AnVAL (ACPI Loader)

Time2Retire · December 18, 2010

Ok,

Source code is now available to whom complaining about

Updated to 5.0.6 on first post. And sorry for the delay

That'll be me thank you. Keep up the good work valv :dev:

valv · December 18, 2010

That'll be me thank you. Keep up the good work valv

honestly, not only you :dev:

apple also (never did manifest them selves though: that means you are more courageous).

And you know I like you girl!

Scorpy22 · December 18, 2010

Hello valv,

I am using version 5.0.6 and this is my bdmesg:

Config: [hd(0,2)/Extra/com.apple.Boot.plist] 3307 bytes.
CPU: Intel® Core(tm) i3 CPU       M 330  @ 2.13GHz
Flex: 16
CPU: Tjmax ~ 90°C 	          Temperature= ~ 57°C
CPU: Attempting to enable IDA      Failed!
CPU: Vendor/Family/ExtFamily: 0x756e6547/0x6/0x0
CPU: Model/ExtModel/Stepping: 0x25/0x2/0x2
CPU: Multipliers x10:         max=160, min=70
Turbo Ratio:                  16/16/0/0
CPU: MaxDiv/CurrDiv:          0x0/0x0
CPU: TSCFreq:                 2127MHz
CPU: CPUFreq:                 2127MHz
CPU: FSBFreq:                 132MHz
CPU: Enhanced SpeedStep:      1
CPU: NoCores/NoThreads:       8/16
CPU: Features:                0x36d803a1
Chipset is UNKNOWN (pci id 0x448086)
We have an NVIDIA Card
Creating 2 Mode Tables
New table with id : 0
New table with id : 1
First Standard VESA Table at offset 0x3f9c
Second Standard VESA Table at offset 0x8cb2
Table #0 has 16 modes
Table #1 has 27 modes
Aspect Ratio is 4/3
Patching Table #0 :
Mode 1024x768 -> 1024x768 (1047 1183 1343 770 776 805)
Patching Table #1 :
Mode 640x200 -> 640x359 (664 672 720 367 H- V+)
Mode 640x350 -> 640x359 (664 678 720 367 H- V+)
Mode 640x400 -> 640x359 (664 680 720 367 H- V+)
Mode 640x480 -> 640x359 (669 685 720 367 H- V+)
Mode 640x480 -> 640x359 (669 685 720 367 H- V+)
Mode 800x600 -> 800x449 (836 852 900 461 H- V+)
Mode 800x600 -> 800x449 (836 852 900 461 H- V+)
Mode 1024x768 -> 1024x575 (1071 1087 1152 591 H- V+)
Mode 1024x768 -> 1024x575 (1071 1087 1152 591 H- V+)
Mode 1280x1024 -> 1280x719 (1343 1359 1440 742 H- V+)
Mode 1280x1024 -> 1280x719 (1343 1359 1440 742 H- V+)
Mode 1280x800 -> 1280x719 (1330 1346 1440 754 H- V-)
Mode 1600x1200 -> 1600x899 (1674 1690 1800 924 H- V+)
Mode 1360x768 -> 1360x764 (1407 1423 1530 771 H- V-)
Resolution : 1366x768 (Graphics Mode key)
Found mode 1360x768 in VESA Table
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 3307 bytes.
Setting boot-uuid to: D958D5C8-8D9C-3C12-8B77-0AD02394860B
Closing VBios
Table #0 : Freeing backup	[OK]
Table #0 : Freeing		[OK]
Table #1 : Freeing backup	[OK]
Table #1 : Freeing		[OK]
Freeing map			[OK]
Hibernate image is too old by 15509 seconds. Use ForceWake=y to override
Loading Darwin 10.6
Loading kernel mach_kernel
LoadDrivers: /Extra/Extensions.mkext
LoadDrivers: /System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext
ACPI: [hd(0,2)/Extra/DSDT.aml] 41077 bytes.
Using PCI-Root-UID value: 0
Slot: 0 Type 24 2048MB (DDR3 SDRAM) 1066MHz Vendor=Samsung
     PartNo=M471B5673FH0-CF8 SerialNo=97CA2836
Slot: 2 Type 24 2048MB (DDR3 SDRAM) 1066MHz Vendor=Samsung
     PartNo=M471B5673FH0-CF8 SerialNo=97CA279C
Patched DMI Table
Found SMBIOS System Information Table 1
Customizing SystemID with : 0097272a-d21d-b211-8000-94fce4ee992a
efi_inject_get_devprop_string NULL trying stringdata
ACPI: [hd(0,2)/Extra/DSDT.aml] 41077 bytes.
Converted ACPI V1 FADT to ACPI V4 FADT
FADT: changing Preferred_PM_Profile from 0x00 to 0x02
FADT: Restart Fix applied !
Found ACPI CPU: CPU0
Found ACPI CPU: CPU1
Found ACPI CPU: CPU2
Found ACPI CPU: CPU3
Found ACPI CPU: CPU4
Found ACPI CPU: CPU5
Found ACPI CPU: CPU6
Found ACPI CPU: CPU7
C-State: Adding 3 states: C1 C3 C6
[b]Voltage: min= 700mV, max= 700mV[/b]
P-State: Added [Frequency 2112 MHz, FID 0x10]
P-State: Added [Frequency 1980 MHz, FID 0xf]
P-State: Added [Frequency 1848 MHz, FID 0xe]
P-State: Added [Frequency 1716 MHz, FID 0xd]
P-State: Added [Frequency 1584 MHz, FID 0xc]
P-State: Added [Frequency 1452 MHz, FID 0xb]
P-State: Added [Frequency 1320 MHz, FID 0xa]
P-State: Added [Frequency 1188 MHz, FID 0x9]
P-State: Added [Frequency 1056 MHz, FID 0x8]
P-State: Added [Frequency 924 MHz, FID 0x7]
P-State: [Frequency 792 MHz, FID 0x6] is over the limit. Removed!
FADT: Restart Fix applied !
Patched ACPI version 2 DSDT
Starting Darwin x86
Press any key to continue...

Is the bold line significant ?

I used GeneratePStates=yes and GenerateCStates=Yes, I can see fluctuations in MSR Tools, I would to know how I can check if C-States are working.

