Boombeng Posted January 17, 2009 Share Posted January 17, 2009 Anyone got the sbwoofer on the dv7 working yet? May be it can help ?? http://forum.insanelymac.com/index.php?s=&...t&p=1017336 Link to comment Share on other sites More sharing options...
metamasterplay Posted January 17, 2009 Share Posted January 17, 2009 Thank's for the reply. Will try this as soon as I can. Hope it works, i'm a total addicted to iTunes and music. This thing is... Mac world is totally new to me, so a little help will, euh, help . I know how to install a kext file but where can i get the "MaximumBootBeep", "MuteGPIO" and "SignalProcessing" options? thank's again. Link to comment Share on other sites More sharing options...
Boombeng Posted January 17, 2009 Share Posted January 17, 2009 Well I can not give more details than Rimini gave in his original thread : 1. Make a copy of your AppleHDA.kext to your desktop or a folder. It's in /System/Library/Extensions/2. Right click on it and select "Show Package Contents". This will open a new finder window. 3. Navigate to "Contents/Plugins/" and right click on "AppleHDAPlatformDriver.kext" and select "Show Package Contents" again, opening yet another finder window (a kext within a kext). 4. In this one, right click "Contents/Info.plist" and open it, or right click and select "Open With/Property List Editor". 5. Now you navigate down the tree (keep clicking each subsequent direction triangle) until you reach "PathMapRef" and then open "0" and you'll see all the various inputs and outputs enumerated here. At this point you might want to look around at the various settings. Note that the "LineOut" has no values and that the SignalProcessing assigned to IntSpeaker includes Muting, Gain management and Equalization. DSP is also used on the mic. 6. Select each item within the "IntSpeaker" item ("MaximumBootBeep", "MuteGPIO" and "SignalProcessing") and click on the "Delete" button at the top of the Plist Editor window so that "IntSpeaker" has no entries (like "Line Out"). (In principle you really only need to get rid of "SignalProcessing" cause that's what's killing the bass, but I figured if I was using this out as a line out, then why not make it the same. Up to you.) 7. Save the plist and close plist editor and the two "Content" finder windows. 8. Now replace the original kext. I find Kext Helper 0.7 works fine for this; open Kext Helper and drag and drop your modded kext on it's window, and click on Easy Install... wait 20 seconds or so before rebooting (let the HD finish thrashing about) 9. Reboot and you're done. You need "Property List editor", you can google to download this application... Also, Mr.Krabs found that for dell Studio IDT Audio just needed to delete "SignalProcessing" and keep "MaximumBootBeep" and "MuteGPIO" so you have to try both and may be bass will be back... Link to comment Share on other sites More sharing options...
ckybam69 Posted January 18, 2009 Share Posted January 18, 2009 ok so i am using sabres' kext and everything is working mic/audio for my hp dv5t except when i wake the computer from sleep my audio disappears. is there a fix for this? i have tried everything. also is there anything i can manually do to get audio back without having to restart the computer? Link to comment Share on other sites More sharing options...
