[GUIDE]+[STUDIO] ZOTAC GEForce 9300 WIFI DDR2 and DDR3 Snow --> ML TEST 1082 sleep #795

[tinush]

I wouldn't risk getting version with 65W. Q8300 has max TPD at 95W. Most likely it wont' be enough with higher CPU load. I get with one HDD, 4GB of Ram and Pentum Dual Core E6300 (max TDP is 45W for that one) max usage of about 80W for whole system when cpu it's at 100% both cores.



+1

i have a 80w psu (Noah case) and it can barely have a full size dvd player (sometime's the system shut's down)

e6750 65w, 2gb (2x1gb) Corsair pc6400, Wd scorpio 7200rpm



T.



btw the dvd was only for testing, no issues with a slimline

[Mdegon]

I want to add a graphics card to my build but not sure how too...would love some advise....thinking the 200 series from Nvidia but not picky just want to get a little more performance from my machine. Thanks!



marv

[Hugo_bee]

for mrdale.. you have to read somewhere about p-state and c-state methods. this is a must if you want to inject in dsdt informations specific for your processor. So: the best effort is to take infos with another o.s. .. extract tables.. clean data and put into dsdt. If you don't want to do that.. the alternative is to remove actual dsdt p-state anc c-state data of other processor from your dsdt (if it has those data or not .. I don't know!) and use voodooPstate

[toshibo]

zotac h55-itx wifi + i5 661 + geforce g210

http://www.tonymacx86.com/

on boot i use busratio=25 add on com.apple.Boot.plist

but for now only 32bits

can some one helpe me for work in 64bit?

[mrdale]

mrdale.. you have to read somewhere about p-state and c-state methods. this is a must if you want to inject in dsdt informations specific for your processor. So: the best effort is to take infos with another o.s. .. extract tables.. clean data and put into dsdt. If you don't want to do that.. the alternative is to remove actual dsdt p-state anc c-state data of other processor from your dsdt (if it has those data or not .. I don't know!) and use voodooPstate



Thanks, Ugokind. Actually I don't think I want to do any of that p-state/c-state editing. I just want a dsdt.aml file that works with my processor (q8300) and does not contain items edited for other specific processors (as I believe dreamwatchers's is). I want all the fixes minus the processor specific stuff. So any advice on which dsdt to use would be greatly appreciated.



my 9300-g-e is coming today!

[Hugo_bee]

If I'm not wrong.. Gaansan a couple of posts above has posted the dsdt you can use for yourself!

and remember to go in Google and search site:insanelymac.com Voodoopstate )



that's all.. nothing so easy as it!!

[mikeetastic]

heres my lspci of my Zotac G43 ITX-A-E.



note that the wireless mini pci-e is Atheros AR9285.. anyone know how to make the wifi work?



my issues on this board is



- i cant shut down - it just turn itself back on

- no sleep - actually there is but when it wakes up its black screen.



anyone? Thanks.





00:00.0 Host bridge [0600]: Intel Corporation 4 Series Chipset DRAM Controller [8086:2e20] (rev 03)

00:01.0 PCI bridge [0604]: Intel Corporation 4 Series Chipset PCI Express Root Port [8086:2e21] (rev 03)

00:1a.0 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #4 [8086:3a37]

00:1a.1 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #5 [8086:3a38]

00:1a.2 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #6 [8086:3a39]

00:1a.7 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB2 EHCI Controller #2 [8086:3a3c]

00:1b.0 Audio device [0403]: Intel Corporation 82801JI (ICH10 Family) HD Audio Controller [8086:3a3e]

00:1c.0 PCI bridge [0604]: Intel Corporation 82801JI (ICH10 Family) PCI Express Port 1 [8086:3a40]

00:1c.1 PCI bridge [0604]: Intel Corporation 82801JI (ICH10 Family) PCI Express Port 2 [8086:3a42]

00:1d.0 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #1 [8086:3a34]

00:1d.1 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #2 [8086:3a35]

00:1d.2 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #3 [8086:3a36]

00:1d.7 USB Controller [0c03]: Intel Corporation 82801JI (ICH10 Family) USB2 EHCI Controller #1 [8086:3a3a]