Also, I find that the bootloader GUI is very slow (problem also exists in chameleon RC5) compared to another computer I use.

Thanks.

MiniHack · December 18, 2010

Something though I don't understand.

This is from BDMESG:

Found ACPI CPU: P000

Found ACPI CPU: P001

Found ACPI CPU: P002

Found ACPI CPU: P003

C-State: Adding 3 states: C1 C3 C6

Voltage: min= 1676mV, max= 908mV

P-State: Added [Frequency 2244 MHz, FID 0x11]

P-State: Added [Frequency 2112 MHz, FID 0x10]

But these are the min and Max volt values in the plist:

<key>minVolt</key>

<key>maxVolt</key>

So, why is the minVolt from BDMESG reported as very much higher than maxVolt?

wojnar0 · December 19, 2010

@valv

I Think I found a bug, my time is going slower, after few hours using laptop time is back of 20 miniuts, when I run Date and Time from Preferences I see like is changing to normal time.

Here is my log:

(I upload images becouse when I paste text everything is in one line)

My com.boot.plist is almoust vanilla:

        	Default Partition  	hd(0,2)

EthernetBuiltIn  	Yes

ForceWake  	Yes

Graphics Mode  	1440x900x32

GraphicsEnabler  	Yes

Hide Partition  	hd(0,3) hd(0,4) hd(1,3) hd(1,5)

Kernel  	mach_kernel

Kernel Flags  	-v

Rescan  	Yes

SMBIOS  	/Extra/smbios.plist

SystemType  	2

Theme  	Mint

Timeout  	2

VBIOS  	No

busratio  	12

valv · December 19, 2010

Is the bold line significant ?

Hi Scorpy22,

There is nothing to worry about. That's because I did not find a working register to gather voltage of I-series yet. We'll come to this later if you'd like to help fixing it

I would to know how I can check if C-States are working.

on terminal type this: ioreg -lw0 | grep CSTInfo. If it returns some value like 19136773, then it is working.

Also, I find that the bootloader GUI is very slow (problem also exists in chameleon RC5) compared to another computer I use.

Once you generated the needed SSDTs with it, you could dump 'em to your /Extra folder, getting rid of auto-generation. Maybe then the boot-time could be lower.

Voltage: min= 1676mV, max= 908mV
But these are the min and Max volt values in the plist:

<key>minVolt</key>

<string>650</string>

<key>maxVolt</key>

<string>920</string>

So, why is the minVolt from BDMESG reported as very much higher than maxVolt?

Wow! That's huge. Would you mind uploading the whole files here (bdmesg & boot.plist).

I Think I found a bug, my time is going slower, after few hours using laptop time is back of 20 miniuts, when I run Date and Time from Preferences I see like is changing to normal time.

Did this happen with AnVAL latest version only. What about other versions of chameleon. Would it be possible for you to test an boot-loader other that anval and see if the behavior disappeared.

I feel like the "bug" is tsc/apic/hpet related. Maybe your DSDT still needs some fixing.

MiniHack · December 19, 2010

Wow! That's huge. Would you mind uploading the whole files here (bdmesg & boot.plist).

Here you go.

Minihack.zip

Scorpy22 · December 19, 2010

Once you generated the needed SSDTs with it, you could dump 'em to your /Extra folder, getting rid of auto-generation. Maybe then the boot-time could be lower.

That's not what I meant by slow, for example when I set Timeout=2, I have to wait something like 8 seconds and there is a half-second delay between each printed line in the bootloader stage.

valv · December 19, 2010

@MiniHack,

I did fix some minor errors on your boot.plist. I also removed the minVolt key to be able to see the default value.

would you mind testing it and dropping me a bdmesg?com.apple.Boot.plist.zip

That's not what I meant by slow, for example when I set Timeout=2, I have to wait something like 8 seconds and there is a half-second delay between each printed line in the bootloader stage.

ah! that sounds better. got it! am going to see what could be done in the next release(s).

wojnar0 · December 19, 2010

@valv

With Chameleon from trunk r668 everythink is normal, no time problem, no sound cracking but now Memory Freq is lower 613 (AnVAL 666) and CPU freq 733 (AnVAL 800) and I lost 400 points in geekbench (from 4000 to 3600).

Here is bdmesg (trunk 668):

Last login: Sun Dec 19 13:57:00 on console



/Extra/Util/bdmesg ; exit;

MacBook-Pro-wojnar:~ wojnar$ /Extra/Util/bdmesg ; exit;

msr(221): ia32_perf_stat 0x06000d28

max: 13 current: 13

CPU: Vendor/Model/ExtModel: 0x756e6547/0x17/0x1

CPU: Family/ExtFamily:      0x6/0x0

CPU: MaxCoef/CurrCoef:      0xd/0xd

CPU: MaxDiv/CurrDiv:        0x0/0x0

CPU: TSCFreq:               2394MHz

CPU: FSBFreq:               184MHz

CPU: CPUFreq:               2394MHz

CPU: NoCores/NoThreads:     2/2

CPU: Features:              0x0000035f

Attempting to read GPT

Read GPT

Reading GPT partition 1, type C12A7328-F81F-11D2-BA4B-00A0C93EC93B

Reading GPT partition 2, type 48465300-0000-11AA-AA11-00306543ECAC

Reading GPT partition 3, type 48465300-0000-11AA-AA11-00306543ECAC

Reading GPT partition 4, type 48465300-0000-11AA-AA11-00306543ECAC

Read HFS+ file: [hd(0,2)/Extra/com.apple.Boot.plist] 919 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/theme.plist] 2806 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/background.png] 2409 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/logo.png] 236 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_generic.png] 7354 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_hfsplus.png] 7844 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_hfsraid.png] 8121 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_ext3.png] 7915 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_fat.png] 7711 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_ntfs.png] 8122 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_cdrom.png] 7696 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_selection.png] 1302 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_scroll_prev.png] 935 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/device_scroll_next.png] 941 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_boot.png] 1051 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_verbose.png] 982 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_ignore_caches.png] 949 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_single_user.png] 990 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_memory_info.png] 965 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_video_info.png] 1143 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_help.png] 1235 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_verbose_disabled.png] 749 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_ignore_caches_disabled.png] 749 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_single_user_disabled.png] 749 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/menu_selection.png] 546 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/progress_bar.png] 450 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/progress_bar_background.png] 169 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/text_scroll_prev.png] 632 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/text_scroll_next.png] 650 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/font_console.png] 6038 bytes.