bagulhoz Posted January 27, 2009 Share Posted January 27, 2009 Hi guys, I already try to config my audio on Ideneb 1.3 10.5.5, but OsX don't find and istall any device. I read this post and try to install almost the dumps that i've download in hdapatcher 1.6 and delete applehda and/or alcinkject, use disk utility, etc., but never find the audio device. This is my config: Ideneb works for me with the line comand: -v -x cpus=1 Mobo: pcchips p17g proc intel core2duo 2GB DDR2 Sound: SigmaTel STAC9221 A2 @ Intel 82801GB ICH7 - High Definition Audio Controller [A-1] HDAUDIO\FUNC_01&VEN_8384&DEV_7682&SUBSYS_10192633&REV_1036 HDAUDIO\FUNC_01&VEN_8384&DEV_7682&SUBSYS_10192633&REV_1036\4&CC92D09&0&0001 Device ID 8086-27D8 Sub System ID 1019-2633 Device class: 0403 (High Definition Audio) I already try the 9221D.txt /9221.txt and many others: I think this is my dump, but doesn't work... Codec: SigmaTel STAC9221 A2 Address: 0 Vendor Id: 0x83847682 Subsystem Id: 0x10192633 Revision Id: 0x103601 No Modem Function Group found Default PCM: rates [0x7e0]: 44100 48000 88200 96000 176400 192000 bits [0xe]: 16 20 24 formats [0x1]: PCM Default Amp-In caps: ofs=0x00, nsteps=0x0e, stepsize=0x05, mute=1 Default Amp-Out caps: ofs=0x7f, nsteps=0x7f, stepsize=0x02, mute=1 Node 0x02 [Audio Output] wcaps 0xd0c05: Stereo Amp-Out Amp-Out caps: N/A Amp-Out vals: [0x65 0x65] Power: 0x0 Node 0x03 [Audio Output] wcaps 0xd0c05: Stereo Amp-Out Amp-Out caps: N/A Amp-Out vals: [0x65 0x65] Power: 0x0 Node 0x04 [Audio Output] wcaps 0xd0c05: Stereo Amp-Out Amp-Out caps: N/A Amp-Out vals: [0xff 0xff] Power: 0x0 Node 0x05 [Audio Output] wcaps 0xd0c05: Stereo Amp-Out Amp-Out caps: N/A Amp-Out vals: [0x65 0x65] Power: 0x0 Node 0x06 [Audio Input] wcaps 0x1d0541: Stereo Power: 0x0 Connection: 1 0x17 Node 0x07 [Audio Input] wcaps 0x1d0541: Stereo Power: 0x0 Connection: 1 0x18 Node 0x08 [Audio Output] wcaps 0x40211: Stereo Digital PCM: rates [0x7e0]: 44100 48000 88200 96000 176400 192000 bits [0xe]: 16 20 24 formats [0x5]: PCM AC3 Node 0x09 [Audio Input] wcaps 0x140311: Stereo Digital PCM: rates [0x160]: 44100 48000 96000 bits [0xe]: 16 20 24 formats [0x5]: PCM AC3 Connection: 1 0x11 Node 0x0a [Pin Complex] wcaps 0x400181: Stereo Pincap 0x08173f: IN OUT HP Detect Pin Default 0x2221401f: [Jack] HP Out at Sep Front Conn = 1/8, Color = Green Pin-ctls: 0xc0: OUT HP Connection: 1 0x02 Node 0x0b [Pin Complex] wcaps 0x400181: Stereo Pincap 0x081737: IN OUT Detect Pin Default 0x22a19020: [Jack] Mic at Sep Front Conn = 1/8, Color = Pink Pin-ctls: 0x24: IN Connection: 1 0x04 Node 0x0c [Pin Complex] wcaps 0x400181: Stereo Pincap 0x081737: IN OUT Detect Pin Default 0x01119012: [Jack] Speaker at Ext Rear Conn = 1/8, Color = Pink Pin-ctls: 0x40: OUT Connection: 1 0x03 Node 0x0d [Pin Complex] wcaps 0x400181: Stereo Pincap 0x08173f: IN OUT HP Detect Pin Default 0x01114010: [Jack] Speaker at Ext Rear Conn = 1/8, Color = Green Pin-ctls: 0x40: OUT Connection: 1 0x02 Node 0x0e [Pin Complex] wcaps 0x400081: Stereo Pincap 0x0824: IN Detect Pin Default 0x40f000f1: [N/A] Other at Ext N/A Conn = Unknown, Color = Unknown Pin-ctls: 0x20: IN Node 0x0f [Pin Complex] wcaps 0x400181: Stereo Pincap 0x0837: IN OUT Detect Pin Default 0x01113011: [Jack] Speaker at Ext Rear Conn = 1/8, Color = Blue Pin-ctls: 0x40: OUT Connection: 1 0x05 Node 0x10 [Pin Complex] wcaps 0x400301: Stereo Digital Pincap 0x0810: OUT Pin Default 0x01411130: [Jack] SPDIF Out at Ext Rear Conn = 1/8, Color = Black Pin-ctls: 0x40: OUT Connection: 3 0x08* 0x17 0x19 Node 0x11 [Pin Complex] wcaps 0x430681: Stereo Digital Pincap 0x0810024: IN EAPD Detect Pin Default 0x40f000f2: [N/A] Other at Ext N/A Conn = Unknown, Color = Unknown Pin-ctls: 0x00: Power: 0x0 Node 0x12 [Audio Selector] wcaps 0x30010d: Stereo Amp-Out Amp-Out caps: ofs=0x00, nsteps=0x04, stepsize=0x27, mute=0 Amp-Out vals: [0x01 0x01] Connection: 7 0x0e 0x15 0x0f 0x0b* 0x0c 0x0d 0x0a Node 0x13 [Audio Selector] wcaps 0x30010d: Stereo Amp-Out Amp-Out caps: ofs=0x00, nsteps=0x04, stepsize=0x27, mute=0 Amp-Out vals: [0x03 0x03] Connection: 7 0x0e 0x15 0x0f 0x0b* 0x0c 0x0d 0x0a Node 0x14 [beep Generator Widget] wcaps 0x70000c: Mono Amp-Out Amp-Out caps: ofs=0x03, nsteps=0x03, stepsize=0x17, mute=0 Amp-Out vals: [0x00] Node 0x15 [Pin Complex] wcaps 0x400001: Stereo Pincap 0x0820: IN Pin Default 0x9033012e: [Fixed] CD at Int N/A Conn = ATAPI, Color = Unknown Pin-ctls: 0x20: IN Node 0x16 [Volume Knob Widget] wcaps 0x600000: Mono Node 0x17 [Audio Selector] wcaps 0x300903: Stereo Amp-In Amp-In caps: N/A Amp-In vals: [0x0b 0x0b] Connection: 1 0x12 Node 0x18 [Audio Selector] wcaps 0x300903: Stereo Amp-In Amp-In caps: N/A Amp-In vals: [0x0b 0x0b] Connection: 1 0x13 Node 0x19 [Vendor Defined Widget] wcaps 0xf30201: Stereo Digital Node 0x1a [Audio Output] wcaps 0x30201: Stereo Digital Node 0x1b [Pin Complex] wcaps 0x400301: Stereo Digital Pincap 0x0810: OUT Pin Default 0x40f000f3: [N/A] Other at Ext N/A Conn = Unknown, Color = Unknown Pin-ctls: 0x00: Connection: 1 0x1a Please help me, You're my only hope!!! And Sorry for my bad english... Link to comment Share on other sites More sharing options...
chassler Posted February 3, 2009 Share Posted February 3, 2009 ex. mine is 0x293e8086 your guna love this but i think u have the exact same setup as me lol try my kext with my pinconfig in it: http://rapidshare.com/files/156344109/111D...pleHDA.kext.zip I'm quoting this post because this kext works on my HP dv3510nr...almost. I originally installed this kext on an iDeneb installation 10.5.5. I used this kext out of sheer desperation as I had been attempting to make my own following the guide. To my surprise...it worked! Everything worked, including the built in mic. Fast forward a bit to an iATKOS v5i installation, vanilla everything. A successful upgrade to 10.5.6 straight from software update. I am running the 9.6 vanilla kernel. The system is running much better now and this same kext still gives me audio. However, my microphone shows no input controls in system preferences. Here's the kicker, my device id is 0x103C1505 The binary in that kext and the information in the plists all points to this poster's device id which is 111D76B2. I believe the reason the sound works is because we share the same (pin config, oicpprimary match?, I don't know what it's called) but it's 0x293e8086 That does match my system. What I don't understand is how the microphone somehow got lost in the switch from iDeneb to iATKOS. I'm very diligent about searching for my answers via google and various forums, but this one is stumping me. Any help is appreciated. I have attached two screenshots of my system. Link to comment Share on other sites More sharing options...