00:1e.0 PCI bridge [0604]: Intel Corporation 82801 PCI Bridge [8086:244e] (rev 90)

00:1f.0 ISA bridge [0601]: Intel Corporation 82801JIB (ICH10) LPC Interface Controller [8086:3a18]

00:1f.2 SATA controller [0106]: Intel Corporation 82801JI (ICH10 Family) SATA AHCI Controller [8086:3a22]

00:1f.3 SMBus [0c05]: Intel Corporation 82801JI (ICH10 Family) SMBus Controller [8086:3a30]

01:00.0 VGA compatible controller [0300]: nVidia Corporation G92 [GeForce GTS 250] [10de:0615] (rev a2)

02:00.0 Network controller [0280]: Atheros Communications Inc. AR9285 Wireless Network Adapter (PCI-Express) [168c:002b] (rev 01)

03:00.0 Ethernet controller [0200]: Realtek Semiconductor Co., Ltd. RTL8111/8168B PCI Express Gigabit Ethernet controller [10ec:8168] (rev 03)



EDIT:



wifi is working now (i can turn it on/off) but cant detect any network? anyone?



Software Versions:

Menu Extra: 6.2.1 (621.1)

configd plug-in: 6.2 (620.15.1)

System Profiler: 6.0 (600.9)

Network Preference: 6.2.1 (621.1)

AirPort Utility: 5.5.1 (551.19)

IO80211 Family: 3.1 (310.6)

Interfaces:

en1:

Card Type: AirPort Extreme (0x168C, 0x1089)

Firmware Version: Atheros 9285: 2.1.9.8

Locale: Unknown

Country Code:

Supported PHY Modes: 802.11 b/g/n

Supported Channels: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14

Wake On Wireless: Supported

Status: Not Associated

[toshibo]

on my zotac h55-itx wifi

i download [url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url] from http://www.tonymacx86.com/viewtopic.php?f=...5fe518f4b4a1b0a

all work only graphics card not work

only 32bits





heres my lspci of my Zotac G43 ITX-A-E.



note that the wireless mini pci-e is Atheros AR9285.. anyone know how to make the wifi work?



my issues on this board is



- i cant shut down - it just turn itself back on

- no sleep - actually there is but when it wakes up its black screen.



anyone? Thanks.









EDIT:



wifi is working now (i can turn it on/off) but cant detect any network? anyone?

[mikeetastic]

do we have the same Atheros 9285 Wi-Fi?



on my zotac h55-itx wifi

i download [url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url] from http://www.tonymacx86.com/viewtopic.php?f=...5fe518f4b4a1b0a

all work only graphics card not work

only 32bits

[toshibo]

i not home now but tomorrow i go home, but i think is same Atheros 9285

sorriy for my bad inglish

do we have the same Atheros 9285 Wi-Fi?

[concord]

Nice to see this thread is still going strong! So I have been a happy 10.5 user since Aug/09, but about a month ago I decided to install a nVidia GT240 video card. Thats where all the trouble started! 10.5 just would not boot up anymore. So I bought another hard drive and the 10.6 update dvd. Might as well start fresh and go to 10.6



#1 - Thank you ugokind for keeping the first post up-to-date! Helped a lot! Step #6 was very easy!

#2 - Thank you dreamwatcher for your dsdt! 10.6 works great. (I don't use sleep mode, so to me it is perfect)

#3 - Thank you minihack, your post #200 (make your own custom dsdt is amazing!)

#4 - Thank you tinnush for the AppleHDA.kext info



So I now have Snow Leopard running great!!!! With ONE small annoying problem!!! Really annoying!!!



Does anyone else here 'dual boot' to ubuntu with chameleon? I do! I use OSX and Linux all day...



Here is the problem: If I'm in OSX, everything works 100%. If I want to reboot into Ubuntu 10.04 (or 9.10) I NEVER get the network card to work in Linux! I have to shutdown the computer and also TURN POWER OFF for about 10 seconds, then I can boot Linux and the network card will work. If I go from Linux -> OSX network card will work, OSX -> Linux network card will not work! This is really annoying. Does anyone else have this problem?