Read HFS+ file: [hd(0,2)/Extra/Themes/Mint/font_small.png] 5223 bytes.

Read HFS+ file: [hd(0,2)/Extra/com.apple.Boot.plist] 919 bytes.

Setting boot-uuid to: F959FE65-8D2E-348F-B794-62B4A262E3CA

Read HFS+ file: [hd(0,2)/System/Library/CoreServices/SystemVersion.plist] 479 bytes.

Loading Darwin 10.6

Loading kernel mach_kernel

Read HFS+ file: [hd(0,2)/mach_kernel] 4096 bytes.

Read HFS+ file: [hd(0,2)/mach_kernel] 5579907 bytes.

LoadDrivers: Loading from [/Extra/Extensions.mkext]

Read HFS+ file: [hd(0,2)/Extra/Extensions.mkext] 4096 bytes.

Read HFS+ file: [hd(0,2)/Extra/Extensions.mkext] 21590 bytes.

LoadDrivers: Loading from [/system/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext]

Read HFS+ file: [hd(0,2)/System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext] 4096 bytes.

Read HFS+ file: [hd(0,2)/System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext] 19776515 bytes.

Read HFS+ file: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.

Using PCI-Root-UID value: 0

nVidia GeForce 8800M GTS 512MB NV92 [10de:0609] :: PciRoot(0x0)/Pci(0x1,0x0)/Pci(0x0,0x0)

LAN Controller [10ec:8168] :: PciRoot(0x0)/Pci(0x1c,0x2)/Pci(0x0,0x0)

Setting up lan keys

Read HFS+ file: [hd(0,2)/Extra/smbios.plist] 578 bytes.

Intel GM965/GL960 DRAM Controller [8086:2a00] at 00:00.0

Frequency detected: 306 MHz (613) Dual Channel

CAS:5 tRC:5 tRP:5 RAS:15 (5-5-5-15)

Slot: 0 Type 19 1024MB (DDR2 SDRAM) 613MHz Vendor=Samsung

     PartNo=M470T2953EZ3-CE63E SerialNo=74225C19

Slot: 2 Type 19 2048MB (DDR2 SDRAM) 613MHz Vendor=Samsung

     PartNo=M470T5663CZ3-CE63C SerialNo=261D3F87

CPU is Intel® Core(tm)2 Duo CPU     T8300  @ 2.40GHz, family 0x6, model 0x17

Patched DMI Table

Found SMBIOS System Information Table 1

Customizing SystemID with : 108adec0-ab9b-11dc-805a-efb9f38380ca

Read HFS+ file: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.

ACPI table not found: SSDT.aml

FADT: changing PM_Profile from 0x00 to 0x02

FADT: Restart Fix applied!

FADT: Using custom DSDT!

FADT: Restart Fix applied!

FADT: Using custom DSDT!

Starting Darwin x86_64



logout

com.apple.plist is the same as previous.

Have u any idea what is wrong.

I attach my dsdt.

DSDT.dsl.zip

MiniHack · December 19, 2010

Here's the BDMESG out put with your boot plist.

Thanks,

BDMESG.txt.zip

valv · December 19, 2010

@wojnar0, seems to me like applesmcpdrc is somehow interfering with what we try to accomplish. Which mac model do you have. I'd suggest something like mbp4,1.

I'd also like to see the ssdts you are actually using.

let's go step by step: make use of ForceFSB (inside of your boot.plist) and give it a value from 186 to 189 (look which one sounds better).

@MiniHack, sorry I don't know what is going on with minVolt

hope this gonna be addressed asap.

wojnar0 · December 19, 2010

I'm using mbp5,1. With mbp4,1 my performance dramaticly going down.

Here are my ssdt tables:

Archiwum.zip

Now i'm going to test forcefsb.

Thanks

valv · December 19, 2010

Thanks

no it is me that needs to thank u.

btw, those seem to be oem's.

wojnar0 · December 19, 2010

Ok, first shot, forcefsb 186 seemst to be ok.

Here is bdmesg:

Last login: Sun Dec 19 18:24:08 on console

/Extra/Util/bdmesg ; exit;

MacBook-Pro-wojnar:~ wojnar$ /Extra/Util/bdmesg ; exit;

Config: [hd(0,2)/Extra/com.apple.Boot.plist] 962 bytes.

CPU: Mobile Intel® Core(tm)2 Duo CPU     T8300  @ 2.40GHz

Thermal Monitor: TM, TM2, PROCHOT, FERR

Specified FSB: 186Mhz. Assuming you know what you 're doing !

Bus-Ratio defaults: min=6, max=12

Sticking with [FSB: 186Mhz, Bus-Ratio: 12]

CPU: Tjmax ~ 104°C 	          Temperature= ~ 40°C

CPU: Intel Dynamic Acceleration   Enabled!

CPU: Vendor/Family/ExtFamily: 0x756e6547/0x6/0x0

CPU: Model/ExtModel/Stepping: 0x17/0x1/0x6

CPU: Multipliers x10:         max=120, min=60

CPU: MaxDiv/CurrDiv:          0x0/0x0

CPU: TSCFreq:                 2394MHz

CPU: CPUFreq:                 2232MHz

CPU: FSBFreq:                 186MHz

CPU: SLFM:                    1

CPU: Enhanced SpeedStep:      1

CPU: NoCores/NoThreads:       2/2

CPU: Features:                0x26d803a3

Chipset is 965GM (pci id 0x2a008086)

We have an NVIDIA Card

Creating 2 Mode Tables

New table with id : 0

New table with id : 1

First Standard VESA Table at offset 0x7bbb

Second Standard VESA Table at offset 0x4832

Table #0 has 16 modes

Table #1 has 32 modes

Aspect Ratio is 16/10

Patching Table #0 :

Mode 1024x768 -> 1440x900 (1047 1183 1343 770 776 805)

Patching Table #1 :

Mode 640x200 -> 640x400 (664 672 720 408 H- V+)

Mode 640x350 -> 640x400 (664 678 720 408 H- V+)

Mode 640x480 -> 640x400 (669 685 720 408 H- V+)

Mode 640x480 -> 640x400 (669 685 720 408 H- V+)

Mode 800x600 -> 800x500 (836 852 900 512 H- V+)

Mode 800x600 -> 800x500 (836 852 900 512 H- V+)

Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)

Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)

Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)

Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)

Mode 1400x1050 -> 1400x875 (1474 1488 1575 908 H+ V+)

Mode 1600x1200 -> 1600x1000 (1674 1690 1800 1025 H- V+)

Mode 2048x1536 -> 2048x1280 (2144 2160 2048 1314 H+ V+)

Theme: [hd(0,2)].