ckybam69 Posted February 6, 2009 Share Posted February 6, 2009 Hey, I successfully got this driver installed, (yay sound works!) my device id = 0x111D76B2 and I used a pre-modded kext that was posted here, but I'm getting a kernel panic on AppleHDA.kext on shutdown. I have ALCInject removed, and I've repaired the permissions with diskutil. I saw someone else on this forum repaired disk permission with OnyX to get rid of this problem, is this necessary? Is there any difference with using OnyX to fix my kext permissions, and has any1 else encountered this this kernel panic problem with these drivers on shutdown/restart. Best Arthur you can repair permissions properly by grabbing a terminal and typing this 'sudo chown -R root:wheel /System/Library/Extensions' enter ur password then 'sudo chmod -R 755 /System/Library/Extensions' then 'sudo touch /System/Library/Extensions' enter these without the ' also do this any time u change a kext or touch the extensions folder I'm quoting this post because this kext works on my HP dv3510nr...almost. I originally installed this kext on an iDeneb installation 10.5.5. I used this kext out of sheer desperation as I had been attempting to make my own following the guide. To my surprise...it worked! Everything worked, including the built in mic. Fast forward a bit to an iATKOS v5i installation, vanilla everything. A successful upgrade to 10.5.6 straight from software update. I am running the 9.6 vanilla kernel. The system is running much better now and this same kext still gives me audio. However, my microphone shows no input controls in system preferences. Here's the kicker, my device id is 0x103C1505 The binary in that kext and the information in the plists all points to this poster's device id which is 111D76B2. I believe the reason the sound works is because we share the same (pin config, oicpprimary match?, I don't know what it's called) but it's 0x293e8086 That does match my system. What I don't understand is how the microphone somehow got lost in the switch from iDeneb to iATKOS. I'm very diligent about searching for my answers via google and various forums, but this one is stumping me. Any help is appreciated. I have attached two screenshots of my system. this might not help much but the 0x103C1505 is your subsystem id. the injector sets this so basically what i am saying is dont trust system profiler. also check your subsystem id and vista and see if it matches this. Link to comment Share on other sites More sharing options...
jjones Posted February 8, 2009 Share Posted February 8, 2009 RaidenII: nVidia HDMI @ intel 82801ib ich9, devid 000610de is not HDA controller. It's another Audio Card play through HDMI interface. We are still waiting for its driver. Any news on getting HDMI audio from this hardware? Just for kicks I added entries in the AppleHDAController info.plist for the modem and hdmi (codec1 and codec2 respectively on linux). The '1' entry in HDAConfigDefault is pretty sparse but for '2' I used the rules of pin config formatting for this: <20571c10 20571d01 20571e56 20571f18 20771c21 20771d01 20771e56 20771f58 20971c22 20971d01 20971e56 20971f58 20b71c23 20b71d01 20b71e56 20b71f58 20d71c24 20d71d01 20d71e56 20d71f58> But no luck. Need the binary. RaidenII: nVidia HDMI @ intel 82801ib ich9, devid 000610de is not HDA controller. It's another Audio Card play through HDMI interface. We are still waiting for its driver. Any news on getting HDMI audio from this hardware? Just for kicks I added entries in the AppleHDAController info.plist for the modem and hdmi (codec1 and codec2 respectively on linux). The '1' entry in HDAConfigDefault is pretty sparse but for '2' I used the rules of pin config formatting for this: <20571c10 20571d01 20571e56 20571f18 20771c21 20771d01 20771e56 20771f58 20971c22 20971d01 20971e56 20971f58 20b71c23 20b71d01 20b71e56 20b71f58 20d71c24 20d71d01 20d71e56 20d71f58> But no luck. Need the binary. Link to comment Share on other sites More sharing options...
Silverstone Posted February 16, 2009 Share Posted February 16, 2009 After update 10.5.6 my audio don't work ! Help Link to comment Share on other sites More sharing options...
pcmantinker Posted February 17, 2009 Share Posted February 17, 2009 Thanks for the great guide. I've been looking for a sound fix for months for my OSX86 install on my laptop. Works beautifully. Link to comment Share on other sites More sharing options...