Here are my details:



Chameleon 2 RC4

OSX 10.6.3

Ubuntu 10.04 (32bit)

Zotac GeForce 9300 ITX wifi VER 00, with pa105 firmware

Asus Silent GeForce GT 240 video card

dreamwatcher DSDT/boot.plist(with GT 240 NVCAP injection)/smbios.plist

E/E - fakesmc.kext, IOAHCIBlockStorageInjector.kext, LegacyHDA.kext, OpenHaltRestart.kext, PlatformUUID.kext

S/L/E - tinnush - AppleHDA.kext



Here is what I have tried so far:



Build my own custom DSDT using post #200 method - same problem.

Build a DSDT for Ubuntu 10.04 and recompile Linux Kernel (Maybe will reset NIC on bootup?) - same problem.

Try LiveCD 9.10/9.04/8.10 - same problem

Try nForceLAN.kext - same problem



For what ever reason, when I restart OSX or shutdown OSX it looks like it kills the onboard NIC and Linux can't use it. It 'sees' it, but says 'network cable unplugged'



Does anyone have any suggestions? I'm one problem away from perfection!



Thanks...

[bibendum]

I had the same problem with my UD3P system - replaced my 9800 with a GTX275 - booted into Snow Kitty just fine - because thats where the drivers were added to OSX - but couldn't bring up Leopard. There are, however drivers that were backfilled into Leopard. You can find them here or online from Aquamac or Netkas. I think I'm using Aquamac's.



Just google GTX LEOPARD DRIVERS



That doesn't help your network problem, but will let you boot back into Leopard.



Patrick

[Mdegon]

How did you get your graphics card to work I am new and have everything working but want a little more power out of my box. I have a Geforce 7600gt from long ago and wanted to test it out so I downloaded that osx86tools app but no luck......really just learning as I go to treat me like a big clumsy puppy!





Thanks!



Nice to see this thread is still going strong! So I have been a happy 10.5 user since Aug/09, but about a month ago I decided to install a nVidia GT240 video card. Thats where all the trouble started! 10.5 just would not boot up anymore. So I bought another hard drive and the 10.6 update dvd. Might as well start fresh and go to 10.6



#1 - Thank you ugokind for keeping the first post up-to-date! Helped a lot! Step #6 was very easy!

#2 - Thank you dreamwatcher for your dsdt! 10.6 works great. (I don't use sleep mode, so to me it is perfect)

#3 - Thank you minihack, your post #200 (make your own custom dsdt is amazing!)

#4 - Thank you tinnush for the AppleHDA.kext info



So I now have Snow Leopard running great!!!! With ONE small annoying problem!!! Really annoying!!!



Does anyone else here 'dual boot' to ubuntu with chameleon? I do! I use OSX and Linux all day...



Here is the problem: If I'm in OSX, everything works 100%. If I want to reboot into Ubuntu 10.04 (or 9.10) I NEVER get the network card to work in Linux! I have to shutdown the computer and also TURN POWER OFF for about 10 seconds, then I can boot Linux and the network card will work. If I go from Linux -> OSX network card will work, OSX -> Linux network card will not work! This is really annoying. Does anyone else have this problem?



Here are my details:



Chameleon 2 RC4

OSX 10.6.3

Ubuntu 10.04 (32bit)

Zotac GeForce 9300 ITX wifi VER 00, with pa105 firmware

Asus Silent GeForce GT 240 video card

dreamwatcher DSDT/boot.plist(with GT 240 NVCAP injection)/smbios.plist

E/E - fakesmc.kext, IOAHCIBlockStorageInjector.kext, LegacyHDA.kext, OpenHaltRestart.kext, PlatformUUID.kext

S/L/E - tinnush - AppleHDA.kext



Here is what I have tried so far:



Build my own custom DSDT using post #200 method - same problem.

Build a DSDT for Ubuntu 10.04 and recompile Linux Kernel (Maybe will reset NIC on bootup?) - same problem.

Try LiveCD 9.10/9.04/8.10 - same problem

Try nForceLAN.kext - same problem



For what ever reason, when I restart OSX or shutdown OSX it looks like it kills the onboard NIC and Linux can't use it. It 'sees' it, but says 'network cable unplugged'



Does anyone have any suggestions? I'm one problem away from perfection!



Thanks...