Resolution : 1440x900 (Graphics Mode key)

Theme: [hd(0,2)].

Found mode 1440x900 in VESA Table

Config: [hd(0,2)/Extra/com.apple.Boot.plist] 962 bytes.

Setting boot-uuid to: F959FE65-8D2E-348F-B794-62B4A262E3CA

Closing VBios

Table #0 : Freeing backup	[OK]

Table #0 : Freeing		[OK]

Table #1 : Freeing backup	[OK]

Table #1 : Freeing		[OK]

Freeing map			[OK]

Loading Darwin 10.6

Loading kernel mach_kernel

LoadDrivers: /Extra/Extensions.mkext

LoadDrivers: /System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext

ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.

Using PCI-Root-UID value: 0

nVidia GeForce 8800M GTS 512MB NV92 [10de:0609] :: PciRoot(0x0)/Pci(0x1,0x0)/Pci(0x0,0x0)

NVCAP: 04000000-00000100-7e000000-0000000a-00000000

@0,display-cfg: ffffffff

@1,display-cfg: ffffffff

LAN Controller [10ec:8168] :: PciRoot(0x0)/Pci(0x1c,0x2)/Pci(0x0,0x0)

Setting up lan keys

SMBios: [hd(0,2)/Extra/smbios.plist] 578 bytes.

Intel GM965/GL960 DRAM Controller [8086:2a00] at 00:00.0

Frequency detected: 310 MHz (620) Dual Channel

CAS:5 tRC:5 tRP:5 RAS:15 (5-5-5-15)

Slot: 0 Type 19 1024MB (DDR2 SDRAM) 620MHz Vendor=Samsung

     PartNo=M470T2953EZ3-CE63E SerialNo=74225C19

Slot: 2 Type 19 2048MB (DDR2 SDRAM) 620MHz Vendor=Samsung

     PartNo=M470T5663CZ3-CE63C SerialNo=261D3F87

Patched DMI Table

Found SMBIOS System Information Table 1

Customizing SystemID with : 108adec0-ab9b-11dc-805a-efb9f38380ca

ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.

FADT: changing Preferred_PM_Profile from 0x00 to 0x02

FADT: Restart Fix applied !

FADT: Restart Fix applied !

Patched ACPI version 2 DSDT

Starting Darwin x86_64



logout



[Proces zakończony]

And here is complete dump from ubuntu:

P_6831FX.zip

valv · December 19, 2010

@wojnar0,

actually what I wanted you to do is try the p/c-states auto-generator. To see if you could get better scores on geekbench

wojnar0 · December 19, 2010

com.apple.plist

Default Partition hd(0,2)
EthernetBuiltIn Yes
ForceFSB 186
ForceWake Yes
Graphics Mode 1440x900x32
GraphicsEnabler Yes
Hide Partition hd(0,3) hd(0,4) hd(1,3) hd(1,5)
Kernel mach_kernel
Kernel Flags -v
Rescan Yes
SMBIOS /Extra/smbios.plist
SystemType 2
Theme Mint
Timeout 2
VBIOS No
busratio 12