Glauber Lobo Posted February 22, 2009 Share Posted February 22, 2009 Hi, age_sabres18, please, help me guy. My english is very poor to understand all the instructions correctly. My card is IDT 92HD202. Please make me to get sound !! codec.txt.tar.gz codec.txt Link to comment Share on other sites More sharing options...
ole2 Posted February 25, 2009 Share Posted February 25, 2009 hizzi have a compaq mini 700el with a IDT card with ID Ven 111 Dev 7608 rev 1001 i have installed ideneb 1.3 10.5.5 everything works except sound even sleep mode.how can i enable the sound card? if i enable sound card i will post here all the files and instructions "how to" in this post: http://forum.insanelymac.com/index.php?sho...p;#entry1011580 P.S in mac the ID given is : 0x103c361A thanks anticipated it's confirmed on some linux forum, working configuration require to enable MSI: My current setup: * Ubuntu 8.10 - kernel 2.6.27-7-generic * System fully up-to-date, all updates installed * Standard ALSA drivers * Added options snd-hda-intel enable_msi=1 to /etc/modprobe.d/alsa-base * No additional kernel options (like pci=noacpi) I'm afraid without MSI-X enabled in AppleHDA driver, sound on compaq mini 700 will not work. Link to comment Share on other sites More sharing options...
psirus Posted February 28, 2009 Share Posted February 28, 2009 DO I have to delete the HDAENABLER.KEXT if my applehda.kexts is setuped? Link to comment Share on other sites More sharing options...
Supercar1000 Posted March 6, 2009 Share Posted March 6, 2009 Hi there... I've worked 2 days on getting my iPC OS X 10.5.6 up and rooling.. the only simple problem is that I have no sound... I've tried almost everything on this topic to make it work but.. I juste don't understaind why, it dosen't work. On my Sound preferences I have no device! Can somebody make a final clear to understaind tutorial on how to make work this thing.... Thanks alot fo your futur help! Another question... Is a USB headset a device for the sound preferances (Can it remplace my integrated sound device ?)?? Link to comment Share on other sites More sharing options...
sammi93 Posted March 6, 2009 Share Posted March 6, 2009 hello, i am new to mac and i am desperate to have my sound working.. I have a dell studio 1737 and i use kernel voodoo on ideneb 10.5.6. My IDT is 92HD73C1 and the hex is 102802A0. in decimal that is 271057568. I dont understand how to do this. And i am not sure if i have the correct codes and ID's. can someone please help me. thank you Link to comment Share on other sites More sharing options...
Ivan G. Posted March 7, 2009 Share Posted March 7, 2009 Just in case if this might help someone - I have patched AppleHDA.kext and have internal connectors working now (sound and mic). My laptop model: HP 2754TX, Intel High Definition Audio ID: 0x103C30CD and here's my Linux dump of the sound codec: Codec: Conexant CX20549 (Venice) Address: 0 Vendor Id: 0x14f15045 Subsystem Id: 0x103c30cd Revision Id: 0x100100 Modem Function Group: 0x2 Default PCM: rates [0x140]: 48000 96000 bits [0xe]: 16 20 24 formats [0x1]: PCM Default Amp-In caps: N/A Default Amp-Out caps: N/A GPIO: io=0, o=0, i=0, unsolicited=0, wake=0 Node 0x10 [Pin Complex] wcaps 0x40058d: Stereo Amp-Out