[mikeetastic]

i not home now but tomorrow i go home, but i think is same Atheros 9285

sorriy for my bad inglish



please do get back to us as soon as you can check it.. lspci will do.



im interested too on how did you make your H55 WIFI work? maybe i might change board and return this Zotac G43.

[toshibo]

this pic is my harware info



http://tonymacx86.blogspot.com/2010/04/ibo...ac-os-x-on.html

*on [url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url]

1-[url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url]:

-[url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url] For Suported CPU



2-Disc Utilies

-All if you want



3-Advanced Options

1-3Audio

-HDAEnable=ALC888

-VoodooHDA256



2-3-Disk

-All



3-3-Graphics

-NVEnabler

-ATY_Init



4-3Network

-All



4-Non-DSDT Systems

-All



5-Chameleon

-Chameleon 2.0 RC4 by AsereBLN



6-Patched Kernel

-10.3.0



7-com.apple.boot.plist

-64-bit Apple Boot Screen



8-smbios.plist

-iMac11,1( core i5 or i7)



9-Themes

-i use tonymacx86 Themes



10-OSx86 Sftware

-all if u want



this is my com.apple.boot.plist



<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">

<plist version="1.0">

<dict>

<key>Graphics Mode</key>

<string>1680x1050x32</string>

<key>Kernel</key>

<string>mach_kernel</string>

<key>Kernel Flags</key>

<string>GraphicsEnabler=Yes busratio=25</string>

<key>Legacy Logo</key>

<string>Yes</string>

<key>Timeout</key>

<string>1</string>

</dict>

</plist>



i don`t know wy my cpu show 32bits and i can`t install 64bits software





but is not perfect, graphics card not wor all, and i can't instal 64bits softwares!!

but i trying more

i hope work all!



good lock!!!



please do get back to us as soon as you can check it.. lspci will do.



im interested too on how did you make your H55 WIFI work? maybe i might change board and return this Zotac G43.

[concord]

How did you get your graphics card to work I am new and have everything working but want a little more power out of my box. I have a Geforce 7600gt from long ago and wanted to test it out so I downloaded that osx86tools app but no luck......really just learning as I go to treat me like a big clumsy puppy!





Thanks!



all I did was add the NVCAP string into the com.apple.Boot.plist file like this: (its the device-properties key and string) made with osx86tools...



<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
<key>GraphicsEnabler</key>
<string>No</string>
<key>Kernel</key>
<string>mach_kernel</string>
<key>Kernel Flags</key>
<string>arch=i386</string>
<key>Theme</key>
<string>default1</string>
<key>device-properties</key>
<string>d10300000100000001000000c50300001500000002010c00d041030a0100000001010600000c
0101060000007fff04003a000000400032002c0068007700730065006e0073006f0072002d0070006
100720061006d0073002d00760065007200730069006f006e00000008000000000000022200000040
0032002c006400650076006900630065005f0074007900700065000000120000004e5644412c67707
52d64696f64650e0000004e00560050004d0000002000000001000000000000000000000000000000
0000000000000000000000001e00000072006f006d002d007200650076006900730069006f006e000
000090000003331373261100000004e00560043004100500000001800000004000000000003000c00
0000000000070000000022000000400032002c002300730069007a0065002d00630065006c006c007
3000000080000000000000022000000400030002c006400650076006900630065005f007400790070
00650000000b000000646973706c6179100000006d006f00640065006c0000001e0000004e5649444
941204765466f72636520393830302047542045464914000000400030002c006e0061006d00650000
00120000004e5644412c446973706c61792d4120000000400032002c0063006f006d0070006100740
0690062006c0065000000160000004e5644412c73656e736f722d706172656e741400000040003100
2c006e0061006d0065000000120000004e5644412c446973706c61792d4212000000400032002c007
20065006700000008000000000000021c0000006400650076006900630065005f0074007900700065
000000100000004e5644412c4765466f72636520000000400031002c0063006f006d0070006100740
0690062006c00650000000e0000004e5644412c4e564d616326000000400032002c00230061006400
72006500730073002d00630065006c006c007300000008000000000000010e0000006e0061006d006
50000000f0000004e5644412c506172656e7422000000400031002c00640065007600690063006500
5f00740079007000650000000b000000646973706c617920000000400030002c0063006f006d00700
061007400690062006c00650000000e0000004e5644412c4e564d6163220000005600520041004d00
2c0074006f00740061006c00730069007a0065000000080000000000004036000000400032002c006
80077006300740072006c002d0070006100720061006d0073002d00760065007200730069006f006e
000000080000000000000214000000400032002c006e0061006d00650000001100000073656e736f7
22d706172656e74</string>
</dict>
</plist>

[toshibo]

my zotc h55-itx core i5-661

i use tony multbest-busratio=25, work good but cpu show 32bits. i can`t install 64bits software.

someone know how to fix this? and fix onbord graphics card?

please, only this for make this motherboader perfecti!



thanks!