GeneratePStates=Yes

GenerateCStates=Yes

Last login: Sun Dec 19 19:17:34 on console
/Extra/Util/bdmesg ; exit;
MacBook-Pro-wojnar:~ wojnar$ /Extra/Util/bdmesg ; exit;
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1062 bytes.
CPU: Mobile Intel® Core™2 Duo CPU     T8300  @ 2.40GHz
Thermal Monitor: TM, TM2, PROCHOT, FERR
Specified FSB: 186Mhz. Assuming you know what you 're doing !
Bus-Ratio defaults: min=6, max=12
Sticking with [FSB: 186Mhz, Bus-Ratio: 12]
CPU: Tjmax ~ 104°C 	          Temperature= ~ 42°C
CPU: Intel Dynamic Acceleration   Enabled!
CPU: Vendor/Family/ExtFamily: 0x756e6547/0x6/0x0
CPU: Model/ExtModel/Stepping: 0x17/0x1/0x6
CPU: Multipliers x10:         max=120, min=60
CPU: MaxDiv/CurrDiv:          0x0/0x0
CPU: TSCFreq:                 2394MHz
CPU: CPUFreq:                 2232MHz
CPU: FSBFreq:                 186MHz
CPU: SLFM:                    1
CPU: Enhanced SpeedStep:      1
CPU: NoCores/NoThreads:       2/2
CPU: Features:                0x26d803a3
Chipset is 965GM (pci id 0x2a008086)
We have an NVIDIA Card
Creating 2 Mode Tables
New table with id : 0
New table with id : 1
First Standard VESA Table at offset 0x7bbb
Second Standard VESA Table at offset 0x4832
Table #0 has 16 modes
Table #1 has 32 modes
Aspect Ratio is 16/10
Patching Table #0 :
Mode 1024x768 -> 1440x900 (1047 1183 1343 770 776 805)
Patching Table #1 :
Mode 640x200 -> 640x400 (664 672 720 408 H- V+)
Mode 640x350 -> 640x400 (664 678 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1400x1050 -> 1400x875 (1474 1488 1575 908 H+ V+)
Mode 1600x1200 -> 1600x1000 (1674 1690 1800 1025 H- V+)
Mode 2048x1536 -> 2048x1280 (2144 2160 2048 1314 H+ V+)
Theme: [hd(0,2)].
Resolution : 1440x900 (Graphics Mode key)
Theme: [hd(0,2)].
Found mode 1440x900 in VESA Table
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1062 bytes.
Setting boot-uuid to: F959FE65-8D2E-348F-B794-62B4A262E3CA
Closing VBios
Table #0 : Freeing backup	[OK]
Table #0 : Freeing		[OK]
Table #1 : Freeing backup	[OK]
Table #1 : Freeing		[OK]
Freeing map			[OK]
Loading Darwin 10.6
Loading kernel mach_kernel
LoadDrivers: /Extra/Extensions.mkext
LoadDrivers: /System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
Using PCI-Root-UID value: 0
nVidia GeForce 8800M GTS 512MB NV92 [10de:0609] :: PciRoot(0x0)/Pci(0x1,0x0)/Pci(0x0,0x0)
NVCAP: 04000000-00000100-7e000000-0000000a-00000000
@0,display-cfg: ffffffff
@1,display-cfg: ffffffff
LAN Controller [10ec:8168] :: PciRoot(0x0)/Pci(0x1c,0x2)/Pci(0x0,0x0)
Setting up lan keys
SMBios: [hd(0,2)/Extra/smbios.plist] 578 bytes.
Intel GM965/GL960 DRAM Controller [8086:2a00] at 00:00.0
Frequency detected: 310 MHz (620) Dual Channel
CAS:5 tRC:5 tRP:5 RAS:15 (5-5-5-15)
Slot: 0 Type 19 1024MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T2953EZ3-CE63E SerialNo=74225C19
Slot: 2 Type 19 2048MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T5663CZ3-CE63C SerialNo=261D3F87
Patched DMI Table
Found SMBIOS System Information Table 1
Customizing SystemID with : 108adec0-ab9b-11dc-805a-efb9f38380ca
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
FADT: changing Preferred_PM_Profile from 0x00 to 0x02
FADT: Restart Fix applied !
Found ACPI CPU: CPU0
Found ACPI CPU: CPU1
C-State: Adding 3 states: C1 C2 C3
Voltage: min= 1000mV, max= 1212mV
P-State: Added [Frequency 2232 MHz, FID 0xc, VID 0x28]
P-State: Added [Frequency 2046 MHz, FID 0xb, VID 0x27]
P-State: Added [Frequency 1860 MHz, FID 0xa, VID 0x25]
P-State: Added [Frequency 1674 MHz, FID 0x9, VID 0x24]
P-State: Added [Frequency 1488 MHz, FID 0x8, VID 0x22]
P-State: Added [Frequency 1302 MHz, FID 0x7, VID 0x21]
P-State: Added [Frequency 1116 MHz, FID 0x6, VID 0x1f]
P-State: Added [Frequency 930 MHz, FID 0x8a, VID 0x1e]
P-State: Added [Frequency 744 MHz, FID 0x88, VID 0x1c]
P-State: Added [Frequency 558 MHz, FID 0x86, VID 0x1b]
FADT: Restart Fix applied !
Patched ACPI version 2 DSDT
Starting Darwin x86_64

logout

GeneratePStates=Yes

GenerateCStates=No

Last login: Sun Dec 19 19:23:00 on console
/Extra/Util/bdmesg ; exit;
MacBook-Pro-wojnar:~ wojnar$ /Extra/Util/bdmesg ; exit;
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1061 bytes.
CPU: Mobile Intel® Core™2 Duo CPU     T8300  @ 2.40GHz
Thermal Monitor: TM, TM2, PROCHOT, FERR
Specified FSB: 186Mhz. Assuming you know what you 're doing !
Bus-Ratio defaults: min=6, max=12
Sticking with [FSB: 186Mhz, Bus-Ratio: 12]
CPU: Tjmax ~ 104°C 	          Temperature= ~ 42°C
CPU: Intel Dynamic Acceleration   Enabled!
CPU: Vendor/Family/ExtFamily: 0x756e6547/0x6/0x0
CPU: Model/ExtModel/Stepping: 0x17/0x1/0x6
CPU: Multipliers x10:         max=120, min=60
CPU: MaxDiv/CurrDiv:          0x0/0x0
CPU: TSCFreq:                 2394MHz
CPU: CPUFreq:                 2232MHz
CPU: FSBFreq:                 186MHz
CPU: SLFM:                    1
CPU: Enhanced SpeedStep:      1
CPU: NoCores/NoThreads:       2/2
CPU: Features:                0x26d803a3
Chipset is 965GM (pci id 0x2a008086)
We have an NVIDIA Card
Creating 2 Mode Tables
New table with id : 0
New table with id : 1
First Standard VESA Table at offset 0x7bbb
Second Standard VESA Table at offset 0x4832
Table #0 has 16 modes
Table #1 has 32 modes
Aspect Ratio is 16/10
Patching Table #0 :
Mode 1024x768 -> 1440x900 (1047 1183 1343 770 776 805)
Patching Table #1 :
Mode 640x200 -> 640x400 (664 672 720 408 H- V+)
Mode 640x350 -> 640x400 (664 678 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1400x1050 -> 1400x875 (1474 1488 1575 908 H+ V+)
Mode 1600x1200 -> 1600x1000 (1674 1690 1800 1025 H- V+)
Mode 2048x1536 -> 2048x1280 (2144 2160 2048 1314 H+ V+)
Theme: [hd(0,2)].
Resolution : 1440x900 (Graphics Mode key)
Theme: [hd(0,2)].
Found mode 1440x900 in VESA Table
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1061 bytes.
Setting boot-uuid to: F959FE65-8D2E-348F-B794-62B4A262E3CA
Closing VBios
Table #0 : Freeing backup	[OK]
Table #0 : Freeing		[OK]
Table #1 : Freeing backup	[OK]
Table #1 : Freeing		[OK]
Freeing map			[OK]
Loading Darwin 10.6
Loading kernel mach_kernel
LoadDrivers: /Extra/Extensions.mkext
LoadDrivers: /System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
Using PCI-Root-UID value: 0
nVidia GeForce 8800M GTS 512MB NV92 [10de:0609] :: PciRoot(0x0)/Pci(0x1,0x0)/Pci(0x0,0x0)
NVCAP: 04000000-00000100-7e000000-0000000a-00000000
@0,display-cfg: ffffffff
@1,display-cfg: ffffffff
LAN Controller [10ec:8168] :: PciRoot(0x0)/Pci(0x1c,0x2)/Pci(0x0,0x0)
Setting up lan keys
SMBios: [hd(0,2)/Extra/smbios.plist] 578 bytes.
Intel GM965/GL960 DRAM Controller [8086:2a00] at 00:00.0
Frequency detected: 310 MHz (620) Dual Channel
CAS:5 tRC:5 tRP:5 RAS:15 (5-5-5-15)
Slot: 0 Type 19 1024MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T2953EZ3-CE63E SerialNo=74225C19
Slot: 2 Type 19 2048MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T5663CZ3-CE63C SerialNo=261D3F87
Patched DMI Table
Found SMBIOS System Information Table 1
Customizing SystemID with : 108adec0-ab9b-11dc-805a-efb9f38380ca
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
FADT: changing Preferred_PM_Profile from 0x00 to 0x02
FADT: Restart Fix applied !
Found ACPI CPU: CPU0
Found ACPI CPU: CPU1
Voltage: min= 1000mV, max= 1212mV
P-State: Added [Frequency 2232 MHz, FID 0xc, VID 0x28]
P-State: Added [Frequency 2046 MHz, FID 0xb, VID 0x27]
P-State: Added [Frequency 1860 MHz, FID 0xa, VID 0x25]
P-State: Added [Frequency 1674 MHz, FID 0x9, VID 0x24]
P-State: Added [Frequency 1488 MHz, FID 0x8, VID 0x22]
P-State: Added [Frequency 1302 MHz, FID 0x7, VID 0x21]
P-State: Added [Frequency 1116 MHz, FID 0x6, VID 0x1f]
P-State: Added [Frequency 930 MHz, FID 0x8a, VID 0x1e]
P-State: Added [Frequency 744 MHz, FID 0x88, VID 0x1c]
P-State: Added [Frequency 558 MHz, FID 0x86, VID 0x1b]
FADT: Restart Fix applied !
Patched ACPI version 2 DSDT
Starting Darwin x86_64