Amp-Out caps: ofs=0x2b, nsteps=0x2b, stepsize=0x05, mute=1 Amp-Out vals: [0x23 0x23] Pincap 0x0810014: OUT EAPD Detect EAPD 0x2: EAPD Pin Default 0x95170110: [Fixed] Speaker at Int Top Conn = Analog, Color = Unknown DefAssociation = 0x1, Sequence = 0x0 Misc = NO_PRESENCE Pin-ctls: 0x40: OUT Unsolicited: tag=00, enabled=0 Power: setting=D0, actual=D0 Connection: 2 0x19 0x17* Node 0x11 [Pin Complex] wcaps 0x40058d: Stereo Amp-Out Amp-Out caps: ofs=0x2b, nsteps=0x2b, stepsize=0x05, mute=1 Amp-Out vals: [0x23 0x23] Pincap 0x08113c: IN OUT HP Detect Vref caps: HIZ 80 Pin Default 0x0221401f: [Jack] HP Out at Ext Front Conn = 1/8, Color = Green DefAssociation = 0x1, Sequence = 0xf Pin-ctls: 0xc0: OUT HP VREF_HIZ Unsolicited: tag=37, enabled=1 Power: setting=D0, actual=D0 Connection: 2 0x19 0x17* Node 0x12 [Pin Complex] wcaps 0x40058d: Stereo Amp-Out Amp-Out caps: ofs=0x2b, nsteps=0x2b, stepsize=0x05, mute=1 Amp-Out vals: [0xab 0xab] Pincap 0x08113c: IN OUT HP Detect Vref caps: HIZ 80 Pin Default 0x62a1902e: [N/A] Mic at Sep Front Conn = 1/8, Color = Pink DefAssociation = 0x2, Sequence = 0xe Pin-ctls: 0x24: IN VREF_80 Unsolicited: tag=00, enabled=0 Power: setting=D0, actual=D0 Connection: 2 0x19* 0x17 Node 0x13 [Pin Complex] wcaps 0x400301: Stereo Digital Pincap 0x0810: OUT Pin Default 0x21451130: [Jack] SPDIF Out at Sep Rear Conn = Optical, Color = Black DefAssociation = 0x3, Sequence = 0x0 Misc = NO_PRESENCE Pin-ctls: 0x40: OUT Connection: 1 0x18 Node 0x14 [Pin Complex] wcaps 0x400081: Stereo Pincap 0x081124: IN Detect Vref caps: HIZ 80 Pin Default 0x97a701f0: [Fixed] Mic at Int Riser Conn = Analog, Color = Unknown DefAssociation = 0xf, Sequence = 0x0 Misc = NO_PRESENCE Pin-ctls: 0x24: IN VREF_80 Unsolicited: tag=00, enabled=0 Node 0x15 [Pin Complex] wcaps 0x400001: Stereo Pincap 0x0820: IN Pin Default 0x54330121: [N/A] CD at Int Right Conn = ATAPI, Color = Unknown DefAssociation = 0x2, Sequence = 0x1 Misc = NO_PRESENCE Pin-ctls: 0x00: Node 0x16 [beep Generator Widget] wcaps 0x70000c: Mono Amp-Out Amp-Out caps: ofs=0x07, nsteps=0x07, stepsize=0x0b, mute=1 Amp-Out vals: [0x06] Node 0x17 [Audio Mixer] wcaps 0x20050b: Stereo Amp-In Amp-In caps: ofs=0x14, nsteps=0x2b, stepsize=0x05, mute=1 Amp-In vals: [0x10 0x10] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] Power: setting=D0, actual=D0 Connection: 5 0x19 0x14 0x12 0x11 0x15 Node 0x18 [Audio Output] wcaps 0x211: Stereo Digital Converter: stream=0, channel=0 Digital: Digital category: 0x0 PCM: rates [0x40]: 48000 bits [0x6]: 16 20 formats [0x5]: PCM AC3 Node 0x19 [Audio Output] wcaps 0xc11: Stereo R/L Converter: stream=0, channel=0 PCM: rates [0x540]: 48000 96000 192000 bits [0xe]: 16 20 24 formats [0x1]: PCM Power: setting=D0, actual=D0 Node 0x1a [Audio Input] wcaps 0x100d0b: Stereo Amp-In R/L Amp-In caps: ofs=0x00, nsteps=0x17, stepsize=0x05, mute=1 Amp-In vals: [0x17 0x17] [0x00 0x00] [0x00 0x00] [0x00 0x00] [0x00 0x00] Converter: stream=0, channel=0 SDI-Select: 0 Power: setting=D0, actual=D0 Connection: 5 0x17 0x14* 0x12 0x11 0x15 Node 0x1b [Vendor Defined Widget] wcaps 0xf00000: Mono Attaching the modified kext and HDALoader.kext so you can try to use this one. HP_IntelSound_Kexts.zip Link to comment Share on other sites More sharing options...