[mactition]

.

[concord]

In my opinion the Nvidia 200 series aren't worth the money. You'll find that some of the pros here are using 9400 GT thru 9800 GT. Apple's currently using 120's (OEM only), the 220 is the same GPU. The 9400 GT and 9500 GT are ranked slightly below the 220. The 9600 GT and the 9800 GT are higher. This is based on benchmarks which give a comparable idea of where they stand. Any card 9400 and above should work, most important with any graphics card is to be sure it supports OpenGL for OSX's quartz extreme and check for compatibly issues with your build and any enablers required. That part I can't help with, but you should be able to find the answer in this forum or OSx86 site.



Interestingly some builds are using the 8800 GT which also ranks above the 220.



There may be other reasons for using the 200 series that I'm not aware, even better than the 9600 Gt and the 9800 GT.



I'm buying an EVGA 9500 for my build. There is a rebate program on until the 17th bringing it in at $40. It will be a huge leap above the 7300 in my Mac Pro, so top of the line isn't needed at all.



Hope that helps, this is a learning adventure for me too.



The reason I choose a GT240 was because both Zotac and Asus make a Silent version of it. Completely fanless. They have huge heat sinks around and over the cards and they still fit in a SG06 or SG05 case, making this a very quiet build! I only have one fan in my case (the front one) with a GeminII heatsink for the Q9400 cpu. Let's just say that I can hear the Seagate Momentus 2.5" hard drive more than the fan! I know it's not the fastest video card, but it is faster than the on-board, and has full VDPAU acceleration in Linux. I mostly do photo/video editing in OSX, I'm not much of a gamer

[mrdale]

Hi Guys.



Just completed my build and install, and The only thing I have not got working is LAN and WIFI(obviously)...



* Zotac 9300-G-E

* Winsis si-12b

* Q8300 Core 2 Quad

* 2GB Ram

* 500 GB HD

* Toshiba Slim DVD_+RW



Cost was under $500, great value, Really super install... it feels way more responsive than my q6600 shuttle.



Any Ideas on LAN? It Just will not recognize a connection. I'm using minihack's DSDT modified with the alc662 fix. Tried everything. I notice that when you enable MAC Lan to auto in BIOS the lights show up on the Connector and not when it's disabled. What should that setting be?



I also removed nvenet.kext according to an earlier recommendation.



er... HELP?

[toshibo]

live LAN auto on bios!

donwload this bootloader and install

http://rapidshare.com/files/322726512/Zotac_9300_ITX.zip



update you mac and donwload this and install

http://rapidshare.com/files/373568162/Cham...C4Zotac_Pkg.rar



afiter install go to Snow Leopard HDD/sistema/biblioteca/extensions and delet AppleHDA.kext and install this new on this file! afiter use Kext Utility and restart you mac



thi wifi in thi motherboader not work on mac, you have to buy new one!



i hope work fo you!





Hi Guys.



Just completed my build and install, and The only thing I have not got working is LAN and WIFI(obviously)...



* Zotac 9300-G-E

* Winsis si-12b

* Q8300 Core 2 Quad

* 2GB Ram

* 500 GB HD

* Toshiba Slim DVD_+RW



Cost was under $500, great value, Really super install... it feels way more responsive than my q6600 shuttle.



Any Ideas on LAN? It Just will not recognize a connection. I'm using minihack's DSDT modified with the alc662 fix. Tried everything. I notice that when you enable MAC Lan to auto in BIOS the lights show up on the Connector and not when it's disabled. What should that setting be?



I also removed nvenet.kext according to an earlier recommendation.



er... HELP?