logout

GeneratePStates=No

GenerateCStates=Yes

Last login: Sun Dec 19 19:33:13 on console
/Extra/Util/bdmesg ; exit;
MacBook-Pro-wojnar:~ wojnar$ /Extra/Util/bdmesg ; exit;
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1061 bytes.
CPU: Mobile Intel® Core™2 Duo CPU     T8300  @ 2.40GHz
Thermal Monitor: TM, TM2, PROCHOT, FERR
Specified FSB: 186Mhz. Assuming you know what you 're doing !
Bus-Ratio defaults: min=6, max=12
Sticking with [FSB: 186Mhz, Bus-Ratio: 12]
CPU: Tjmax ~ 104°C 	          Temperature= ~ 41°C
CPU: Intel Dynamic Acceleration   Enabled!
CPU: Vendor/Family/ExtFamily: 0x756e6547/0x6/0x0
CPU: Model/ExtModel/Stepping: 0x17/0x1/0x6
CPU: Multipliers x10:         max=120, min=60
CPU: MaxDiv/CurrDiv:          0x0/0x0
CPU: TSCFreq:                 2394MHz
CPU: CPUFreq:                 2232MHz
CPU: FSBFreq:                 186MHz
CPU: SLFM:                    1
CPU: Enhanced SpeedStep:      1
CPU: NoCores/NoThreads:       2/2
CPU: Features:                0x26d803a3
Chipset is 965GM (pci id 0x2a008086)
We have an NVIDIA Card
Creating 2 Mode Tables
New table with id : 0
New table with id : 1
First Standard VESA Table at offset 0x7bbb
Second Standard VESA Table at offset 0x4832
Table #0 has 16 modes
Table #1 has 32 modes
Aspect Ratio is 16/10
Patching Table #0 :
Mode 1024x768 -> 1440x900 (1047 1183 1343 770 776 805)
Patching Table #1 :
Mode 640x200 -> 640x400 (664 672 720 408 H- V+)
Mode 640x350 -> 640x400 (664 678 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1400x1050 -> 1400x875 (1474 1488 1575 908 H+ V+)
Mode 1600x1200 -> 1600x1000 (1674 1690 1800 1025 H- V+)
Mode 2048x1536 -> 2048x1280 (2144 2160 2048 1314 H+ V+)
Theme: [hd(0,2)].
Resolution : 1440x900 (Graphics Mode key)
Theme: [hd(0,2)].
Found mode 1440x900 in VESA Table
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1061 bytes.
Setting boot-uuid to: F959FE65-8D2E-348F-B794-62B4A262E3CA
Closing VBios
Table #0 : Freeing backup	[OK]
Table #0 : Freeing		[OK]
Table #1 : Freeing backup	[OK]
Table #1 : Freeing		[OK]
Freeing map			[OK]
Loading Darwin 10.6
Loading kernel mach_kernel
LoadDrivers: /Extra/Extensions.mkext
LoadDrivers: /System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
Using PCI-Root-UID value: 0
nVidia GeForce 8800M GTS 512MB NV92 [10de:0609] :: PciRoot(0x0)/Pci(0x1,0x0)/Pci(0x0,0x0)
NVCAP: 04000000-00000100-7e000000-0000000a-00000000
@0,display-cfg: ffffffff
@1,display-cfg: ffffffff
LAN Controller [10ec:8168] :: PciRoot(0x0)/Pci(0x1c,0x2)/Pci(0x0,0x0)
Setting up lan keys
SMBios: [hd(0,2)/Extra/smbios.plist] 578 bytes.
Intel GM965/GL960 DRAM Controller [8086:2a00] at 00:00.0
Frequency detected: 310 MHz (620) Dual Channel
CAS:5 tRC:5 tRP:5 RAS:15 (5-5-5-15)
Slot: 0 Type 19 1024MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T2953EZ3-CE63E SerialNo=74225C19
Slot: 2 Type 19 2048MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T5663CZ3-CE63C SerialNo=261D3F87
Patched DMI Table
Found SMBIOS System Information Table 1
Customizing SystemID with : 108adec0-ab9b-11dc-805a-efb9f38380ca
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
FADT: changing Preferred_PM_Profile from 0x00 to 0x02
FADT: Restart Fix applied !
Found ACPI CPU: CPU0
Found ACPI CPU: CPU1
C-State: Adding 3 states: C1 C2 C3
FADT: Restart Fix applied !
Patched ACPI version 2 DSDT
Starting Darwin x86_64

