if possible

Link to comment
Share on other sites
Florin9doi
Florin9doi
Posted
Posted (edited)
On 1/31/2016 at 5:12 PM, ezee said:

Will BCM4360 work? Its been configured 3x3:3(1.3Gbps). The difference is in interface, 4352 has voids while there is no voids for 4360

https://wikidevi.com/wiki/Broadcom

http://www.broadcom.com/products/Wireless-LAN/802.11-Wireless-LAN-Solutions/BCM4360

You need a half size pcie card because the full size slot (WWAN) present in Dell N5110 is USB only.

The only half size card which use BCM4360 is BCM94360HMB but

- it needs 3 antennas

- it uses a new type of antenna connectors

You can install it, but you need to change/add antennas.

BCM4352 is plug and play. You don't need anything else.

Edited by Florin9doi
  • Like 1
Link to comment
Share on other sites
mokeev1995
mokeev1995
Posted
Posted

I have basically used AppleHDA "kexts for El-capitan" and copied the two zlib in it and put that inside S/L/E

http://www.mediafire.com/download/yuzzdeypjedng1a/AppleHDA.kext.zip



I have to buy a WLAN card to get it wifi working. Which one do you all recommend? There are range of Atheros card with matching interface, can I go with anyone of them? I would prefer card with BT 4 if possible



azurewave aw-ce123h ( http://www.ebay.com/sch/i.html?_from=R40&_trksid=p2047675.m570.l1313.TR0.TRC0.H0.TRS0&_nkw=azurewave+aw-ce123h&_sacat=0 )

with this card you can use airdrop and continuity, as i know :-)



try to use it

  • Like 1
Link to comment
Share on other sites
ezee
ezee
Posted
Posted

azurewave aw-ce123h ( http://www.ebay.com/sch/i.html?_from=R40&_trksid=p2047675.m570.l1313.TR0.TRC0.H0.TRS0&_nkw=azurewave+aw-ce123h&_sacat=0 )

with this card you can use airdrop and continuity, as i know :-)



try to use it

any difference between the two...

BroadCom BCM4352 BCM94352HMB

BCM4352 azurewave aw-ce123h

there are few more like DW1550 BCM4352

so much confusing

http://www.aliexpress.com/w/wholesale-bcm4352.html?spm=2114.01010208.0.325.6Fl7C8&site=glo&groupsort=1&SortType=price_asc&g=y&SearchText=bcm4352&isUnitPrice=y&initiative_id=SB_20160202033112&shipCountry=IN&needQuery=n&isRtl=yes



I found this one, I hope this is one would be good to buy

http://www.aliexpress.com/item/AzureWave-AW-CE123H-BCM4352-BCM94352HMB-Half-Mini-PCIe-PCI-express-802-11AC-867Mhz-Wireless-WIFI-WLAN/32472259138.html?spm=2114.01010208.3.206.NU7F6u&ws_ab_test=searchweb201556_3,searchweb201644_1_505_506_503_504_502_10001_10002_10016_10005_10006_10003_10004,searchweb201560_2,searchweb1451318400_-1,searchweb1451318411_6451&btsid=c2330f1f-4f8a-4346-961b-7213883d7bf2

Link to comment
Share on other sites
rezsicc
rezsicc
Posted
Posted

Hello guys,



Could you help me, please? Which version of OS X works smoothly?

Would be El Captain good if I installed it? Do kexts work perfectly? Because I saw that some functions aren't available.

Or is Yosemite still better?



I had ML few years ago.



Do I only need to use the description of page 1? Is it up-to-date?

Link to comment
Share on other sites
mokeev1995
mokeev1995
Posted
Posted

Link to  VoodooPS2Controller:

http://www.filedropper.com/voodoops2controllerkext-2016-01-15



I have facetime, appstore,imessages working on chameleon(enoch 2773) with macbook pro 8,1 SMBios.

I had Yosemite and all was working except turbo boost, even sleep was working, also with Chameleon bootloader.



Do you think it will break the boot even if i have  Chameleon? I mean if i flash that Bios?

If anyone is interested i can make a guide for chameleon installing, but first it's needed to repair the sleep so it can be a fully functional guide.



Thank you @ezee for the tip about Turbo Boost



P.S.

I have used a DSDT for i7 provided by kenjiloc and it would use multiplier x28 on my i5 getting it to 2.77ghz getting score of 4666 in geekbench 3 (32bit) with i5 DSDT i get 4090 score. The onlything it was that power management wasn't working.so always 2.77ghz  60*C idle(not good for cpu)



can you send this kext one more time and via Google Drive/Mega or something like that?

Link to comment
Share on other sites
mokeev1995
mokeev1995
Posted
Posted

http://www.megafileupload.com/62b7/VoodooPS2Controller.kext.zip



Remember to delete all ps2 kexts form S/L/E: ApplePS2 VoodooPS2.



Can anyone help me fix the sleep for el capitan with chameleon?

Thank you very much



last my attempt shows that all you needed -- run kext utility and drag&drop this kext (i use yosemite, so don't know if it works in el capitan)



-----

HERE IS LINK IN GOOGLE DRIVE:



https://drive.google.com/open?id=0B7C42B_4OyzTRFRNWkx4el9iM3c

Link to comment
Share on other sites
ptcptc
ptcptc
Posted
Posted

Hey,

I found what is the problem with sleep.

When i disable some USB kexts the sleep works.

But i don't know how to fix it, i think it's usb 3.0 the problem because:

When i plug anything in usb 3.0(even if i take it out after) when i try to shut down or reboot, it hangs like it hangs when i try to put it to sleep(black screen, usb power cut off, fans working )

And i don't think it s DSDT related because without DSDT sleep not work.(and on yosemite sleep worked without DSDT)



Thank you in advance for anyone who tries to igure this out

Link to comment
Share on other sites
rezsicc
rezsicc
Posted
Posted

Dell Wireless 1702 can't run Continuity, for example, and has older versions of bluetooth and wi-fi (bt 3.0+hs, 802.11b/g/n). New card supports all new features of OS X 10.10 like Continuity and has new versions (bt4, 802.11 b/g/n/ac).



So, this card (1702) works fine but without new features... and for me without 802.11n (don't know why)...



Dear mokeev1995,



So my notebook is not able to send any content to iPhone (like pics)?

If I install yosemite won't airdrop function work?

https://support.apple.com/en-us/HT203106



If it is true it makes no sense to upgrade from mavericks to yosemite.

Link to comment
Share on other sites
mokeev1995
mokeev1995
Posted
Posted

Dear mokeev1995,



So my notebook is not able to send any content to iPhone (like pics)?

If I install yosemite won't airdrop function work?

https://support.apple.com/en-us/HT203106



If it is true it makes no sense to upgrade from mavericks to yosemite.

yeah, our Wi-Fi+BT card don't support airdrop and continuity. if you want this you should replace it with compatible card like azurewave aw-ce123h. if you'll do this then you'll have Wi-Fi 802.11b/g/n/ac support and Bluetooth 4.0

Link to comment
Share on other sites