[mrdale]

live LAN auto on bios!



Actually, All I needed to do was place the nvenet.kext back in the IONetworkingFamily.kext plugins directory. now I'm fully functional!



>Edit: LAN does not survive sleep



>Edit: Any wisdom anyone? I edited minihack's DSDT and it works nicely in all respects other than working LAN after sleep



>Edit:OK, so after reading again, it seems you need nForceLan.kext AND delete nvEnet.kext plugin but now my system refuses to go all the way to sleep and refuses to wake...



any thoughts

[scrax]

I've just ordered this board and just to check if I understood correctly for SnowLeo it needs:



Chamelon 2RC5preXX (last revision in trunk)

graphics enabler = Yes for a full working video,

modded DSDT with HPET, RTC, CMOS, HDEF, LAN, Speedstep (c-state and p-state)

patche AppleHDA.kext found in this post

extensions.zip from this minihack post with

fakesmc.kext



AHCIPortInjector.kext

ATAPortInjector.kext

IOAHCIBlockStorageInjector.kext



NullCPUPowerManagement.kext (not needed with native speedstep)

OpenHaltRestart.kext

PlatformUUID.kext (auto submitted by the last chameleon rev)

SleepEnabler.kext (my board is a d-e so no sleep for what I understand)



Here my questions:



1) I'm thinking that with the last version of Chameleon and a correct Speedstep in DSDT the last 4 kext can be unnecessary, or am I wrong?



2) Is there someone how tried to resolve AHCI issue with DSDT patching instead of the injector? If it's a no go I think will try to putt all the injector in a single dummy kext.



3) I'll buy a usb wifi card and maybe a pci-e SATAIII controller, any suggestion?



This is the other hardware i'll put on ZOTAC GEForce 9300 WIFI

Core 2 Quad Q9300

ZALMAN CNPS 9300 AT

2x2GB DDR2 800 Ram

1 500 GB SATA HD

1 SATA DVD-RW



and so thi will be mine i9300Hack

thank's to yall for the info posted till now!

[Smith@@™]

I've just ordered this board and just to check if I understood correctly for SnowLeo it needs:



Chamelon 2RC5preXX (last revision in trunk)

graphics enabler = Yes for a full working video,

modded DSDT with HPET, RTC, CMOS, HDEF, LAN, Speedstep (c-state and p-state)

patche AppleHDA.kext found in this post

extensions.zip from this minihack post with

fakesmc.kext



AHCIPortInjector.kext

ATAPortInjector.kext

IOAHCIBlockStorageInjector.kext



NullCPUPowerManagement.kext (not needed with native speedstep)

OpenHaltRestart.kext

PlatformUUID.kext (auto submitted by the last chameleon rev)

SleepEnabler.kext (my board is a d-e so no sleep for what I understand)



Here my questions:



1) I'm thinking that with the last version of Chameleon and a correct Speedstep in DSDT the last 4 kext can be unnecessary, or am I wrong?



2) Is there someone how tried to resolve AHCI issue with DSDT patching instead of the injector? If it's a no go I think will try to putt all the injector in a single dummy kext.



3) I'll buy a usb wifi card and maybe a pci-e SATAIII controller, any suggestion?



This is the other hardware i'll put on this board

Core 2 Quad Q9300

2x2GB DDR2 800 Ram

1 500 GB SATA HD

1 SATA DVD-RW



thank's to yall for the info posted till now!





2)Use dummy. My still for waiting is for you... simply



AHCIPortInjector.kext --> use dummy, or my or your with simple "copia e incolla plist" from my or from google

ATAPortInjector.kext --> come sopra

IOAHCIBlockStorageInjector.kext --> in this case no dsdt, use "come sopra"



Good job my friend!

[scrax]

2)Use dummy. My still for waiting is for you... simply



AHCIPortInjector.kext --> use dummy, or my or your with simple "copia e incolla plist" from my or from google

ATAPortInjector.kext --> come sopra

IOAHCIBlockStorageInjector.kext --> in this case no dsdt, use "come sopra"



Good job my friend!

thank's smith@@ and with this mobo i'm back on track

by the way i'll contact you soon for some suggestion for OC the CPU. For today i'll be away all day, maybe back tomorrow.

See you bro'