logout

GeneratePStates=No

GenerateCStates=No

Last login: Sun Dec 19 19:28:06 on console
/Extra/Util/bdmesg ; exit;
MacBook-Pro-wojnar:~ wojnar$ /Extra/Util/bdmesg ; exit;
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1060 bytes.
CPU: Mobile Intel® Core™2 Duo CPU     T8300  @ 2.40GHz
Thermal Monitor: TM, TM2, PROCHOT, FERR
Specified FSB: 186Mhz. Assuming you know what you 're doing !
Bus-Ratio defaults: min=6, max=12
Sticking with [FSB: 186Mhz, Bus-Ratio: 12]
CPU: Tjmax ~ 104°C 	          Temperature= ~ 43°C
CPU: Intel Dynamic Acceleration   Enabled!
CPU: Vendor/Family/ExtFamily: 0x756e6547/0x6/0x0
CPU: Model/ExtModel/Stepping: 0x17/0x1/0x6
CPU: Multipliers x10:         max=120, min=60
CPU: MaxDiv/CurrDiv:          0x0/0x0
CPU: TSCFreq:                 2394MHz
CPU: CPUFreq:                 2232MHz
CPU: FSBFreq:                 186MHz
CPU: SLFM:                    1
CPU: Enhanced SpeedStep:      1
CPU: NoCores/NoThreads:       2/2
CPU: Features:                0x26d803a3
Chipset is 965GM (pci id 0x2a008086)
We have an NVIDIA Card
Creating 2 Mode Tables
New table with id : 0
New table with id : 1
First Standard VESA Table at offset 0x7bbb
Second Standard VESA Table at offset 0x4832
Table #0 has 16 modes
Table #1 has 32 modes
Aspect Ratio is 16/10
Patching Table #0 :
Mode 1024x768 -> 1440x900 (1047 1183 1343 770 776 805)
Patching Table #1 :
Mode 640x200 -> 640x400 (664 672 720 408 H- V+)
Mode 640x350 -> 640x400 (664 678 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 640x480 -> 640x400 (669 685 720 408 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 800x600 -> 800x500 (836 852 900 512 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1024x768 -> 1024x640 (1071 1087 1152 656 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1280x1024 -> 1280x800 (1343 1359 1440 823 H- V+)
Mode 1400x1050 -> 1400x875 (1474 1488 1575 908 H+ V+)
Mode 1600x1200 -> 1600x1000 (1674 1690 1800 1025 H- V+)
Mode 2048x1536 -> 2048x1280 (2144 2160 2048 1314 H+ V+)
Theme: [hd(0,2)].
Resolution : 1440x900 (Graphics Mode key)
Theme: [hd(0,2)].
Found mode 1440x900 in VESA Table
Config: [hd(0,2)/Extra/com.apple.Boot.plist] 1060 bytes.
Setting boot-uuid to: F959FE65-8D2E-348F-B794-62B4A262E3CA
Closing VBios
Table #0 : Freeing backup	[OK]
Table #0 : Freeing		[OK]
Table #1 : Freeing backup	[OK]
Table #1 : Freeing		[OK]
Freeing map			[OK]
Loading Darwin 10.6
Loading kernel mach_kernel
LoadDrivers: /Extra/Extensions.mkext
LoadDrivers: /System/Library/Caches/com.apple.kext.caches/Startup/Extensions.mkext
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
Using PCI-Root-UID value: 0
nVidia GeForce 8800M GTS 512MB NV92 [10de:0609] :: PciRoot(0x0)/Pci(0x1,0x0)/Pci(0x0,0x0)
NVCAP: 04000000-00000100-7e000000-0000000a-00000000
@0,display-cfg: ffffffff
@1,display-cfg: ffffffff
LAN Controller [10ec:8168] :: PciRoot(0x0)/Pci(0x1c,0x2)/Pci(0x0,0x0)
Setting up lan keys
SMBios: [hd(0,2)/Extra/smbios.plist] 578 bytes.
Intel GM965/GL960 DRAM Controller [8086:2a00] at 00:00.0
Frequency detected: 310 MHz (620) Dual Channel
CAS:5 tRC:5 tRP:5 RAS:15 (5-5-5-15)
Slot: 0 Type 19 1024MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T2953EZ3-CE63E SerialNo=74225C19
Slot: 2 Type 19 2048MB (DDR2 SDRAM) 620MHz Vendor=Samsung
     PartNo=M470T5663CZ3-CE63C SerialNo=261D3F87
Patched DMI Table
Found SMBIOS System Information Table 1
Customizing SystemID with : 108adec0-ab9b-11dc-805a-efb9f38380ca
ACPI: [hd(0,2)/Extra/DSDT.aml] 28205 bytes.
FADT: changing Preferred_PM_Profile from 0x00 to 0x02
FADT: Restart Fix applied !
FADT: Restart Fix applied !
Patched ACPI version 2 DSDT
Starting Darwin x86_64

logout

Strange heh

//edit:

One of problematic thinks was cracky preview on movies, now I use ForceFSB=199, and that bug gone .

Sound is still problem. Not always, only when something new starting play (for example when I listen music and I run movie), this only for one second, after that everything is normal.

Geekbench show me 4016 points

Now I must spend some time and I will see is time ok.

Cheers

//edit 2:

2394 / 12 = 199,5

Can I use that value for ForceFSB?

//edit:

I have still time bug :whistle:

Any ideas?

valv · December 19, 2010

I have still time bug :mellow:

Dont worry, we gonna get it (hopefully)

look at those values in red

Now try to add the correct values for an mbp5,1 under smbio.plist (those keys need to be added there).