Guest BuildSmart Posted March 17, 2009 Share Posted March 17, 2009 If your using a DSDT.aml file you can do away with HDAEnabler.kext and fix audio in DSDT for a better solution. Link to comment Share on other sites More sharing options...
underball Posted March 19, 2009 Share Posted March 19, 2009 Hy, I have a problem with IDT 92hd73e on 10.5.6 on VMWare. Tried all found solutions on this forum (AppleHDAPatcher, editing AppleHDA.kext ... ) and no sound so far on my Intel DG45ID. My hardware id: 111d7676 subsy[s 80865002 rev 1002 Linux codec dump attached. Help would be appreciated. codec.txt I have this same Motherboard, and can't get the IDT sound to work either. Anyone have any idea on this setup? Link to comment Share on other sites More sharing options...
the_diller Posted March 29, 2009 Share Posted March 29, 2009 I have this same Motherboard, and can't get the IDT sound to work either. Anyone have any idea on this setup? Yep. DP45SG with IDT 92HD73E audio, still no sound. Followed this guide, pin config guide, and tried azalia audio also. I am thinking we need to pay attention to the NODEID in the controller plist...not sure though. It seems that after editing the kexts the ports are not correctly configured as well some other issues involving the InputAmp and other internal devices. I don't really understand any of it, but I am trying to learn...several posts back someone brings it up, but I haven't been able to understand/apply this to my board. I will surely post my kext if I can figure it out, but I am sure someone smarter will beat me to it. Keep up the hard work everyone, we will get it eventually! Dylan Manthei Link to comment Share on other sites More sharing options...
drewkie Posted March 31, 2009 Share Posted March 31, 2009 Hey, I would appreciate it if anyone could help me get the audio working for my HP Mini 1030NR. I installed using iDeneb 1.3 10.5.5 and got everything to work except for audio. I have tried performing the hexedit but honestly do not know where to begin. My device ID = 0x103C361A and dec is 272381466. If anyone could help I would appreciate it. Thanks in advance. Okay I finally figured how to follow the guide to fix the audio. I did not do the pinconfig because I no longer have windows on the system. But when I followed the steps system profiler shows the speakers and mic as internal and mic as 1/8 jack but no sound icon and nothing in system preference pane. Went back to the original kext from myhpmini.com and got sound icon but profiler shows everything as 1/8 jack with no internal speakers. Any suggestions????? Thanks. Link to comment Share on other sites More sharing options...
juanbosco Posted April 1, 2009 Share Posted April 1, 2009 Hi all, I would appreciate if someone in the forum could help me to get the audio working on my PCChips P17G Motherboard, AUDIO CODEC: Intel High Definition Audio Specification Rev. 1.0 Compliant. Already try some sugestions here but dont work... I am using JAS Mac os 10.4.8, and all work OK...But can not get the sound to work. Thanks for your help!!!! Link to comment Share on other sites More sharing options...
samjoandco Posted April 1, 2009 Share Posted April 1, 2009 I am on IPC 10.5.6. I cannot get it to work after following all instructions from first port. HDAUDIO\FUNC_01&VEN_111D&DEV_76B2&SUBSYS_103C30FC&REV_1003 HDAUDIO\FUNC_01&VEN_111D&DEV_76B2&SUBSYS_103C30FC Vendor ID: 111D 76B2 SUB Vendor: 103C 30FC Vendor ID: 1002 791A SUB Vendor: 0079 1A00 Does anybody have a working kext with the above mentioned vendor id? Link to comment Share on other sites More sharing options...
samjoandco Posted April 2, 2009 Share Posted April 2, 2009 I am on IPC 10.5.6. & cant get it to work after following all instructions from first port.Does anybody have a working kext with the above mentioned vendor id? What should be the codecid in IOPCIPrimaryMatch? Here are the details printed in Vista : HDAUDIO\FUNC_01&VEN_1002&DEV_791A&SUBSYS_00791A00&REV_1000\5&344C0D81&0&0001 Name: High Definition Audio Device Hardware ID's: HDAUDIO\FUNC_01&VEN_1002&DEV_791A&SUBSYS_00791A00&REV_1000 HDAUDIO\FUNC_01&VEN_1002&DEV_791A&SUBSYS_00791A00 Compatible ID's: HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_960F&VEN_1002&DEV_791A&REV_1000 HDAUDIO\FUNC_01&CTLR_VEN_1002&VEN_1002&DEV_791A&REV_1000 HDAUDIO\FUNC_01&VEN_1002&DEV_791A&REV_1000 HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_960F&VEN_1002&DEV_791A HDAUDIO\FUNC_01&CTLR_VEN_1002&VEN_1002&DEV_791A HDAUDIO\FUNC_01&VEN_1002&DEV_791A HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_960F&VEN_1002 HDAUDIO\FUNC_01&CTLR_VEN_1002&VEN_1002 HDAUDIO\FUNC_01&VEN_1002 HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_960F HDAUDIO\FUNC_01&CTLR_VEN_1002 HDAUDIO\FUNC_01&GF&VEN_1002&DEV_791A&SUBSYS_00791A00&REV_1000 HDAUDIO\FUNC_01 HDAUDIO\FUNC_01&VEN_111D&DEV_76B2&SUBSYS_103C30FC&REV_1003\4&11E8BB83&0&0001 Name: IDT High Definition Audio CODEC Hardware ID's: HDAUDIO\FUNC_01&VEN_111D&DEV_76B2&SUBSYS_103C30FC&REV_1003 HDAUDIO\FUNC_01&VEN_111D&DEV_76B2&SUBSYS_103C30FC Compatible ID's: HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_4383&VEN_111D&DEV_76B2&REV_1003 HDAUDIO\FUNC_01&CTLR_VEN_1002&VEN_111D&DEV_76B2&REV_1003 HDAUDIO\FUNC_01&VEN_111D&DEV_76B2&REV_1003 HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_4383&VEN_111D&DEV_76B2 HDAUDIO\FUNC_01&CTLR_VEN_1002&VEN_111D&DEV_76B2 HDAUDIO\FUNC_01&VEN_111D&DEV_76B2 HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_4383&VEN_111D HDAUDIO\FUNC_01&CTLR_VEN_1002&VEN_111D HDAUDIO\FUNC_01&VEN_111D HDAUDIO\FUNC_01&CTLR_VEN_1002&CTLR_DEV_4383 HDAUDIO\FUNC_01&CTLR_VEN_1002 HDAUDIO\FUNC_01&GF&VEN_111D&DEV_76B2&SUBSYS_103C30FC&REV_1003 HDAUDIO\FUNC_01 Link to comment Share on other sites More sharing options...
juanbosco Posted April 2, 2009 Share Posted April 2, 2009 Hi again, As I mentioned before, I am using JAS Mac os 10.4.8 in my PCChips P17G Motherboard (AUDIO CODEC: Intel High Definition Audio Specification Rev. 1.0 Compliant), but the sound dont work.... Does someone in the forum have this PCChips P17G Motherboard? Anyone knows how to get the sound to work? Thanks for your help!!!! Link to comment Share on other sites More sharing options...
hambola Posted April 8, 2009 Share Posted April 8, 2009 Yep. DP45SG with IDT 92HD73E audio, still no sound. Followed this guide, pin config guide, and tried azalia audio also. I am thinking we need to pay attention to the NODEID in the controller plist...not sure though. It seems that after editing the kexts the ports are not correctly configured as well some other issues involving the InputAmp and other internal devices. I don't really understand any of it, but I am trying to learn...several posts back someone brings it up, but I haven't been able to understand/apply this to my board. I will surely post my kext if I can figure it out, but I am sure someone smarter will beat me to it. Keep up the hard work everyone, we will get it eventually! Dylan Manthei Yeah I'm using the DP45SG as well. Tried this guide, as well as the pin config, no cigar. Took me forever, but I tried to be accurate to make sure I got all the steps right. It doesn't seem like anyone with that IDT audio has got it working. On a side note, I don't have USB working either (except the keyboard mouse if they're plugged in from before). Which distro and/or kext did you use for USB on this board? Link to comment Share on other sites More sharing options...