Also, I'd suggest you stick with a value under 190 for ForceFSB. You can also try to edit the multiplier's value.

- I can't set Graphics Mode to 1920x1080x32. I get a black screen during the boot and it is not responding. I am using a custom theme with this resolution. 1280x1024x32 works fine.

Got your post on the other topic. So am answering you here: This my friend is not chameleon's fault. It is simply because 1920x1080 isn't allowed by vesa.

Even-though, as soon as we get into desktop that mode is supported. As it then becomes handled by the driver.

JBraddock · December 19, 2010

Got your post on the other topic. So am answering you here: This my friend is not chameleon's fault. It is simply because 1920x1080 isn't allowed by vesa.
Even-though, as soon as we get into desktop that mode is supported. As it then becomes handled by the driver.

I see.

Also I was able to use a theme designed for 1920x1080 prior to RC5, which I can use right now to some extend as timeout screen and the actual Chameleon menu where the HDD icons show up seem to be overlapped.

Is this also related to the mode you mentioned?

Then I assume that you'd done some fundamental changes to graphics mode which I couldn't follow.

Edit: I added the following to get the correct Motherboard version.

<key>SMboardversion</key>
<string>Mac-F2268AC8</string>

But after running the Geekbench, I have "Apple Inc. Mac-F42D89C8 Mac-F2268AC8" appear in the Motherboard section.

Mac-F42D89C8 is for MacbookPro5,1 and MacbookPro4,1.

So it seems that the value I added can't override the one that Chameleon tries to assign but append to it.

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
<key>SMbiosdate</key>
<string>06/15/2009</string>
<key>SMbiosvendor</key>
<string>Apple Computer, Inc.</string>
<key>SMbiosversion</key>
<string>MBP55.88Z.00AC.B00.0905060849</string>
<key>SMboardmanufacturer</key>
<string>Apple Computer, Inc.</string>
<key>SMboardversion</key>
<string>Mac-F2268AC8</string>
<key>SMexternalclock</key>
<string>266</string>
<key>SMfamily</key>
<string>MacBook Pro</string>
<key>SMmanufacturer</key>
<string>Apple Inc.</string>
<key>SMmaximalclock</key>
<string>2261</string>
<key>SMmemmanufacter</key>
<string>Apple Computer Inc.</string>
<key>SMmemspeed</key>
<string>800</string>
<key>SMmemtype</key>
<string>19</string>
<key>SMproductname</key>
<string>MacBookPro5,5</string>
<key>SMsystemversion</key>
<string>1.0</string>
</dict>
</plist>

Hardware Overview:

 Model Name:	MacBook Pro
 Model Identifier:	MacBookPro5,5
 Processor Name:	Intel Core 2 Duo
 Processor Speed:	2.26 GHz
 Number Of Processors:	1
 Total Number Of Cores:	2
 L2 Cache:	3 MB
 Memory:	4 GB
 Bus Speed:	1.07 GHz
 Boot ROM Version:	MBP55.00AC.B00
 SMC Version (system):	0.147f2
 Serial Number (system):	SOMESRLNMBR
 Hardware UUID:	// deleted

valv · December 20, 2010

But after running the Geekbench, I have "Apple Inc. Mac-F42D89C8 Mac-F2268AC8" appear in the Motherboard section.
Mac-F42D89C8 is for MacbookPro5,1 and MacbookPro4,1.

So it seems that the value I added can't override the one that Chameleon tries to assign but append to it.

you would need this instead (literally the same as in real mbp5,5)

	<key>SMboardversion</key>
<string>Not Specified</string>

The one you are trying to override should be the SMboardproduct (in the green rectangle on the image).

Add it to the smbios.plist file with the right value (you 've been trying to add).

wojnar0 · December 20, 2010

I have the same problem, two motherboards

Here is my smbios.plist:

SMbiosdate 04/01/2008
SMbiosversion MBP51.88Z.00C1.B03.0802271651
SMfamily MacBook Pro
SMmanufacter Apple Inc.
SMproductname MacBookPro5,1
SMboardversion Mac-F42D89C8
SMserial W88033AKY51
SMsystemversion 1.2

valv · December 20, 2010

the same problem, two motherboards

the same instructions. You should add SMboardproduct to smbios.plist. As of an original mbp5,1, this has "Proto" as value.

btw, That is not showing two motherboards, as the first is for the board version and second one is for the board product.

To make it clear for everybody, here is the new SMBios injection's terms:

[list]
[*]SMbiosvendor
[*]SMbiosversion
[*]SMbiosdate
[*]SMmanufacter
[*]SMproductname
[*]SMsystemversion
[*]SMserial
[*]SMUUID
[*]SMfamily
[*]SMboardmanufacter
[*]SMboardproduct
[*]SMboardversion
[*]SMboardserial
[*]SMchassismanufacter
[*]SMchassisversion
[*]SMchassisserial
[*]SMProcessorfamily
[*]SMexternalclock
[*]SMmaximalclock
[*]SMmemdevloc
[*]SMmembankloc
[*]SMmemtype
[*]SMmemspeed
[*]SMmemmanufacter
[*]SMmemserial
[*]SMmempart
[*]SMoemcpu
[*]SMcputype
[*]SMbusspeed
[/list]

mitch_de · December 20, 2010

Very interesting about that !

I thougth that only the MacModell (MacPro3,1 ....) does have effect on cpu powermanagement (clockings) and the other parameters in smbios are only cosmetik / for getting hackintosh seen as Mac and not hackintosh in geekbench.

valv · December 20, 2010

Updated to 5.0.7 with minor changes to SMBios default values, some png files for open/freebsd (thanks to my dear friend Blackosx) and added nvidia 0x10DE10C3 (GeForce 8400 GS).

Carstiman · December 20, 2010

hello tried 5.0.7 on my maschine. still got:

CPU: Attempting to enable IDA Failed!

did i something wrong ?

i also get bad geekbench results if i use any mac model with boot Rom Version.

but get it with the other bootloaders too. it is the same as if i use SMBIOSdefaults=Yes

5.0.7.txt

com.apple.Boot.plist.zip

dsdt.aml.zip

AnVAL (ACPI Loader)

Recommended Posts

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites
